Maytag FLOOR-2-FLOOR User manual

Floor-2-Floor™
Hard Floor Cleaner
®®
ENGLISH ➜pp.1-17
ESPAÑOL ➜pág. 19-30
FRANÇAIS ➜p. 31-42
ITALIANO ➜p. 43-50
DEUTSCH ➜p. 51-58

2
Important Safeguards!
When using an electrical appliance, always follow basic precautions, including the following:
WARNING: To reduce the risk of fire, electric shock, or injury:
• Use indoors only.
• Use only on surfaces moistened by the cleaning process or small spills. Do not immerse product.
• For use on bare floors or sealed wood floors. NOT for use on carpets.
• Always install float before any wet pick up operation.
• Close supervision is necessary when any appliance is used by or near children. Do not allow cleaner to be used
as a toy or to run unattended at any time.
• The appliance is not intended for use by young children or infirm persons without supervision.
• Keep hair, loose clothing, fingers, feet and all parts of body away from openings and moving parts.
• Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
• Do not pick up or use flammable or combustible materials such as gasoline or fine wood sandings or use in
areas where they may be present.
• Avoid picking up hard, sharp objects with the cleaner. They may damage the machine.
• Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and any-
thing that may reduce air flow.
• Do not pull or carry by cable, use cable as a handle, close door on cable or pull cable around sharp edges or cor-
ners. Do not run appliance over cable. Keep cable away from heated surfaces.
•Always disconnect cable from electrical source before servicing the cleaner.
•Unplug cleaner when not in use. Turn off all controls before unplugging.
• Do not unplug by pulling on cable. To unplug, grasp the plug, not the cable.
• Never handle plug or appliance with wet hands.
• Connect to a properly earthed source using the factory fitted plug and cable only.
• Do not clean over floor electrical outlets.
• Do not use without tanks in place.
• The use of an extension cord is not recommended.
• Keep detergents and other cleaners out of children's reach.
• Do not pick up chlorine bleach, drain cleaner, gasoline or any other toxic material with this appliance.
• When using recommended chemicals with this machine, be certain area is well ventilated.
• Follow manufacturer’s instructions for all chemicals used with this machine. Do not exceed recommended mix-
ing ratios.
• Store in a dry place. Do not expose machine to freezing temperatures.
• Do not use with damaged cable or plug. If appliance is not working as it should, please refer to “Trouble
Shooting”.
• Use cleaner only for its intended use as described in the instructions.
READ ALL INSTRUCTIONS BEFORE USING APPLIANCE.
Save these instructions!

3
Fill in and Save
For your records, enter the model number and
serial numbers in the spaces provided. These
numbers are located on the data label on the back
of the cleaner body.
Model No. ____________________________
Serial No. _____________________________
Save your sales receipt and attach it to this
manual. Proof of date of purchase may be
required for warranty service of your cleaner.
Important safeguards . . . . . . . . 2
Carton contents . . . . . . . . . . . . . 3
Cleaner description . . . . . . . . . . 4
Assembly
Brush/nozzle assembly. . . . . . 5
General operation
Mode selector dial. . . . . . . . . . 7
Solution tank . . . . . . . . . . . . 8-9
Recovery tank . . . . . . . . . . . . 10
Automatic shut-off . . . . . . . . 10
To clean filters . . . . . . . . . 10-11
How to clean
Recommended cleaning
sequence. . . . . . . . . . . . . . . . . 11
Cleaning floors . . . . . . . . . . . 12
Picking up spills . . . . . . . . . . 12
Storage. . . . . . . . . . . . . . . . . . . . 13
Maintenance
Cleaning the nozzle. . . . 13-14
Cleaning the brushes . . . . . 15
Troubleshooting. . . . . . . . . . . . 16
Service. . . . . . . . . . . . . . . . . . . . 17
Warranty . . . . . . . . . . . . . . . . . . 17
A.Hard floor cleaner
B. Brush assemblies (2)
C. Nozzle
D. Floor cleaning
concentrates
Continued ➜
Contents
Carton Contents
A
C
B
D
Maytag Intl., Inc.
Schaumburg, IL 60173

4
Cleaner Description
Features
1. Soft hand grip 12. Nozzle
2. ON/OFF switch 13. Squeegee (underneath nozzle)
3. Solution trigger: squeeze to release 14. Bumper
cleaning solution 15. Soft-tread wheels
4. Mode selector dial: turns brushes 16. Carrying handle
ON for wet cleaning and OFF for wet 17. Upper handle release button
pickup and dry vacuuming 18. Cable hooks: top hook rotates
5. Clean solution tank cap/measuring cup for quick cable release
6. Clean solution tank 19. Handle release pedal
7. Clean solution tank release
8. Recovery tank release
9. Recovery tank lid and filter
10. Recovery tank: collects dry debris as
well as dirty cleaning solution
11. Nozzle release buttons: release
nozzle for easy clean-up (located
behind nozzle)
17
18
12
13
14
11
15
16
11
10
9
19
7
8
6
4
5
4
2
3
1
1
This cleaner is intended for household
use.
Operate cleaner only at voltage speci-
fied on data plate on back of cleaner.
Plug cleaner into a properly earthed
source.

To install brushes, place handle in
upright position. Tilt cleaner back so
that it rests on the floor.
Align post (A) on brush block with hole
(B) on bottom of cleaner. Turn brushes
slightly until post fits easily into hole.
5
2
Install brushes and nozzle 2B
A
Continued ➜
C
CDE
5
3
4
While holding nozzle in place, slide
latches inward to lock in place.
Press brush assembly firmly to
snap into place.
To install nozzle, make sure latches
(C) are out.
Align middle section (D) of nozzle with
opening (E) on cleaner.
Remove cardboard packing insert from
squeegee area on underside of nozzle.
3
4
5

To move your cleaner from room to
room, put handle in upright posi-
tion, tilt cleaner back on rear wheels and
push forward.
Transporting
A
A
9
10
Push switch (A) once to turn cleaner
ON. Push switch again to turn
cleaner OFF.
Handle release pedal
ON/OFF switch
8
Step on pedal (A) to lower handle
to operating position. Handle does
not lock into a single position, but
“floats” to allow convenient operation.
6
8
9
10
B
A
7
Unfold handle
Raise upper handle (A) to upright
position until it locks in place.
6
How to fold handle
Press upper handle release button
(B) to fold handle to storage
position.
6
7

7
11
The cleaner may also be lifted using
the carrying handle (A) on the front
of the cleaner.
A
Continued ➜
11
Your MAYTAG®Floor-2-Floor™ Hard Floor Cleaner can be used to both vacuum dry debris and wet
clean non-carpeted floor surfaces such as vinyl, tile and sealed wood. It is not intended for use on
carpet or rugs.
CAUTION: To prevent damage to wood floors, follow the flooring manufacturer’s cleaning
recommendations.
If using cleaner on sealed wood floors, inspect floor surface for worn finish, bare wood or sepa-
rated joints. Do not use Floor-2-Floor™ Hard Floor Cleaner to wet clean sealed wood floors if any
of these conditions exist.
General operation
12
Mode selector dial
A
13
The Mode selector dial (A) turns
the brushes on and off.
For dry debris pickup, turn the dial to the
DRY VAC position. In this position, the
brushes will not rotate and are raised off the floor
surface.
To wet clean with brushes turned ON, turn the
dial to the WASH position.
For wet pickup, turn the dial to the WET PICK-
UP position.
Refer to “How to clean” section for complete
cleaning instructions.
12
13

14
To remove tank, squeeze release
button and pull tank straight out.
15 Carry tank to a sink.
Rotate tank cap counter-clockwise
and lift up to remove cap (A).
16
Turn cap (A) upside down to serve
as a measuring cup.
For hard surface floors such as vinyl,
linoleum, marble, laminate wood,
polyurethane sealed wood or other
wood floors that can normally be
cleaned using water, use one cup (60 mL
[2 oz.]) MAYTAG®Floor to Floor™
Cleaner.
Check for worn spots or joint separa-
tions before using, as these conditions
could lead to damaged flooring when
using water to clean floor.
When cleaning ceramic and other tiles,
use the set of grout brushes with gray
bristles included with your Floor-2-
Floor™ Hard Floor Cleaner. Use these for
tile floors where extra attention is needed
for cleaning grout. (See “Cleaning the
brushes” section for how to remove and
replace the brush assemblies.)
Using cup, measure 1-1/2 cupfuls (90 mL
[3 oz.]) of MAYTAG®Grout Cleaner.
Solution (upper) tank
The solution tank holds detergent and
water that is to be dispersed onto the sur-
face being cleaned.
How to fill
Disconnect cleaner from electrical out-
let.
Place cleaner handle in upright, locked
position.
The tanks
8
14
15
16
A
A

9
Pour cleaning concentrate into tank (B). Fill tank to
fill line (C) (0,9 L [1 quart]) with warm water.
If rubber ring (D) on cap has become dislodged,
reposition it with uneven side against ledge (E) as
shown.
Replace cap. Rotate cap clockwise until it locks in
place. Cap must be locked in place for proper per-
formance and to prevent leaking.
Slide tank straight into position until latch snaps in
place.
D
CB
E
17
18
19
20
DO NOT use cleaning concentrates that contain solvent based ingredients.
CAUTION: MAYTAG®Grout Cleaner cannot be used in Maytag Agility™ products.
Doing so could damage your Agility™ Cleaner.
17
18
19
20
Continued ➜

Recovery (lower) tank
Automatic shut-off
An automatic suction shut-off is built
into the recovery tank to prevent the
tank from overflowing.
When the shut-off activates, the cleaner
will not pick up debris and the sound of
the motor will change. The recovery
tank is full and must be emptied.
How to empty
Turn cleaner off and disconnect from
electrical source.
Although not necessary for satisfactory
performance, it is recommended that the
recovery tank be emptied after dry vac-
uuming and before wet operation.
Check the solution tank also. It may
need to be refilled at this time.
To remove tank, press down on
release button (B) and pull tank
straight out.
Remove tank lid (C). Empty tank.
The tank lid contains a washable,
reusable filter. Clean this filter when
suction is low or reduced.
Turn cleaner off and disconnect from
electrical source.
Remove recovery tank and lid (Figs.
21 & 22). Remove filter lid (A), then
remove filter (B). Remove loose debris
from filter by tapping the filter or gently
brushing using your hand. The filter
may also be rinsed for additional clean-
ing. Allow filter to air dry between uses.
10
AB
21
C
B
22
23 To clean filters
21
22
23
