Key
1
While carrying the Advanced Key you can...
 • Lockthevehiclebysimplypressingthe
driver’sdoorrequestswitchonce.
 • Closethewindowsandmoonroofby
pressingandholdingthedriver’sdoor
requestswitch;releasetostop.
 • Unlockthevehiclebypressingthe
driver’sdoorrequestswitch.
 • Unlockallthedoorsbypressingthe
driver’sdoorrequestswitchtwice
ORbypressingtheunlockbutton
ontheadvancedkey/keylessentry
transmittertwice.
 • Unlocktheliftgatebypressingthe
liftgaterequestswitch.
ADVANCED KEYLESS
ENTRY SYSTEM
• AdvancedKeylessEntryallowsyouto
 lock/unlockthedoorsandliftgateof
 thevehicle,andevenstarttheengine
 withoutevertakingthekeyoutof
 yourpocket.
Auxiliary Key
Advanced Key
Door Request Switch
Liftgate Request Switch
Lock Panic
Alarm
Unlock
164817_09a_Mazda CX-7_SSG_080808.indd 2 8/8/08 2:22:40 PM

2
STARTING THE ENGINE WITH THE ADVANCED KEY
While carrying the Advanced Key you can...
 • StarttheenginebypushingtheStartknoballthewayin.Whenthe
KEYindicatorlightilluminatesgreen,turntheStartknobfrom
theACCpositiontotheSTARTpositionandholduntiltheenginestarts.
 • ShuttheengineOFFbyturningtheStartknobtotheACCpositionand
thenpressinginandturningtotheLockposition.
 • TheKEYindicatorlightwillshowgreenwhentheadvancedkeyis
detected.IftheKEY indicatorlightashesgreen,theadvancedkey
transmitterbatterypowerislow.
Note:EmergencyVehicle
Entry/EngineStart
Iftheadvancedkeycannotbe
usedduetoamalfunctionor
deadtransmitterbattery,usethe
auxiliarykeytolock/unlockthe
doorsandtostarttheengine.
Tostart,removetheStartknob
coverbypressingbothside
releasebuttonsandpullingthe
coveroff.Inserttheauxiliarykey
intothekeycylinderandturnitto
starttheengine.
Thissystemremotelylocksandunlocksthe
doorsandtheliftgate,andopensthepower
windowsandmoonroof.
 • Toextendthekey,pressthereleasebutton.
 • Toretractthekey,pressthereleasebutton
andfoldthekeybackintotheholder.
KEYLESS ENTRY SYSTEM
Release
Button
Lock
Unlock
Panic
Alarm
164817_09a_Mazda CX-7_SSG_080808.indd 3 8/8/08 2:22:53 PM

3
Seats
ELECTRONICALLY OPERATED DRIVER SEAT
Recline Switch
Pushforwardor
backwardtoadjust
seatbackangle.
REAR CENTER POSITION SEAT BELT
•Toconnecttheseatbelt,pulltheseatbeltfromtheceilingrecessand
connecttongueAtobuckleB.
•Toweartheseatbelt,slowlypulloutthelap/shoulderbeltandinsert
tongueCintothebuckleDuntilaclickisheard.
•Tounfastentheseatbelt,depressthebucklebuttontorelease.
Note: Leavetherearcenterlapportionofseatbeltfastenedatalltimesexceptwhen
foldingtherearseat.
1Tostowtheseatbelt,insertakeyorothersmallobjectintotheanchor
buckleslottoreleaseentirebelt.
2Letitfullyretract.
3Then,puttonguesAandCtogetherandinsertsecurelyintoroofrecess.
(A)
(B)
(C)
(D)
Slide/Tilt Switch
Pushforwardorbackwardto
slidetheseatbottom.Theseat
canalsoberaised,loweredor
tiltedwiththiscontrol.
Roof Recess
Anchor Buckle Slot
164817_09a_Mazda CX-7_SSG_080808.indd 4 8/8/08 2:23:25 PM

4
FOLDING SECOND-ROW SEATS
Folding second-row seats
1 Unfastenthelapportionoftherearcenterseatbelt.
2 Supporttheseatbackwithyourhand.
3 Pushtherearseatbackknobdown.
4 Bringtheseatbackforward.
Returning second-row seats to upright position
1 Raiseseatbacksuntiltheylockintoposition.
2 Pullonthetopoftheseatbacksfrominsidethevehicle
tomakesuretheyarelocked.
3 Checkthatallseatbeltsareroutedproperlyforpassengeruse.
LIFTGATE
 • Toopen,pulluponthehandleandraisetheliftgate.
 • Toclose,pushtheliftgatedownwithbothhandsuntilitsecurelylocks,
butdonotslam.
Seatback Knob
Liftgate Handle
164817_09a_Mazda CX-7_SSG_080808.indd 5 8/8/08 2:23:41 PM

Driver’s View (shown with optional
5
LIGHTING/
TURN SIGNAL
HEADLIGHT
LEVELING
TRACTION
CONTROL
SYSTEM
(TSC)
HOOD
RELEASE
TILT STEERING
WHEEL LEVER
(behind steering wheel)
BLUETOOTH
& AUDIO
164817_09a_Mazda CX-7_SSG_080808.indd 6 8/8/08 2:23:53 PM

Driver’s View (shown with optional
6
Navigation System)
WIPER/
WASHER
CRUISE
CONTROL/
BLUETOOTH
HAZARD
WARNING
INFORMATION
DISPL AY
NAVIGATION/AUDIO
DISPL AY
CLIMATE
CONTROL
AUDIO SYSTEM
WITHOUT NAVIGATION
AUXILIARY
POWER POINT
164817_09a_Mazda CX-7_SSG_080808.indd 7 8/8/08 2:24:11 PM

Instrument Cluster
7
Engine Oil Pressure
Tire Pressure Monitoring
System (TPMS)
Check Engine
4WD
Dealer inspection is required
if this light is flashing,
indicating high temperature
differential oil, or if the light
stays illuminated, indicating an
abnormality with the system.
Brake System
ABS
(Antilock Brake System)
TCS OFF
(Traction Control System)
TCS/DSC
(Traction Control System/
Dynamic Stability Control)
Security Indicator
Headlight High Beam
Automatic Transmission
TACHOMETER
GLOSSARY OF WARNING AND INDICATOR LIGHTS
Please see Owner’s Manual for more details and explanations
SPEEDOMETER
TCS
OFF
4WD
INSTRUMENT CLUSTER DIMMER
164817_09a_Mazda CX-7_SSG_080808_IC.indd 1 8/8/08 2:45:38 PM

8
FUEL GAUGE
Shift Position
Air Bag/Front Seat Belt
Pretensioner System
Charging System
Seat Belt
Turn Signal/
Hazard Warning
Door Ajar
Lights On (Exterior Lights)
KEY Warning Light
(RED)Advanced key not
detected or transmitter
battery is dead.
KEY Indicator Light
(GREEN)Advanced key
detected; engine is ready
to start.
Cruise Main Indicator
Light (AMBER)/Cruise Set
Indicator Light (GREEN)
Low Fuel
ENGINE COOLANT
TEMPERATURE GAUGE
GEAR INDICATOR ODOMETER/
TRIP METER
ODOMETER/TRIP
METER SELECTOR
KEY
KEY
164817_09a_Mazda CX-7_SSG_080808_IC.indd 2 8/8/08 2:45:45 PM

Feature Highlights
9
WINDSHIELD WIPER/WASHER
 • MIST-Pushtheleverupforasingleswipetoclearmist.
 • INT-Pushdowntorstposition,rotatetheinnerringforspeedcontrol.
 • LO-Pushdowntosecondposition.
 • HI-Pushdowntothirdposition.
 • Pulllevertowardyoutodispensewasheruid;thewiperswillmake
severalpassesacrossthewindshield.
Rear Window Wiper/Washer
 • Rotatetherearwindowwiper/washeroutercontrolknobtothe
  desiredspeed.
O F F = OFF
INT =Intermittent
ON =Normalspeed
=Rearwash/wipercycle,holdasdesired
More sensitive
Less sensitive
164817_09a_Mazda CX-7_SSG_080808.indd 10 8/8/08 2:24:40 PM

AUTO
WiththeheadlightswitchinAUTOpositionandtheignitionON,the
lightsensordeterminesthesurroundinglightnessordarknessand
automaticallyturnstheheadlights,otherexteriorlightsanddashboard
illuminationonoroff.
10
TURN SIGNAL/LIGHTING CONTROL LEVER
 • Rotatetheouterknobuptotherstpositionfortail,parkingand
dashboardlights.
 • Rotatetheouterknobuptothesecondpositionfortail,parking,
dashboard,andheadlights.
 • RotatetheouterknobuptothethirdpositionforAUTO.
 • Rotatetheinnerringforfoglamps.
 • Pushtheleverawayfromyoutoturnthehighbeamson.
 • Pulltheleverbackonepositiontoturnthehighbeamsoff.
 • Pulltheleverallthewaybackandreleasetoashthehighbeams.
Outer Knob
Inner Ring
164817_09a_Mazda CX-7_SSG_080808.indd 11 8/8/08 2:24:45 PM

Feature Highlights
11
TURBOCHARGER TIPS
Afterdrivingatfreewayspeedsorupalonghill,idleengineatleast30
secondsinordertocoolturbocharger.Avoidshuttingtheengineoff
abruptlyafterahardorlongdriveasturbochargerdamagemayresult.
DoNOTraceorover-revANYenginewhenstarting,particularlya
turbochargedengine.
DoNOTaddaftermarketdevicestoaltertheengine’signition,fueldelivery,
orturboboostpressure,asthismayleadtoseriousenginedamageand
voidyourwarranty.
Fuel: PremiumFuelRecommended–91-93Octane.
Lower Octane Fuel Usage
If91octanefuelisnotavailable,fuelaslowas87octanecanbeused.Use
ofloweroctanefuelcandecreaseperformance;refuelingthevehiclewith
thecorrectoctanefuelacoupleoftimeswillrestorevehicleperformance
andshiftquality.
TheSportATManualShiftModegivesyouthe
feelofdrivingamanualtransmissionbyallowing
youtomanuallyshifttocontrolenginerpmand
torquewhenmorecontrolisdesired.
To Use Manual Shift Mode:
ShifttheleverfromDtoM.
Note: Changingtomanualmode
canbedonewhiledrivingthevehicle.
To Shift Up To A Higher Gear:
Taptheshiftleverback(+)once.
To Shift Down To A Lower Gear:
Taptheshiftleverforward(-)once.
SPORT AT MANUAL SHIFT MODE
164817_09a_Mazda CX-7_SSG_080808.indd 12 8/8/08 2:24:55 PM

12
Indicator Light Auto-Dimming On and OffHomeLink
Auto-Dimming Mirror
 • Auto-Dimmingwillautomaticallydarkenyourrearviewmirrorto
reduceheadlightglarefromvehiclesbehindyou.
 • TheAuto-Dimmingfeatureisactivewhenthevehicleisstartedand
cancelswhenthetransmissioninplacedinReverse.
HomeLink®
 • Thisfeatureprovidesaconvenientwaytoreplaceuptothree
transmitterssuchasgaragedooropeners,homelightingremotes
andotherradiofrequencydevices.
 • RefertoyourOwner’sManualforcompleteprogrammingdetails.
AUTO-DIMMING MIRROR AND HOMELINK®
Light Sensor
164817_09a_Mazda CX-7_SSG_080808.indd 13 8/8/08 2:25:08 PM

Feature Highlights
13
BACK-UP CAMERA (only with Navigation System)
ThisautomaticallyoperateswhenthegearshiftleverisputintoReverse
andisviewableviathenavigationdisplayscreen.
Whenusingtheback-upcamera,pleasecheckyoursurroundingsas
objectsmaybecloserthantheyappear.
Back-up Camera
164817_09a_Mazda CX-7_SSG_080808.indd 14 8/8/08 2:25:16 PM

14
YourvehicleisequippedwithanAUXorauxiliaryjackthatwillallowyouto
playyourMP3playerthroughthevehicle’saudiosystem.
1 LocatetheAUXjackinsidethecenterconsole.
2 PlugyourMP3playerintotheAUXjackandturniton.
3 Turnthevehicleaudiosystemon.
4 PresstheMEDIAbuttonontheaudioface,ortheModebuttononthe
steeringwheelcontrols.
5 UsetheMP3playercontrolstoplaybackmusic.
MP3 PLAYER INTEGRATION USING THE AUX JACK
Note: SetthevolumelevelonyourMP3playertothehighestlevelbeforedistortion
starts.Then,adjustvolumeinthevehicleusingtheaudiosystempower/volume
controlorthesteeringwheelvolumeupanddowncontrols.
164817_09a_Mazda CX-7_SSG_080808.indd 15 8/8/08 2:25:30 PM

Manual Climate Control
15
Note: Applies to Manual and Automatic Climate Control Systems: Withanytype
ofdefrosteroperation(evenintheFLOORmodewheresomeairgoestodefrostto
keepthewindowsdefrosted),thesystemturnsontheA/CandselectstheFRESHAIR
mode.Thishelpsdefrostthewindowsmoreefcientlybydehumidifyingtheair.The
A/Cwillalwaysbeonindefrostermode,butthedefroster(andoor)willdeliverwarm
airwhenthetemperaturedialissettoawarmertemperatureandtheenginewarmsup.
Temperature
control dial
•  P u s h the
buttontoturnAir
ConditioningON
andOFF.
• Rotatetheknob
toselectawarmer
orcoolerair
temperature.
Fan control dial
•  R o tatetheknob
tosetdesiredfan
speed(1-4).
•  P u s h button
torecirculate
cabinair,reduce
exhaustodorsand
increasecooling.
Mode selector dial
• Rotatetheknobto
selectairowmode.
  Dashboard
vents
  Dashboardand
oorvents
  Floorvents
  Defrosterand
oorvents
  Windshield
defroster
  Pushtodefrost
rearwindow
164817_09a_Mazda CX-7_SSG_080808.indd 16 8/8/08 2:25:44 PM

Information Display Functions
 • Clock
• AudioDisplay
 •  B l u e t o o t h ®Hands-FreeDisplay
 • ClimateControlDisplay
 • AmbientTemperatureDisplay
 • PassengerAirBagOffIndicator
Pushtodefrostthefrontwindshield.
Pushtoselectdesiredairow.
Pushtomanuallyturnon/offandcontroltheairconditioning
system.Rotatefanspeeddialtodesiredfanspeed.
Pushtorecirculatecabinairandreduceoutsideexhaust,
odorsandimprovecooling.
Pushtodefrosttherearwindow.
Pushtodisplaytheambienttemperatureinthe
InformationDisplay.
AUTOMATIC AIR CONDITIONING
1 PushAUTOdialtoturntheautomaticairconditioningsystemon.
2 RotateAUTOdialtothedesiredcabinairtemperaturesetting
(shownintheInformationDisplayabove).
3 PushOFFdialtoturnclimatecontrolsystemoff.
Automatic Climate Control
16
Information Display
164817_09a_Mazda CX-7_SSG_080808.indd 17 8/8/08 2:25:53 PM

Audio Controls Without Navigation
17
Audio System On
 • PressthePOWER/VOLUME
buttontoturntheradioon.
Media selection
• FM1/2
• AM
• SAT(SIRIUSTMSatelliteradio)
• CD
• MEDIA
(toswitchtoAUXjackinput)
Note: IftheFMbroadcastsignal
becomesweak,receptionautomatically
changesfromSTEREOtoMONOfor
reducednoise,andthe“ST”indicator
willgoout.
SAT:SIRIUSTMSatelliteradiowill
deliverthebroadest,deepestmixof
radioentertainment.SeeOwner’s
Manualformoredetails.
Tuning
Theradiohasthefollowing
tuningcontrols:
• MANUAL
 • TRACK/SEEK
 • SCAN
 • PRESETCHANNEL
 • AUTO-M
Manual tuning
 • TurningtheTUNEdialwill
changethefrequencyhigher
orlower.
Seek tuning
 • PressingtheTRACK/SEEK
tuningbuttonwillseeka
higherorlowerfrequency
automatically.
1. Turntheignitionswitchtothe
ACCorONposition.
2 . PressandholdtheCLOCK
buttonfor1-1/2secondsuntil
thedisplayedtimeashes.
3 . UseHtosethoursandMto
setminutes,thenpressthe
CLOCKbutton.
SETTING YOUR CLOCK
164817_09a_Mazda CX-7_SSG_080808.indd 18 8/8/08 2:26:00 PM

18
Scan tuning
 • PresstheSCANbutton
toautomaticallysample
strongstations.
 • Toholdastation,press
theSCANbuttonagain
duringthisinterval.
Preset channel tuning
The6presetchannelscanbeused
tostore6AMand12FMstations.
 • Tosetachannel,rstselect
AM,FM1,orFM2.
 • Tunetothedesiredstation.
 • Pressandholdapresetbutton
untilabeepisheard.
 • Repeatthisoperationforthe
otherstationsandbandsyou
wanttostore.
Auto-memory
Thisisespeciallyusefulwhen
drivinginanareawherethelocal
stationsarenotknown.Additional
AM/FMstationscanbestored
withoutdisturbingthepreviously
setchannels.RefertoyourOwner’s
Manualforcompletedetails.
164817_09a_Mazda CX-7_SSG_080808.indd 19 8/8/08 2:26:08 PM

Audio Controls With Navigation
19
Audio System On
 • Pressabandselectorbutton
(FM/AM)toturntheradioon.
Media selection
 • Presstheappropriatebutton:
FM/AM,SAT(SIRIUSTMSatellite
radio),CD,MEDIA(toswitchto
AUXjackinput)
Tuning
 • Theradiohasthefollowing
tuningmethods:Manual,Seek,
Scan,Presetchannel,and
auto-memorytuning.
Manual tuning
 • PresstheSEEKTUNEbutton
tochangethefrequency
higherorlower.
Seek tuning
 • PressandholdtheSEEKTUNE
button toautomatically
seekahigherorlower
frequencyortrack,depending
onmediaselected.
Note: Ifyoucontinuetopressandhold
thebutton,thefrequencywillcontinue
changingwithoutstopping.
Scan tuning
 • PresstheSCANbutton
toautomaticallysample
strongstations.
 • Toholdastation,pressthe
SCANbuttonagainduring
thisinterval.
Audio
 • PresstheAUDIObuttonto
displaytheaudioscreen.
164817_09a_Mazda CX-7_SSG_080808.indd 20 8/8/08 2:26:18 PM
