CABINET PARTS
1
5−08 Litho In U.S.A. (pl)(bay) Part No. W10206697 Rev.A
REFRIGERATOR
For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10
(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

CABINET PARTS
2W10206697
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10198858 Tech Sheet
W10175446 Owners Manual
W10187813 Tag, Energy
2
W10137519 Elbow, Fill Tube
3 67003405 Block, Pivot
4 B5759649 Gasket
5 67005955 Hinge, Top Right
6 A3076901 Plug, Button
7 67006118 Roller Assy. (2)
8 67006287 Screw
9 67006521 Screw
10 M0108105 Clamp, Tube
11 67006380 Screw (6)
12 67006611 Bolt, Adjusting
(Front)
13 Cover, Left Hinge
67005953 White
67005951 Black
W10191116 Apollo Grey
14 67006303 Screw (6)
15 Hinge, Center (RT)
67006379 White
67006443 Black
W10191143 Apollo Grey
16 67004092 Block, Filter (2)
17 Cover, Corner
67003484 White
67003485 Black
W10191102 Apollo Grey
18
W10199045 Hinge, Top Left
19
W10208641 Bracket, Foot (2)
20 67006564 Screw
21 Shim, Hinge
67006308 Left
67006309 Right
22 Grille, Toe
67006377 White
67006375 Black
W10191107 Apollo Grey
23
W10157973 Clip, Drain Tube
24 Hinge, Center (LT)
67006277 White
67006275 Black
W10191142 Apollo Grey
25 67006425 Screw (10)
26 67003331 Cover, Water Line
27 67004098 Cover, Water Valve
28 67006669 Screw (2)
29 67004101 Sweep, Dual Tube
30 67006102 Cover, Unit
31
W10164397 Tube, Drain
32 M0114003 Clip, Speed
33 67003796 Insulation, Sound
34 67003868 Foot Brake
35 Cover, Right Hinge
67005958 White
67005956 Black
W10191117 Apollo Grey
36 Cabinet (Not a
Servicable Part)
For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10
(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

FREEZER LINER PARTS
3
For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10
(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)
W10206697

FREEZER LINER PARTS
4W10206697
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 67001291 Gasket, Foam
3 12002497 Gear
(Includes LH & RH)
4 67003905 Cover, Light
5 67004017 Shaft
6
Y12570701 Socket, Light
7 67005874 Guide, Fill Tube
8 67006473 Screw (8)
9 A0282812 Bulb, Light
10 67001035 Housing, Light
11 67005873 Cover, Evaporator
12 67006425 Screw (4)
13 Bracket, Door
W10122147 Left
W10122148 Right
14 67003906 Module, Light
15
W10208602 Clip, Evap Motor
16 67005653 Switch, Light
17 67006287 Screw (2)
18 Cradle, Basket
W10187668 Left
W10187667 Right
19
W10120018 Slide, Drawer (2)
20 67002492 Gasket, Bottom
21 Adapter, Slide
W10149390 Left
W10149391 Right
22
W10175909 Grille, Fz Air
23
W10167023 Shroud, Evap Fan
24 2169142 Blade, Fan
(Evaporator)
25
W10150583 Grommet
26
W10199049 Motor, Evaporator
27 D7753903 Funnel, Drain
28 M0500703 Seal
29 B8381501 Gasket
30 12002355 Thermistor
31 67003924 Cover, Thermistor
32 67006406 Screw (6)
33 67006530 Screw
34
W10157765 Diverter, Air
35 Rail, Side
W10146443 Left
W10146444 Right
Following Parts Not Illustrated
67006095 Harness, Fz Module
For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10
(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

REFRIGERATOR LINER PARTS
5
W10206697
For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10
(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

REFRIGERATOR LINER PARTS
6W10206697
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 67004078 Bracket, Control
and Lights
3
W10175935 Keyboard
4
W10185585 Housing, Control
5
W10207861 Board, Control
6 C3680310 Switch, Light (2)
7 67003897 Cover, Light
8 67003901 Housing, Light
9 A0282812 Bulb, Light (2)
10
Y12570701 Socket, Light (2)
11 67003900 Insert,
Damper Cover
12 67006602 Screw (2)
13 67003899 Cover, Damper
14 67006604 Insulation
15
W10127429 Control, Damper
(Incl. Harness)
16 12002355 Thermistor
17 67001668 Plate
18 67006524 Head, Filter
19
UKF8001AXX Filter, Water
20 12568001 Cover, Filter
21 67006287 Screw (2)
22 B8390302 Clip, Facade (2)
23
W10158503 Facade, Dispenser
24 67002742 Plate, Switch
25 12575501 Switch, Limit
26 67003728 Guide, Waterline
27 67002816 Clip, Waterline
28 67005674 Facade (Top)
29
W10153959 Tank, Water
30 61006182 Union
31 12664501 Plug, Bypass
32 67006400 Screw (2)
33
W10117358 Insulation, Tank
34
W10130483 Gasket
Following Parts Not Illustrated
67005417 Harness, Control
(Refrigerator)
For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10
(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

REFRIGERATOR DOOR PARTS
7
W10206697
For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10
(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

REFRIGERATOR DOOR PARTS
8
For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10
(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)
W10206697
Illus. Part
No. No. DESCRIPTION
1 Door, Left
W10199095 White
W10199872 Black
W10199863 Stainless
W10199868 Satina
2 Door, Right
W10199092 White
W10200711 Black
W10199865 Stainless
W10199871 Satina
3 67003637 Door, Dairy
4 67001279 Tray, Dairy
5 67004748 Bin, Shelf (3)
(Medium)
6 Mullion, Door
67003263 White
67003264 Black
W10199882 Apollo Grey
7 67006786 Screw
8 Gasket, Door (2)
W10163894 White
12723206B Black
W10179332 Apollo Grey
9 Handle, Door
67006114 White
67006115 Black
W10191144 Antique Pewter
W10136871 Stainless
10 67006287 Screw
11 Stop, Door
12968202W White
67007011 Black
W10191119 Apollo Grey
12 67006439 Nameplate
13 67006113 Mount, Handle
14 67002935 Screw
15 Closure, Door
67003638 White
67003639 Black
W10191100 Apollo Grey
16 67004749 Bin, Shelf (2)
(Gallon)

UNIT PARTS
9
For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10
(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)
W10206697

UNIT PARTS
10
For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10
(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)
W10206697
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 67006433 Screw
2
W10162928 Blade, Fan
3 67005889 Basepan
4 67006425 Screw (2)
5 67004954 Screw (3)
6
W10134623 Compressor
(Incudes items
11,12,17,27, &
30)
7
W10171661 Harness, Evap
Heater
8 67007175 Pan, Drain
9 61004743 Grommet (3)
10 67002493 Heater, Defrost
11 2264017 Capacitor
12
W10128791 Start Device
13 61003210 Gasket
14
W10165425 Thermostat, Def.
15 67005680 Grommet (2)
16
W10158508 Shroud
17 2255199 Clip, Capacitor
18 67006131 Condenser
19
W10134293 Tube, Discharge
20 67002490 Tray, Drip
21 10623002 Clip, Evaporator
22 12002041 Evaporator Kit
(Inc. Evap., Heat
Shield, & Instr.
Sheet)
23 Dam
67001084 Right Side
67001083 Left Side
24 67004432 Motor, Fan
25 10428101 Clip, Heater
26 13060202 Harness, MC
27 2317845 Drier
28 10547003 Clip, Drier
29 67004953 Bracket, Fan Motor
30
W10169124 Grommet (4)
31 67006432 Screw (3)
32 67006573 Screw (4)
33 67005421 Cover, HV Box
34
W10205114 Board, HV Control
(Inc. Inst. Sheet)
35 67005719 Spacer, HV Box
36 67005718 Box, HV
37 67006550 Screw (2)
38 12972902 Harness, HV
39 67006615 Screw, Cover
40 67005149 Roller (2)
41 67006434 Axle (2)
42
W10137529 Grommet (4)
43 67005491 Block, Condenser
44 67006737 Screw
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.25 Ozs.
(R−134A)

SHELF PARTS
11
W10206697
For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10
(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

SHELF PARTS
12 W10206697
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 67002761 Glass, Pantry
2
W10208663 Shelf, Glide Out
3 67004585 Rack, Can
4 67006010 Extr, Glass
Support (2)
5 67002330 Brace, Pantry (2)
6 67001719 Track, Pantry
7 67006626 Screw (4)
8
W10171557 Divider,
Upper Basket
9 67002329 Gasket, Pantry
10 67005625 Housing, Control
11
W10205737 Shelf, Stat (2)
12 67003793 Slide, Temperature
13 67001054 Glide, Left
14 67007026 Glide, Drawer(2)
15 67001053 Glide, Right
16 Endcap, Pantry
67005863 Left
67005858 Right
17 67004515 Pan, Crisper (2)
18 67002748 Brace, Crisper
19 67004510 Trim, Crisper
20 67003854 Frame, Crisper
21 67006704 Glass, Crisper
Cover
22 67001073 Ladder, Center
23 67002489 Ladder, Side
24 67006400 Screw (6)
25 67006360 Screw (2)
26 67006415 Screw (4)
27 67005864 Slide, Humidity
Control
28 67003795 Rod, Temperature
Control
29 67003531 Drawer, Pantry
30 67003791 Knob, Temperature
Control
31 67005903 Door,
Pantry Drawer
32
W10150039 Basket, Freezer
(Lower)
33
W10146440 Divider,
Lower Basket
34
W10169949 Basket, Freezer
(Upper)
35 67002759 Divider,
Pantry Drawer
36 67006287 Screw (4)
37 67004514 Rail, Center
Crisper Frame
38 12603701 Supports,
Crisper Frame
39
W10171558 Divider,
Upper Freezer
40
W10146446 Gear
41
W10146442 Mount, RH Gear
42
W10146441 Mount, LH Gear
43
W10149389 Lift, Bail Arm
44
W10158749 Gear
45
W10199044 Shaft
For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10
(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)

ICEMAKER PARTS
13
For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10
(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)
W10206697

ICEMAKER PARTS
14
Illus. Part
No. No. DESCRIPTION
For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10
(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)
1 2256086 Bracket, Ice Maker
2 67003729 Tubing, Plastic
3 67003932 Clamp
4 489276 Screw
5 67006531 Valve, Water
6 67004028 Arm, Shutoff
7 67004710 Cover
8 A3223101 Insert, Tube
9
W10122527 Mold & Heater
Assembly (Also
Order 542638)
10 628515 Cup, Water Fill
11 627843 Ejector
12 2182124 Ice Stripper
13 2194712 Support, Housing
14 2315522 Retainer,
Thermostat
15 627985 Thermostat
(Order 542369
Cement)
16 8533917 Screw (2)
17 489464 Screw
18
W10146389 Harness, Ice Maker
19 M0114003 Clip, Speed
20 626678 Module Assembly
(Includes Items
21 & 22)
21 626684 Motor
22 489136 Screw
23
W10137519 Elbow, Fill Tube
24 67005603 Funnel, Fill Tube
25
W10182748 Pan, Ice
100
W10122519 Icemaker Assembly
Following Parts Not Illustrated
10244904 Coupling
W10206697

FREEZER DOOR PARTS
15
Illus. Part
No. No. DESCRIPTION
For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10
(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)
W10206697
1 Freezer Door
W10199889 White
W10199891 Black
W10199885 Stainless
W10205735 Satina
2 Handle
67007107 White
67007105 Black
W10138763 Stainless
W10191147 Antique Pewter
3 Gasket, Door
W10133249 White
W10131754 Black
W10199892 Apollo Grey
4 67002935 Screw
5 67006113 Mount, Handle

OPTIONAL PARTS (NOT INCLUDED)
16 W10206697
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
Parts Not Illustrated and
Optional Parts (Not Included)
Customer Touch−Up Material
350942 Primer, White
(13 Oz. Spray Can)
350939 Enamel, Black
(13 Oz. Spray Can)
350930 Enamel, White
(13 Oz. Spray Can)
72017 Brush Touch−Up Kit
(White)
72032 Brush Touch−up kit
(Black)
Important: The spray paint is
not to be used where the paint
may make contact with the door
gaskets.
Refinishing Material
799340 Enamel, Black
(1 Qt. Uncut)
799344 Enamel, White
(1 Qt. Uncut)
Miscellaneous
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4 x 108")
876370 Kit, Insulation
(2 Pcs. x 3" x 24"
X 48")
876305 Kit, Insulation
(14 Pcs. x 3"
x 24" x 48")
978941 Insulation,
Fiberglass
(63−1/2" x 35−1/2"
X 2−5/8)
876029 Kit, Foam Slab
(30" x 32−1/2"
x 1−1/2")
505587 Sealer, Mastic
(1 Qt.)
503695 Cork, Sealer
(1/4 Pound)
20000008 Cleaner,
Stnls Steel Magic
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
606755 Bag, Insulation
(36−5/8" x 46")
799833 Kit, Evaporator
Repair
(Aluminum Epoxy)
833938 Kit, Terminal
Connector
TORX SCREW WRENCH
1117510 Torx Key
For Models: MFD2562VEA10, MFD2562VEB10, MFD2562VEM10, MFD2562VEW10
(Monochromatic Satina) (Black) (Monochromatic Stainless) (White)
