mbt Lighting LEDDANCER48 User manual

LEDDANCER48
User Manual
Please read this user manual before using this product.

Features
Voltage: AC100-240V 50Hz/60Hz
Power: 20W
Light source: 1*3W Red, 1*3W Green, 1*3W Blue LEDs
4operation modes: Automatic running, DMX, Sound Active, Master/Slave
Sound controlled via built-in microphone
6 DMX channels
Advantages of LED-technology: extremely long life, low power
consumption minimal heat emission, defacto maintenance free with
brilliant light radiation
INTRODUCTION
Thank you for choosing our LEDDANCER48, you will see you have
acquired a powerful and versatile device.
DMX512 Controller instruction
ON
OFF
Function
CH 1
………….
Red dimmer
CH 2
Green dimmer
CH 3
Blue dimmer
CH 4
Open light
CH 5
Strobe
CH6
…….
Motor
DIP control instruction
Address code
Address code
Function instruction
ON
OFF
1
2.3.4.5.6.7.8.9,10
Sound
active(Master),auto run
when no sound
1,2
3.4.5.6.7.8,9,10
Slow run(when no
sound)
1,3
2.4.5.6.7.8,9,10
Quick run(when no
sound)
9
1.2.3.4.5.6.7.8.10
All bright, motor auto
run
1.2.3.5.6.7.8.9,10
Slave 1(DMX)
10
1.2.3.4.5.6.7.8.9
Slave 2
1,2,3,4,5,6,7,8,9
DMX
Safety instruction
This device has left our premises in absolutely perfect condition. In order
to maintain this condition and to ensure a safe operation, it is absolutely
necessary for the user to follow the safety instructions and warning notes
written in this manual.
Please note: information is subject to change without prior
notice.
CAUTION!
Be careful with your operations. With a dangerous voltage you can
suffer a dangerous electric shock when touching the wires！
Electric shock when touching the wires!
