Maxtrack CS 25-8 L User manual

HDMI2.0 3D Ultra HD 4Kx2K@60Hz 1X8 Splitter
HDMI SPLITTER CS 25-8 L
User Manual
HDMI2.0 1x8 Splitter
(3D Ultra HD 4Kx2K@60Hz HDCP2.2)
Bring High-Definition to your life!

HDMI2.0 3D Ultra HD 4Kx2K@60Hz 1X8 Splitter
1.0 Introduction:
HDMI Splitter is a product which can distribute HDMI signal without loss to one or more high definition
display device such as HDTV. It can optimize your home theatre system to the best effect.
HDMI signal is distributed from source device such as DVD, Satellite Receiver, Set-Top Box, DV
Camera, A/V Receiver and other HDMI enabled device to high definition display device such as HDTV
and HDMI Flat panel Display.
2.0 Features:
1.Compliant with HDMI2.0, HDCP2.2 and DVI 1.0.
2.Support video format up to 4k2k@60Hz with 24bit RGB/YcbCR 4:4:4/YCBCR4:4:4,
and up to 4k2k@60Hz with 12bit YCBCR 4:4:4.
3.Support 3D frame sequential video format up to 1080p@60.
4.Support high resolution VESAmode video format up to QSXGA@60Hz.
5.Support HDR and 18Gbps Signal Speed.
6.Supports LPCM 7.1CH, Dolby True HD, and DTS-HD Master Audio.
7.Compatible with DVI by using HDMI to DVI adapter.
8.Extend the transmission distance and improve transmission signal.
9.Metal casing design and overall shielding without signal interference.
10.Power supply (please refer to technical parameter).
3.0 Packaging accessories:
1. HDMI 1×8 Splitter------------------------------------------------1 PCS
2. 5V DC Power Adaptor-------------------------------------------1 PCS
3. User Manual-------------------------------------------------------1 PCS
4.0 Technical parameters
HDMI Source Input Port-------------------------------------------------------------------1
Display Device Output Port---------------------------------------------------------------8
Source Port Connector----------------------------------------------------19 PIN HDMI
Display Device Port Connector------------------------------------------19 PIN HDMI
HDCP Compliant------------------------------------------------------------------------YES
Single Link Range--------------------------------------------------------------4096x2160
Input Video Signal------------------------------------------------------0.5-1.0 Volts P-P
Input DDC Signal--------------------------------------------------------5 Volts P-P(TTL)
Deep Color------------------------------------------------------------------------------48 bit
HDMI Version-----------------------------------------------------------------------HDMI2.0
Bandwidth---------------------------------------------------------------------Up to 600MHz
Signal Speed-----------------------------------------------------------------Up to 18Gbps
The length of input cable-------------------------------------------------------------≤10m
The length of output cable-----------------------------------------------------------≤10m
The cable standard-----------------------------------------------------28AWG HDMI2.0
Vertical Frequency Range------------------------------------------------------------60Hz
Operation Temperature---------------------------------------------------------0℃- 70℃
Working Voltage-----------------------------------------------------------------------DC 5V
Power Adaptor-------------------------------------------------------------------------5V 2A
Net Weight-----------------------------------------------------------------------------0.98Kg
Dimension: L*W*H(mm)------------------------------------------------------276x110x25

HDMI2.0 3D Ultra HD 4Kx2K@60Hz 1X8 Splitter
5.0 Panel Introduction
EDID --------------------------------------------EDID Setting button
IR Ext-------------------------------------------------without function
L1-L8-----------------------------------------HDMI Output Indicator
Power-------------------------------------------------Power Indicator
Reset-----------------------------------------------------Reset button
ON/OFF-------------------------------------------------Power Switch
DC/5V------------------------------------------------Power Input port
HDMI Output 8-1--------------------------------HDMI 1-8 outputs
HDMI Input------------------------------------------HDMI Input port
6.0 Connection diagram
Before installation, please make sure all devices you wish to connect have been turned off.
6.01 Connect the HDMI cable between signal source and input port of Splitter.
6.02 Connect the HDMI cable between output port of Splitter and HDTV.
6.03 Connect splitter and power adapter.
6.04 Open the signal source and the power of HDTV, then it works.
Explanation: With different brands of the input or output device, the length of the
connecting cables will differ too.
7.0 EDID Selector: Select HDMI output signal format via EDID Selector.

HDMI2.0 3D Ultra HD 4Kx2K@60Hz 1X8 Splitter
Number
EDID Selector
Description
1
0000
1080I,Stereo-Audio-2.0
2
0001
1080I,Dolby-DTS-5.1
3
0010
1080I,HD-Audio-7.1
4
0011
1080P,Stereo-Audio-2.0
5
0100
1080P,Dolby-DTS-5.1
6
0101
1080P,HD-Audio-7.1
7
0110
3D,Stereo-Audio-2.0
8
0111
3D,Dolby-DTS-5.1
9
1000
3D,HD-Audio-7.1
10
1001
4K2K@30,Stereo-Audio-2.0
11
1010
4K2K@30,Dolby-DTS-5.1
12
1011
4K2K@30,HD-Audio-7.1
13
1100
4K2K@60,Stereo-Audio-2.0
14
1101
4K2K@60,Dolby-DTS-5.1
15
1110
4K2K@60,HD-Audio-7.1
16
1111
Copy EDID From Sink
8.0 Installation and Precautions
To avoid electric shock , product damage and to protect your safety , please notice the following:
1.Please slowly plug or unplug signal cables and do not often plug , unplug , or shake them.
2.The equipment should not be placed under the sun , rain and damp or unventilated environment.
3.Liquid items should not be placed on the equipment.
4.Do not install the equipment near heat sources such as fire , power , or other amplifiers that produce
heat.
5.Do not insert the metal or other objects to the equipment in addition to connecting cables to ports.
6.Do not demolish the equipment by yourself ; it should be maintained by professional maintenance
staff.
