CABINET PARTS
1
For Models: MFD2562VEW2, MFD2562VEA2
(White) (Monochromatic Satina)
12−09 Litho In U.S.A. (mat) (psw) Part No. W10304456 Rev.A
REFRIGERATOR

CABINET PARTS
2
For Models: MFD2562VEW2, MFD2562VEA2
(White) (Monochromatic Satina)
W10304456
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10279334 Tech Sheet
W10175446 Owners Manual
W10187813 Tag, Energy
2
10463203SP Elbow, Fill Tube
3 12698403 Block, Pivot
4 B5759655 Gasket
5
12963205ED Hinge, Top Right
6 A3076901 Plug, Button
8 12990504 Screw
9 12992602 Screw
10 M0108107 Clamp, Tube
11 12992201 Screw (6)
13 Cover, Left Hinge
W10217491 White
W10217488 Apollo Grey
14 12992403 Screw (6)
15 Hinge, Center (RT)
13000002WD White
13000002AP Apollo Grey
16 12777701 Block, Filter (2)
17 Cover, Corner
12587703W White
12587703AP Apollo Grey
18
12963204ED Hinge, Top Left
19 Roller Assy.
W10275849 Right
W10275850 Left
20 12991302 Screw
21 Shim, Hinge
12999501 Left
12999502 Right
22 Grille, Toe
W10244559 White
W10244558 Apollo Grey
24 Hinge, Center (LT)
13000001WD White
13000001AP Apollo Grey
25 12990511 Screw (10)
26 12726003 Cover, Water Line
27
W10208593 Guard−Water Valve
28 12990303 Screw (2)
29 12831101 Sweep, Dual Tube
30
W10211855 Cover, Unit
31
W10210988 Tube, Drain
32
M0114003SP Clip, Speed
33 12820505 Insulation, Sound
34 10354002 Foot Brake
35 Cover, Right Hinge
12962302W White
12962302AP Apollo Grey
36 Cabinet (Not a
Servicable Part)

FREEZER LINER PARTS
3
For Models: MFD2562VEW2, MFD2562VEA2
(White) (Monochromatic Satina)
W10304456

FREEZER LINER PARTS
4
For Models: MFD2562VEW2, MFD2562VEA2
(White) (Monochromatic Satina)
W10304456
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 A3189392 Gasket, Foam
3 12932103 Guide, Fill Tube
5 13062901 Motor, Evaporator
6
12570701V Socket, Light
8 12815301 Cover, Thermistor
9
W10194422V Bulb, Light
10
W10277466 Foil, Housing
11 12226112 Cover, Evaporator
12 12990511 Screw (4)
13
W10150583 Grommet
14
W10277025 Module, Light
15 13058002 Clip, Evap Motor
16 12466105 Switch, Light
18 D7753903 Funnel, Drain
19 M0500703 Seal
20 A3189396 Gasket, Bottom
21 B8381501 Gasket
22 13024803 Grille, Fz Air
23 13057901 Shroud, Evap Fan
24 2169142 Blade, Fan
(Evaporator)
25 Bracket, Door
W10122147 Left
W10122148 Right
26 12990521 Screw (8)
27 Cradle, Basket
W10280608 Left
W10280613 Right
28
W10120018 Slide, Drawer (2)
29 Adapter, Slide
W10261203 Left
W10261204 Right
30 12990501 Screw (6)
33 Rack−Side
W10284694 Left
W10284695 Right

REFRIGERATOR LINER PARTS
5
For Models: MFD2562VEW2, MFD2562VEA2
(White) (Monochromatic Satina)
W10304456

REFRIGERATOR LINER PARTS
6
For Models: MFD2562VEW2, MFD2562VEA2
(White) (Monochromatic Satina)
W10304456
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 12806302 Module, Light
3
W10217740 Overlay
4 12806405 Housing, Control
5
W10217475 Board, Control
6
C3680310V Switch, Light (2)
7 12806501 Cover, Light
8
12806601V Housing, Light
9
W10194422V Bulb, Light (2)
10
12570701V Socket, Light (2)
11 12806801 Insert,
Damper Cover
12 12990604 Screw
13 12806701 Cover, Damper
14 13012402 Insulation
15
W10207517 Control, Damper
17 12704801 Plate
18 12590620 Head, Water Filter
19
UKF8001AXX Filter, Water
20 12568001 Cover, Filter
21 12990512 Screw (2)
22
B8390302SP Clip, Facade (2)
23
12706909SP Facade, Disp.
24
12707303SP Plate, Switch
25 12575501 Switch, Limit
26
12707206SP Guide, Waterline
27
12251001SP Clip, Waterline
28 12707005 Facade, Disp (Top)
29 12706112 Tank, Water
30 61006182 Union
31 61003146 Plug, Bypass
32 12990513 Screw
33
W10117358 Insulation, Water
Tank
Following Parts Not Illustrated
W10224292 Harness, Control
(Refrigerator)
(Includes
Thermistor)

REFRIGERATOR DOOR PARTS
7
For Models: MFD2562VEW2, MFD2562VEA2
(White) (Monochromatic Satina)
W10304456

REFRIGERATOR DOOR PARTS
8
For Models: MFD2562VEW2, MFD2562VEA2
(White) (Monochromatic Satina)
W10304456
Illus. Part
No. No. DESCRIPTION
1 Door, Left
W10199095 White
12978035LQ Satina
2 Door, Right
W10199092 White
12978034LQ Satina
3
12804701SP Door, Dairy
4
12369502SP Tray, Dairy
5 12801904 Bin, Shelf (3)
(Medium)
6 Mullion, Door
12722803W White
12722803AP Apollo Grey
7 12990204 Screw
8 Gasket, Door (2)
W10163894 White
W10179332 Apollo Grey
9 Handle, Door
13004701W White
13004701L Antique Pewter
10 12990504 Screw
11 Stop, Door
12968202W White
12968202AP Apollo Grey
12
W10170766 Nameplate
13 13001201 Mount, Handle
14 12991703 Screw
15 Closure, Door
12028505W White
12028505AP Apollo Grey
16 12840002 Bin, Shelf (2)
(Gallon)

UNIT PARTS
9
For Models: MFD2562VEW2, MFD2562VEA2
(White) (Monochromatic Satina)
W10304456

UNIT PARTS
10
For Models: MFD2562VEW2, MFD2562VEA2
(White) (Monochromatic Satina)
W10304456
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 12992301 Screw
2 12825803 Blade, Fan
3
W10210985 Basepan
4 12990511 Screw
5 2264017 Capacitor
6
W10233569 Tube, Discharge
7
W10224515 Harness, Evap.
Heater
8
W10296785 Pan, Drain
9
W10216919 Screw, Shoulder
10 12729129 Heater, Defrost
11
W10174384 Strap, Bale
12
W10194431 Start Device
13
W10137529 Grommet, Cond (4)
15 12477102 Roller (2)
16 12992101 Screw
17
10835903SP Grommet (4)
18
W10135026 Condenser
19 10547003 Clip, Drier
20
W10292803 Tray, Drip
21 12990701 Screw
22 12726403 Evaporator
23 Dam
12225702 Right Side
12225602 Left Side
24
W10239053 Motor, Fan
25 10428101 Clip, Heater
26
W10234025 Harness, Unit
with Power Cord
27
W10143759 Drier
28
W10164016 Compressor
(Includes items
11,12,17,27)
29 10623002 Clip, Evaporator
30 12477202 Axle, Roller (2)
31
W10189184 Shroud
32
W10257665 Box, HV Control
33 12957702 Lid, HV Box
34 12957801 Gasket, HV Box
35
W10205552 Board, Control
36
W10206338 Extension−Basepan
37
W10206339 Fastener−Basepan
38 12961602 Cover−Control Box
39 12990702 Screw
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
5.25 Ozs.
(R−134A)

SHELF PARTS
11
For Models: MFD2562VEW2, MFD2562VEA2
(White) (Monochromatic Satina)
W10304456

SHELF PARTS
12
For Models: MFD2562VEW2, MFD2562VEA2
(White) (Monochromatic Satina)
W10304456
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 12204830 Glass, Pantry
2 12654610 Shelf, Glide Out
3
12503805SP Rack, Can
4
12655902SP Extr, Glass
Support (2)
5
12227305WD Brace, Pantry (2)
6 12531901 Track, Pantry
7 12990515 Screw (4)
8
W10241046 Divider,
Upper Basket
9 12656901 Gasket, Pantry
10 12656202 Housing, Control
11
12654710SP Shelf, Stat (2)
12 12655402 Slide, Temperature
13
12656601SP Glide, Left
14
13058101V Glide, Drawer(2)
15
12656602SP Glide, Right
16 Endcap, Pantry
12656106 Left
12656019 Right
17 12804601 Pan, Crisper (2)
18
12642303WD Brace, Crisper
19
W10231345 Trim, Crisper
20
12796301SP Frame, Crisper
21 12204824 Glass, Crisper
Cover
22
W10273463 Ladder, Center
23
W10251971 Ladder, Side
24 12990513 Screw (6)
25 12990515 Screw (2)
26 12990512 Screw (4)
27
12530805SP Slide, Humidity
Control
28 12655304 Rod, Temperature
Control
29 12731302 Drawer, Pantry
30
12655204V Knob, Temperature
Control
31 12656815 Door,
Pantry Drawer
32
W10150039 Basket, Freezer
(Lower)
33
W10146440 Divider,
Lower Basket
34
W10209706 Basket, Freezer
(Upper)
35 12731901 Divider,
Pantry Drawer
36 12990504 Screw (4)
37 12796401 Rail, Center
Crisper Frame
38 13062602 Supports,
Crisper Frame
39
W10171558 Divider,
Upper Freezer
40
W10146446 Gear
41
W10233899 Mount, RH Gear
42
W10233898 Mount, LH Gear
43
W10149389 Lift, Bail Arm
44
W10158749 Gear
45
12812904WD Shaft

ICEMAKER PARTS
13
For Models: MFD2562VEW2, MFD2562VEA2
(White) (Monochromatic Satina)
W10304456

ICEMAKER PARTS
14
For Models: MFD2562VEW2, MFD2562VEA2
(White) (Monochromatic Satina)
W10304456
Illus. Part
No. No. DESCRIPTION
1 2256086 Bracket, Ice Maker
2
B5705333SP Tubing, Plastic
3 10526702 Clamp
4 489276 Screw
5 12544124 Valve, Water
6
W10202524 Arm, Shutoff
7 12582501 Cover
8
A3223101SP Insert, Tube
9
W10122527 Mold & Heater
Assembly (Also
Order 542638)
10 628515 Cup, Water Fill
11 627843 Ejector
12 2182124 Ice Stripper
13 2194712 Support, Housing
14 2315522 Retainer,
Thermostat
15 628397 Thermostat
(Order 542369
Cement)
16 8533917 Screw (2)
17 489464 Screw
18 D7813011 Harness, Ice Maker
19
M0114003SP Clip, Speed
20
W10223929 Module Assembly
(Includes Items
21 & 22)
21
W10122551 Motor
22 489136 Screw
23
W10137519 Elbow, Fill Tube
24 12918001 Funnel, Fill Tube
25
W10171529 Pan, Ice
100
W10190978 Icemaker Assembly
Following Parts Not Illustrated
10244904 Coupling

FREEZER DOOR PARTS
15
For Models: MFD2562VEW2, MFD2562VEA2
(White) (Monochromatic Satina)
W10304456
Illus. Part
No. No. DESCRIPTION
1 Freezer Door
W10199889 White
12977818LQ Satina
2 Handle
13004702W White
13004702L Antique Pewter
3 Gasket, Door
W10164040 White
W10164042 Apollo Grey
4 12991703 Screw
5 13001201 Mount, Handle

OPTIONAL PARTS (NOT INCLUDED)
16
For Models: MFD2562VEW2, MFD2562VEA2
(White) (Monochromatic Satina)
W10304456
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
Parts Not Illustrated and
Optional Parts (Not Included)
Customer Touch−Up Material
350942 Primer, White
(13 Oz. Spray Can)
350939 Enamel, Black
(13 Oz. Spray Can)
350930 Enamel, White
(13 Oz. Spray Can)
72017 Brush Touch−Up Kit
(White)
72032 Brush Touch−up kit
(Black)
Important: The spray paint is
not to be used where the paint
may make contact with the door
gaskets.
Refinishing Material
799340 Enamel, Black
(1 Qt. Uncut)
799344 Enamel, White
(1 Qt. Uncut)
Miscellaneous
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4 x 108")
876370 Kit, Insulation
(2 Pcs. x 3" x 24"
X 48")
876305 Kit, Insulation
(14 Pcs. x 3"
x 24" x 48")
978941 Insulation,
Fiberglass
(63−1/2" x 35−1/2"
X 2−5/8)
876029 Kit, Foam Slab
(30" x 32−1/2"
x 1−1/2")
505587 Sealer, Mastic
(1 Qt.)
503695 Cork, Sealer
(1/4 Pound)
20000008 Cleaner,
Stnls Steel Magic
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
606755 Bag, Insulation
(36−5/8" x 46")
799833 Kit, Evaporator
Repair
(Aluminum Epoxy)
833938 Kit, Terminal
Connector
TORX SCREW WRENCH
1117510 Torx Key
