Maytag MBR1956KES - Bottom Freezer Refridgerator Manual

Repair
Parts
List
MODEL NUMBER
MBR1956KES
When requesting service or ordering parts, always
provide the following information:
- Product Type - Part Number
- Model Number - Part Description
REFRIGERATOR
©2005 Maytag Services

Section: REFRIGERATOR DOOR
AA44-206
Model: MBR1956KES
1

REFRIGERATOR DOOR
No. Part No. Description
Section:
Series Qty
1 67004978 BUSHING, DOOR (BLK) 10 4
2 67006961 DOOR ASSY., REF. FOAM (STNLS) 10 1
3 67006287 SCREW, SM Note: SCREW, DOOR STOP 10 2
4 67003549 GASKET, REF DOOR (BLK) 10 1
5 67003639 CLOSURE, DOOR (BLK) 10 1
6 67004041 BUCKET, REF DR (SM) 10 2
7 67001011 HINGE, TOP (BLK) 10 1
8 67001012 COVER, TOP HINGE (BLK) 10 1
9 67006303 SCREW Note: SCREW, TOP HINGE 10 3
10 M0310731 PLUG, TOP HINGE BUTTON (BLK) 10 3
11 67003780 STOP, DOOR (BLK) 10 1
12 67006521 SCREW Note: SCREW, TOP HINGE COVER 10 2
13 67004838 PLUG, VENT (BLK) 10 2
14 67001279 TRAY, DAIRY 10 1
15 67003637 DOOR, DAIRY 10 1
16 67002505 RETAINER, DOOR 10 1
17 67004040 BUCKET, REF DR (MED) 10 2
18 67006439 NAMEPLATE 10 1
19 67005822 SCREW, TF HEX/WASHER HD 10 3
20 67001167 HINGE, CENTER (BLK) 10 1
21 67006380 SCREW Note: SCREW, CENTER HINGE 10 3
22 67006642 PIN, CENTER HINGE 10 1
23 67006391 HANDLE ASSY., DOOR (STNLS) 10 1
24 67006113 MOUNT, HANDLE 10 2
25 67002935 SCREW, MOUNT 10 2
2
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: FREEZER DOOR
AA49-60
Model: MBR1956KES
3

FREEZER DOOR
No. Part No. Description
Section:
Series Qty
1 67006959 DOOR ASSY., FRZ. FOAM (STNLS) 10 1
2 67004838 PLUG, VENT (BLK) 10 2
3 67003551 GASKET, FZ DOOR (BLK) 10 1
4 67006391 HANDLE ASSY., DOOR (STNLS) 10 1
5 67006113 MOUNT, HANDLE 10 2
6 67002935 SCREW, MOUNT 10 2
7 67006408 SCREW, SM 10 8
4
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: CONTROLS
AA40-18
Model: MBR1956KES
5

CONTROLS
No. Part No. Description
Section:
Series Qty
1 C3680310 SWITCH, LIGHT Note: SWITCH, LIGHT 10 1
2 Y67003896 MODULE, LIGHT 10 1
3 67003897 COVER, REF LIGHT 10 1
4 67003898 MODULE, REF CONTROL 10 1
5 67006740 BOARD, CONTROL Note: (INCL. INSTR SHEET) 10 1
6 67003899 COVER, DAMPER 10 1
7 67003900 INSERT, DAMPER COVER 10 1
8 67006602 SCREW Note: SCREW, DAMPER BASE 10 2
9 67003901 HOUSING, LIGHT 10 2
10 12570701 SOCKET, LIGHT 10 2
11 67003883 BULB, LIGHT * 10 2
12 67004058 OVERLAY, CONTROL MODULE 10 1
13 67006116 DAMPER, CONTROL (W/HARNESS) 10 1
14 67006604 INSULATION, DAMPER CONTROL 10 1
15 67003905 COVER, FZ LIGHT 10 1
16 67003906 MODULE, FZ CONTROL 10 1
17 67001035 HOUSING, LIGHT 10 1
18 12570701 SOCKET, LIGHT 10 1
19 67003883 BULB, LIGHT * 10 1
20 67005653 SWITCH, LIGHT/INTLK 10 1
21 67006530 SCREW, TC Note: SCREW, HOUSING 10 1
22 12002355 THERMISTOR KIT 10 1
- 67004033 HARNESS, FF CONTROL 10 1
- 67006094 HARNESS, FZ MODULE 10 1
6
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: REFRIGERATOR SHELVES
AA46-127
Model: MBR1956KES
7

REFRIGERATOR SHELVES
No. Part No. Description
Section:
Series Qty
1 67004062 SHELF, STATIONARY 10 3
2 67004062 SHELF, STATIONARY Note: SHELF, MEAT 10 1
3 67001053 GLIDE (RT) Note: RAIL, MEAT PAN (RT) 10 1
- 67006626 SCREW Note: SCREW, RAIL 10 2
- 67006626 SCREW Note: SCREW, RAIL 10 2
4 67001054 GLIDE (LT) Note: RAIL, MEAT PAN (LT) 10 1
5 67001308 PAN, DELI Note: PAN, MEAT 10 1
6 10448903 RACK, BOTTLE 10 1
8
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: CRISPER ASSEMBLY
AA46-128
Model: MBR1956KES
9

CRISPER ASSEMBLY
No. Part No. Description
Section:
Series Qty
1 67001156 GLASS, CRISPER 10 1
2 67001153 FRAME, CRISPER 10 1
3 67001057 RAIL, CENTER CRISPER 10 1
4 67005864 SLIDE, HUMIDITY CONTROL 10 2
5 67002569 PAN, CRISPER 10 2
6 67003879 EXTR, FRONT CRISPER 10 1
7 67001155 BRACE, CRISPER E-CT 10 1
10
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: INTERIOR CABINET/FRZ SHELVES/TOE GRILLE
AA43-99
Model: MBR1956KES
11

INTERIOR CABINET/FRZ SHELVES/TOE GRI
No. Part No. Description
Section:
Series Qty
1 B8381501 GASKET, DRAIN TUBE 10 1
2 M0500703 SEAL, O RING 10 1
3 D7753903 FUNNEL, DRAIN 10 1
4 67006406 SCREW, SM/HEX HEAD Note: SCREW, ADAPTER 10 6
5 67003485 COVER, CORNER (BLK) 10 2
6 67001066 TUBE, DRAIN 10 1
7 67001067 CLIP, DRAIN TUBE 10 1
8 A3076901 PLUG, BUTTON 10 1
9 67004012 BRACKET, DRAWER SLIDE (LT) 10 1
9 67004013 BRACKET, DRAWER SLIDE (RT) 10 1
10 67004430 GEAR (RT) 10 1
11 67006473 SCREW SM/HEX Note: SCREW, BRACKET 10 8
12 67003868 BRAKE, FOOT 10 2
13 67006886 GRILLE, TOE (BLK) 10 1
- 12627302 CLIP, TOE GRILLE 10 2
14 67001073 LADDER, CENTER Note: RAIL, SEHLF SUPPORT (CTR) 10 1
15 67001302 LADDER, SIDES Note: RAIL, SHELF SUPPORT (LT/RT) 10 2
16 67006360 SCREW Note: SCREW, CTR RAIL 10 2
17 67006400 SCREW, SM Note: SCREW, LT/RT RAIL 10 6
18 67004985 BASKET, UPPER Note: BASKET, FRZ. (UPR) 10 1
19 67004067 SHAFT, RACK 10 1
20 67006023 BASKET, LOWER 30 10 1
21 10508506 HANDLE, BASKET/SHELF Note: HANDLE, BASKET 10 1
22 67004127 DIVIDER, BASKET (UPPER) Note: DIVIDER, BASKET (UPR) 10 1
23 67006608 SCREW Note: SCREW, DIVIDER 10 1
24 67004429 GEAR (LT) 10 1
25 67006644 DIVIDER, BASKET (LWR) 10 1
26 67006607 SLIDE, DRAWER 10 2
27 67004015 CRADLE, BASKET (RT) 10 1
27 67004014 CRADLE, BASKET (LT) 10 1
28 67004864 ADAPTER, SIDE (LT) 10 1
28 67004865 ADAPTER, SIDE (RT) 10 1
29 67006112 BRACKET, FOOT CABINET 10 2
- 67006491 SCREW Note: SCREW, BRACKET 10 8
12
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: EVAPORATOR/EVAP MOTOR/FRONT ROLLERS
AA43-51
Model: MBR1956KES
13

EVAPORATOR/EVAP MOTOR/FRONT ROLLE
No. Part No. Description
Section:
Series Qty
1 67006609 GRILLE, FZ AIR * 10 1
2 67001133 TRAY, DRIP E-CT 10 1
3 10623002 CLIP, EVAPORATOR 10 2
4 67005871 COVER, EVAP 30" 10 1
5 67002286 GASKET 10 1
6 67006611 BOLT, ROLLER ADJ Note: SCREW, ROLLER ADJ 10 2
7 67002227 ROLLER BRACKET ASSY 10 2
8 67006425 SCREW, SM 10 5
9 67006573 SCREW 10 4
10 10547002 CLIP, DRIER 10 1
11 B2150504 DRIER 10 1
12 12002051 KIT, EVAPORATOR Note: EVAPORATOR KIT (INCL. HEAT SHIELD, EVAPORATOR &
INSTRUCTION SHEET) 10 1
13 67001083 DAM, LEFT RETURN 10 1
14 67001084 DAM, RIGHT RETURN 10 1
15 67002135 HEATER, DEFROST 10 1
16 10428101 CLIP, EVAP HEATER 10 2
17 67002777 SHROUD, EVAP FAN 10 1
18 67003636 MOTOR, EVAP FAN 10 1
19 67005633 CLIP, EVAP MOTOR Note: CLIP, EVAP MOTOR 10 1
20 67002780 GROMMET, FAN MOTOR (BLK) 10 2
21 12217201 FAN, EVAPORATOR 10 1
22 67001291 GASKET, FOAM 10 2
23 12456801 BRACKET, ROLLER 10 2
24 M0286708 NUT, SPEED 10 2
25 67005127 ROLLER 10 2
26 M1205302 RIVET 10 2
27 67006737 SCREW Note: SCREW, CLIP 10 1
28 67006287 SCREW, SM Note: SCREW, FAN ASSY. 10 2
29 12002355 THERMISTOR KIT 10 1
30 67003924 COVER, FZ THERMISTOR 10 1
- 67003426 THERMOSTAT, DEFROST 10 1
- 67003931 HARNESS, EVAP HEATER 10 1
14
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: COMPRESSOR/COND MOTOR/REAR ROLLERS
AA41-60
Model: MBR1956KES
15

COMPRESSOR/COND MOTOR/REAR ROLLE
No. Part No. Description
Section:
Series Qty
1 67006432 SCREW, SHOULDER Note: SCREW, COMPRESSOR 10 3
2 12002634 KIT, COMPRESSOR Note: COMPRESSOR 10 1
3 67006433 SCREW Note: SCREW, GROUND 10 2
4 67005560 OVERLOAD/RELAY W/CAPACITOR 10 1
5 67004713 PAN, DRAIN 10 1
6 67003493 GROMMET, COMPRESSOR Note: GROMMET, COMPRESSOR 10 4
7 61003210 SEAL Note: SEAL, CONDENSER SHROUD 10 1
8 67004432 MOTOR, CONDENSER FAN 10 1
9 67006425 SCREW, SM 10 2
10 67004203 TUBE, DISCHARGE 10 1
11 67005680 GROMMET, CONDENSER 10 7
12 67006914 BASEPAN 10 1
13 12576801 STRAP, BALE 10 1
14 61004743 GROMMET, BRACKET 10 3
15 67006133 CONDENSER 10 1
16 67001090 SHROUD, CONDENSER FAN 10 1
17 67004952 BLADE, COND FAN 10 1
18 67004953 BRACKET, COND MOTOR 10 3
19 67004954 SCREW Note: SCREW, BRACKET 10 3
20 67005149 ROLLER 10 2
21 67006434 AXLE, ROLLER 10 2
- 67005251 HARNESS, MC 10 1
16
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: CABINET BACK
AA41-63
Model: MBR1956KES
17

CABINET BACK
No. Part No. Description
Section:
Series Qty
1 67006101 COVER, MC BACK 10 1
2 67001173 COVER, WATER VALVE 10 1
3 67006425 SCREW, SM 10 9
4 67006662 SCREW Note: SCREW, WATER VALVE 10 1
5 B5759649 GASKET, MC BACK 10 1
6 67003796 FIBER, ACOUSTIC 10 1
7 67006287 SCREW, SM 10 2
8 67003753 VALVE, WATER 10 1
9 M0104106 CLIP 10 2
- M0114003 CLIP, SPEED 10 1
10 10463201 ELBOW, FILL TUBE 10 1
11 67003331 COVER, WATER LINE 10 1
12 M0108105 CLAMP, TUBE 10 1
- 67006506 CORD, POWER 10 1
18
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: ICE MAKER
AA45-12
Model: MBR1956KES
19
