190366 Rev. 1 08.16.04 BY
ILLUSTRATED PARTS BREAKDOWN
PRO MAC
6.0 HORSEPOWER
22" REAR DISCHARGE LAWN MOWER
MODEL NO. PM655FWG (PM655FWGC)
964 79 57-00

2
ROTARY LAWN MOWER - - MODEL NUMBER PM655FWG (PM655FWGC) PRODUCT NUMBER 964 79 57-00

3
ROTARY LAWN MOWER - - MODEL NUMBER PM655FWG (PM655FWGC) PRODUCT NUMBER 964 79 57-00
KEY PART NO. NO. DESCRIPTION
1 532 18 52-42 Control Bar 2 532 17 76-98 Upper Handle 3 532 15 50-44 Lower Handle 4 532 17 95-85 Rope Guide 5 - - - Engine, Briggs & Stratton, Model Number 122K02 (Order parts from Engine Manufacturer) 6 532 13 19-59 Handle Bolt 7 532 06 64-26 Wire Tie 8 532 18 33-65 Hex Washer Head Screw 1/4-20 x 3 9 532 17 02-94 Throttle Control
10 532 14 66-94 Screw, Self-Tapping 1/4-20 11 532 13 08-61 Engine Zone Control Cable 14 532 17 01-46 Handle Knob 15 532 05 17-93 Hairpin Cotter 16 532 14 76-25 Footguard 17 532 13 20-04 Locknut, Hex 1/4-20 19 532 18 45-90 Blade Adapter 20 532 14 11-14 Blade, 22" 22 532 08 86-52 Screw, Hinge 1/4-20 x 1-1/4 23 532 17 09-47 Kit, Rear Door (Includes Key #61 and #63) 24 532 75 15-92 Locknut, Hex 3/8-16 25 532 18 68-19 Handle Bracket Assembly, LH 26 532 18 68-18 Handle Bracket Assembly, RH 27 532 15 00-78 Thread Cutting Screw 5/16-18 x 3/4 28 532 11 11-90 Cable Clamp 29 532 15 50-47 Wheel Adjusting Bracket 30 532 14 66-30 Spacer 31 532 08 38-16 Screw #10 x 5/8 32 532 14 17-30 Selector Spring 33 532 17 01-43 Selector Knob 34 532 14 98-57 Axle Arm Assembly 35 532 06 23-35 Belleville Washer 36 532 14 27-48 Shoulder Bolt 3/8-16 37 532 16 76-28 Wheel & Tire Assembly, Rear
KEY PART NO. NO. DESCRIPTION
38 532 08 39-23 Nut, Hex, Flangelock 3/8-16 40 532 18 06-60 Hub Cap 41 532 12 84-15 Pop Rivet 42 532 12 53-48 Rear Baffle 43 532 05 45-83 Hex Head Tapping Screw 1/4-20 x 1/2 44 532 15 04-06 Hex Head Thread Rolling Screw 3/8-16 x 1-1/8 45 532 16 68-00 Back Plate 46 532 18 21-66 Danger Decal 47 532 13 88-60 Side Baffle 48 817 60 04-06 Screw, Hex Head, Serrated, Type TT 1/4-20 49 874 10 04-12 Screw, Machine, Flat Head 1/4-20 x 3/4 50 532 75 11-52 Nut, Hex, Flangelock 1/4-20 51 532 17 04-91 Kit, Front Baffle (Includes Key Numbers 48, 49 and 50) 52 532 19 02-75 Kit, Lawn Mower Housing
(Includes Key Numbers 42, 45, 46, 47 and 51)
53 532 85 10-84 Hex Head Machine Screw 3/8-24 x 1-3/8 Grade 8 54 532 85 02-63 Helical Washer 3/8-24 x 1-3/8 Grade 8 55 532 85 10-74 Hardened Washer 56 532 18 08-57 Discharge Baffle 57 532 15 00-50 Self-Tapping Screw #10-24 58 532 16 66-49 Mulcher Plug 59 532 18 49-41 Engine Pulley 60 532 18 77-23 Hi-Pro Key 61 532 17 09-38 Spring, Rear Door, LH 62 532 18 20-02 Debris Shield 63 532 17 09-39 Spring, Rear Door, RH 64 532 18 41-93 Bolt, Rear Door 65 532 12 50-78 Washer, Engine
- - 532 18 21-34 Decal, Warning (not shown) - - 532 19 03-64 Operator’s Manual, European - - 532 19 03-65 Operator’s Manual, Scandinavian NOTE: All component dimensions given in U.S. inches 1 inch = 25.4 mm

4
ROTARY LAWN MOWER - - MODEL NUMBER PM655FWG (PM655FWGC) PRODUCT NUMBER 964 79 57-00

5
ROTARY LAWN MOWER - - MODEL NUMBER PM655FWG (PM655FWGC) PRODUCT NUMBER 964 79 57-00
KEY PART NO. NO. DESCRIPTION
1 532 18 45-87 Drive Control 2 532 16 73-87 Bearing, Wheel Adjuster 3 532 75 11-52 Nut, Hex, Flangelock 1/4-20 4 532 15 87-55 Hex Washer Head Screw 1/4-20 x 2-1/8 5 532 14 65-27 V-Belt 6 532 15 04-95 Spring Retainer 7 532 08 60-12 Driveshaft Cover 8 532 18 06-60 Hubcap 9 532 14 52-12 Nut, Hex, Flangelock
10 532 17 01-51 Drive Cover 11 532 18 07-67 Wheel & Tire Assembly , Front 12 812 00 00-58 E-Ring 13 532 13 70-54 Pinion 14 532 18 05-04 Dust Cover 15 532 17 22-91 Kit, Wheel Adjuster, LH
(Includes Knob and Bearing) KEY PART NO. NO. DESCRIPTION
16 532 06 77-25 Washer 1/2 x 1-1/2 x .134 17 532 17 22-90 Kit, Wheel Adjuster, RH
(Includes Knob and Bearing)
18 532 17 01-43 Selector Knob 19 532 16 99-31 Frame, Grassbag 20 532 19 10-22 Grassbag 21 873 80 04-00 Nut, Hex 22 532 13 20-10 Nut, Hex, Flanged, Zinc Plated 3/8-16 23 532 18 94-07 Drive Pulley 24 532 18 72-11 Gear Case Assembly (See Breakdown) 25 532 13 70-90 Spring 26 532 14 60-72 Hex Washer Head Screw #10-24 x 3/4 27 532 14 97-46 Screw, Slotted, Torx #10-24 x 1-3/4 28 532 07 51-92 Spring
NOTE: All component dimensions given in U.S. inches 1 inch = 25.4 mm

6
ROTARY LAWN MOWER - - MODEL NUMBER PM655FWG (PM655FWGC)
PRODUCT NUMBER 964 79 57-00
GEAR CASE ASSEMBLY - PART NUMBER 532 18 72-11
KEY PART
NO. NO. DESCRIPTION
1 532 18 34-97 Case, Lower
2 532 18 34-98 Case, Upper
3 532 18 34-99 Gear, 27 Teeth
4 532 18 35-00 Lever, Clutch
5 532 18 35-01 Spring, Return
6 532 18 35-02 Shaft, Input
7 532 18 35-03 Dog, Movable
8 532 18 35-04 Dog, Fixed
9 532 18 35-05 Wire, Formed
10 532 18 35-06 Bearing, Ball
11 532 18 35-07 Fork, Shift
12 532 18 35-08 Seal, Output Shaft
13 532 18 35-09 Washer
14 532 18 35-10 Seal, Case
15 532 18 35-11 Bushing
16 532 18 75-21 Shaft, Output
17 532 18 35-13 Screw
18 532 18 35-14 Seal, Input Shaft
NOTE: Use Dow Corning #709 to reseal Gear Case Halves.
NOTE: All component dimensions given in U.S. inches.
1 inch = 25.4 mm
