CABINET PARTS
1
For Models: MBL1956KES3, MBR1956KES3
(Stainless−LH) (Stainless−RH)
5−09 Litho In U.S.A. (rrm) (psw) Part No. W10268088 Rev.A
REFRIGERATOR

CABINET PARTS
2
For Models: MBL1956KES3, MBR1956KES3
(Stainless−LH) (Stainless−RH)
W10268088
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10175446 Use & Care Guide
W10183293 Energy Guide
W10238840 Tech Sheet
2 Cabinet (Not a
Servicable Part)
3 Plug, Button (3)
M0310731 Black
4 B5759655 Gasket
5
W10208592 Guard, Water Valve
6 10354002 Foot, Brake
7 10351006 Pin, Center Hinge
8
W10216614 Sweep, Water Valve
9 12992602 Screw
10 Cover, Hinge
12477601B Black
11 12990101 Screw
12 12990521 Screw
13 12726003 Cover, Water Line
14 12992403 Screw (3)
15 Hinge, Center
12607104ED Black
16
12566604ED Hinge, Top
17 Cover, Corner
12587703B Black
19 12580304 Roller Assembly
20 12991302 Screw (4)
21
W10210978 Cover, Unit
22 Grille, Toe
W10236650 Black
23
M0114003SP Clip, Speed
24
W10210987 Tube, Drain
25 12990511 Screw
26 12820505 Fiber, Acoustic
29
10463203SP Elbow, Fill Tube
30 12990504 Screw

FREEZER LINER PARTS
3
For Models: MBL1956KES3, MBR1956KES3
(Stainless−LH) (Stainless−RH)
W10268088

FREEZER LINER PARTS
4
For Models: MBL1956KES3, MBR1956KES3
(Stainless−LH) (Stainless−RH)
W10268088
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 A3189392 Gasket, Foam (2)
3 12002497 Gear (2)
(Includes RH & LH)
4 12804901 Cover, Light
5
12812902WD Shaft
6
12570701V Socket, Light
8 12990521 Screw (8)
9
W10194422V Bulb, Light
10
12476401V Housing, Frz. Light
11 12226110 Cover, Evaporator
12 12990101 Screw (7)
13 Bracket, Door
W10122147 Left
W10122148 Right
14 12805001 Housing, Lighting
15 13058002 Clip, Evap. Motor
16 12466105 Switch, Light
18 Bracket, Basket
12812303 Left
12812304 Right
19
W10120018 Slide, Drawer (2)
20 A3189397 Gasket, Bottom
21 Adapter, Slide
W10128118 Left
W10128119 Right
22 13024803 Cover, Fan Shroud
23 13057901 Shroud, Evap.Fan
24 2169142 Fan, Evaporator
25
W10121318 Grommet (2)
26
W10128551 Motor, Evaporator
27 D7753903 Funnel, Drain
(Incl. # 28 & 29)
28 M0500703 Seal
29 B8381501 Gasket
30 12002355 Thermistor
31 12815301 Cover, Thermistor
32 12990501 Screw (6)
33
12991603V Screw
34
W10157765 Diverter, Air
Following Parts Not Illustrated
13014801 Harness, Lights
(Freezer)

FREEZER DOOR PARTS
5
For Models: MBL1956KES3, MBR1956KES3
(Stainless−LH) (Stainless−RH)
W10268088
Illus. Part
No. No. DESCRIPTION
1 Door, Freezer
13092206SQ Stainless Steel
2 Handle, Door
W10197295 Stainless
3 Gasket, Door
W10164033 Black
4 13001201 Handle−Mount−(2)
5 12991703 Screw−Flat−(2)

REFRIGERATOR LINER PARTS
6
For Models: MBL1956KES3, MBR1956KES3
(Stainless−LH) (Stainless−RH)
W10268088
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 12806301 Bracket, Control
and Lights
3 12816502 Overlay
4 12806406 Housing,
Electronic Control
5 12868513 Board, Control
6
C3680310V Switch, Light
7 12806501 Cover, Light
8
12806601V Housing, Light
9
W10194422V Bulb, Light (2)
10
12570701V Socket, Light (2)
11 12806801 Insert,
Damper Cover
12 12990604 Screw (2)
13 12806701 Cover, Damper
14 13012402 Insulation
15
W10196393 Control, Damper
16 12002355 Thermistor
17 M0310343 Plug Button
Following Parts Not Illustrated
12868701 Harness, Controls
(Refrigerator)
(Includes # 16)

REFRIGERATOR DOOR PARTS
7
For Models: MBL1956KES3, MBR1956KES3
(Stainless−LH) (Stainless−RH)
W10268088

REFRIGERATOR DOOR PARTS
8
For Models: MBL1956KES3, MBR1956KES3
(Stainless−LH) (Stainless−RH)
W10268088
Illus. Part
No. No. DESCRIPTION
1 Door, Refrigerator
13023847SQ Stainless Steel−LH
13023846SQ Stainless Steel−RH
2 Screw
13001201 Handle−Mount−(2)
3
12804701SP Door, Dairy
4
12369502SP Tray, Dairy
5
12801902V Bucket, Medium (2)
12801901V Bucket−Small (2)
8 Gasket, Door
W10164031 Black
9 Handle, Door
W10197295 Stainless
10 12990504 Screw
11 Stop, Door
10447112 Black
12
W10170766 Nameplate
13 12690501 Retainer, Ref Door
14 Bushing (4)
10961006B Black
15 Closure, Door
12028505B Black
16 12991703 Screw−Flat−(2)

UNIT PARTS
9
For Models: MBL1956KES3, MBR1956KES3
(Stainless−LH) (Stainless−RH)
W10268088

UNIT PARTS
10
For Models: MBL1956KES3, MBR1956KES3
(Stainless−LH) (Stainless−RH)
W10268088
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 12992301 Screw
2 12825803 Blade, Fan
3
W10210982 Basepan
4 12990511 Screw
6
W10217744 Tube, Discharge
7
W10224241 Harness, Evap
Heater
8
W10189185 Pan, Drain
9
W10216919 Screw, Shoulder
10 12729127 Evaporator Heater
11
W10216075 Strap, Bale
12 Start Protect,
Combo
2320150 Production
W10136414 Service
14
12639324SP Thermostat,
Defrost
15
W10206336 Extension, Basepan
17
10835903SP Grommet (4)
18
W10135028 Condenser
19
W10206339 Fastener, Basepan
Extension
20
12225401WD Tray, Drip
21 12990701 Screw
22 12726401 Evaporator
23 Dam
12225702 Right Side
12225602 Left Side
24 12825101 Motor, Fan
25 10428101 Clip, Heater
26
W10234024 Harness, Unit
27
W10143759 Drier
28
W10130129 Compressor Kit
(Contains Items
12, 17, 27, & 29)
29 2264017 Capacitor
30 12477202 Axle, Roller
31
W10189184 Shroud
34 10547003 Clip, Drier
35 12477102 Roller (2)
36 10623002 Clip, Evap (2)
37
W10137529 Grommet (4)
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.25 Ozs.
(R−134A)

SHELF PARTS
11
For Models: MBL1956KES3, MBR1956KES3
(Stainless−LH) (Stainless−RH)
W10268088

SHELF PARTS
12
For Models: MBL1956KES3, MBR1956KES3
(Stainless−LH) (Stainless−RH)
W10268088
Illus. Part
No. No. DESCRIPTION
1 12530701 Rail, Center
Crisper
2
W10231339 Trim, Crisper
3 12990601 Screw
4 12896401 Basket, Freezer
(Upper)
5
W10143560 Basket, Freezer
(Lower)
6 12463608 Shelf (4)
7 12990515 Screw
8
12530805SP Slide, Humidity
Control
9 12693802 Divider, Basket
(Upper)
10 12659608 Divider, Basket
(Lower)
11 12990513 Screw
12
12656504SP Pan, Deli
13
12656601SP Glide, Left
14
12656602SP Glide, Right
15
12990302SP Screw, Glide (4)
16 12531305 Pan, Crisper
17
12227302WD Brace, Crisper
18
12530901SP Frame, Crisper
19 12204823 Glass, Crisper Cover
20 12435807 Ladder, Center
21 12710606 Ladder, Side

ICEMAKER PARTS
13
For Models: MBL1956KES3, MBR1956KES3
(Stainless−LH) (Stainless−RH)
W10268088

ICEMAKER PARTS
14
For Models: MBL1956KES3, MBR1956KES3
(Stainless−LH) (Stainless−RH)
W10268088
Illus. Part
No. No. DESCRIPTION
1 2256086 Bracket, Ice Maker
2
B5705333SP Tube, Plastic
3 10526702 Clamp
4 489276 Screw
5
W10219716 Valve−Inlet
6 12868001 Arm−Shut Off
7 12582501 Cover, Front
8
A3223101SP Insert, Tube
9
W10122527 Mold & Heater
Assembly (Also
Order 542638)
10 628515 Cup Water fill
11 627843 Ejector
12 2182124 Ice Stripper
13 2194712 Support
14 2315522 Retainer
15 628397 Thermostat
Order 542369
Cement
Alumilastic)
16 8533917 Screw
17 489464 Screw
18 D7813011 Harness, Ice Maker
19
M0114003SP Clip, Speed
20
W10223929 Module Assembly
(Includes Items
21& 22)
21 Motor
(Not Available,
Order #20)
22 489136 Screw
23
10463203SP Elbow, Fill Tube
24 12918001 Funnel, Fill Tube
25
12695001V Pan, Ice
26 M0108107 Clamp−Tube
100
W10190978 Complete Ice Maker

OPTIONAL PARTS
15
For Models: MBL1956KES3, MBR1956KES3
(Stainless−LH) (Stainless−RH)
W10268088
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
72032 Black
4392901 Biscuit
PAINT, PRESSURIZED SPRAY
(12 oz.)
350942 Primer, White
350930 White
350939 Black
4392901 Biscuit
Important: The spray paint is
not to be used where the paint
may make contact with the door
gaskets.
PAINT, BULK (1 qt.)
799344 White (Uncut)
799344 Black (Uncut)
4392900 Biscuit (Uncut)
Miscellaneous
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4 x 108")
505587 Sealer, Mastic
(1 Qt.)
503695 Cork, Sealer
(1/4 Pound)
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
799833 Kit, Evaporator
Repair
(Aluminum Epoxy)
833938 Kit, Terminal
Connector
TORX SCREW WRENCH
1117510 Torx Key
ACCESSORIES
31462 Cleaner, 10 oz.
Stainless Steel
