MDHearing AV Series User manual
User Manual
QuietTV Wireless Headphones • Series AV
With QuietTV Wireless Headphones, you can enjoy crystal-clear TV at the volume
you need. QuietTV Headphones utilize the latest digital hearing technology to
clarify voices and reduce the background noise. Easy-to-use controls let you
customize your sound, so your TV can be turned down or even muted completely.
For best results, please read this User Manual in its entirety.
Congratulations
Our U.S.-based team of licensed audiologists and hearing specialists
are the heart and soul of MDHearing. They’re here to guide and assist
you with any questions you may have.
We’re here to help.
844-589-5584
Monday–Friday (Visit MDHearingAid.com/contact-us
for current hours of operation)
24 hours a day, 7 days a week
Table of Contents
Package Contents ..............5
QuietTV Diagram ...............6
Plug In ........................7
Charge........................8
Connect.......................9
Wear ........................13
Adjust Volume/Tone ...........14
Care & Cleaning ...............16
Replacing Domes..............17
Ordering Parts & Protection .....18
Troubleshooting...............19
Safety Warnings...............21
Warranty & Replacements ......22
Return Policy .................23
........25
Notice of Cancellation..........26
Package Contents*
*Contents will vary depending on quantity ordered.
a) Headphone(s)
d) Domesc) Audio Cords
b) Transmitter
LED Indicators
(Power/Cradle 1/Cradle 2)
5
Aux RCAOptical
Power Adapter Cord
QuietTV Diagram
Volume Dial
LED Indicators
(Power/Cradle 1/Cradle 2)
Headphone Arms
Ear Domes
Transmitter/Base
Charging Cradles
Audio Ports
Red = Power
Yellow = Optical
Green = Analog
Tone Dial
6
Plug in the transmitter
Step 1: Plug In
b)
a)
c)
White Light
Power Cord
(USB)
Power
Adapter
a) Connect the power cord USB to the power
adapter.
b) Connect the other end of the power cord
to the red “power” port on the back of the
transmitter.
c) Plug the power cord adapter into
a standard electrical outlet. Once the
transmitter is connected, a white power
light on the transmitter will turn on.
7
a) Place headphones into the transmitter’s
charging cradle with the front facing you. You
cradle and turn on when removed.
b) A blue light will turn on to indicate “charging”.
c) When fully charged, the blue light will turn
headphones. On average, a full charge lasts
5–7 hours.
White/Blue
Lights
Charge the headphones
Step 2: Charge
White Light = Power
connection/plugged in
Blue Light = Charging
O = Fully charged
8
Connect to your TV
Step 3: Connect
Digital
Audio Out
3.5mm/Aux
Audio Out
RCA
Audio Out
9
a) Select the Optical Audio Cord. Remove the
plastic caps from both ends of the Optical
Audio Cord.
b) Look for an “optical audio out” or “digital
audio out” port on the back of your TV. Plug
either end of the Optical Audio Cord into this
port.
c) Plug the other end into the yellow “optical”
port on the back of the transmitter.
Please note: If you get static after connecting the Optical Audio Cord, you
may need to change your TV’s digital audio setting from Dolby/DTS Digital
to “PCM”. Every TV is dierent, but it should be similar to: Settings > Audio
Settings > Digital Audio Out Format > Change from Dolby or DTS to PCM.
Digital Optical
10
a) Select the 3.5mm Aux Audio Cord.
b) Find the “audio out” port on the back of
your TV and plug in either end of the Aux
Audio Cord.
c) Plug the other end into the green “analog”
port on the back of the transmitter.
Please note: If both the Optical and Aux are
connected, the Optical takes priority.
Analog Aux/3.5mm
11
a) Select the 3.5mm RCA Audio Cord and the
3.5mm Aux Audio Cord. Connect the single
(black) end of the RCA cord to your Aux cord.
b) Find the “audio out” port on the back of
your TV and plug in the dual (red and white)
ends.
c) Plug the other end into the green “analog”
port on the back of the transmitter.
Analog RCA
12
Place headphones on ears
Step 4: Wear
b)
a)
a) Remove headphones from the charging
cradle and gently separate the arms of the
headphones.
b) With the logo facing away from your body,
place the earpieces into each ear.
13
Adjust the volume and tone
Step 5: Enjoy TV
b)
a)
QuietTV Headphones use a volume dial (left
side when wearing) and tone dial (right side
when wearing). The volume dial also functions
a) Rotate the volume dial to turn on power.
b) The light on the front of the headphones
will turn green to indicate “on”. It will turn red
when there is less than 20% power.
c) Experiment with the volume and tone dials
Volume
Dial
Tone
Dial
Green/Red
Light
Green Light = On
Red Light = Less than 20%
14
The headphones and transmitter pair automatically in one (1) second.
The transmitter can be paired with an unlimited number of headphones.
Pairing Information
Please note: The headphones will automatically go into standby mode
(turn o) after 10 minutes if there is no audio signal detected from the
transmitter (e.g. TV is turned o for 10 minutes). To exit standby mode,
rotate the volume dial to the o position, wait one (1) second, and then
rotate the volume back on.
15
Care and Cleaning
The headphones can be cleaned with a dry
tissue or soft cloth. Do not use water, alcohol,
or other liquid agent as they may cause
damage.
Use a cleaning tool brush to remove dust,
earwax, or other debris from the ear domes.
Visit www.MDHearing.com/accessories
or call 844-589-5584 to order cleaning
accessories.
16
Replacing Domes
a) Remove dome: Hold the earpiece with one
hand.
b) Attach dome: Push a new dome over the
ridges on the end of the earpiece.
Please note: If you require a dierent size,
please call 844-589-5584 for alternative
dome options.
17
For optimal performance, proper care and maintenance are imperative.
In addition to regularly cleaning your domes, you should also replace
them every 3 months. Over time, these items wear out and may become
your QuietTV headphones sounding and feeling like new.
If you’d like to protect your headphones beyond the one-year warranty,
MDShield™Protection Plan for total coverage
against any accidental damage and more. Call us today for detailed
information about coverage and cost.
Ordering Parts and Protection
Visit www.MDHearing.com/accessories or call 844-589-5584
to order protection, domes, and other accessories.
18
Troubleshooting
Issue:
Headphones have weak or no sound.
or low volume.
Make sure the volume dial is turned on and
Solution:
The headphones battery
may not be charged.
Place the headphones on the charging cradle
(see page 8).
Wax or debris may be
blocking the sound.
Clean the ear domes (see page 16) and ear
canal. Replace the domes if they appear worn.
The headphones may
be out of range.
Move within 100 feet of the transmitter.
19
