Maximum 054-0338-0 User manual

30 L (8 U.S. Gallons)
HEPA Wet/Dry Vacuum
054-0338-0

3
SAVE THESE INSTRUCTIONS This manual contains important safety and operating
instructions. Read all instructions and follow them with
use of this product.
NOTE: If any parts are missing or damaged, or if you have any
questions, please call our toll-free helpline at 1-888-670-6682.
TABLE OF CONTENTS
TABLE OF CONTENTS PAGE
TECHNICAL SPECIFICATIONS 4
SAFETY GUIDELINES 5
SYMBOLS 8
KEY PARTS DIAGRAM 9
GENERAL ASSEMBLY INSTRUCTIONS 11
DRY VACUUM OPERATION 14
WET VACUUM OPERATION 16
MAINTENANCE 18
HEPA CARTRIDGE FILTER & MICROFIBRE PRE-FILTER 20
FOAM WET FILTER 22
HEPA MATERIAL EXHAUST FILTER 23
WHEN TO CHANGE FILTERS 24
TROUBLESHOOTING 25
ACCESSORIES 26
EXPLODED VIEW 27
PARTS LIST 28
WARRANTY 29

model no. 054-0338-0 | contact us 1-888-670-6682
4
TECHNICAL SPECIFICATIONS
SPECIFICATIONS
Tank size 30 L (8 U.S. gallons)
Power 120 V, 60 Hz, 11 A
Tank Polypropylene
Hose 1 7/8’’ x 10’ (4.8 cm x3.05 m)
Water lift 86" at end of hose
Airflow 87 CFM at end of hose
Noise 73 dBA
Filters
HEPA Cartridge Filter, Microfibre Pre-filter,
Foam Sleeve/Wet Filter, High Efficiency
Collection Bag, HEPA Material Exhaust Filter
Weight 28 lb (12.7 kg)

5
SAFETY GUIDELINES
IMPORTANT SAFETY INSTRUCTIONS
READ AND UNDERSTAND ALL
INSTRUCTIONS BEFORE USING THIS
VACUUM.
Read and understand this operator’s manual and all labels on the vacuum before
operating. Safety is a combination of common sense, staying alert and knowing
how your vacuum works. Use this vacuum only as described in this manual. To
reduce the risk of personal injury or damage to your vacuum, use only manufacturer
recommended accessories.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
When using a vacuum, basic precautions should always be followed including the
following: Failure to follow the warnings and instructions may result in explosion, fire
and/or serious injury.
WARNING!
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
• Do not run vacuum unattended.
• Do not use to pick up flammable or combustible liquids, such as gasoline, or use in
areas where they may be present.
• Do not vacuum, or use this Wet/Dry Vacuum near flammable liquids, gases, or
explosive vapors like gasoline or other fuels, lighter fluids, cleaners, oil-based paints,
natural gas, hydrogen, or explosive dusts like coal dust, magnesium dust, grain dust,
or gun powder. Sparks inside the motor can ignite flammable vapours or dust.
• To reduce the risk of health hazards from vapors or dusts, do not vacuum toxic
materials.
• Do not store near hazardous materials.
• Do not pick up anything that is burning or smoking, such as cigarettes, matches, or
hot ashes.
• Do not expose to rain. Store indoors.
• If vacuum is not working as it should, has been dropped, damaged, left outdoors, or
dropped into water, return it to a service centre.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not use with damaged cord or plug.
• Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord
around sharp edges or corners.
• Keep cord away from heated surfaces.
• Do not run the vacuum over cord.
• Do not handle plug or vacuum with wet hands.
• Do not use without dust bag and/or filters in place.
• This is NOT a toy. Close attention is necessary when used by or near children.
• To reduce the risk of injury from accidental starting, unplug power cord before
changing or cleaning filter.

model no. 054-0338-0 | contact us 1-888-670-6682
6
SAFETY GUIDELINES
WARNING:
When using this vacuum for EPA lead based paint renovation,
repair and painting program (RRP), it is not recommended for
vacuuming carpets and rugs.
WARNING:
If filters are contaminated or have been used, they must be
disposed of properly, prior to performing wet vacuuming
operation.
CAUTION:
To reduce the risk of injury from moving parts - unplug before
servicing.
WARNING:
To reduce the risk of electric shock - unplug before cleaning or
servicing.
• Do not leave vacuum when plugged in. Unplug from outlet when not in use and
before servicing.
• Turn off all controls before unplugging.
• Unplug before connecting or disconnecting hose, or any other accessories.
• Do not put any object into openings. Do not use with any opening blocked; keep
free of dust, lint, hair, and anything that may reduce air flow.
• Keep hair, loose clothing, fingers, and all parts of body away from openings and
moving parts.
• Use extra care when cleaning on stairs.
• Use only as described in this manual. Use only manufacturer’s recommended
attachments.
• This vacuum is provided with double insulation. Use only identical replacement
parts. See DOUBLE INSULATION INSTRUCTIONS.
• When using for HEPA EPA RRP clean-up tasks, use only manufacturer certified
HEPA filters.
• Even when used with a HEPA filter, extremely small particles may pass through the
filter; always wear appropriate protective safety equipment.
SAVE THESE INSTRUCTIONS
For Household and Commercial Use

7
SAFETY GUIDELINES
DOUBLE INSULATION INSTRUCTIONS
This Wet/Dry Vacuum is double-insulated, eliminating the need for a separate
grounding system. Use only identical replacements parts. Read the instructions for
Servicing Double-Insulated Wet/Dry Vacuums before servicing. Use this vacuum as
described in this manual.
Observe the following warnings that appear on the motor housing of your vacuum.
DOUBLE INSULATED - GROUNDING NOT REQUIRED - WHEN
SERVICING USE ONLY IDENTICAL REPLACEMENT PARTS.
WARNING:
To reduce the risk of electric shock - do not expose to rain.
Store indoors.
WARNING:
For your own safety, read and understand the operator’s
manual. Do not run unattended. Do not pick up hot ashes,
coals, toxic, flammable materials. Do not use around explosive
liquids or vapours.
WARNING:
Servicing of double-insulated wet/dry vacuum
with a double-insulated wet/dry vacuum, two systems of
insulation are provided instead of grounding. No grounding
means is provided on a double-insulated appliance, nor should
a means for grounding be added. Servicing a double insulated
wet/dry vacuum requires extreme care and knowledge of
the system, and should be done only by qualified service
personnel. Replacement parts for a double-insulated wet/
dry vacuum must be identical to the parts they replace.
Your double-insulated wet/dry vac is marked with the words
'double-insulated’ and the symbol (square within a square)
may also be marked on the appliance.

model no. 054-0338-0 | contact us 1-888-670-6682
8
The following signal words and meanings are intended to explain the levels of risk
associated with this product.
SYMBOL SIGNAL MEANING
DANGER Indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING Indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation, which, if not
avoided, may result in minor or moderate injury.
NOTICE (Without Safety Alert Symbol) Indicates a situation that
may result in property damage.
SYMBOLS
EXTENSION CORDS
When using an extension cord with your Wet/Dry Vacuum refer to the following
table to determine the required A.W.G. wire size. Before using the cleaner make sure
the power cord and extension cord are in good working condition. Make repairs or
replacements before using the vacuum cleaner. Only use extension cords that are
rated for outdoor use.
Length of Extension Cord
120V 25ft
(7.62m)
50ft
(15.24m)
100ft
(30.48m)
150ft
(45.72m)
Ampere rating A.W.G. Wire Size
More than Not more than
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not recommended
SAFETY GUIDELINES

9
KEY PARTS DIAGRAM
1
8
12
13
14
17
23 24 25 26 27 28 29 30 31
18 19 20 21 22
15 16
9
10
11
7
2
3
4
5
6

model no. 054-0338-0 | contact us 1-888-670-6682
10
No. Description No. Description
1 Power Cord Hook 17 Hose
2 HEPA Material Exhaust Filter 18 Crevice Tool
3 Latch (x2) 19 Floor Brush/Squeegee Nozzle
4 Accessory Storage 20 Round Dust Brush
5 Rear Wheel (x2) 21 Metal Accessory Adaptor
6 Locking Castor (x2) 22 Power Tool Adaptor
7 Collection Tank 23 Foam Sleeve/Wet Filter
8
Vacuum Port 24 HEPA Cartridge Filter
9 Power Head 25 Microfibre Pre-filter
10 On/Off Switch 26 High Efficiency Collection Bag
11 Handle 27 Washer (x4)
12 Filter Cage 28 Hub Cap (x2)
13 Float Valve 29 ‘R’ (Lock Pin) (x2)
14 Locking Steel Extension Wand #1 30 Wheel Axle
15 Locking Steel Extension Wand #2 31 Operator’s Manual
16 Steel Elbow with Air Control
KEY PARTS LIST

11
Verify that the power cord is
disconnected from the outlet.
Undo the latches.
GENERAL ASSEMBLY INSTRUCTIONS
1
2
A Philips head screwdriver is required.
This HEPA vacuum is supplied with a certified HEPA filter that has been tested by an
independent lab to IEST-RP-CC001 that meets the EPA's definition of a HEPA vacuum
(must be capable of trapping 99.97% of particles down to 0.3 microns in diameter). It
can be used to pick up materials like sawdust and gravel, as well as ultra fine materials
like drywall dust and cold fireplace ash.
UNPACKING YOUR WET/DRY VACUUM & GENERAL ASSEMBLY
WARNING:
Do not plug the power cord into a power outlet. Make sure the plug is
disconnected before assembling the wet/dry vacuum. To reduce the risk of
electric shock, do not expose to rain.
CAUTION:
This vacuum has been specifically designed to clean up hazardous dust.
Special filters reduce the incidence of airborne dust that would be created by
other methods of cleaning. During the removal of hazardous dust, DO NOT
sweep, scoop, shovel or in any manner handle other than by vacuuming. DO
NOT at any time attempt to substitute or alter the filters in this vacuum. Never
operate without filters in place. Use only manufacturer’s approved vacuum
filters and filter bags. Before attempting to use or before cleaning with this
vacuum, be sure that you fully understand the instructions for setting up
and cleaning/changing filters. Any health hazards associated with use of this
vacuum in conjunction with the removal of hazardous material have not been
investigated by Intertek Testing Services NA Inc.

model no. 054-0338-0 | contact us 1-888-670-6682
12
GENERAL ASSEMBLY INSTRUCTIONS
Lift the power head off the
collection tank .
3
Turn the collection tank upside
down and insert the two castors feet
into the front slots on the bottom of
the base. Apply downward pressure
to each locking castor. Castors
will snap into place when installed
properly. Verify that the castors are
mounted correctly.
Remove the contents from inside
the collection tank; make sure
you have all contents as shown on
pages 9 and 10.
Insert the wheel axle into the rear
wheel housing on the vacuum
base. Insert a washer onto the axle
followed by a rear wheel and insert
another washer. Insert the locking
pin into the hole on the end of the
axle to lock the wheel. Snap the
hub cap onto the wheel. Repeat
the same steps at the other end of
the axle.
5
4
6
28 29 5 5
30
27 27 27 27
29 28

13
GENERAL ASSEMBLY INSTRUCTIONS
Optional: For improved dust
filtration, fit the dust bag flange
onto the inlet port, taking care not
to damage the bag.
Your vacuum comes ready for
dry vacuum cleaning. If the HEPA
cartridge filter and microfibre
pre-filter are not installed, refer to
page 20 for installation instructions.
8
7
IMPORTANT: For vacuuming hazardous dusts, it is recommended that the
vacuum cleaner is fitted with the dust bag.
For wet vacuum cleaning, remove
the microfiber pre-filter, HEPA
cartridge filter and collection bag,
and install the supplied foam wet
filter. See page 22 for the foam wet
filter installation instructions.
9
Place the power head back on the
collection tank aligning the top
section with the latches, and snap
into place.
10

model no. 054-0338-0 | contact us 1-888-670-6682
14
GENERAL ASSEMBLY INSTRUCTIONS
Choose the desired attachment and
insert onto the end of the hose or
extension wand. To use the round
dust brush and crevice tool with an
extension wand you will be required
to use the metal accessory adaptor.
LIGHTED PLUG
This vacuum comes standard with a lighted plug that when plugged in lights up
showing user that the wall receptacle is working and that vacuum has power.
POLARIZED PLUG
To reduce the risk of electrical shock, this appliance has a polarized plug (one blade
wider than the other). This plug will fit in a polarized outlet only one way. If the
plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician to install the proper outlet. Do not change the plug in any way.
Double insulation eliminates the need for the three wire grounded power cord
and grounded power supply system.
Insert the locking end of the
hose into the vacuum port on the
collection tank and turn clockwise
to lock into place.
12
11

15
DRY VACUUM OPERATION
Slide the microfiber pre-filter onto the
assembled HEPA cartridge filter. Tighten
the band clamp on the microfibre pre-
filter with a screwdriver to ensure proper
installation. For installation instructions,
see page 20.
Optional: For improved dust filtration, fit the dust
bag flange onto the inlet port, taking care not to
damage the bag.
3
4
Verify that the power cord is
disconnected from the outlet.
In order to prepare your vacuum for dry
vacuuming, verify that the HEPA cartridge
filter is securely mounted. Remove the
power head and place in an upside down
position. Make sure the HEPA cartridge filter
is pushed in firmly against the power head.
Install the flat rubber washer and retainer.
For installation instructions, see page 20.
1
2
DRY VACUUMING
IMPORTANT: For vacuuming hazardous dusts, it is recommended that the vacuum cleaner
is fitted with the dust bag.

model no. 054-0338-0 | contact us 1-888-670-6682
16
Place the power head back on the
collection tank and secure it in
place using the latches.
5
DRY VACUUM OPERATION
WARNING:
Be sure to read, understand, and apply information stated in “Safety Guidelines”. Do not
vacuum in areas with flammable gases, vapours, or explosive dusts in the air. Flammable
gases or vapours include but are not limited to: lighter fluid, solvent type cleaners, oil-
based paints, gasoline, alcohol, or aerosol sprays. Explosive dusts include but are not
limited to: coal, magnesium, grain, or gun powder. To reduce the risk of health hazards
from vapors or dust, do not vacuum toxic materials.
CAUTION:
NEVER operate the vacuum cleaner without all of the filters installed. This includes the HEPA
cartridge filter and microfibre pre-filter. Motor damage, loss of operating efficiency and
recirculation of hazardous material into the work area will take place if not installed.
WARNING:
Do not plug the power cord into a power outlet. Make sure the plug is disconnected before
changing the filters.

17
Verify that the switch is in the ‘O’
OFF position before plugging the
power cord into the power outlet.
Plug the power cord into the outlet.
Insert the locking end of the
hose into the vacuum port on the
collection tank and lock into place.
Push the required attachment
onto the free end of the hose or
extension wand. To use the round
dust brush and crevice tool with an
extension wand you will be required
to use the metal accessory adaptor.
7
6
DRY VACUUM OPERATION
OPERATING INSTRUCTIONS: DRY VACUUMING
Turn the motor on by flipping the
switch to the ‘I’ ON position and
begin vacuuming.
Once you have completed
vacuuming, flip the switch to the ‘O’
OFF position and unplug the power
cord from the outlet.
8
9
O = OFF I = ON
DO NOT USE THE HEPA CARTRIDGE FILTER AND THE MICROFIBRE PRE-
FILTER FOR VACUUMING LIQUIDS.
DO NOT USE THE COLLECTION BAG FOR VACUUMING LIQUIDS.
WARNING:
If filters are contaminated or have been used, they must be disposed of
properly, prior to performing wet vacuuming operations.
CAUTION:
Hazardous materials must be disposed of properly. NEVER throw contaminated
debris in your usual trash receptacle. Place debris in an OSHA approved bag
or container marked with HAZARDOUS MATERIAL warning and dispose in
accordance with your local Hazardous Waste Regulations.

model no. 054-0338-0 | contact us 1-888-670-6682
18
WET VACUUM OPERATION
Verify that the power cord is
disconnected from the outlet.
Make sure that the collection tank
is clean and free of dust and dirt.
Push the required attachment
onto the free end of the hose
or extension wand. To use the
round dust brush and crevice
tool with an extension wand you
will be required to use the metal
accessory adaptor.
Remove all dry use filters. Carefully
install the foam wet filter over
the filter cage and place power
head back on the collection tank.
For foam wet filter installation
instructions, see page 22.
1
3
2
WET VACUUMING
WARNING:
Be sure to read, understand, and apply information stated in “Safety Guidelines”. Do not
vacuum in areas with flammable gases, vapours, or explosive dusts in the air. Flammable
gases or vapours include but are not limited to: lighter fluid, solvent type cleaners, oil-
based paints, gasoline, alcohol, or aerosol sprays. Explosive dusts include but are not
limited to: coal, magnesium, grain, or gun powder. To reduce the risk of health hazards
from vapors or dust, do not vacuum toxic materials.
WARNING:
Do not plug the power cord into a power outlet. Make sure the plug is disconnected before
changing the filters.
DO NOT USE THE HEPA CARTRIDGE FILTER AND THE MICROFIBRE PRE-
FILTER FOR VACUUMING LIQUIDS.
OPERATING INSTRUCTIONS: WET VACUUMING

19
IMPORTANT: When vacuuming large quantities of liquids, do
not immerse the nozzle completely in the liquid; leave a gap at the
tip of the nozzle opening to allow air inflow. The machine is fitted
with a float valve that stops the suction action when the collection
tank reaches its maximum capacity. You will notice an increase in
motor speed. When this happens, turn off the machine, disconnect
from power supply, and drain the liquid into a suitable receptacle
or drain. To continue vacuuming, refit the power head to the
collection tank. After wet vacuuming, turn the machine off and
remove plug from power supply. Empty the collection tank, clean
and dry the inside and outside before storage.
REMEMBER! The foam wet filter must be removed after wet
vacuuming and the HEPA cartridge filter must be installed before
dry vacuuming again.
WET VACUUM OPERATION
Verify that the switch is in the ‘O’
OFF position before plugging the
power cord into the power outlet.
Plug the power cord into the outlet.
Once you have completed vacuuming,
flip the switch to the 'O' OFF position
and unplug the power cord from the
outlet. After use, drain liquids into a
suitable receptacle or drain. Rinse,
clean, and dry the inside and outside
of the collection tank.
Turn the motor on by flipping the
switch to the ‘I’ ON position.
4
6
5

model no. 054-0338-0 | contact us 1-888-670-6682
20
Verify that the power cord is
disconnected from the outlet.
Undo the latches and remove the
power head from the collection
tank. Place power head on a soft,
clean surface upside down.
Disconnect the hose from the
vacuum.
Clear all dirt or debris from the
collection tank and hose into a proper
waste container.
1
3
2
4
EMPTYING THE COLLECTION TANK
MAINTENANCE
WARNING:
Always disconnect the plug from a power outlet before removing the power head from
collection tank.
