Maytag MED5600TQ1 User manual

CABINET PARTS
1
For Model: MED5600TQ1
(White)
9−07 Litho in U.S.A. (LT) Part No. W10164732 Rev. A
29" ELECTRIC DRYER

CABINET PARTS
2
For Model: MED5600TQ1
(White)
W10164732
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10088770 Use & Care Guide
8576817 Wiring Diagram
W10089170 Sheet,
Cycle Feature
2 343641 Screw, 10−16 x 1/2
3 693995 Screw, 8−18 x 3/8
4 8541400 Bracket, Cabinet
5 3396795 Cover, Block
6 3403630 Plug−Strike
7 3396805 Panel, Rear
8 690363 Lock,
Front Top (2)
9 98234 Clip, Ground
10 3406107 Door Switch
Assembly
11 697773 Screw, 6−20 x 7/8
12 3404413 Plug−Hole
13 685203 Clip, Felt Pad (3)
14 3393008 Screw, 10−16 x 1/2
15 3394083 Clip,
Front Panel (2)
16 3392100 Foot, Dryer
279810 Foot−Optional
(Extended Length
Package of 2)
(Not Included)
17 279318 Terminal, Tinned
& Brass (3)
(Includes Item 39)
18 8530603 Cabinet
(Includes Item 4)
19 3403444 Panel, Front
20 3403431 Strike, Door
21 3406129 Seal & Bearing
Assembly
22 3389441 Catch, Door
Assembly
23 342055 Screw, 8−18 x 1/2
24 3405514 Hinge, Door
25 3405246 Seal−Door
26 3402341 Door, Rear
27 3402335 Door, Front
28 8565970 Handle, Door
29 279393 Terminal Block
Kit (For
Terminal Block)
30 697776 Screw, 10−32 x 5/8
31 3397659 Block, Terminal
32 3404162 Clamp−Motor
(W/Shield)
33 660658 Clamp, Motor
34 8066206 Motor Assembly
60 HZ.
35 8066184 Pulley, 60 Hz.
36 691366 Idler & Pulley
Assembly
37
W10131364 Belt, Drive
38 348780 Base, Motor
39 3400500 Bolt,
5/16−18 x 3/4
40 8066217 Hinge, Top (2)

TOP AND CONSOLE PARTS
3
For Model: MED5600TQ1
(White)
W10164732

TOP AND CONSOLE PARTS
4
For Model: MED5600TQ1
(White)
W10164732
Illus. Part
No. No. DESCRIPTION
1 W10112577 Panel, Rear
Console
2
W10113080 Wire, Jumper
(Tan)
3 693995 Screw, Hex Head
4
W10086704 Console & Shell
Assembly (Includes
Items 5 & 6)
5
W10112569 Badge, Assembly
6 8312709 Clip−Console
7 694419 Buzzer, Mini
8 8533971 Screw, 8−18 x 5/16
9 3399639 Switch,
Temperature
10
W10117655 Switch,
Push−To−Start
11 8536939 Clip, Spring
12
W10110029 Knob, Control (2)
13 3979617 Timer, 60 Hz.
14
W10110861 Wire, Jumper
(Temperature)
15 8565972 Screen, Lint
16
W10112597 Top
17
W10110030 Knob Assembly,
Timer
18 688983 Screw, 8−18 x 5/8
19
W10112578 Bracket, Harness
20 337686 Screw, 8/18 x 1/2
21
W10112603 Seal, Harness
22 3936144 Connector
23
W10110991 Harness, Wiring
24 3395683 Connector
(Motor)
25 3394427 Clip, Harness
26 3401144 Connector
(PTS Relay)
27 3397269 Connector
(Timer)
28 3347243 Connector
6−Circuit
29 94614 Terminal

BULKHEAD PARTS
5
For Model: MED5600TQ1
(White)
W10164732

BULKHEAD PARTS
6
For Model: MED5600TQ1
(White)
W10164732
Illus. Part
No. No. DESCRIPTION
1 348368 Lint Chute
Assembly
2 487909 Screw, 8−15 x 1/2
3 3388703 Washer−Support
4 347139 Seal, Lint
Chute
5 90767 Screw, 8−18 x 3/8
6 696302 Shield, Exhaust
7 3392519 Fuse, Thermal
(91C)
8 3387134 Thermostat,
Internal−Bias
9 3977393 Thermal, Cut−Off
(Includes Item 15)
10 694089 Wheel, Blower
11 8577230 Housing, Blower
12 3398161 Clip
13 343641 Screw, 10−16 x 1/2
14 8541818 Box, Heater
15 3977767 Thermostat,
221 F
(105 C)
16 3977373 Bracket, Drum
Light
17 3403585 Element, Heater
18 8066086 Drum Hole
Plug
19 279457 Wire Kit, Terminal
(For Heater
Element Wiring
Harness Repair)
20 489463 Screw, 8−18 x 5/8
21 3390647 Screw, 8−18 x 1/2
22 3406124 Bulb
23 3402841 Lens, Drum Light
24 690997 Ring, Tri
25 3399506 Shaft, L.H.
26 3399507 Shaft, R.H.
27 3397590 Roller, Support
28 348197 Washer, Support
29 3359452 Nut, 3/8−16
30 3403413 Bulkhead
31
W10136369 Socket Assembly
32 692526 Ring, Bearing (2)
33
W10109200 Screw, 11−16 x 3/4
34 3406130 Seal, Rear Drum
35 695587 Drum Assembly
36 692490 Baffle, Drum (2)
37 3976434 Bracket, Support
38 90296 Clip
39 3403636 Baffle, Drum (1)
40 339956 Seal

OPTIONAL PARTS (NOT INCLUDED)
7
For Model: MED5600TQ1
(White)
W10164732
Illus. Part
No. No. DESCRIPTION
ACCESSORY PARTS
279948 Kit,
Dryer Repair
3406839 Dry Rack
8522199 Kit, Dryer
Vent Testing
PAINT, TOUCH−UP (1/2oz.)
72017 White
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
350938 Primer, Gray
PAINT, BULK (1 qt.)
799344 White (Uncut)
