DOOR AND PANEL PARTS
1
For Models: MDB6701AWB10, MDB6701AWW10, MDB6701AWQ10, MDB6701AWS10
(Black) (White) (Bisque) (Stainless)
5−08 Litho In U.S.A. (CJJ) (eeb) Part No. W10208589 Rev. A
UNDERCOUNTER
DISHWASHER
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10158012 Instructions,
Installation
W10184365 Energy Guide
Y6920186 Guide, Use & Care
2 Bracket, Hinge
W10163109 Left
W10163108 Right
3 99001075 Screw
4
Y99002587 Pad, Foam
5 Panel, Front
99002768 Black
99002770 White
99002769 Bisque
99002771 Stainless
6 Screw
912366 Black
99001194 White
7 Panel, Toe
99002765 Black
99002766 White
99002767 Bisque
8 Support, Front
99003152 Black
99003153 White

CONTROL PANEL PARTS
2
For Models: MDB6701AWB10, MDB6701AWW10, MDB6701AWQ10, MDB6701AWS10
(Black) (White) (Bisque) (Stainless)
W10208589
Illus. Part
No. No. DESCRIPTION
1 99002575 Housing, Board
(Top)
2
W10169323 Board, Fontrol
3 99002576 Housing, Board
4 Panel, Control
99003382 Black
99003384 White
5 99002751 Switch, Door
6 99003347 Latch, Assembly

DOOR AND LATCH PARTS
3
For Models: MDB6701AWB10, MDB6701AWW10, MDB6701AWQ10, MDB6701AWS10
(Black) (White) (Bisque) (Stainless)
W10208589
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 99003537 Harness, Wiring
2
W10169387 Grill, Air/Water
Inlet
3 99002186 Seal, Air/Water
Inlet
4 99003243 Cap, Rinse Aid
5 99003322 Dispenser, Rinse
Aid
6 99002645 Inlet, Air/Water
7 Y912620 Screw, Door
8
W10170234 Inner Door
w/Damper
9 99003316 Bracket, Dispenser
10 912615 Screw

LOWER WASHARM PARTS
4
For Models: MDB6701AWB10, MDB6701AWW10, MDB6701AWQ10, MDB6701AWS10
(Black) (White) (Bisque) (Stainless)
W10208589
Illus. Part
No. No. DESCRIPTION
1 99003083 Cap, Wash Arm
2 99003144 Wash Arm, Lower
(Includes Item 3)
3
W10167918 Shield, Radiant

HEATER PARTS
5
For Models: MDB6701AWB10, MDB6701AWW10, MDB6701AWQ10, MDB6701AWS10
(Black) (White) (Bisque) (Stainless)
W10208589
Illus. Part
No. No. DESCRIPTION
1 99002971 Heater Element
Assembly
W/ Gasket
2 99002972 Nut, Heater
NOTE:
If heater element is
removed, it must be replaced.

FILL AND OVERFILL PARTS
6
For Models: MDB6701AWB10, MDB6701AWW10, MDB6701AWQ10, MDB6701AWS10
(Black) (White) (Bisque) (Stainless)
W10208589
Illus. Part
No. No. DESCRIPTION
1 99002852 Hose, Inlet
2 911856 Clamp, Spring
3 99002975 Valve, Water
4 99002631 Switch, Float
5 99002943 Plate, Switch
Mounting
6 99002652 Hose, Drain
7 99003080 Float
8 99002645 Inlet, Air/Water

TUB AND FRAME PARTS
7
For Models: MDB6701AWB10, MDB6701AWW10, MDB6701AWQ10, MDB6701AWS10
(Black) (White) (Bisque) (Stainless)
W10208589

TUB AND FRAME PARTS
8
For Models: MDB6701AWB10, MDB6701AWW10, MDB6701AWQ10, MDB6701AWS10
(Black) (White) (Bisque) (Stainless)
W10208589
Illus. Part
No. No. DESCRIPTION
1 W10119337 Strike, Door
2 99002648 Bracket, Cabinet
Mounting
3 99002640 Fastener
4 99002610 Bracket, Spring
Adjustment
5 Bracket, Support
99002636 Left
6 99003688 Nut
7
W10173920 Bracket, Cable
8 99002608 Roller, Cable
Bracket
9 99003687 Bolt, Shoulder
10 99002598 Spring, Door
11 99003446 Door Cable Assy.
12 99002849 Insulation, Tub
13 99002588 Seal, Door
14
W10142297 Tub Assembly
15 99002633 Thermostat
Limiting
16 99002634 Clip, Thermostat
17 99002692 Screw, Trim
Mounting
18 99002637 Bracket, Junction
Box
19
W10143258 Leg, Leveling
20 99003306 Strip, Trim
21 99002638 Cover, Junction
Box
22 Support, Hinge
W10137496 Left
W10137495 Right
23 Backer, Hinge
Seal
99002761 Left
99002762 Right
24 99002723 Strip, Trim Top
25 99003307 Strip, Trim Right

PUMP AND MOTOR PARTS
9
For Models: MDB6701AWB10, MDB6701AWW10, MDB6701AWQ10, MDB6701AWS10
(Black) (White) (Bisque) (Stainless)
W10208589

PUMP AND MOTOR PARTS
10
For Models: MDB6701AWB10, MDB6701AWW10, MDB6701AWQ10, MDB6701AWS10
(Black) (White) (Bisque) (Stainless)
W10208589
Illus. Part
No. No. DESCRIPTION
1 99002666 Screw
2 99003468 Guard, Filter
3 99002668 Screw
4 99003145 Discharge, Housing
Assembly
5 99002659 Wash Impeller
Assembly
6
W10142623 Filter/Flowplate
Assembly
7 99002663 Gasket, Motor
Mount
8 99002651 O−Ring, Turbidity
Sensor
9
W10120019 Sensor, Turbidity
10 99003697 Pivot, Wash Arm
11 99002668 Screw
12 99003427 Chopper
13 99003430 Wash Motor Assy.
14 99003309 Flapper, Drain
Pump Inlet
15 99002857 O−Ring, Drain Pump
16 99002740 Screw
17 99003141 Drain Pump Assy.
18
W10167912 Sheild, Capacitor
19 99002665 Capacitor
20 99002601 Screw

UPPER AND LOWER RACK PARTS
11
For Models: MDB6701AWB10, MDB6701AWW10, MDB6701AWQ10, MDB6701AWS10
(Black) (White) (Bisque) (Stainless)
W10208589

UPPER AND LOWER RACK PARTS
12
For Models: MDB6701AWB10, MDB6701AWW10, MDB6701AWQ10, MDB6701AWS10
(Black) (White) (Bisque) (Stainless)
W10208589
Illus. Part
No. No. DESCRIPTION
1 W10129047 Dishrack, Upper
2 99002621 Rail, Inner Slide
3 99003072 Clip, Upper Wash
Manifold (Front)
4 99003071 Clip, Upper Wash
Manifold (Back)
5 99003081 Wash Manifold
(Upper)
6 99003070 Arm, Wash (Upper)
7
W10129049 Dishrack, Lower
8 99003149 Wheel Assembly (8)
Lower
9
W10169390 Stop, Rail
10 99003268 Basket, Silverware
11 99002947 Wheel, Tub (8)

UPPER WASH AND RINSE PARTS
13
For Models: MDB6701AWB10, MDB6701AWW10, MDB6701AWQ10, MDB6701AWS10
(Black) (White) (Bisque) (Stainless)
W10208589
Illus. Part
No. No. DESCRIPTION
1 99003081 Feed Tube
Assembly
2 99002643 Bracket
3 99002753 Retainer, Top
Wash Arm
4 99003143 Station, Docking
(With Flapper)
5 99002676 Wash Arm, Top
(With Retainer)

OPTIONAL PARTS (NOT INCLUDED)
14
For Models: MDB6701AWB10, MDB6701AWW10, MDB6701AWQ10, MDB6701AWS10
(Black) (White) (Bisque) (Stainless)
W10208589
Illus. Part
No. No. DESCRIPTION
INSTALLATION KIT
8212488rc KIT INSTALLATION
(INCLUDES POWER
CORD, 6 FT. FILL
HARDWARE FOR
INSTALLATION)
4396897RP KIT, INSTALLATION
(INCLUDES 6 FT.
FILL HOSE AND
FOR INSTALLATION)
MOISTURE BARRIER KIT
4396277 KIT
DRAIN HOSE
8212486 12 FT.
4396897RW 6 FT.
PAINT, TOUCH−UP (1/2oz.)
72017 WHITE
72032 BLACK
4392899 BISCUIT
