MB QUART N1-RFBT Instruction Manual

Surface Mounting
Battery Replacement
CAUTION
Always consider consulting a professional audio installer
before installing any audio components. Be careful and take
your time. Do not let wires make contact with metal edges or
hot engine components.
Congratulations on your choice of a MBQuart Bluetooth
controller. This “Quick Start” Installation guide is meant to
help you complete a basic installation. For more detailed
information, visit our website at MBQuart.com
The controller can be mounted on any flat surface using the surface
mount cradle. This will allow the controller to be removed for use in
hand as well as kept in the cradle when not in use.
Before drilling any holes make sure there are no obstructions behind
the mounting surface. Also make sure there is enough space around
the cradle to remove and replace the controller easily.
The controller battery can be changed by sliding the access door
downward.
This method will allow the controller to sit flush to the mounting
surface. This requires a perfectly flat surface and ideally should have
access to the rear of the mounting panel.
Before drilling the mounting hole, make sure there are no
obstructions behind the mounting area.
The wiring and connections should be secure and away from any
moving parts or extremely hot surfaces.
The RCA pre amp output can be connected directly to an amplifier.
The RCA aux input can be used to connect a secondary source.
The remote input wire should be connected to a switched +12V
source.
The remote output wire provides a +12V output to turn on an
amplifier.
Flush Mounting
Wiring
55mm
2.18” (2-3/16”)
35mm (1-3/8”)
minimum clearance
+12V (red)
REMOTE OUT
REMOTE IN (blue)
USB Charger
Status Indicator
GROUND (black)
PRE AMP OUT
AUX IN
CR2032

Quick Start
Installation Guide
WARRANTY
Maxxsonics USA Inc. warrants this product, to the original consumer purchaser, to be free from
defects in material and workmanship for a period of one (1) year from the date of purchase.
Maxxsonics USA Inc. will, at it’s discretion, repair or replace defective products during the warranty
period.Componentsthatprovetobedefectiveinmaterialsandworkmanshipunderproperinstallation
and use must be returned to the original authorized Maxxsonics USA Inc. retailer from where it was
purchased. A photocopy of the original receipt must accompany the product being returned. The
costs associated with removal, re-installation and freight are not the responsibility of Maxxsonics
USA Inc. This warranty is limited to defective parts and specifically excludes any incidental or
consequential damages connected therewith. To view the full warranty, please visit the website.
MBQuart products are designed and engineered in the USA by
847-540-7700
www.maxxsonics.com
N1-RFBT
N1-RFBT
Wireless Bluetooth
Wireless Bluetooth®
Controller
Controller
MBQ N1-RFBT QSG 01 - rev4
Volume UP - Each press will increase the volume.
Volume DOWN - Each press will decrease the volume.
Track UP - Press to advance to the next track.
Track DOWN - Press to restart the current track or to back up to previous tracks.
PLAY / PAUSE - Press once to pause. Press again to play.
Mode - One press will toggle between Bluetooth function and the auxiliary input.
Controls
Bluetooth Device Pairing
Auxiliary Input
Volume DOWN
Volume UP
Track DOWN
PLAY / PAUSE
Track UP
Mode
1
3
4
6
5
2
1
2
3
4
5
6
The pairing process can vary based on your particular device.
Refer to the operating instructions of your device. Below is the
general process to connect the controller.
A secondary device can connected through the AUX INPUT.
Pressing the MODE button will switch to this input. The status
indicator will change to solid red.
The status indicator will flash slowly when “searching” for the last paired device. If no
device is located, it will flash quickly indicating it is ready to pair to a new device.
On your Bluetooth enabled device, search for “MB QUART” under Bluetooth settings.
Select MB QUART, wait for the device to indicate “connected”.
The status indicator will change to solid blue.
Music will now play through the system.
