MLG35PD
MAYTAG®COMMERCIAL
ENERGY ADVANTAGE™
MULTI-LOAD STACK DRYER
MY120135
Shown in Stainless Steel.
visit maytagcommerciallaundry.com
or call 800-662-3587
LEGENDARY MAYTAG DEPENDABILITY
Maximizing your equipment investment for over a half century.
ENERGY-SAVING SOLUTIONS
Maytag built the first appliance ever to receive the ENERGY STAR®label.
Today we offer energy-saving laundry solutions for all commercial laundry
needs—from energy-efficient dryers to highly efficient ENERGY STAR®-
qualified washers— to help you save money and build profits.
UPDATED CONTROLS
New soft-touch keypad for ease-of-use and durability. Includes Maytag®
Accu Trac®audit system that uses a PDA to communicate with the
microprocessor controls—so you can set up, monitor and audit your
equipment in seconds.
CAPACITY:
• 35 lb. Capacity
• 17% Greater Capacity Than a Maytag® 30-lb. Stack Dryer
FOR YOUR CUSTOMERS:
• Fast-Drying Axial 100% Airflow System Enhances Airflow
• ThermoGuard™System Helps Prevent Laundry Overheating
• Owner-Programmable Single-Phase Reversing
• Extra-Large Door Openings With Dual Pane Glass Door
• Time Remaining Digital Display
• Self-Diagnostic Microprocessor Controls
FOR YOUR OPERATION:
• Low BTUs and Fast Dry
• Enhanced Insulation For Greater Efficiency
• Front Serviceable
• Accu Trac® Audit System With Two-Way Data Communication
• Single Payment System
• 2 Large-Capacity Lint Drawers
BUILT-TO-LAST™FEATURES:
• Heavy-Duty Enclosed Motors
• Fire Suppression System
• Four-Point Roller Support System
• 5 Year Limited Warranty—All Parts Covered

DRYER SPECIFICATIONS
MODEL MLG35PD
MOTOR
Single-phase, thermoprotected against overload,
auto-reset
•
Drive Motor — HP (kw) .25 (.19)
Blower Motor — HP (kw) .50 (.37)
CAPACITY
Lbs. (kg) per drying chamber
2 x 35 (2 x 15.8)
Cu. ft. (cu. m) per drying chamber 2 x 12.27 (2 x .347)
AIRFLOW
Cfm (cmm) per drying chamber
380 (10.76)
TUMBLERS
Diameter — in. (mm)
2 x 30 (2 x 762)
Depth — in. (mm) 2 x 30 (2 x 762)
ELECTRICAL REQUIREMENTS 120V, 60 Hz
Export Models — options available 220-380V/1PH or 3 PH
BREAKER/FUSE REQUIREMENTS
Amps per drying chamber
15
EXHAUST DUCT DIAMETER
In. (mm)
2 x 6 (152)
GAS RATING
BTU/hr. (kcal/hr.) per drying chamber
64,000 (16,138)
GAS INLET
M.N.P.T. in. (mm)
2 inlets, 1⁄2 (12.7)
COLORS
White
•
Stainless Steel •
APPROXIMATE WEIGHT
Crated — lbs. (kg)
630 (286)
Uncrated — lbs. (kg) 600 (272)
DIMENSIONS
Height — in. (mm)
803/8 (2,042)
Width — in. (mm) 311/8 (791)
Depth — in. (mm) 395/8 (1,006)
Door opening diameter — in. (mm) 193/8 (492)
See specific instructions for proper installation.
Because of continuous product improvement, May tag reserves the right to change specifications without notice.
At Maytag, we believe durable goods should remain just that.
That’s why every Maytag®product is constructed of the
highest-quality materials and with the utmost in precision
craftsmanship. It’s also why we stand behind our equipment
with solid service and support from our professional Maytag
laundry suppliers. Simply put, when you choose Maytag®
products, you ensure your peace of mind.
OUR COMMITMENT
TO DEPENDABLE QUALITY
10/12
MLG35PD
MAYTAG®COMMERCIAL
ENERGY ADVANTAGE™
MULTI-LOAD
STACK DRYER
Maytag®Commercial Energy Advantage™
Multi-Load Stack Dryer
MICROPROCESSOR COIN-DROP
5 YEAR LIMITED WARRANTY
ALL PARTS COVERED
For a period from the date of original purchase through
the time listed above, the designated parts that fail in
normal commercial use will be repaired or replaced free
of charge for the part itself, with the owner paying all
other costs, including labor, transportation and customs
duty. Chemical damage is excluded from all warranty
coverage. See complete warranty for details.
