AtMaytag,webelievedurablegoodsshouldremainjust
that.That’swhyeveryMaytag®product is constructed of the
highest-quality materials and with the utmost in precision
craftsmanship.It’salsowhywestandbehindourequipment
with solid service and support from our professional Maytag
laundrysuppliers.Simplyput,whenyouchooseMaytag®
products,youensureyourpeaceofmind.
OUR COMMITMENT
TO DEPENDABLE QUALITY
1/09
MLE/MLG24PR
MAYTAG®COMMERCIAL
SINGLE LOAD
SUPER-CAPACITY
STACK DRYER
Maytag®Super-Capacity Dryer
MICROPROCESSOR CARD READER-READY
5 YEARS ON ALL PARTS
Foraperiodfromthedateoforiginalpurchasethroughthetimelisted
above,thedesignatedpartsthatfailinnormalcommercialusewillbe
repairedorreplacedfreeofchargeforthepartitself,withtheowner
payingallothercosts,includinglabor,transportationandcustomsduty.
Chemicaldamageisexcludedfromallwarrantycoverage.
See complete warranty for details.
DRYER SPECIFICATIONS
MODEL MLE/MLG24PR
MOTOR
Single-phase,thermoprotectedagainstoverload,
auto-reset •
HP(kw)
1
⁄
3
(.25)
CAPACITY
Cu.ft.(liters) 7.4(209.5)
AIRFLOW —cfm(cmm)
Gas/Electricmodels—perpocket 230(6.5)/215(6.1)
Export,Gas/Electricmodels—perpocket 230(6.5)/215(6.1)
TUMBLE SPEED
RPM 50+1.5
ELECTRICAL REQUIREMENTS
MDEmodel—voltage 240V/60Hz*
MDGmodel—voltage 120V/60Hz
Exportmodels—voltage 220-240V/50Hz
BREAKER/FUSE REQUIREMENTS —amps
Electricmodel—domestic(eachdryingchamber) 30
Electricmodel—export(oneterminalblockperstack) 40
Electricmodel—Canada(oneterminalblockperstack) 60
Gasmodels,allversions—(onepowercordperstack) 15
HEATER ELEMENT RATING —watts
Domesticmodel—perpocket 5,600
Exportmodels—perpocket 4,600
EXHAUST DUCT DIAMETER
In.(mm) 4(101.6)
ELECTRONIC BURNER IGNITION
MDGmodel •
GAS RATING
MDGmodels,allversions—BTU/hr.(kcal/hr.) 24,000(6,048)
GAS INLET
MDGmodel—in.
3
⁄
8
N .P.T.
AUTOMATIC PRESSURE REGULATOR
MDGmodels •
ADJUSTABLE LEVELING LEGS •
APPROXIMATE WEIGHT
Crated—lbs.(kg) 275(124.7)
Uncrated—lbs.(kg) 250(113.4)
DIMENSIONS
Width—in.(mm) 27(685.8)
Depth—in.(mm) 29(736.6)
Height—in.(mm) 76.75(1949)
Seespecificinstructionsforproperinstallation.Becauseofcontinuousproductimprovement,Maytagreservestheright
to change specifications without notice.
*
208-Voltelectricalelementkitavailable
MAXIMUM EXHAUST DUCT LENGTH
PER NUMBER OF TURNS
Number Of
90° Turns
Rigid Metal Vent
Box Hood and Angled Hood
Louvered Style Style
0 135 ft. (41.2 m ) 129 ft. (39.3 m )
1 125 ft. (38.1 m ) 119 ft. (36.3 m )
2 115 ft. (35.1 m ) 109 ft. (33.2 m )
3 106 ft. (32.3 m ) 100 ft. (30.5 m )
4 98 ft. (29.9 m ) 92 ft. (28.0 m )
Flexible Metal Vent
Box Hood and Angled Hood
Louvered Style Style
0 76 ft. (23.2 m ) 62 ft. (18.9 m )
1 71 ft. (21.6 m ) 57 ft. (17.4 m )
2 67 ft. (20.4 m ) 53 ft. (16.2 m )
3 65 ft. (19.8 m ) 51 ft. (15.6 m )
4 63 ft. (19.2 m ) 49 ft. (14.9 m)
