CABINET PARTS
1
For Models: MBF1956KEB11, MBF1956KEQ11, MBF1956KEW11
(Black) (Bisque) (White)
2−08 Litho In U.S.A. (pl) Part No. W10188311 Rev.A
REFRIGERATOR

CABINET PARTS
2
For Models: MBF1956KEB11, MBF1956KEQ11, MBF1956KEW11
(Black) (Bisque) (White)
W10188311
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10137641 Use & Care Guide
67007103 Energy Guide
W10165418 Tech Sheet
2 Cabinet (Not a
Servicable Part)
3 Plug, Button (3)
M0310729 White
M0310731 Black
M0310738 Bisque
4 B5759649 Gasket
5 67006118 Roller AssY. (2)
6 67003868 Foot, Brake
7 67006642 Pin, Center Hinge
8 67006611 Bolt, Adjusting
(Front Roller)
9 67006521 Screw
10 Cover, Hinge
67001014 White
67001012 Black
67001013 Bisque
11 67005822 Screw
12 67006473 Screw
13 67003331 Cover, Water Line
14 67006303 Screw (3)
15 Hinge, Center
67006960 White
67007043 Black
16
12566604ED Hinge, Top
17 Cover, Corner
67003484 White
67003485 Black
67003486 Bisque
18 67001067 Clip, Drain
19 67007174 Bracket, Foot (2)
20 67006564 Screw (4)
21 67006101 Cover, Unit
22 Grille, Toe
67006905 White
67006886 Black
67006904 Bisque
23 M0114003 Clip, Speed
24 67001066 Tube, Drain
25 67006425 Screw
26 67003796 Fiber, Acoustic
27 67001173 Cover, Water Valve
28 M0108105 Clamp, Tube
29
W10137519 Elbow, Fill Tube
30 67006287 Screw

FREEZER LINER PARTS
3
For Models: MBF1956KEB11, MBF1956KEQ11, MBF1956KEW11
(Black) (Bisque) (White)
W10188311

FREEZER LINER PARTS
4
For Models: MBF1956KEB11, MBF1956KEQ11, MBF1956KEW11
(Black) (Bisque) (White)
W10188311
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 67001291 Gasket, Foam
3 67005874 Guide, Fill Tube
4 67003905 Cover, Light
5 67003636 Motor, Evaporator
6
Y12570701 Socket, Light
7 12002355 Thermistor
8 67003924 Cover, Thermistor
9 A0282812 Bulb, Light
10 67001035 Housing, Light
11 67005871 Cover, Evaporator
12 67006425 Screw
13
W10121318 Grommet
14 67003906 Module, Light
15
W10167028 Clip, Evap. Motor
16 67005653 Switch, Light
17 67006530 Screw
18 D7753903 Funnel, Drain
19 M0500703 Seal
20 67002286 Gasket, Bottom
21 B8381501 Gasket
22
W10175909 Grille, Fz Air
23
W10167023 Shroud, Evap.Fan
24 2169142 Blade, Fan
(Evaporator)
25 Bracket, Door
W10122147 Left
W10122148 Right
26 67006473 Screw (8)
27 Cradle, Basket
67004014 Left
67004015 Right
28
W10120018 Slide, Drawer (2)
29 Adapter, Slide
W10128118 Left
W10128119 Right
30 67006406 Screw (6)
31 67004067 Shaft
32 12002497 Gear (Left)
(Includes Item 33)
33 12002497 Gear (Right)
(Includes Item 32)
Following Parts Not Illustrated
67006095 Harness, Lights
(Freezer)

FREEZER DOOR PARTS
5
For Models: MBF1956KEB11, MBF1956KEQ11, MBF1956KEW11
(Black) (Bisque) (White)
W10188311
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Door, Freezer
W10192430 White
W10190236 Black
W10192431 Bisque
2 Handle, Door
W10119651 White
W10119653 Black
W10119652 Bisque
3 Gasket, Door
W10130150 White
12683816B Black
4 12992902 Screw, Handle
5 Plug, Button (2)
10712401 White
67004838 Black

REFRIGERATOR LINER PARTS
6
For Models: MBF1956KEB11, MBF1956KEQ11, MBF1956KEW11
(Black) (Bisque) (White)
W10188311
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2
Y67003896 Module, Light
3 67004058 Overlay
4 67003898 Module, Control
5
W10165748 Board, Control
(Incl Instr Sheet)
6 C3680310 Switch, Light
7 67003897 Cover, Light
8 67003901 Housing, Light
9 A0282812 Bulb, Light (2)
10
Y12570701 Socket, Light (2)
11 67003900 Insert,
Damper Cover
12 67006602 Screw
13 67003899 Cover, Damper
14 67006604 Insulation
15
W10127429 Control, Damper
(Includes Harness)
16 12002355 Thermistor
17 M0310343 Plug Button
White
Following Parts Not Illustrated
67004033 Harness, Controls
(Refrigerator)

REFRIGERATOR DOOR PARTS
7
For Models: MBF1956KEB11, MBF1956KEQ11, MBF1956KEW11
(Black) (Bisque) (White)
W10188311

REFRIGERATOR DOOR PARTS
8
For Models: MBF1956KEB11, MBF1956KEQ11, MBF1956KEW11
(Black) (Bisque) (White)
W10188311
Illus. Part
No. No. DESCRIPTION
1 Door, Refrigerator
67004039 White
67004036 Black
67004037 Bisque
2 Screw (4)
67006668 White
67006806 Black
67004707 Bisque
3 67003637 Door, Dairy
4 67001279 Tray, Dairy
5 Bucket, Door
67004041 Small (2)
67004040 Medium (2)
6 Screw (4)
12991103 White
67007166 Black
12991104 Bisque
7 Plug, Button (2)
10712401 White
67004838 Black
8 Gasket, Door
W10130148 White
12683815B Black
9 Handle, Door
67006119 White
67006120 Black
67006887 Bisque
10 67006287 Screw
11 Stop, Door
67003779 White
67003780 Black
67003781 Bisque
12 67006439 Nameplate
13 67002505 Retainer, Ref Door
14 Bushing (4)
67004977 White
67004978 Black
15 Closure, Door
67003638 White
67003639 Black
16 67215−2 Tray, Egg

UNIT PARTS
9
For Models: MBF1956KEB11, MBF1956KEQ11, MBF1956KEW11
(Black) (Bisque) (White)
W10188311

UNIT PARTS
10
For Models: MBF1956KEB11, MBF1956KEQ11, MBF1956KEW11
(Black) (Bisque) (White)
W10188311
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 67006433 Screw
2
W10162928 Blade, Fan
3 67006914 Basepan
4 67006425 Screw
5 67005491 Block, Condenser
6
W10174591 Tube, Discharge
7
W10119856 Harness, Evap.
Heater
8 67004713 Pan, Drain
9 61004743 Grommet (3)
10 67002135 Heater, Defrost
11
W10131991 Clip, Capacitor
12
W10174592 Start Device
13 61003210 Gasket
14
W10165425 Thermostat,
Defrost
15 67005680 Grommet (2)
16 67006573 Screw
17
W10169124 Grommet (4)
18 67006133 Condenser
19 67006432 Screw
20 67001133 Tray, Drip
21 67006737 Screw
22 12002051 Evaporator Kit
(Incl. Evap., Heat
Shield, & Instr.
Sheet)
23 Dam
67001084 Right Side
67001083 Left Side
24 67004432 Motor, Fan
25 10428101 Clip, Heater
26 13060301 Harness, Unit
with Power Cord
27 2317845 Drier
28
W10130129 Compressor
(Includes items
11,12,17,27,29)
29 67005562 Capacitor
30 67006434 Axle, Roller (2)
31
W10158508 Shroud
32 67004953 Bracket, Fan Motor
33 67004954 Screw
34 10547003 Clip, Drier
35 67005149 Roller (2)
36
W10137529 Grommet, Cond. (4)
37 10623002 Clip, Evaporator
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.0 Ozs.
(R−134A)

SHELF PARTS
11
For Models: MBF1956KEB11, MBF1956KEQ11, MBF1956KEW11
(Black) (Bisque) (White)
W10188311

SHELF PARTS
12
For Models: MBF1956KEB11, MBF1956KEQ11, MBF1956KEW11
(Black) (Bisque) (White)
W10188311
Illus. Part
No. No. DESCRIPTION
1 67001057 Rail, Center
Crisper
2 67003879 Trim, Crisper
3 67006608 Screw
4 67004985 Basket, Freezer
(Upper)
5 67006023 Basket, Freezer
(Lower)
6 67004062 Shelf (4)
7 67006360 Screw
8 67005864 Slide, Humidity
Control
9 67004127 Divider, Basket
(Upper)
10 67006644 Divider, Basket
(Lower)
11 67006400 Screw
12 67001308 Pan, Deli
13 67001054 Glide, Left
14 67001053 Glide, Right
15 67006626 Screw, Glide (4)
16 67002569 Pan, Crisper
17 67001155 Brace, Crisper
18 67001153 Frame, Crisper
19 67006877 Glass, Crisper Cover
20 67001073 Ladder, Center
21 67001302 Ladder, Side
22 10448903 Rack, Bottle
23 12603701 Support, Crisper
Frame

ICEMAKER PARTS
13
For Models: MBF1956KEB11, MBF1956KEQ11, MBF1956KEW11
(Black) (Bisque) (White)
W10188311

ICEMAKER PARTS
14
For Models: MBF1956KEB11, MBF1956KEQ11, MBF1956KEW11
(Black) (Bisque) (White)
W10188311
Illus. Part
No. No. DESCRIPTION
1 2256086 Bracket, Ice Maker
2 67003729 Tube, Plastic
3 67003932 Clamp
4 489276 Screw
5 67003753 Valve−Inlet
6 67004028 Arm−Shut Off
7 67004710 Cover, Front
8 A3223101 Inert, Tube
9
W10122527 Mold & Heater
Assembly (Also
Order 542638)
10 628515 Cup Water fill
11 627843 Ejector
12 2182124 Ice Stripper
13 2194712 Support
14 2315522 Retainer
15 627985 Thermostat
Order 542369
Cement
Alumilastic)
16 8533917 Screw
17 489464 Screw
18
W10146389 Harness, Ice Maker
19 M0114003 Clip, Speed
20 626678 Module Assembly
(Includes Items
21& 22)
21 626684 Motor
22 489136 Screw
23
W10137519 Elbow, Fill Tube
24 67005603 Funnel, Fill Tube
25 67001255 Pan Ice
100
W10122519 Complete Ice Maker

OPTIONAL PARTS
15
For Models: MBF1956KEB11, MBF1956KEQ11, MBF1956KEW11
(Black) (Bisque) (White)
W10188311
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
72032 Black
4392901 Biscuit
PAINT, PRESSURIZED SPRAY
(12 oz.)
350942 Primer, White
350930 White
350939 Black
4392901 Biscuit
Important: The spray paint is
not to be used where the paint
may make contact with the door
gaskets.
PAINT, BULK (1 qt.)
799344 White (Uncut)
799344 Black (Uncut)
4392900 Biscuit (Uncut)
Miscellaneous
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4 x 108")
505587 Sealer, Mastic
(1 Qt.)
503695 Cork, Sealer
(1/4 Pound)
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
799833 Kit, Evaporator
Repair
(Aluminum Epoxy)
833938 Kit, Terminal
Connector
TORX SCREW WRENCH
1117510 Torx Key
ACCESSORIES
31462 Cleaner, 10 oz.
Stainless Steel
