PHASE 7.2
OPL
USER’S MANUAL
122002JEV/mcronan PartNo.113162
For replacement parts, contact the distributor from which the dryer
was purchased or contact:
Maytag Co.
403 West Fourth St North
Newton, Iowa 50208
[phone]

Retain This Manual In ASafe Place For Future Reference
Please read this manual carefully to thoroughly familiarize yourself with the Phase 7 OPL computer system
features, operational instructions, and programming characteristics. This manual contains important information
on how to employ ALL the features of your new Maytag dryer in the safest and most economical way.
Our products embody advanced concepts in engineering, design, and safety. If this product is properly
maintained, it will provide many years of safe, efficient, and trouble free operation.
We have tried to make this manual as complete as possible and hope you will find it useful. Manufacturer
reserves the right to make changes from time to time, without notice or obligation, in prices, specifications, colors,
and material, and to change or discontinue models.
“IMPORTANTNOTETOPURCHASER”
Informationmustbeobtainedfromyourlocalgassupplierontheinstructions
tobefollowedifthe user smells gas. These instructionsmustbepostedin a
prominentlocationnearthe dryer.

IMPORTANT
YOU MUST DISCONNECT AND LOCKOUT THE ELECTRIC SUPPLY
AND THE GAS SUPPLYOR THE STEAM SUPPLYBEFOREANY COVERS
ORGUARDSAREREMOVEDFROMTHE MACHINETOALLOWACCESS
FOR CLEANING, ADJUSTING, INSTALLATION, OR TESTING OF ANY
EQUIPMENT PER OSHA (Occupational Safety and Health Administration)
STANDARDS.
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE
VAPORS AND LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER
APPLIANCE.
FOR YOUR SAFETY
DO NOT DRY MOP HEADS IN THE DRYER.
DO NOT USE DRYER IN THE PRESENCE OF DRY CLEANING FUMES.
CHILDREN SHOULD NOT BE ALLOWED TO PLAY ON OR NEAR
THE DRYERS.
WARNING
CHILDREN SHOULD BE SUPERVISED IF NEAR DRYER(S) IN
OPERATION.
DRYERS SHOULD NEVER BE LEFT UNATTENDED WHILE IN
OPERATION.
CAUTION
WARNING
The dryer must never be operated with any of the back guards, outer tops,
or service panels removed. PERSONAL INJURY OR FIRE COULD
RESULT.

IMPORTANT
PLEASE OBSERVE ALL SAFETY PRECAUTIONS displayed on the
equipment and specified in the installation manual included with the dryer.
WARNING
DRYER MUST NEVER BE OPERATED WITHOUT THE LINT
FILTER OR SCREEN IN PLACE, EVEN IF AN EXTERNAL LINT
COLLECTION SYSTEM IS USED.
Dryers must not be installed or stored in an area where it will be exposed to
water or weather.
The wiring diagram for the dryer is located in the front electrical control box area.
WARNING
Power must be disabled prior to changing S.A.F.E. system temperature probe!!
The S.A.F.E. system will be activated if probe is removed while dryer in power.
NOTE
If power to the dryer is off, the S.A.F.E. system is disabled.

Table of Contents
SECTION I
INTRODUCTION.......................................................................................................3
SECTION II
FEATURES..................................................................................................................4
A. Dependable MicroprocessorSolid StateIntegratedCircuitry ....................................................... 4
B. SensorActivatedFireExtinguishing(S.A.F.E.)System ................................................................ 4
C. ProgramChangesAreEasilyMadeAtTheKeyboard (TouchPad) ............................................. 4
D. Automatic DryingCycle (PatentNo. 4,827,627) ......................................................................... 4
E. Timed(Manual)DryingCycle ..................................................................................................... 4
F. PreprogrammedCycles .............................................................................................................. 4
G. ManuallyLoadedCycles ............................................................................................................ 4
H. Variable(Programmable) Fabric/TemperatureSelections ............................................................. 4
I. CoolDown/ControlledCoolDownProgram............................................................................... 4
J. LightEmittingDiode(L.E.D.)Display ......................................................................................... 4
K. WrinkleGuardProgram .............................................................................................................. 4
L. Diagnostics ................................................................................................................................. 4
M. AudioAlertSignal....................................................................................................................... 4
N. TemperatureConversion Status................................................................................................... 4
O. High-TemperatureProtection ...................................................................................................... 5
P. CyclePreview ............................................................................................................................ 5
Q. ReversingOption ........................................................................................................................ 5
R. RPM .......................................................................................................................................... 5
S. CleanLint................................................................................................................................... 5
T. LanguageSelection ..................................................................................................................... 5
U. ModelSelection ......................................................................................................................... 5
V. DefaultFactorySettings .............................................................................................................. 5
W. Keyboard(Touch Pad)Symbols ................................................................................................. 5
X. SteamInjection Option ............................................................................................................... 5
SECTION III
PROGRAM SELECTIONS ......................................................................................6
A. PreprogrammedCycles .............................................................................................................. 6
B. ManuallyLoadedCycles ............................................................................................................ 7
C. AutomaticDryingCycle (Patent No. 4,827,627)Operations ....................................................... 8
D. Timed(Manual)DryingCycleOperation ..................................................................................... 8
E. LightEmittingDiode(L.E.D.)DotMatrixDisplay........................................................................ 8
F. CycleInProgressTemperatureDisplay ....................................................................................... 9
G. TemperatureConversionStatus................................................................................................... 9
H. WrinkleGuardProgram .............................................................................................................. 9
I. AudioAlertOnTimes0 to10 ................................................................................................... 10
J. PreprogrammedCyclePreview................................................................................................. 10

K. ReversingOption ...................................................................................................................... 10
L. Diagnostics ............................................................................................................................... 10
M. ProgramLocations ................................................................................................................... 11
SECTION IV
OPERATING INSTRUCTIONS.............................................................................13
A. Operating Sequence ................................................................................................................. 13
B. OperatingNotes ....................................................................................................................... 17
C. Rev2.2SensorActivatedFire Extinguishing (S.A.F.E.)SystemTheoryOfOperation ................ 18
SECTION V
L.E.D DISPLAY MESSAGES .................................................................................19
A. L.E.D.Display Operating Status ............................................................................................... 19
SECTION VI
PROGRAMMING INSTRUCTIONS ....................................................................20
A. IntroductiontoProgramming ..................................................................................................... 20
B. ProgrammingFlowcharts .......................................................................................................... 22
SECTION VII
FACTORY PRESET PARAMETERS (PROGRAMS)........................................71
A. Cycle“A-F” Parameters (Programs)Preset By TheFactory...................................................... 71
B. Cycle “0-40” Parameters(Programs) Preset ByThe Factory..................................................... 71
SECTION VIII
PHASE 7 OPL PROGRAMMING LIMITS ..........................................................72
A. PreprogrammedCycles ............................................................................................................ 72
B. SystemParameters(ProgramLocations) ................................................................................... 73
C. FixedParameters...................................................................................................................... 73
SECTION IX
PHASE 7 AUTO CYCLE (PATENT NO. 4,827,627) CYCLE ADJUSTMENT
VALUES......................................................................................................................74
SECTION X
PHASE 7 OPL SYSTEM DIAGNOSTICS............................................................75
A. Diagnostic(L.E.D.Display)FaultMessages .............................................................................. 75
B. Input/Output(I/O)BoardLightEmittingDiode(L.E.D.) Indicators ............................................ 76
C. Keyboard(TouchPad) Layout ................................................................................................. 78
SECTION XI
CUSTOMER CUSTOM PARAMETER SETTINGS..........................................79

3
SECTION I
INTRODUCTION
Phase 7 “On-Premise Laundry” Microprocessor Drying System
The Phase 7 On-Premise Laundry (OPL) Drying System has been designed with super performance in mind to
provide for better temperature regulation, efficiency, performance, consistency, and faster drying times.
Among its many amenities, the Phase 7 OPL Drying System has a true Automatic Drying Cycle. The Phase 7
OPL Automatic Drying Cycle (Patent No. 4,827,627) principle is based on one (1) of the most fundamental
laws of thermodynamics, which governs the flow of heat in thermal systems.
Utilizing this microprocessor technology, the user simply has to place the load in the dryer and push one (1) single
button to start the drying cycle. The Phase 7 OPL microprocessor controller (computer) will directly monitor the
moisture content in the load and stop the drying cycle automatically when the selected dryness level is reached.
The Phase 7 OPL Automatic Drying Cycle(Patent No. 4,827,627) virtually eliminatesALL guesswork. The
Phase 7 OPL microprocessor controller (computer) determines how much drying time is needed and compensates
for various types of fabrics and load sizes, thus, avoiding damage to fabrics by over drying, as well as avoiding
wasted time and energy for any given load. Once the Phase 7 microprocessor controller (computer) determines
the load is dry, the microprocessor controller (computer) will go into Cool Down Cycle until the preprogrammed
time or temperature is reached, and then shuts the dryer off automatically.

4
SECTION II
FEATURES
A. Dependable Microprocessor Solid State Integrated Circuitry - To eliminate as many moving parts as
possible.
B. SensorActivated Fire Extinguishing (S.A.F.E.)System- A standard feature, which continually monitors
the basket (tumbler) for fires, in the event of a fire a water supply to the basket (tumbler) will suppress the
fire. The Phase 7 OPL microprocessor controller (computer) will also notify the user that a fire has taken
place.
C. Program Changes Are Easily Made At The Keyboard (Touch Pad) - Actual programs are viewed at
the light emitting diode (L.E.D.) display for verification.
D.Automatic Drying Cycle (Patent No. 4,827,627) - Computerized monitoring of load dryness for precise,
fast, and efficient drying.
E.Timed (Manual) Drying Cycle - For special loads, programming allows for a specific amount of time in
minutes for both drying and Cool Down Cycles.
F.Preprogrammed Cycles - The Phase 7 OPL microprocessor controller (computer) can store in its memory
six (6) preprogrammed cycles in either the Automatic Drying Mode (Patent No. 4,827,627) or Manual
Drying Mode in the “A-F” keys and an additional 41 in the numerical memory of “0-40.”
G.Manually Loaded Cycles - For occasional or onetime special loads, the user can set a specific program in
either the Automatic Drying Cycle (Patent No. 4,827,627) or Manual Timed Drying Cycle.
H.Variable (Programmable) Fabric/Temperature Selections - Accommodates the type of fabric to be
dried.
I.Cool Down/Controlled Cool Down Program - Cool down lowers the temperature of the exhaust to make
the material cool enough to handle. Controlled cool down slowly lowers the temperature over 10 minutes for
materials sensitive to shrinking.
J.L.E.D. Display - Informs user of cycle status, programs and displays important diagnostic and fault codes.
K.Wrinkle Guard Program - Helps keep items wrinkle-free when they are not removed from the dryer
promptly at the end of the drying and cooling cycles.
L.Diagnostics - Major circuits, including the door switch(es), microprocessor temperature sensor and heat
output circuits and more are individually monitored, give precise messages of your failure
M.Audio Alert Signal - The tone will sound at the end of a complete drying cycle at a 1-second rate for the
duration programmed. It will also sound for any fault conditions at a quarter second rate for 4-beeps. Finally,
there is a 3-beep warning at the beginning of every Wrinkle Guard On Cycle a continuous rapid pulse is used
for the entire duration of S.A.F.E. system activation. A connection is also available to install an external
24VDC (volts direct current) buzzer or relay with a maximum power consumption of 250 mA (milliamperes).

5
N. Temperature Conversion Status - Temperature related programs can be set in either Fahrenheit (ºF) or
Celsius (ºC). ALL temperatures will automatically convert to the corresponding values (+/- 1º) when changes
are made.
O. High-Temperature Protection- If the Phase 7 OPL microprocessor controller (computer) senses that the
temperature in the basket (tumbler) has exceeded 180º F (82º C) for axial airflow, 220º F (104º C) for radial
airflow and it will end the drying cycle and a fault code will be displayed, indicating an overheating problem.
P. Cycle Preview - Entire dryer parameters (programs) or the preprogrammed cycles are displayed for
verification upon a coded entry to the keyboard (touch pad).
Q. Reversing Option- Helps reduce the balling up or tangling of large items. A cycle can be set to have the
reversing option where the basket (tumbler) will turn in the forward direction from 30- to 120-seconds, stop
from 5- to 10-seconds, and then proceed in the reverse direction for the same time. This process is repeated
throughout the drying and cooling cycles.
R. RPM - Phase 7 microprocessor controller (computer) also displays basket (tumbler) RPM by pressing and
holding the “DOWN ARROW” key and holding it while the basket (tumbler) is on. (The basket [tumbler]
must be rotating for approximately 30-seconds before getting a true RPM reading).
S. Clean Lint - This feature monitors the value of the “Lint Count” register. The register contains the acceptable
limit of dryer cycles the machine will be allowed to operate before the microprocessor locks the user out.
Once the feature prompts the user to “CLEAN LINT ACCESS” the dryer is now in a locked state and will
not be cleared until the lint drawer has been cleaned. When the lint drawer is opened, the display will read
“LINT ACCESS OPEN” and when the lint drawer is closed, the display will read “READY.” (NOTE:The
lint drawer must be opened for 15-seconds or more for the reset to occur.) The dryer circuit is now active
and can be programmed.
T.Language Selection - Phase 7 has the ability to display 5 different languages, English, French, Spanish,
Italian, and German.
U.Model Selection- The Phase 7 can be programmed to be used on 3 modes of heat, gas, steam and electric.
It can also be configured for reversing and non-reversing dryers.
V. Default Factory Settings - This feature will set ALL programmed parameters to their default values.
W. Keyboard (Touch Pad) Symbols - =“STOP/CLEAR” key
=“START/ENTER” key
=“UP ARROW” key (scroll up)
=“DOWN ARROW” key (scroll down)
X. Steam Injection Option - The Phase 7 has the ability to program up to 5 steam injection intervals for a
programmed amount of time at different points of a cycle including cool down.

6
SECTION III
PROGRAM SELECTIONS
A. PREPROGRAMMED CYCLES
“A-F” CYCLES
The Phase 7OPL microprocessor controller (computer) can store in its memory six (6) preprogrammed cycles
(keys “A-F” on the keyboard [touch pad]). This allows the user to have the six (6) most commonly used cycles,
requiring only the push of a single keyboard (touch pad) entry to start the dryer.
“0-40” CYCLES
The Phase 7OPL microprocessor controller (computer) can store 41 preprogrammed cycles in its numerical
memory. (Use keys “0-9” on the keyboard [touch pad]). This allows the user to have up to 41 customized
programmed cycles that may not be as commonly used as the six (6) “A-F.” Theseare not one (1) touch entries
to start the dryer like the “A-F.” They are selected by entering the number, which represents the cycle desired
and pressing the “START/ENTER” key to start the cycle.
Both types of the preprogrammed cycles can be set in either the Automatic Drying Mode (Patent 4,827,627),
where the drying cycle will end when the selected dryness level has been reached, or in the Manual Timed
Drying Mode where the dryer will operate for the specific drying time programmed. These cycles can be
programmed in any combination.
Once the heating cycle is completed, the Phase 7 OPL microprocessor controller (computer) then goes into the
Cool Down Cycle where the articles are tumbled at room temperature or a controlled cool down where the dryer
goes into a slow cool down mode for 10 minutes sloping the temperature 10º F (5.5º C) every minute.
When the cooling cycle is completed, the dryer will go into the Wrinkle Guard Cycle. Where the load will be
tumbled without heat for 2 minutes. It will then stop for 2 minutes. This process is repeated until either the doors
are opened, the “STOP” key pressed, or 99 minutes has elapsed, whichever comes first. When Wrinkle Guard
is ended, the display will read “CYCLE DONE.” At this point the dryer is locked out from drying again until the
doors are opened. This will insure that if a cycle has been completed, the operator will attend to it, before
starting another heat cycle.
NOTE: To enter program mode press clear/stop and the up arrow.
PREPROGRAMMED CYCLE MENU SELECTIONS (CYCLES “A-F” or “0-40”):
1. Automatic Drying Cycle (Patent No. 4,827,627)
a. The Phase 7 OPL microprocessor controller (computer) can be programmed to reverse or not reverse.
This is done in “DRYER SETUP” parameter.
b. Drying Temperature - Programmable from 160º F to 200º F (71º C to 93º C) in one-degree increments
and preset at 160º F (71º C) for axial.

7
c. Dryness Level - Programmable for finishing, dry, and extra dry.
d. Cool Down Time - Programmable from 0 to 99 minutes in 1 minute increments.
e. Cool Down Temperature - Programmable from 70º F to 100º F (21º C to 38º C) in one-degree increments.
f. Cycle Adjustment - Programmable from 0 to 99.
2. Timed (Manual) Cycle
a. The Phase 7 OPL microprocessor controller (computer) can be programmed to reverse or not reverse.
This is done in “DRYER SETUP” parameter.
b. Drying Time - Programmable from 0 to 99 minutes in 1 minute increments.
c. Drying Temperature - Programmable from 100º F to 200º F (38º C to 93º C) in one-degree increments.
d. Cool Down Time - Programmable from 0 to 99 minutes in 1 minute increments.
e. Cool Down Temperature - Programmable from 70º F to 100º F (21º C to 38º C) in one-degree increments.
f. The Spin Time can be programmed from 30-seconds to 120-seconds in 1-second increments.
g. The Dwell (stop) Time can be programmed from 5-seconds to 10-seconds in 1-second increments.
h. Steam Injection (optional) - Programmable 0-5 intervals.
ALL six (6) “A-F” preprogrammed cycles along with cycles “0-40” have been programmed by the
factory as outlined in Section VII. However, even though cycles “A-F” are the most common cycles
used, they should be reviewed to ensure they meet the location application or needs. Should changes
be found necessary, refer to the Programming Section of this manual.
B. MANUALLYLOADED CYCLES
For occasional or onetime special loads, the operator must enter the specific program features needed. This
cycle is not stored within the Phase 7 OPL microprocessor controller (computer) and must beentered each and
every time.
The Manually Loaded Cycle can be set in either the Automatic Drying Mode (Patent No. 4,827,627) or the
Timed (manual) Drying Mode. These are selected by pressing the “AUTO” or “MAN” keys on the keyboard
(touch pad).

8
C. AUTOMATIC DRYING CYCLE (PATENT NO. 4,827,627) OPERATIONS
In this mode, the Phase 7 OPL microprocessor controller (computer) determines how much drying time is
needed and compensates for various types of fabrics and load sizes, ALL automatically. The Phase 7 OPL
microprocessor controller (computer) accomplishes this by calculating the dryness level (percentage of extraction)
using the temperature selected, as well as, the dryness level preset by the factory.
The Phase 7 OPL microprocessor controller (computer) monitors the first three (3) heat peaks (slopes), at
which time it calculates the dryness level (heat loss) along with the percentage of extraction selected. When the
Phase 7 OPL microprocessor controller (computer) determines that ALL the factors are met, the drying cycle
will end, and the dryer will go into the Cool Down Cycle.
D. TIMED (MANUAL) DRYING CYCLE OPERATION
This drying cycle is intended for special loads where a specific amount of drying time and cooling time is needed,
especially for fine, delicate items which require very low temperatures and long drying and/or Cool Down Time
periods.
ALL the parameters set in “COOL DOWN SETUP” pertain to the Manually Loaded Manual and Auto Cycles.
The “A-F” and “0-40” cycles that have been selected to be manual, have separate settings forALL the parameters
contained in the “COOL DOWN SETUP” menu.
The program limitation is the same as in Section III A2.
NOTE: The Cool Down Cycle will run either until the Cool Down Temperature is reached or until the
Cool Down Time has expired, whichever comes first.
NOTE: If there has been no Drying Time selected, then the Cool Down Cycle will ignore the Cool
Down Temperature and do the Cool Down Time only.
E. LIGHT EMITTING DIODE (L.E.D.) DOT MATRIX DISPLAY
The L.E.D. display informs the user of cycle status, program verification, and displays important diagnostic and
fault information. A complete listing of the various display messages and their meanings are shown in Section
Vof this manual.
CYCLE IN PROGRESS DISPLAYSTATUS
During the Drying Cycle, the display will indicate the type of cycle in progress by presenting either one (1) of the
following:
1. “AUTO DRYING CYCLE” - Manually Loaded Auto Cycle.
2. “AUTO DRYING CYCLE #” - The “#” is replaced with “A-F” or “0-40.”
3. “MANUAL DRYING CYCLE” - Manually Loaded Manual Cycle.
4. “MANUAL DRYING CYCLE #” - The “#” is replaced with “A-F” or “0-40.”

9
F. CYCLE IN PROGRESS TEMPERATURE DISPLAY
While the dryer cycle is in progress, the temperature in the basket (tumbler) can be displayed by pressing and
holding the “UP ARROW” key. The temperature will be displayed in either Fahrenheit (ºF) or Celsius (ºC),
depending on what the system temperature has been set for in “DRYER SETUP.”
G. TEMPERATURE CONVERSION STATUS
Temperature related programs are programmable to be operated in either Fahrenheit (ºF) or Celsius (ºC). The
temperature selection is made in “SYSTEM TEMP.” Programs affected are:
1. Temperature Display Mode
2. Drying Temperatures
3. Cool Down Temperatures
IMPORTANT: When changing the temperature conversion status from Fahrenheit to Celsius or vice
versa, ALL the Temperature Selections and Cool Down Temperatures willbe
changed accordingly. The Phase 7 OPL microprocessor controller (computer)
automatically calculates and converts the temperatures in these programs to the
previously set value. For example, when changing from ºF to ºC, if the
preprogrammed Cycle “A” drying temperature was set for 160º F, the Phase 7 OPL
microprocessor controller (computer) will change to 71º C (+/- [1] one-degree
Celsius).
H. WRINKLE GUARD PROGRAM
This program keeps items wrinkle-free when they are not removed from the dryer promptly at the end of the
drying cycle and/or cooling cycle.
When the drying and cooling cycles are completed, the dryer will shut off, the tone will sound, and the light
emitting diode (L.E.D.) display will read “WRINKLE GUARD.” If the dooris not opened or the cycle stopped,
the Phase 7 OPL microprocessor controller (computer) will wait until the Wrinkle Guard Delay Time of 2
minutes has expired, at which time the fan will start and the basket (tumbler) will rotate (without heat) for the
Wrinkle Guard On Time of 2 minutes. The Phase 7 OPL microprocessor controller (computer) will repeat this
process until the Maximum Wrinkle Guard Time of 99 minutes has expired or until the door is opened, or cycle
stopped, whichever comes first. Prior to each ON time, there is a 3-beep warning that the fan and basket
(tumbler) rotation are about to start. The beeps at the end of the Wrinkle Guard Cycle can be programmed to be
ON/OFF. This is done in “WRINKLE GUARD SETUP.”
WRINKLE GUARD PROGRAM SELECTIONS:
1. Wrinkle Guard Audio Alert On/Off
The operator can select to turn on or off the beeps at the end of each Wrinkle Guard Cycle. The amount
of beeps are programmed in “AUDIO ALERT ON TIMES.”

10
I. AUDIO ALERTON TIMES 0 TO 10
The tone will sound at the end of the Cool Down Cycle to indicate that the cycle is complete. Programming
allows for the elimination of the tone during the Wrinkle Guard Cycle. This is done in “WRINKLE GUARD
SETUP.” Programming also allows the beeps to be set from 0 to 10 times in increments of one (1). This is done
in “DRYER SETUP.”
J. PREPROGRAMMED CYCLE PREVIEW
The parameters of the preprogrammed cycles can be displayed for verification. To view an “A-F” preset
program (parameter), simply press the “START/ENTER” l key and the desired preset program “A-F.” The
light emitting diode (L.E.D.) display will read the program parameter settings, then return to the “READY”
display mode. To view a “0-40” preset program parameter, simply press the “START/ENTER” l key and the
desired preset program number “0-40” followed by “START/ENTER” l key again. The L.E.D. display will
read the program parameter settings, then return to the “READY” display mode.
K. REVERSING OPTION
This feature helps reduce balling up or tangling of large items.
REVERSING OPTION SELECTIONS:
1. Reverse On or Reverse Off
2. This Is Set For Each Cycle
3. Basket (tumbler) Spin Time and Dwell (stop) Time
a. Fixed in the Automatic “AUTO” Mode and cannot be changed.
1) Spin Time - 2 minutes forward and 2 minutes reverse.
2) Dwell (stop) Time - 5-seconds.
b.Programmable in the Manual Mode.
1) Spin Time - Programmable from 30-seconds to 120-seconds in 1-second increments.
2) Dwell (stop) Time - Programmable from 5-seconds to 10-seconds in 1-second increments.
L. DIAGNOSTICS
The Phase 7 OPL, microprocessor controller (computer) monitors “Drying function,” which is the following:
1. Drying Functions: These include temperatures, burners, sail switches, blower, basket (tumbler), and lint
drawer.

11
M. PROGRAM LOCATIONS
This is where system parameters are programmed. These system parameters (programs) are stored in memory.
Access to this location is acquired by pressing the “STOP/CLEAR”
O
and the “UP ARROW” together. Too
exit the Programming Location, simply press the “STOP/CLEAR”
O
key. If you are several menu layers deep,
continue to press the “STOP/CLEAR”
O
key to back up the menu until you are ALL the way out of the
programming mode.
0. SELECT LANGUAGE - This menu allows the selection of five (5) different languages to operate the
dryer. The language that is selected will be used for every displayed message as well as faults and menus.
ENGLISH
FRANCAIS
ESPANOL
ITALIANO
DEUTSCH
1. SELECT SYSTEM PARAMETERS - This menu level has four (4) sections. ALL programmable parameters
other than preprogrammed cycles are done here.
0. DRYER SETUP - ALL parameters that pertain to drying are in this menu level.
0. SELECT MODEL - This allows the selection of the heat source applied to the dryer as well as if
the dryer is reversing or non-reversing.
GAS (reversing) GAS (non-reversing)
STEAM (reversing) STEAM (non-reversing)
ELECTRIC (reversing) ELECTRIC (non-reversing)
1. SYSTEM TEMP - This selection controls whether the temperature related programswill be operated
in Fahrenheit (ºF) or Celsius (ºC). The programs affected are as follows:
1) Temperature Display Mode
2) Drying Temperatures
3) Cool Down Temperatures
IMPORTANT: The Phase 7 OPL microprocessor controller (computer) automatically calculates and
converts the temperatures in these programs to the previously set value. For example,
when changing from ºF to ºC, if the preprogrammed Cycle “A” drying temperature
was set for 160º F, the Phase 7 OPL microprocessor controller (computer) will
change to 71º C (+/- one-degree Celsius).
2. ENTER LINT COUNT 1 TO 5 - This selection sets the maximum amount of cycles it will run
before being locked out (out of service). The operator will be prompted to clean the lint drawer to
continue drying.
NOTE: A minimum of 15-seconds is required to have the lint drawer opened in order to return to the
“READY” state once it is closed.

12
3. ENTER AUDIO ALERT ON TIMES 0 TO 10 - This selection allows the operator to adjust the
amount of signal tones. This parameter (program) affects the tone at the end of the Cool Down
Cycle, as well as, at the end of the Wrinkle Guard On Time.
4. ROTATIONAL SENSOR (Optional) - This selection is used to turn the optional rotational sensor
on or off.
1. REVERSING SETUP - The parameters that pertain to the reversing mode are in this menu level.
0. ENTER SPIN TIME 30 TO 120-SECONDS - This parameter (program) is fixed at 2 minutes in the
forward direction and 2 minutes in the reverse direction for the Automatic Mode. In the Manual Mode,
it is programmable. This Spin Time is programmed here for the Manually Loaded Manual Cycle only.
1. ENTER STOP TIME 5 TO 10-SECONDS - This parameter (program) is fixed at 5-seconds in the
Automatic Mode and programmable in the Manual Mode. This Dwell (stop) Time is programmed here
for the Manually Loaded Manual Cycle only.
2. WRINKLE GUARD SETUP - The parameters that pertain to the Wrinkle Guard is in this menu level.
0. WRINKLE GUARD AUDIO ALERT - This parameter (program) allows the operator to turn the
Audio Alert tone on or off at the end of each Wrinkle Guard Cycle. The amount is the same that is
selected in “DRYER SETUP” for AUDIO ALERT ON TIMES 0 TO 10.
AUDIO ALERT ON
AUDIO ALERT OFF
3. STEAM INJECTION (Optional) - This parameter is used to inject steam into the basket (tumbler) up
to 5 times into the basket (tumbler). 0-5 on time is first entered MM:SS (minutes:seconds) and then the
off time is entered MM:SS (minutes: seconds).
2. PROGRAM “A-F” CYCLE - This menu allows the programming of cycle “A-F.” The parameters selected
in this menu for each letter will be stored in memory for that key. This will allow the operator to utilize one
(1) touch drying through keys “A-F.”
3. PROGRAM “0-40” CYCLE - This menu allows the programming of cycle “0-40.” The parameters
selected in this menu for each numberwill be stored in memory for that number key(s). This will allow the
operator to utilize preprogrammed drying cycles stored in memory under a numerical location.
NOTE: BOTH THE “A-F” and “0-40” ALLOWS FOR A TOTAL OF 47 PREPROGRAMMED
LOCATIONS FOR CUSTOM DRYING.
4. DEFAULT SETTINGS - This menu allows the operator to set ALL the programmable parameters to the
default settings. This option has a password selection of 1 2 3. It will then ask to confirm settings. It will
default to “NO.” Use the arrow keys to select “YES.”
CAUTION: Once the settings have been set to their default settings, there is no way to
retrieve the old settings. Use caution when using this feature.
5. SENSOR ACTIVATED FIRE EXTINGUISHING (S.A.F.E.) VALVE TEST - This is used to test the
S.A.F.E. system to verify valve is operating correctly. Press and hold start button to open valve.

13
SECTION IV
OPERATING INSTRUCTIONS
The Phase 7 OPL microprocessor controller (computer) allows the operator to choose from six (6) preprogrammed
cycles (keys “A-F”). These have been preprogrammed by the factory with the parameters (programs) shown
in Section VII. There are an additional (“0-40”) preprogrammable cycles that are preprogrammed by the
factory with the parameters (programs) shown in Section VII. For occasional or onetime special loads, the
Manually Loaded Cycles can be used where the operator must set the specific program(s) needed.
NOTE: Refer to Section III of this manual for a complete explanation of the various cycles/selections
available.
After the load is put into the basket (tumbler) and the dryer is ready to dry, determine which cycle will best suit
the application (type of load). We recommend using the Automatic Drying Cycle (Patent No. 4,827,627) for
most loads. This cycle provides for the best drying in the shortest time, ALL automatically.
A. OPERATING SEQUENCE
1. Preprogrammed Cycles
a. Automatic Drying Cycle (Patent No. 4,827,627)
1) Light emitting diode (L.E.D.) display reads “READY” (no cycle in progress).
2) Press the letter on the keyboard (touch pad) corresponding to the cycle desired (i.e., key “A”).
NOTE: “0-40” will require the “START/ENTER” key to be pressed after the number is selected in
order to accept the selection and start drying.
3) The dryer will then start. (I.E., Blower, basket [tumbler], and heat).
4) L.E.D. display reads AUTO DRYING CYCLE “A,” ELAPSED TIME __ MIN 00:00. During the
drying cycle, the Phase 7 OPL microprocessor controller (computer) will monitor the amount of
moisture in the load. Once the temperature is above 160º F (71º C), the Cycle Status portion of the
L.E.D. will change from ELAPSED TIME __ MIN to __ % DRY. The display will count upward
until the percentage of extraction programmed is reached.
NOTE: Press and hold the “UP ARROW” to view the basket (tumbler) temperature at any time.
NOTE: The dryer can be stopped at any time by pressing the “STOP/CLEAR”
O
key, at this time the
dryer will go into a cycle pause. If the “STOP/CLEAR”
O
key is pressed again at this point,
the cycle that was in progress will be cancelled and returned to the “READY” state.

14
5) Once the preprogrammed percentage of extraction (dryness level) is reached, the drying cycle will
end and the Cool Down Cycle will begin.
6) Once the Cool Down Cycle begins at the end of the heat cycle, the light emitting diode (L.E.D.)
display will read COOL DOWN TEMP ___/___ MINUTES REMAINING. At the end of the
heat cycle, the dryer will shut off the heat and continue the fan and basket (tumbler) until the Cool
Down Time or temperature is reached.
7) Once the Cool Down Cycle is completed the Phase 7 OPL microprocessor controller (computer)
will proceed into the Wrinkle Guard Cycle. The Audio Alert tone will sound (for amount set in
Audio Alert On Time). The L.E.D. display will read “WRINKLE GUARD.” The times are fixed
at 2 minutes OFF, 2 minutes ON for a maximum time of 99 minutes. These times are not
programmable. During the ON time, the blower (fan) and the basket (tumbler) will start to rotate
(without heat for 2 minutes). The Phase 7 OPL microprocessor controller (computer) will repeat
this process until the Maximum Wrinkle Guard On Time has expired (99 minutes). The L.E.D.
display will then read “CYCLE DONE” and lockout the dryer functions until the doors are opened.
It will then return to “READY.”
b. Timed (Manual) Drying Cycle
1) L.E.D. display reads “READY” (no cycle in progress).
2) Press the letter on the keyboard (touch pad) corresponding to the cycle desired (i.e., key “D”).
NOTE: “0-40” WILL REQUIRE THE “START/ENTER” l KEY TO BE PRESSED AFTER THE
NUMBER IS SELECTED IN ORDER TO ACCEPT THE SELECTION and START
DRYING.
3) The dryer will then start. (I.E., blower, basket [tumbler], and heat).
4) The L.E.D. display will read MANUAL DRYING CYCLE D, 00:00 MIN REMAIN.
NOTE: Press and hold the “UP ARROW” to view the basket (tumbler) temperature at any time.
NOTE: The dryer can be stopped at any time by pressing the “STOP/CLEAR”
O
key, at this time the
dryer will go into a cycle pause. If the “STOP/CLEAR”
O
key is pressed again at this point,
the cycle that was in progress will be cancelled and returned to the “READY” state.
NOTE: Press and hold the “DOWN ARROW” to view the basket (tumbler) RPM.
5) When the programmed drying time has expired, the Phase 7 OPL microprocessor controller
(computer) will proceed into the Cool Down Cycle.
6) Once the Cool Down Cycle begins at the end of the heat cycle, the L.E.D. display will read COOL
DOWN TEMP ___/___ MINUTES REMAINING. At the end of the heat cycle, the dryer will
shut off the heat and continue the fan and basket (tumbler) until the Cool Down Time or temperature
is reached.

15
7) Once the Cool Down Cycle is completed the Phase 7 OPL microprocessor controller (computer)
will proceed into the Wrinkle Guard Cycle. The Audio Alert tone will sound (for amount set in
Audio Alert On Time). The light emitting diode (L.E.D.) display will read “WRINKLE GUARD.”
The times are fixed at 2 minutes OFF, 2 minutes ON for a maximum time of 99 minutes. These
times are not programmable. During the ON time, the blower (fan) and the basket (tumbler) will
start to rotate (without heat for 2 minutes). The Phase 7 OPL microprocessor controller (computer)
will repeat this process until the Maximum Wrinkle Guard On Time has expired (99 minutes). The
L.E.D. display will then read “CYCLE DONE” and lockout the dryer functions until the doors are
opened. It will then return to “READY.”
2. Manually Loaded Cycles
a. Automatic Drying Cycle (Patent No. 4,827,627)
1) L.E.D. display reads “READY” (no cycle in progress).
2) Press AUTO key.
3) L.E.D. display will now read ENTER DRY TEMP 160 TO 200. (Defaults to 160° F [71° C]).
Enter the temperature desired (from 160º F to 200º F [71º C to 93º C] in one-degree increments).
I.E., for 180º F (82º C), press key “1,” key “8,” key “0,” and then press the “START/ENTER” l
key to accept the value.
4) L.E.D. display will now read ENTER DRY LEVEL finishing, dry, and extra dry. Enter the amount
of extraction (dryness level desired). Finishing has the most moisture content to extra dry, which
has little or no moisture content.
5) L.E.D. display will now read “REVERSE MODE” (defaults to ON). The ON/OFF selection can
be toggled with the “UP ARROW” and “DOWN ARROW.” Once selected, press the “START/
ENTER” l key to accept selection.
NOTE: In addition to entering a value by pressing the number keys, the “UP ARROW” and “DOWN
ARROW” can be used to scroll to the number desired or toggle between selections.
6) The dryer will now display “PRESS START.” Press the “START/ENTER” l key to start the
dryer. The L.E.D. display will read AUTO DRYING CYCLE, ELAPSED TIME __ MIN. During
the Drying Cycle, the Phase 7 OPL microprocessor controller (computer) is monitoring the moisture
in the load. Once the temperature is above 160º F (71º C), the Cycle Status portion of the L.E.D.
will change from ELAPSED TIME __ MIN to DRYNESS LEVEL__. The display will count
upward until the percentage of extraction programmed is reached.
NOTE: Press and hold the “UP ARROW” to view the basket (tumbler) temperature at any time.
NOTE: The dryer can be stopped at any time by pressing the “STOP/CLEAR”
O
key, at this time the
dryer will go into a cycle pause. If the “STOP/CLEAR”
O
key is pressed again at this point,
the cycle that was in progress will be cancelled and returned to the “READY” state.

16
NOTE: Press and hold the “DOWN ARROW” to view the basket (tumbler) RPM.
7) Once the preprogrammed percentage of extraction (dryness level) is reached, the drying cycle will
end, and the Cool Down Cycle will begin.
8) Once the Cool Down Cycle begins at the end of the heat cycle, the light emitting diode (L.E.D.)
display will read COOL DOWN TEMP ___/___MINUTES REMAINING. At the end of the heat
cycle, the dryer will shut off the heat and continue the fan and basket (tumbler) until the Cool Down
Time or temperature is reached.
9) Once the Cool Down Cycle is completed, the Phase 7 OPL microprocessor controller (computer)
will proceed into the Wrinkle Guard Cycle. The Audio Alert tone will sound (for amount set in
Audio Alert On Time). The L.E.D. display will read “WRINKLE GUARD.” The times are fixed
at 2 minutes OFF, 2 minutes ON for a maximum time of 99 minutes. These times are not
programmable. During the ON time, the blower (fan) and the basket (tumbler) will start to rotate
(without heat for 2 minutes). The Phase 7 OPL microprocessor controller (computer) will repeat
this process until the Maximum Wrinkle Guard On Time has expired (99 minutes). The L.E.D.
display will then read “CYCLE DONE” and lockout the dryer functions until the doors are opened.
It will then return to “READY.”
NOTE: Mechanical functions of the dryer are not allowed during the ON time. The blower (fan)
must be OFF to perform mechanical functions. However the “STOP/CLEAR”
O
key may
be pressed at any time to end the Wrinkle Guard Cycle. Mechanical functions of the dryer are
allowed during the OFF time.
b. Timed (Manual) Drying Cycle
1) L.E.D. display reads “READY” (no cycle in progress).
2) Press MAN key.
3) L.E.D. display will now read “ENTER DRY TIME 0 TO 99 MINUTES” (defaults to 0). I.E., for
40 minutes, press key “4,” key “0,” and then press the “START/ENTER” l key to accept the
value.
4) L.E.D. display will now read “ENTER DRY TEMP __ TO __” (defaults to 100° F [38° C]). Enter
the temperature desired (from 100º F to 200º F [38º C to 93º C] in one-degree increments). I.E., for
182º F (83º C), press key “1,” key “8,” key “2,” and then press the “START/ENTER” l key to
accept the value.
5) L.E.D. display will now read “ENTER COOL DOWN TIME 0 TO 99 MINUTES.” I.E., for 10
minutes, press key “1,” key “0,” and then press the “START/ENTER” l key to accept the value.
6) L.E.D. display will now read “REVERSE MODE” (defaults to ON). The ON/OFF selection can
be toggled with the “UP ARROW” and “DOWN ARROW.” Once selected, press the “START/
ENTER” l key to accept selection.
7) The dryer will now display “PRESS START.” Press the “START/ENTER” l key to start the
dryer. The L.E.D. display will read MANUAL DRYING CYCLE, __MINUTES REMAIN.
