Maytag MGR5775QDB - 30" Gas Range User manual

COOKTOP PARTS
1
For Models: MGR5775QDW1, MGR5775QDQ1, MGR5775QDB1, MGR5775QDS1
(White) (Bisque) (Black) (Stainless Steel)
30" GAS FREESTANDING
SELF CLEAN RANGE
SEALED BURNER
CONVECTION
12−09 Litho In U.S.A. (ll) (psw) Part No. W10282172 Rev C
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
8101P571−60 Installation
Instructions
8113P735−60 Owners Manual
8119P328−60 Wiring Diagram
9762761 Tips, Safe Cooking
2 Cap, Burner
(RF)
7504P137−60 Black
7504P140−60 Gray
7504P143−60 Taupe
Center
7504P136−60 Black
7504P139−60 Gray
7504P142−60 Taupe
(RR & LR)
7504P138−60 Black
7504P141−60 Gray
7504P144−60 Taupe
(LF)
7504P219−60 Black
7504P205−60 Grey
7504P206−60 Taupe
3
8010P149−60 Spacer, Snap−In
4 Burner
8286183 (RF)
8286181 Center
7540P043−60 (RR & LR)
8286182 (LF)
5 Cooktop
2001F287−09 Black
2001F287−81 White
2001F287−88 Bisque
6 Panel, Manifold
2616N381−09 Black
2616N381−81 White
2616N381−88 Bisque
2616N382−50 Stainless
7 Knob, Control (4)
7733P416−60 Black
7733P417−60 White
7733P418−60 Bisque
8 Grate, Burner (2)
7518P187−60 Black
7518P189−60 Grey
7518P188−60 Taupe
9
7101P685−60 Screw (8)
10
7101P388−60 Screw

CONTROL PANEL PARTS
2
For Models: MGR5775QDW1, MGR5775QDQ1, MGR5775QDB1, MGR5775QDS1
(White) (Bisque) (Black) (Stainless Steel)
W10282172
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Endcap, Left Hand
3807F703−70 Black
3807F703−71 White
3807F703−78 Bisque
Endcap, Right Hand
3807F702−70 Black
3807F702−71 White
3807F702−78 Bisque
2 Heat Shield,Visor
3604F382−09 Black
3604F382−81 White
3604F382−88 Bisque
3 Panel, Control
5701M721−60 Black
5701M710−60 White
5701M709−60 Bisque
4
7431P053−60 Module, Spark
5
4005F803−51 Cover, Upper
6
3604F381−19 Shield, Vent
7 Control
(Includes Overlay)
74009227 Black
74009152 White
74009151 Bisque
8
7403P757−60 Switch, Rocker
9
3801F844−51 Bracket, Control
10 3196178 Screw
11
4005F748−51 Cover, Main Wire
12
3604P372−51 Extension, Shield

CHASSIS PARTS
3
For Models: MGR5775QDW1, MGR5775QDQ1, MGR5775QDB1, MGR5775QDS1
(White) (Bisque) (Black) (Stainless Steel)
W10282172

CHASSIS PARTS
4
For Models: MGR5775QDW1, MGR5775QDQ1, MGR5775QDB1, MGR5775QDS1
(White) (Bisque) (Black) (Stainless Steel)
W10282172
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8026P080−60 Vent, Oven
2
8010P148−60 Spacer, Side Panel
3
3807P680−45 Support, Oven
Bottom
4 Panel, Side (2)
2618F172−69 Black
2618F172−58 White
2618F172−57 Bisque
5
3604P409−51 Shield, Heat
6 3196178 Screw
7
3801F656−51 Bracket, Anti−Tip
8 Frame, Front
(Not Serviced)
9
7106P125−60 Hinge, Receiver
10
7101P507−60 Foot, Leveler (4)
11
2205F053−19 Bottom, Oven
12
7430P041−60 Sensor, Oven
13
3601P356−45 Baffle, Burner
14 3196178 Screw
15
3605P146−51 Plate, Conduit
16
4005P704−51 Panel, Access
17 3196160 Screw (2)
18
4005F753−45 Cover, Broil
19
4005P703−51 Cover, Lower Wire
20
4002F347−51 Back, Main
21
W10162385 Seal, Oven
22
7101P336−60 Screw
24
7112P158−60 Clip (4)
26
3801P798−51 Bracket, Oven
Bottom
27
3401F082−45 Pan, Bake
28
7407P181−60 Light Assembly
29
7407P103−60 Bulb, Oven Light
30
8002P104−60 Latch, Door Lock
31
3804F316−51 Retainer,
Insulation
33
7101P500−60 Screw (2)
34
3801P822−45 Bracket, Oven
35 3196560 Screw
36
7002P494−60 Insulation
37
7101P388−60 Screw
38
7101P282−60 Screw (4)
43
7101P618−60 Screw
44
7101P385−60 Screw
INSULATION
7002P424−60 Insulation, Wrap
7002P492−60 Insulation, Back
4820F015−59 Strap, Insulation

MANIFOLD PARTS
5
For Models: MGR5775QDW1, MGR5775QDQ1, MGR5775QDB1, MGR5775QDS1
(White) (Bisque) (Black) (Stainless Steel)
W10282172

MANIFOLD PARTS
6
For Models: MGR5775QDW1, MGR5775QDQ1, MGR5775QDB1, MGR5775QDS1
(White) (Bisque) (Black) (Stainless Steel)
W10282172
Illus. Part
No. No. DESCRIPTION
1 7101P681−60 Screw, Valve
2 Holder, Orifice
7527P095−60 (RF)
7527P124−60 (RR)
7527P125−60 (LR)
7527P101−60 (LF)
7527P097−60 Center
3
8010P149−60 Spacer, Snap−In
4
7506P361−60 Tubing,
Main Supply
5 Harness, Igniter
Includes Switches
6 82000311 Ignitor, Top
Burner (5)
7
7513P524−60 Pipe, Manifold
8 Valve
7502P501−60 (RF)
7502P500−60 (LR/LF/RR)
7502P499−60 Center
9
7103P030−60 Nut
10
W10160904 Burner, Broiler
11
7505P331−60 Burner, Bake
12
7501P233−60 Valve/Regulator
13 Igniter
7432P106−60 Broil
7432P136−60 Bake
14
7506P368−60 Tubing (Broiler
Fitting To Valve)
15
7507P357−60 Fitting, Broiler
16
4005F421−45 Cover, Igniter
17 Orifice, Burner
7509P123−60 Left Front
7509P124−60 Right Front
7509P122−60 (LR/RR)
7509P120−60 Center
18 3196178 Screw
19 3196385 Screw
20
7101P027−60 Screw
21
7507P366−60 Orifice
22
3601P336−45 Baffle,
Broil Burner
23 3196154 Screw
Following Parts Not Illustrated
7509P115−60 Spuds, LP Gas
(Kit of 5)
7403P983−60

DOOR PARTS
7
For Models: MGR5775QDW1, MGR5775QDQ1, MGR5775QDB1, MGR5775QDS1
(White) (Bisque) (Black) (Stainless Steel)
W10282172

DOOR PARTS
8
For Models: MGR5775QDW1, MGR5775QDQ1, MGR5775QDB1, MGR5775QDS1
(White) (Bisque) (Black) (Stainless Steel)
W10282172
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Trim, Top
3608F140−70 Black
3608F140−71 White
3608F140−78 Bisque
2 Screw
3196557 Black
3196166 White
8281194 Bisque
3 Handle, Door
7701P516−60 Black
7701P517−60 White
7701P518−60 Bisque
4
2402W297−19 Liner, Door
5
7902P436−60 Glass, Inner (2)
6 74004224 Tape (White)
7
7101P388−60 Screw
8
7002P246−60 Insulation, Door
9
3601F380−51 Retainer,
Insulation
10
7106P124−60 Hinge, Door
11 Glass, Outer Door
7902P791−60 Black
7902P781−60 White
7902P782−60 Bisque
7902P803−60 Stainless
12 Trim, Door Side
3608F126−70 Black
3608F126−71 White
3608F126−78 Bisque
13
7101P633−60 Screw
14 Trim, Lower Door
3608F092−70 Black
3608F092−71 White
3608F092−78 Bisque
16
7101P427−60 Screw
17
7101P282−60 Screw
18 Bracket, Handle
3801P857−45 Right
3801P858−45 Left
19
7002P484−60 Insulation, Corner
20
W10208311 Tape, Foil (3")
21
3801F886−51 Bracket, Window(2)
22
7103P190−60 Nut

DRAWER AND RACK PARTS
9
For Models: MGR5775QDW1, MGR5775QDQ1, MGR5775QDB1, MGR5775QDS1
(White) (Bisque) (Black) (Stainless Steel)
W10282172
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 W10179196 Rack, Oven
3 74009268 Screw
4
3405F037−80 Drawer
5
7701P547−60 Handle, SS Model
6
7101P388−60 Screw
7 Panel, Drawer Frnt
2416F104−70 Black
2416F104−71 White
2416F104−78 Bisque
7760P228−60 Stainless
8
3605P337−51 Panel, Inner
9
8038P037−60 Drawer, Stop
10
7101P072−60 Screw
11
3406P034−51 Rail, Drawer
12
7118P032−60 Shaft, Storage
Drawer Roller
13
W10272883 Roller, Drawer
14
7103P082−60 Nut
15
7801P139−60 Rack, Half
16
W10275560 Insert, Half Rack

OPTIONAL PARTS (NOT INCLUDED)
10
For Models: MGR5775QDW1, MGR5775QDQ1, MGR5775QDB1, MGR5775QDS1
(White) (Bisque) (Black) (Stainless Steel)
W10282172
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
Following Parts Not Illustrated
REFINISHING MATERIAL
799832 Kit, Porcelain
Repair (White)
242756 Touch−Up
Self−Clean(1/2 Pt)
INSULATION
261514 Insulation,
Fiberglass (1−1/2"
x 24" x 120")
240132 Insulation,
Fiberglass (2−1/2"
x 22" x 120")
PAINT, TOUCH−UP (1/2oz.)
72017 White
4392899 Biscuit
72032 Black
511873 White Porcelain
(2 Oz.)
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
4392901 Biscuit
350939 Black
285006 Superior Black
206922 Primer (White)
PAINT, BULK (1 qt.)
799344 White (Uncut)
4392900 Biscuit (Uncut)
799340 Black (Uncut)
ACCESSORY PARTS
241430 Foil, Aluminum
5789A598−60 Kit, LP Convert
Oven (18" x 25’)
WIRING HARNESS PARTS
5171P727−60 Harness, Gas
8019P026−60 Clip, Harness
7101P027−60 Screw, Ground
8019P013−60 Clip, Wire
7111P009−60 Clamp, Harness
