McIntosh MC312 Instruction manual

MC312 Connection Diagram
1A
McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903-2699 Phone: [phone] www.mcintoshlabs.com Part No. 04188400
DISABLED
Note: Refer to the MC312 Owner’s Manual page 7 for additional connection information.
Connection Legend:
Data Cable*- Digital Signal Cable -
Sensor/Keypad Cable - Network/RS232 Cable -
Power Control Cable* - Ground Wire -
Audio Signal Cable - AC Power Cords -
Video Signal Cable - Loudspeaker Cable -
RF Signal Cable -
* 2 conductor shielded with 1/8 inch stereo mini phone plug on each end.
Connect to
AC Outlet
Audio Preamplifier
Left Loudspeaker System
-+
Right Loudspeaker System
-+

MC312 Bi-Amp Connection Diagram
1B
McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903-2699 Phone: [phone] www.mcintoshlabs.com
DISABLED
DISABLED
Audio Preamplifier
Power Amplifier
One
Connect to
AC Outlet
Note: Refer to the MC312 Owner’s Manual page 9 for additional connection information.
Connection Legend:
Data Cable*- Digital Signal Cable -
Sensor/Keypad Cable - Network/RS232 Cable -
Power Control Cable* - Ground Wire -
Audio Signal Cable - AC Power Cords -
Video Signal Cable - Loudspeaker Cable -
RF Signal Cable -
* 2 conductor shielded with 1/8 inch stereo mini phone plug on each end.
Connect to
AC Outlet
Power Amplifier
Two
Left Loudspeaker System
-+
Right Loudspeaker System
-+
-+
-+
