Maytag MDB7600AWW Manual

Repair
Parts
List
MODEL NUMBER
MDB7600AWW
When requesting service or ordering parts, always
provide the following information:
- Product Type - Part Number
- Model Number - Part Description
DISHWASHER
©2005 Maytag Services

SUPPLEMENTAL INFORMATION
No. Part No. Description
Section:
Series Qty
- 99002562 MANUAL, USE & CARE (MDB-3) 10 1
- 16021814 TALL TUB SERVICE MANUAL 10 1
- 99003027 GUIDE, ENERGY 22 1
- 99002908 GUIDE, ENERGY 14 1
- 99002667 GUIDE, ENERGY 10 1
- 99002854 MISC. PARTS PACKAGE 10 1
- DAX3400AXE TOE PANEL SPACER KIT (WHT) 10 1
- DAX3200AXN TRIM STRIP KIT (BSQ) 10 1
- DAX3200AXE TRIM STRIP KIT (WHT) 10 1
- DAX3000AXQ WOOD PANEL KIT (BSQ) 10 1
- DAX3000AXB WOOD PANEL KIT (BLK) 10 1
- DAX3000AXW WOOD PANEL KIT (WHT) 10 1
1
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: CONTROL PANEL
DW11-84
Model: MDB7600AWW
2

CONTROL PANEL
No. Part No. Description
Section:
Series Qty
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, PANEL 10 4
1 99002789 PANEL, CONTROL (WHT) 10 1
2 99002573 VENT SEAL, CONTROL PANEL 10 1
3 99002579 HANDLE, LATCH (WHT) 10 1
4 99002751 SWITCH, DOOR 10 2
5 99002580 LATCH ASSEMBLY 10 1
6 99002576 HOUSING, BOARD (BASE) 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, HOUSING 10 2
7 99002574 BOARD, CONTROL 10 1
7 99002976 BOARD, CONTROL 19 1
7 99002842 BOARD, CONTROL 11 1
8 99002575 HOUSING, BOARD (TOP) 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, HOUSING 10 1
- N 99002581 WIRE HARNESS, MICROPROCESSOR Note: (NEED TO ORDER CONTROL BOARD KIT 99002863) 10 1
- 99002986 WIRE HARNESS, MICROPROCESSOR 20 1
- 99002845 WIRE HARNESS, MICROPROCESSOR 11 1
3
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: DOOR
DW12-68
Model: MDB7600AWW
4

DOOR
No. Part No. Description
Section:
Series Qty
1 99002770 PANEL, DECO (W/DAMPER-WHT) 10 1
2 99002673 VENT HOUSING ASSEMBLY 10 1
3 N 99002604 CROSSBRACE, HINGE 13 1
3 N 99002604 CROSSBRACE, HINGE 10 2
4 99002929 BRACKET, HINGE (LT) 16 1
4 99002930 BRACKET, HINGE (RT) 16 1
4 W10124350 NOT REQUIRED PART OR SEE NOTE Note: ***SEE NOTE*** (IF YOU NEED THE LEFT OR
RIGHTHINGE BRACKET FOR MODELS PRIORTO SERIES 16 ORDER 12002134) 10 1
- 99001075 SCREW Note: SCREW, BRACKET 10 4
5 Y99002587 INSULATION, DOOR 10 1
6 903233 FOAM STRIP, INSULATION 10 1
7 99002589 SEAL, DOOR (BTM) 10 2
- 99002756 PUSHNUT, STAINLESS 10 2
- Y912620 SCREW Note: SCREW, DOOR 10 11
8 99002970 DOOR, INNER (W/DAMPER) 17 1
8 99002776 DOOR, INNER (W/DAMPER) 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, BRACKET 10 6
9 99002613 BRACKET, DISPENSER MOUNTING 10 1
10 99002270 SEAL, BASE 10 1
11 99002611 RINSE AID/DETERGENT DISPENSER 10 1
12 99002614 KNOB, RINSE AID (W/O-RING) 10 1
13 99002186 SEAL, DOOR VENT 10 1
14 99002590 BEZEL, DOOR VENT 10 1
15 99002586 REINFORCEMENT, INNER DOOR 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, REINFORCEMENT 10 3
5
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: TRACK & RACK ASSEMBLY
DW15-94
Model: MDB7600AWW
6

TRACK & RACK ASSEMBLY
No. Part No. Description
Section:
Series Qty
- 99002905 CAP, RACK (DARK GRAY) 10 1
1 99003206 RACK ASSEMBLY (UPR) 23 1
1 99002705 RACK ASSEMBLY (UPR) 10 1
2 99002853 SNUGGER, RACK 10 2
3 99002712 VARILOCK (REAR) 10 1
4 99002715 SPRING, VARILOCK 10 1
5 99002714 CUP, VARILOCK 10 1
6 99002713 SUPPORT, VARILOCK 10 1
7 99002711 VARILOCK (FRT) 10 1
8 99002621 TRACK, RACK 10 2
- 99002623 STOP, RACK (GRAY) 10 4
- 99002343 SHAFT, TUB WHEEL 10 8
- Y912798 WASHER, TUB WHEEL 10 8
9 99002622 WHEEL, TUB 10 8
10 99002696 CLIP, CUP (BLUE) 10 3
11 99002624 ARM, WASH (UPR) 10 1
- 99002740 SCREW, TRUSS HEAD (10-18X.75) Note: SCREW, WASH ARM 10 1
12 99002669 CLIP, UPR WASH MANIFOLD (FRT) 10 1
13 99002670 CLIP, UPR WASH MANIFOLD (BACK) 10 1
14 99002679 WASH MANIFOLD ASSY (UPR) 10 1
15 99002620 BASKET, AUXILLARY (BLUE) 10 1
16 99002710 LATCH, FOLD AWAY TINE 10 1
17 99002708 TINE, FOLD AWAY (LT) 10 1
18 99002707 TINE, FOLD AWAY (RT) 10 1
19 99002709 PIVOT, FOLD AWAY TINE 10 2
- N 99002782 ADJUSTER, RACK (LT) Note: (MUST ORDER RACK ASSEMBLY) 10 1
20 N 99002783 ADJUSTER, RACK (RT) Note: (MUST ORDER RACK ASSEMBLY 10 1
- 99003010 SCREW (T15) 8-18 X .500 23 11
- 99003020 STABILIZER, RACK ADJUSTER 23 1
- 99003009 RACK ADJUSTER ASSEMBLY (RT) 23 1
- 99003008 RACK ADJUSTER ASSEMBLY (LT) 23 1
- 99003011 COVER, RACK ADJUSTER (GRAY) 23 2
- 99003178 LEVER, ADJUSTER (BLUE) 23 2
21 99002716 SHELF, CUP (UPR-SHORT) 10 2
22 99002813 RACK ASSEMBLY (LWR) 10 1
- 99002905 CAP, RACK (DARK GRAY) 10 1
22 99002963 RACK ASSEMBLY (LWR) 17 1
23 99002672 SHELF, CUP (LWR) 10 2
24 99002717 TINES, CONVERTIBLE (FRT) 10 1
25 99002687 PIVOT, CONVERTIBLE TINE (BLUE) 10 2
26 99002718 TINES, CONVERTIBLE (REAR) 10 1
27 99002688 LATCH, CONVERTIBLE TINE 10 1
28 99002689 LATCH, SECOND CONVERTIBLE TINE 10 2
29 99002780 WHEEL ASSEMBLY (LWR) 10 8
30 99002683 SPLIT/FIT BSKT ASSY 10 1
- 99002684 BASKET, SILVERWARE (HALF) 10 1
- 99002697 COVER, SPLIT/FIT BASKET 10 1
7
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: TUB
DW13-94
Model: MDB7600AWW
8

TUB
No. Part No. Description
Section:
Series Qty
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 2
1 99002629 BRACKET, WATER VALVE 10 1
2 99002975 VALVE, WATER 19 1
- 99002553 SCREW-#8X7/16 HEX WASHER HEAD Note: SCREW, VALVE 10 2
2 99002628 VALVE, WATER 10 1
3 911856 CLAMP, SPRING 10 1
4 99002852 HOSE, INJECTOR 10 1
- N 99002955 FOAM BLOCK, AIR/WATER INLET Note: (APPLY TO PLASTIC TUB BELOW AIR WATER INLET) 10 1
- 99002646 SEAL, AIR/WATER INLET 10 1
5 99002645 INLET, AIR/WATER 10 1
- 99002647 COVER, AIR/WATER INLET 10 1
- 99002867 FOAM INSERT, AIR/WATER INLET 10 2
- N 99002954 FELT, AIR/WATER INLET Note: (APPLY TO PLASTIC TUB BELOW AIR WATER INLET) 10 1
6 99002588 SEAL, DOOR 10 1
7 99002648 BRACKET, CABINET MOUNTING 10 2
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, STRIKER 10 1
8 99002644 STRIKER, DOOR 10 1
9 99002610 BRACKET, SPRING ADJUSTMENT 10 2
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 4
10 99002598 SPRING, DOOR 10 2
11 99002605 CABLE, DOOR 10 2
12 99002606 LINK, DOOR CABLE 10 2
- 99002761 BACKER, HINGE SEAL (LT) 10 1
13 99002762 BACKER, HINGE SEAL (RT) 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, SUPPORT 10 4
14 99002763 SUPPORT, HINGE (RT) 10 1
14 99002764 SUPPORT, HINGE (LT) 10 1
15 99002608 ROLLER, CABLE BRACKET 10 2
16 99002609 SHOULDER BOLT, CABLE BRACKET 10 2
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 4
17 99002607 BRACKET, CABLE 10 2
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 2
18 99002637 BRACKET, JUNCTION BOX SUPPORT 10 1
19 99002635 LEG, LEVELING 10 4
- 912365 SCREW Note: SCREW, COVER 10 1
20 99002638 COVER, JUNCTION BOX 10 1
21 99002630 FLOAT 10 1
22 99002631 SWITCH, FLOAT 10 1
23 99002632 PLATE, SWITCH MOUNTING 10 1
- 99002749 SCREW, STEEL HEX HD PLASITE Note: SCREW, PLATE 10 1
- 99002858 CLIP, TINNERMAN 12 1
- 99002749 SCREW, STEEL HEX HD PLASITE Note: SCREW, SHIELD 10 1
- 99002754 CLIP, WIRE 10 1
- 99002855 CLAMP, HARNESS 12 1
24 99002641 SHIELD, TUB 10 1
24 99002856 SHIELD, TUB 12 1
25 99002634 CLIP, THERMOSTAT 10 1
26 99002633 THERMOSTAT, LIMITING 10 1
27 99002636 BRACKET, SUPPORT (LT) 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 2
28 99002971 HEATER (W/GASKET) 18 1
28 99002625 HEATER 10 1
- 99002973 GASKET, HEATER 18 2
29 99002626 BRACKET, HEATER SUPPORT 10 2
30 99002972 NUT, HEATER 18 2
30 99002627 NUT, HEATER 10 2
9
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: TUB
DW13-94
Model: MDB7600AWW
10

TUB
No. Part No. Description
Section:
Series Qty
- Y913079 O-RING, HEATER 10 2
- 99002692 SCREW, TRIM MOUNTING 10 4
31 99002690 STRIP, TRIM/MOUNTING (LT) 10 1
32 99002723 STRIP, TRIM/MOUNTING (TOP) 10 1
33 99002691 STRIP, TRIM/MOUNTING (RT) 10 1
- 99002692 SCREW, TRIM MOUNTING 10 4
34 99002702 GAP SEAL, TOE KICK (BSQ) 10 1
- 99001194 SCREW, ACCESS PANEL Note: SCREW, SUPPORT (WHT) 10 2
35 99002860 SUPPORT, FRONT (W/SEALS)(WHT) 10 1
36 99002766 PANEL, TOE (W/DAMPER-WHT) 10 1
- 99001194 SCREW, ACCESS PANEL Note: SCREW, PANEL (WHT) 10 2
- 99002698 SOUND SEAL, TOE PANEL (WHT) 10 1
37 99002849 INSULATION, TUB 10 1
- 99002640 FASTENER, INSULATION 10 2
11
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: WATER DISTRIBUTION ASSEMBLY
DW14-58
Model: MDB7600AWW
12

WATER DISTRIBUTION ASSEMBLY
No. Part No. Description
Section:
Series Qty
1 99002642 MANIFOLD, MAIN 10 1
2 99002643 BRACKET, MANIFOLD MOUNTING 10 2
3 99002846 FILTER, OVER-PRESSURE (W/CVR) 10 1
- W10124350 NOT REQUIRED PART OR SEE NOTE Note: (PART NO LONGER NEEDED AT SERIES 25) 25 0
4 99002674 STATION, DOCKING (W/FLAPPER) 10 1
5 99002676 WASH ARM, TOP (W/RETAINER) 10 1
6 99002753 RETAINER, TOP WASH ARM 10 1
13
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: PUMP & MOTOR
DW14-59
Model: MDB7600AWW
14

PUMP & MOTOR
No. Part No. Description
Section:
Series Qty
1 99002654 CAP, WASH ARM 10 1
2 99002678 WASH ARM, LOWER (W/SHIELDS) 10 1
3 99002653 SHIELD, RADIANT 10 2
4 99002655 GUARD, FILTER (GRAY) 10 1
- 99002666 SCREW Note: SCREW, GUARD 10 3
- 99002664 SCREW, DISCHARGE HOUSING 10 6
5 99002677 DISCHARGE HOUSING ASSY (UPR) 10 1
6 99002659 WASH IMPELLER ASSEMBLY 10 1
- 99002660 SCREW, IMPELLER 10 1
- 99002668 SCREW, STAINLESS PAN HEAD Note: SCREW, FILTER/FLOWPLATE 10 3
7 99002661 FILTER/FLOWPLATE ASSEMBLY 10 1
8 99002658 CHOPPER 10 1
9 99002760 WASH MOTOR SEAL KIT 10 1
9 99002981 WASH MOTOR SEAL KIT 20 1
10 99002980 WASH MOTOR ASSY SEAL NOT INCL 20 1
10 99002759 WASH MOTOR ASSY SEAL NOT INCL Note: ORIG PART HAS SEAL. SUB PART WILL NOT HAVE
SEAL. ORDER SEAL SEPERATELY. 10 1
- 99002651 O-RING, TURBIDITY SENSOR Note: O-RING, TURBIDITY SENSOR 10 1
11 99002650 SENSOR, TURBIDITY 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, SENSOR 10 2
12 99002663 GASKET, PUMP 10 1
13 99002665 CAPACITOR, MOTOR 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, CAPACITOR 10 1
- 99002815 FLAPPER, DRAIN PUMP VALVE 10 1
14 99002750 DRAIN PUMP ASSEMBLY 10 1
15 99003058 FLAPPER, DRAIN FILTER 10 1
16 99002857 O-RING, DRAIN PUMP 10 1
17 99002752 BRKT, DRAIN PUMP (W/GROMMET) 10 1
- 99002657 SCREW, DRAIN PUMP MOUNTING 10 1
- 99002656 CLAMP, DRAIN HOSE (1-3/8") 10 1
18 99002652 HOSE, DRAIN 10 1
15
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: WIRING INFORMATION
15003043
Model: MDB7600AWW
