MECHLINE AQUAJET AJPR50-2 Installation guide

installation &care instructions REVISION: 04/2018 | page 1 of 4
GENERAL ADVICE
Please follow these instructions carefully to ensure
trouble free operation.
• Inspect the product for damage carefully before installation.
No claims for damage can be accepted after installation.
• Ensureallpipeworkisushedfreeofdebrisbeforeinstallation.
• Installation must be in accordance with local authority regulations.
• Werecommendaservicevalveisttedtothehot&coldsupplies.
• Ensure supply pipes are properly sized to avoid problems with
 owrate,pressurelossorwaterhammer.
•
Werecommendtheinstallationisprotectedwithwaterlters,
water-hammer arrestors and water pressure reducers as required.
• Do not install where there is the possibility of the water
supplies freezing.
• Recommended minimum water pressure 1.5 Bar (22.5psi).
Maximum water pressure 5 Bar (75psi).
• Maximum recommended water temperature 55ºC (131ºF).
• Leave this Manual with the operator after installation.
Thank you for purchasing your AquaJet product.
INSTALLATION &
CARE INSTRUCTIONS
AJPR50-2 - PRE-RINSE PRODUCT

installation &care instructionsREVISION: 04/2018 | page 2 of 4
AquaJet Pre-Rinse Products
AJPR50 INSTALLATION
1.1 Remove the transit screws before installation.
1.2 Measure and mark any guides for mounting at a height of 1120mm from sink top to allow for an
  adequateairbreakgap,topreventpotentialwaterbackow.
NOTE: The pre-rinse hose coils will relax with use and allow the gun to hang slightly lower.

installation &care instructions REVISION: 04/2018 | page 3 of 4
AquaJet Pre-Rinse Products
Cont’d...
 1.3 Securelyxthewallboxtoasolidwallsurfaceusingappropriatexings.Ifpossible,usethe
screw caps supplied.
1.4 Connect the water hose to the water inlet/isolation valve using a thread
sealing compound or PTFE tape.
IMPORTANT: Do not twist valve during installation. To ensure a secure t
use a 24mm spanner to hold the valve in place when tightening hose to valve.
1.5 Test unit for water leaks.
1.6 The gun hook is used to store the gun out of the way when not in use.
Install in an appropriate position that is convenient for the operator.

©2018 All rights reserved. All material on these pages, including and without limitation text, logos, icons, photographs and all other artwork, is copyright
material of Mechline Developments Ltd, unless otherwise stated. Commercial use of this material may only be made with the express, prior, written
permission of Mechline. This includes material provided by any third party, including material obtained through links to other sites from Mechline’s pages
or its affiliates and commercial associates. Material and information included are correct at time of print. Intending buyers and users must satisfy themselves
as to the suitability and safety of the products for their particular purposes and duties. Dimensions shown in mm unless otherwise stated. Product accreditation
may not apply to all products in the relevant range. Please contact Mechline to confirm. Unless otherwise stated, all products carry a warranty of twelve (12) months
against manufacturing defect or workmanship on parts with no inclusion for labour or site attendance.
04/2018 (AJPR50-2-MANUAL)
MAINTENANCE & CLEANING
Ensure isolation valve is always in the CLOSED position when unit is not in use.
When cleaning the pre-rinse unit wipe over with clean water using a clean disposable cloth.
Do not use abrasive, chlorine or acid-based cleaning products. Avoid contact with concentrated
bleach. Do not over-extend or twist the coiled water hose or gun.
TECHNICAL ASSISTANCE
For technical help please call 01908 267713 or e-mail [e-mail]
