MDR Electronics MX-3242 User manual

MX VGA HDDB 15
PIN MALE TO VGA
HDDB 15 PIN MALE,
MX-3242
MDR Electronics
www.mdrelectronics.com

http://www.mdrelectronics.com/| © at MDR Electronics 2010 Page 2
Table of contents
1. Introduction 3
2. Images 4
3. Specifications 5
4. Warranty 6

http://www.mdrelectronics.com/| © at MDR Electronics 2010 Page 3
INTRODUCTION
Congratulations on purchase of MX- 3242, VGA HDDB 15 PIN MALE TO VGA HDDB
15 PIN MALE cable.
MX has a product range of over 3500 products. MX categories include Home theater
Cables and Connectors, Computer/Laptop Accessories, Pro Audio/Studio Cables and
Connectors, Audio/Video Components and Accessories, Fiber Optic Components and
Accessories, Cable TV Components and Accessories.
Manufactured To Meet or Exceed Ul Vw-1 Standards, Ferrite Cores, Double Shielded
(Foil and Braided), Quality Hp-15 Connectors, Molded Connectors, Easy To Use
Screws Caps, Lengths from 1.5M’ To 50M’, Male-To-Male or Male-To-Female Ends
3 Analog & 8 Signal Connectors.
MX APPLE SERIES is a special design patented by MDR Electronics with the following
features:
1. RUBBERIZED FIRE PROOF- FLEXIBLE WHITE JACKET.
2. GOLD PLATED CONTACTS PROVIDE FULL CONDUCTIVITY WITHOUT
GHOSTING AND DATA LOSS
3. DUAL-MOULDED WHITE SHELLS (CONNECTORS) PROVIDE DURABILITY
AND INCREASE STRENGTH AT CABLE ENTRY POINT.
4. IT’S GOT THE APPLE (WHITE COLOR) LOOK TO IT.
Our Commitment
There are many outstanding technological innovations in the world. Through innovative
thinking we are committed to enriching the lives of people all around the world. It
aspires us to go beyond and touch people in ways that could make their lives more
satisfying. We continuously aim to exceed our customer’s expectations.

http://www.mdrelectronics.com/| © at MDR Electronics 2010 Page 4
IMAGES
MX-3242
THERE ARE AT LEAST FOUR VERSIONS OF THE VGA CONNECTOR, WHICH ARE
THE THREE-ROW 15 PIN DE-15 (ALSO CALLED MINI SUB D15) IN ORIGINAL AND
DDC2 PINOUTS, A LESS FEATUREFULL AND FAR LESS COMMON 9-PIN VGA,
AND A MINI-VGA USED FOR LAPTOPS. THE IMAGE AND BELOW TABLE ARE THE
NEWER 15-PIN VGA VESA DDC2 CONNECTOR PINOUT.
Connector Size: 32.5mmW x 16.3mmH x 48.0mmL
Ferrite Core distance from the end of the connector face: ~95mm
Ferrite Core Size: 20.4mm (diameter) by 34.7mm long
Wire Size: Signal Wire Size: 24 AWG - 2.4mm (Insulator core)
Connector: HP-15 - Screw size is 4/40 locknut (standard in the USA &
Canada)
LENGTH FROM 1.5 METER TO 50 METER MOLDED AVAILABLE.
FEATURES:
Your Life Deserves a Great Picture. Get it with High Performance
VGA.
VGA: The Connection
These days, you want to connect your laptop, desktop, or media computer
to different kinds of displays: desktop monitors, home theater HDTVs, and
meeting room projectors. The problem is, there may not be an HDMI™ or
DVI connection you can hook up to. The best choice When HDMI or DVI
aren’t an option is VGA.

http://www.mdrelectronics.com/| © at MDR Electronics 2010 Page 5
MX VGA Delivers the Best Possible Picture
MX High Performance VGA is engineered to deliver the best possible
picture to the largest PC monitors, projectors, and HDTVs. Advanced MX
cable construction helps maximize signal transfer, so your movies, games,
and presentations maintain their true color with razor sharp clarity.
Long Length For Convenience
Best of all, the extra-long cable gives you the freedom to make long
connections for easy hookup in your home theater, home office, or large
meeting rooms. We have VGA cables upto 100METERS.
SPECIFICATIONS
VGA CONNECTOR PINOUT:-
Note: Direction is Computer relative Monitor. All VGA pinout signals except R, G, B are TTL
level signals
Pin
Name
Dir
Description
1
RED
Red Video (75 ohm, 0.7 V p-p)
2
GREEN
Green Video (75 ohm, 0.7 V p-p)
3
BLUE
Blue Video (75 ohm, 0.7 V p-p)
4
ID2
Monitor ID Bit 2
5
GND
Ground
6
RGND
Red Ground
7
GGND
Green Ground
8
BGND
Blue Ground
9
KEY
-
Key (No pin)
10
SGND
Sync Ground
11
ID0
Monitor ID Bit 0
12
ID1 or SDA
Monitor ID Bit 1
13
HSYNC or CSYNC
Horizontal Sync (or Composite Sync)
14
VSYNC
Vertical Sync
15
ID3 or SCL
Monitor ID Bit 3

http://www.mdrelectronics.com/| © at MDR Electronics 2010 Page 6
WARRANTY
MDR Electronics gives warranty on the equipment it manufactures to be
free from defects in material and workmanship. If equipment fails because
of such defects and MX is notified within ONE year from the date of
shipment, MX will, at its option, repair or replace the equipment, provided
that the equipment has not been subjected to mechanical, electrical, or
other abuse or modifications. Equipment that fails under conditions other
than those covered will be repaired at the current price of parts and labor in
effect at the time of repair.
This warranty is in lieu of all other warranties expressed or implied,
including without limitation, any implied warranty or merchantability or
fitness for any particular purpose, all of which are expressly disclaimed.
THE WARRANTY IS VOID IF THE SEAL OF THE PRODUCT IS
BROCKEN
The information in this manual has been carefully checked and is believed
to be accurate. However, MX assumes no responsibility for any
inaccuracies that may be contained in this manual. In no event will MX, be
liable for direct, indirect, special, incidental, or consequential damages
resulting from any defect or omission in this manual, even if advised of the
possibility of such damages. The technical information contained herein
regarding Product features and specifications is subject to change without
notice.
For the latest warranty coverage information, please visit:
http://www.mdrelectronics.com/warranty.asp

http://www.mdrelectronics.com/| © at MDR Electronics 2010 Page 7
ASKING FOR ASSISTANCE
Technical Support:
Telephone: [phone]
Fax: [phone]
Technical Support HRS:
10.00AM to 7.00PM (IST)
Monday to Saturday
Write to:
MDR Electronics
Unit No 5/K, Laxmi Industrial Estate,
New Link Road, Andheri (West),
Mumbai 400053
India
[e-mail]
www.mdrelectroncs.com
