McCulloch PM655HW Setup guide

190343 01.09.04 BY
ILLUSTRATED PARTS BREAKDOWN
PRO MAC
6.0 HORSEPOWER
22" SIDE-DISCHARGE LAWN MOWER
MODEL NO. PM655HW (PM655HWB)
964 79 59-00

2
ROTARY LAWN MOWER - - MODEL NUMBER PM655HW (PM655HWB) PRODUCT NUMBER 964 79 59-00

3
ROTARY LAWN MOWER - - MODEL NUMBER PM655HW (PM655HWB) PRODUCT NUMBER 964 79 59-00
KEY PART NO. NO. DESCRIPTION
2 532 18 14-56 Control Bar 3 532 17 95-85 Rope Guide 4 532 17 42-06 Upper Handle 5 532 17 42-91 Lower Handle 6 532 06 91-80 Locknut 1/4-20 7 532 13 19-59 Handle Bolt 5/16-18 8 532 17 02-94 Throttle Control 9 532 18 33-65 Screw 10 532 11 11-90 Clamp 11 532 13 08-61 Engine Zone Control Cable 12 532 75 06-34 Hex Thread Rolling Screw #10-24 x1/2 13 532 12 51-62 Up-Stop Bracket 14 532 08 38-16 Screw 16 532 17 01-46 Handle Knob 19 532 05 17-93 Hairpin Cotter 21 532 15 41-47 Footguard 22 532 06 64-26 Wire Tie 23 532 16 08-31 Discharge Guard 27 532 16 08-32 Torsion Spring 30 532 16 08-33 Hinge Rod 33 873 80 05-00 Locknut 5/16-18 34 532 17 44-13 Wheel Bracket Support (Left) 35 532 17 44-14 Wheel Bracket Support (Right) 36 532 16 57-04 Wheel Bracket Adjuster 39 532 16 85-99 Selector Spring 40 532 17 01-43 Selector Knob 41 532 18 36-62 Axle Arm Assembly (RR) 43 532 18 39-01 Washer 44 532 16 08-28 Shoulder Bolt KEY PART NO. NO. DESCRIPTION
45 532 18 13-83 Wheel Assembly (Rear) 46 532 08 39-23 Locknut 1/16-18 47 532 15 71-78 Wheel Assembly (Front) 50 532 18 06-60 Hubcap 51 874 76 05-14 Hex Head Bolt 5/16-18 x 3/4 52 532 15 04-06 Hex Head Thread Rolling Screw 3/8-16 x 1 55 532 18 21-66 Danger Decal 59 532 18 52-63 Lawn Mower Housing (Incl. Key No. 55) 61 532 18 45-90 Blade Adapter 62 532 1411-14 22" Blade 63 532 8510-74 Hardened Washer 64 532 8502-63 Helical Lockwasher 3/8 65 532 8510-84 Hex Head Screw 3/8-24 x 1/4 Grd. 8 67 - - - Engine, Briggs & Stratton, Model Number 122K02 (Order parts from engine manufacturer) 70 532 18 36-61 Axle Arm Assembly (LR) 72 532 18 92-77 Axle Arm Assembly (LF) 73 532 18 92-78 Axle Arm Assembly (RF) 74 532 16 67-85 Nut, Hex 75 532 16 08-30 Plate, Mulcher 76 532 16 16-22 Clip, Closeout 77 532 08 58-25 Hex Head Screw 1/4 80 532 13 20-04 Nut, Hex - - 532 18 21-91 Warning Decal (Not Shown) - - 532 18 52-58 Operator’s Manual, European - - 532 18 52-60 Operator’s Manual, Scandinavian NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
