Maxus MIFA 9 2022 User manual

9.
High
voltage
component
VIP type seat
of 2nd row
Other type seats
of 2nd row
4.
Airbag Stored
gas inflator
Seat belt
pretensioner
SRS control
unit
Gas strut/
Preloaded
spring
High
strength
zone
Zone
requiring
special
attention
Battery
low voltage
High
voltage
battery
pack
High voltage
power cable/
component
Fuse box
disabling
high voltage
system
Li-ion Battery
395V
MAXUS MIFA
MPV,5 Doors
2022-
ID No.
01 06/2022 1 of 4
Version No. Version date Page
LSK-MIFA-EV-E001

1. Identification / recognition
2. Immobilisation / stabilisation / lifting
3. Disable direct hazards / safety regulations
ID No.
01 06/2022 2 of 4
Version No. Version date Page
LSK-MIFA-EV-E001
R
N
D
R
N
D
P <
A - Immobilisation / stabilisation
B - Lifting
Turn off - main method for disable direct hazards
R
PUSHPUSH
Press the Hazard warning lamp switch 5 times in 3 seconds
Just press the button once, The vehicle will be in P. Click the “power off ”button on the screen.
Suitable lifting points High-voltage battery
Open and remove the driver-side compartment Pull out the F27 fuse as shown
R
N
D
R
N
D
P <
PUSH 1xPUSH 1x
PUSH 1x
PUSH 1x
Secure the vehicle using P gear and parking brake
Just press the button once, P gear and parking brake work at the same time.
1
2
1
2Click the “power off” button on the screen.
Disconnect 12 Volt battery
1 2
5m
3 4
Emergency shutdown - alternative method for disable direct hazards
5m
21
Disconnect 12 Volt battery
3
Deactivating the high-voltage system – alternative method for deactivation in the vehicle interior
1 2
Disconnect 12 Volt battery
3
PULLPULL

Steering column adjustment
Disconnect from the charging station (emergency release)
Access to 12V Battery
PUSH 1xPUSH 1x
Pull the switch twice to open the hood Disconnect 12 Volt battery
Safety regulations:
Always assume the vehicle is powered, even if it is silent!
Make sure that the vehicle is immobilized and the propulsion system is deactivated;
Never touch, cut, or open any orange high voltage power cable or high voltage component;
In case of a collision with airbag deployment and/or seat belt pretensioner activation, the propulsion system will be disabled. The restraint systems are still active.
Li-ion
12V
R-1234yf 1000g
395V
Pull the loopPull the loop
PULL 2xPULL 2x
High strength body areas
If coolant escapes from the battery cooling system,
there is a risk of a thermal reaction , in the high-voltage battery.
Monitor the temperature of the high-voltage battery!
Open the cover
1. Remove the left side panel.
2. Locate the loop of the emergency release .
3. Pull the loop
1st
row
2nd
row
3th row
Seat adjustment
B
B
A
ALaminated glass
Tempered glass
Manual Electric
3. Disable direct hazards / safety regulations
4.Access to the occupants
5. Stored energy / liquids / gases / solids
ID No.
01 06/2022 3 of 4
Version No. Version date Page
LSK-MIFA-EV-E001
VIP

Centre airbag
BATTERY RE-IGNITION!
Wear appropriate PPE. Remove the vehicle from the water and continue with the deactivation
procedure for this vehicle (see chapter 3). Vehicles submerged in salt water should be handled
with a greater potential risk of a HV battery fire.
USE LARGE AMOUNT OF WATER
If it is difficult to apply copious amounts of water to the high
voltage battery, it is recommended to allow the high voltage
battery to burn itself out.
PUSH 1xPUSH 1x
Flammable
Low voltage device
that disconnects
high voltage
Hazardous to
the human health Acute toxicity Corrosives Environmental hazard
Electric Vehicle
Warning, Electricity General
warning sign
Use water to
extinguish the fire
Use thermal
Infrared camera Remove smart key Bonnet Boot
Explosive
Air-conditioning
component
6. In case of fire
7. In case of submersion
8. Towing / transportation / storage
9. Important additional information
10. Explanation of pictograms used
ID No.
01 06/2022 4 of 4
Version No. Version date Page
LSK-MIFA-EV-E001
