MC VISTA MEDIUM HANGING Instruction manual

ASSEMBLY AND INSTALLATION
INSTRUCTIONS
MEDIUM HANGING UNIT
18" / 24" / 30" / 36"
1-844-969-4247
suppor[email protected]

ASSEMBLY AND INSTALLATION INSTRUCTIONS
MEDIUM HANGING UNIT - 18" / 24" / 30" / 36"
N
OPQ
M
AB
CD
E
HG
F
IJK
1
FRONT FRONT
FINISHED EDGE FINISHED EDGE
FINISHED EDGE
TOOLS REQUIRED
(purchased separately)
1.1
1.2
Lay parts out on a protective surface to prevent damage. Tip: Spread out the cardboard packaging to use as a
protective surface.
Inventory parts against the Parts List. Make sure all parts are present before proceeding.
PARTS LIST
A
B
C
D
E
F
G
Left Side Panel
Right Side Panel
Set Shelf (Qty 2)
Adjustable Shelf (Qty 2)
Rear Cleat (Qty 2)
Hanging Rod (Qty 1)
"O" Rod Bracket (Qty 1)
H
I
J
K
L
M
"U" Rod Bracket (Qty 1)
Cam Post (Qty 16)
Camlock (Qty 16)
Screw (Qty 4)
Shelf Pins (Qty 8)
Screws, 3" (Qty 6)
N
O
Level
Stud Finder
P
Q
Drill, 3/32" bit size
Phillips Screwdriver
L

ASSEMBLY AND INSTALLATION INSTRUCTIONS
MEDIUM HANGING UNIT - 18" / 24" / 30" / 36"
2
3
3.1 Assemble Set Shelves (C) and Rear Hanging Cleats (E) onto Right Side Panel (B)
by sliding the Shelves and Cleats onto the Cam Posts (I) on Right Side Panel. BE
SURE dowel pins in Shelves and Cleats engage drilled holes in Right Side Panel,
and all parts are pressed flush against Right Side Panel.
IMPORTANT NOTES
Install Set Shelves (C) with finished edges
facing forward (toward front of unit).
Install Rear Hanging Cleats (E) with holes
for Cam Locks facing the rear of the unit and
the unfinishededge against the Set Shelf (C).
Install upper Set Shelf (C) with holes for Cam
Locks facing the top of the unit.
Install lower Set Shelf (C) with holes for Cam
Locks facing the bottom of the unit.
2.1 Install one Cam Post (I) into each of the eight holes on Left Side Panel (A)
and Right Side Panel (B). Tighten until Cam Posts are seated against Side
Panels.
I
I
B
A
CE
I
B
CE
I

ASSEMBLY AND INSTALLATION INSTRUCTIONS
MEDIUM HANGING UNIT - 18" / 24" / 30" / 36"
4
5
5.1
5.2
Insert Camlocks (J) in holes in Set Shelves (C)
and Rear Hanging Cleats (E), with arrow pointing
toward Cam Post opening. Be sure Camlocks engage
Cam Posts, and are fully seated in Shelves and
Cleats.
Tighten Camlocks (J) clockwise to lock.
ARROW TOWARD
CAM POST OPENING
3.1 Install Left Side Panel (A) onto
assembled Set Shelves (C) and
Rear Hanging Cleats (E). BE SURE
dowel pins in Shelves and Cleats
engage drilled holes in Left Side
Panel, and Left Side Panel is pressed
flush against Set Shelves and Cleats.
A
B
E
C
E
C
J
J
J
J

ASSEMBLY AND INSTALLATION INSTRUCTIONS
MEDIUM HANGING UNIT - 18" / 24" / 30" / 36"
INSTALLATION
6
6.1
6.2
6.3
Determine the mounting location for the unit.
Using a stud finder, locate studs to which the unit will be secured. Mark stud locations with a pencil.
With the unit positioned at the desired location, level the unit, then drill pilot holes through Rear Hanging Cleats (E),
NOTE: For 18" and 24" units, it is likely that only one stud will pass through the unit. In these cases, use two screws
through each Rear Hanging Cleat.
STANDARD
HEIGHT
-
84" FROM
FLOOR
PILOT HOLES
STUDS
E
E

ASSEMBLY AND INSTALLATION INSTRUCTIONS
MEDIUM HANGING UNIT - 18" / 24" / 30" / 36"
7
7.1 Secure Rear Hanging Cleats (E) to studs using 3" Screws (M).
E
M
E
M

ASSEMBLY AND INSTALLATION INSTRUCTIONS
DOUBLE HANGING UNIT - 24" / 30" / 36"
8
8.1 Position "U" Bracket (H) on Left Side Panel (A) and secure Bracket with two screws (K).
K
K
H
A
H

ASSEMBLY AND INSTALLATION INSTRUCTIONS
MEDIUM HANGING UNIT - 18" / 24" / 30" / 36"
9
9.1
9.2
9.3
Insert one end of Hanging Rod (F) into "O" Bracket (G).
Slide assembled Hanging Rod (F) and "O" Bracket (G) into unit. Rest free end of Hanging Rod in "U" Bracket.
Secure "O" Bracket (G) to Right Side Panel (B) with two Screws (K).
NOTE: Use care when installing Hanging Rod (F) to avoid scratching finish inside unit.
G
K
K
F
F
G
B

ASSEMBLY AND INSTALLATION INSTRUCTIONS
MEDIUM HANGING UNIT - 18" / 24" / 30" / 36"
10
10.1
10.2
For each Adjustable Shelf (D), insert
four Shelf Pins (L) into pin holes inside
the Tower at the desired height.
Rest Adjustable Shelves (D) on Shelf
Pins (L).
D
L
LL
L
