TOP AND CONSOLE PARTS
1
For Models: MGD5801TW0
(White/Grey)
10−07 Printed in U.S.A.(LT) Part No. W10169357 Rev. A
27" GAS DRYER

TOP AND CONSOLE PARTS
2
For Models: MGD5801TW0
(White/Grey)
W10169357
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10151000 Wiring Diagram
W10155111 Guide, Use & Care
W10155113 Dryer
Cycle Sheet
2 8317305 Panel, Rear
Console
3 8566184 Timer, 60 Hz.
4
W10112569 Badge
5 3398094 Switch,
Push−To−Start
6 3391885 Connector, Edge
7 3395683 Connector
(Motor)
8 8530169 Switch, Rotary
Temperature
9 3405156 Switch, Rotary
10 8533971 Screw, 8−18 x 5/16
11 694419 Mini−Buzzer
12 94614 Terminal
13 3347243 Connector,
6−Circuit
14 3391018 Tie, Cable
15 8312709 Clip, Console
16 3397269 Connector, Timer
17 717252 Receptacle, 2−Way
18 3403499 Connector,
2−Position
(Gas Valve)
19
W10150998 Harness, Wiring
20
W10110036 Knob, Timer
Assembly
21
W10110037 Knob Assembly
Push−To−Start
22 8568314 Strap, Console
23 3394427 Clip, Harness
24 8274462 Top
25 3936144 Connector
26 3390814 Screw, 8−18 x 3/8
27 8317340 Cover,
Terminal Block
28 3403498 Connector,
3−Position
(Gas Valve)
29 8558178 Control,
Electronic
30
W10110035 Knob, Control
Assembly (3)
31
W10112601 Console & Control
Panel Assembly
(Includes
Items. 4 & 15)
32 693995 Screw, 8−18 x 3/8
33 8536939 Clip, Spring
34 3390647 Screw, 8−18 x 1/2

CABINET PARTS
3
For Models: MGD5801TW0
(White/Grey)
W10169357

CABINET PARTS
4
For Models: MGD5801TW0
(White/Grey)
W10169357
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 697773 Screw, 6−20 x 7/8
2 8529757 Bracket, Burner
3 488729 Screw
4 3394331 Plate, Cover
5 3394881 Switch, Broken
Belt
6 344020 Cord, Power
7 8310656 Cabinet
8 3392100 Foot, Dryer
279810 Foot − Optional
(Extended Length
Package Of 2)
(Not Included)
9 660658 Clamp, Motor (2)
10 3387374 Spring, Idler
11 3389420 Retainer, Idler
12 697750 Plug, Multivent
13 3388672 Pulley Assembly
14 343641 Screw, 10−16 x 1/2
15 8533974 Screw, Ground
16 3398948 Wire, Jumper
(Broken Belt
Switch)
17 8563747 Exhaust Pipe
& Bracket
18 233520 Washer, Thrust
19 297092 Clip (2)
20
W10121334 Washer
21 3387560 Hinge, Door (R.H.)
3387559 Hinge, Door (L.H.)
22 3387565 Spring, Door (2)
23 8066120 Lever, Snap
Switch
24 3394081 Wire, Belt Switch
25 49026 4" − 90 Elbow
26
W10116360 Handle, Door
27 8538263 Motor, Assembly
60 HZ.
28 8563750 Exhaust Pipe
(Short)
29 8578220 Pulley, Motor
30 3387610 Belt, Drive
31 693995 Screw, 8−18 x 3/8
32 3387118 Bracket, Motor
33 8563749 Exhaust Pipe
(Long)
34 8281212 Screw, 8−18 x 3/8
35 98129 Screw,
6−20 x 1 3/8
36 693152 Bumper
37 3390736 Door Seal
38 690081 Catch, Door
Assembly
39 3388674 Idler Bracket
40 3357011 Screw, 10−16 x 1/2
41 3406107 Door Switch
Assembly
42 697215 Toe, Panel
(Includes
Item. 36)
43 3387242 Seal, Front Panel
44 3388229 Retainer
45 697655 Door, Rear
46 694091 Screw, 8−18 x 3/8
47 697221 Door, Front
48 697227 Upper Front Panel
49 696144 Strike, Door
Optional Parts Not Included
Dryer Exhaust Kit
(For Side & Bottom Venting)
50 279818 White

BULKHEAD PARTS
5
For Models: MGD5801TW0
(White/Grey)
W10169357

BULKHEAD PARTS
6
For Models: MGD5801TW0
(White/Grey)
W10169357
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8575324 Shaft, R.H. Thread
2 3390647 Screw, 8−18 x 1/2
3 90767 Screw, 8−18 x 3/8
4 3394986 Spring, Lint
Screen Door
5 3394346 Air Duct Assembly
6 697813 Seal, Outlet
Housing
7 697814 Seal, Drum Front
8 3934666 Nut,3/8 x 16(R.H.)
9 8066086 Drum Hole
Plug
10
W10128629 Shield,
Blower Housing
11 3392258 Wire
12 487909 Screw, 8−15 x 1/2
14 3394984 Door, Lint
Screen
15 8066224 Exhaust Pipe
16
W10001120 Nut, 3/8−16 (L.H.)
17 8520836 Bulkhead, Rear
18 3387459 Washer, Support
19 8575325 Shaft, L.H. Thread
20 690997 Ring, Tri
21 8536973 Roller, Support
22 695240 Screw, 8−18 x 1/2
23 3394985 Outlet Housing
Assembly
24 359625 Screw, 8−18 x 1/2
25 8318215 Complete Drum
Assembly
26
W10109200 Screw, 11−16 x 3/4
27 697694 Seal, Drum
28 8533971 Screw
29 697557 Bulkhead, Front
30 8572105 Clip, Exhaust
31 489463 Screw
32 8299979 Grille, Outlet
33 3392519 Thermal Fuse
34 3387223 Electrode, Sensor
35 3402841 Lens, Drum
Light
36 3406124 Bulb, Light
37 697772 Wheel, Blower
38 3977373 Bracket, Light
39
W10136369 Socket, Assembly
40 697770 Seal, Cover Plate
41 8066170 Screen, Lint
42 8318268 Thermostat,
Internal Bias
43 3403140 Thermostat,
High−Limit 205 F
(96 C)
44 8544362 Housing, Blower
45 8066168 Lint Duct Assembly
46 8066047 Funnel, Burner
47 338906 Sensor, Radiant
48 3387230 Screw,
10−16 x 13/16
49 697693 Baffle, Drum

USE WITH TYPE 1 − NATURAL
AND TYPE 4 LIQUEFIED PROPANE AND BUTANE GASES
8576353 BURNER ASSEMBLY
BA−153A
7
For Models: MGD5801TW0
(White/Grey)
W10169357

Illus. Part
No. No. DESCRIPTION
BA−153A
8576353 BURNER ASSEMBLY
USE WITH TYPE 1 − NATURAL
AND TYPE 4 LIQUEFIED PROPANE AND BUTANE GASES
1 8576353 Burner Assembly
60 Hz.
(Type 1)
(White Rodgers)
2 688617 Tube, Burner
3 694298 Bracket, Ignitor
4 686590 Ignitor
5 3393909 Screw & Washer
(8−32 x 7/8)
6 343641 Screw, 10−16 x 1/2
7 3389871 Base, Burner
8 3387057 Screw,
8−18 x 3/8
9 Orifice, Burner
15418 Type 1
15422 Type 4 (Butane)
234867 Type 4 (Propane)
10
W10118347 Valve, Gas
60 Hz. (Complete)
(Includes Pipe &
Illus. #7).
11 694421 Screw,
8−32 x 1/2 (2)
12 694538 Bracket, Coil
13 694540 Coil, 60 Hz.
(2 Terminal)
(Main)
14 694539 Coil, 60 Hz.
(Split)
(3 Terminal)
(Pilot Position)
15 694424 Leak, Limiter
16 694423 Screw, Regulator
Adjustment
17 694422 Spring, Regulator
18 3390647 Screw, 8−18 x 1/2
20 239822 Plug, Pipe
25 3387561 Clamp, Pipe
26 3389889 Bracket, Support
Following Parts Not Illustrated
8576846 Conversion Kit
(Type (1)
to Type (4) LPG).
8
For Models: MGD5801TW0
(White/Grey)
W10169357

OPTIONAL PARTS (NOT INCLUDED)
9
For Models: MGD5801TW0
(White/Grey)
W10169357
Illus. Part
No. No. DESCRIPTION
ACCESSORY PARTS
80047 Kit,
Dryer Repair
8522199 Kit, Dryer
Vent Testing
346764 Kit, Hold−Down
(Gas Dryer Mobile
Home Installation)
3406911 Dry Rack
PAINT, TOUCH−UP (1/2oz.)
72017 White
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
350938 Primer, Gray
PAINT, BULK (1 qt.)
799344 White (Uncut)
