MEDA 159388A User manual

BOLTZERO BUNK BED
MODEL: 159388A & 159388B
NEED ASSISTANCE?
Call 4D CONCEPTS directly for parts or assembly assistance.
Individual stores do not stock parts
Call our Toll-free number 5 days a week except holidays:
Monday through Friday 8:00am to 5:00pm
Pacific Standard Time
1-888-310-4DCO or 1-888-310 4326
www.4dconceptsusa.com
IMPORTANT: Before calling please have the model number and the packing code
number ready for our customer service representatives. You will find the model
number printed on the carton label and the packing code printed in black ink on the
side of the carton.
Model 159388A & 159388B Packing Code
It is important that you retain the model number and the packing code along with the
original receipt of purchase for future reference.
20160727
MODEL:159388A & 159388B
Page 1 - 8

• Important: Please read these instructions fully before
starting assembly.
• Do not discard any of the packaging until you have
checked that you have all the parts and the pack of
fittings.
• Discard all extra fittings and keep fittings out of reach
of children.
• Assemble this product on a flat and protected surface.
• Assemble all parts and bolts loosely during assembly,
only once the product is complete should you fully
tighten the bolts.
• Assemble this product as close to its final position (in
the same room) as possible.
• At least 2 people are required to assemble this
product.
Warnings:
• This product should only be used on firm, level
ground.
• Make sure the legs remain in contact with the ground.
• Do not stand on the product.
Care and maintenance:
• Please clean the product using either damp (not wet)
cloth and a mild domestic soap solution or by using an
appropriate polish.
• Do not use abrasive materials when cleaning.
• From time to time, check that there are no loose bolts
on this unit.
BOLTZERO BUNK BED
Assembly Instructions - Please keep for future reference
Safety and Care Advice
MODEL: 159388A & 159388B
MODEL:159388A & 159388B
Page 2 - 8

1
2
1
2
2
1
1
1
1
1
44
1
2
3
4
5
6
7
8
9
10
11
BACK LEFT END POST
FRONT LEFT/BACK RIGHT END POST
FRONT RIGHT END POST
UPPER SIDE RAIL
LOWER SIDE RAIL
LOWER FRONT RAIL
LOWER BACK RAIL
LADDER
UPPER FRONT SAFETY RAIL
UPPER BACK SAFETY RAIL
SLATS
QTY.DESCRIPTIONCODE
Parts List:
16
7
4
A
B
C
LONG CAP
SHORT CAP
HOOK & LOOP FASTENER
QTY.DESCRIPTIONCODE
Fittings List:
1
5
7
4
5
9
10
4
6
11
2
x22
11 x22
Arrow up
sticker (1)
sticker (2)
sticker (2)
sticker (3)
3
2
8
holes
MODEL:159388A & 159388B
Page 3 - 8

Step 1
Step 2
3
5
5
2
2
1
2
2
5
5
sticker (1)
sticker (2)
sticker (2)
sticker (3)
4
3
4
2
1
2
MODEL:159388A & 159388B
Page 4 - 8

Step 3
Step 4
1
2
6
7
6
7
3
2
holes
MODEL:159388A & 159388B
Page 5 - 8

Step 6
Step 5
6
1
10
2
Arrow up
6
8
x2
C
C
C
C
8
MODEL:159388A & 159388B
Page 6 - 8

Step 7
Step 8
8
9
3
2
10
9
6
7
11
11
x22
11 x22
9
a:
b:
8
9
9
3
x2
C
C
C
C
MODEL:159388A & 159388B
Page 7 - 8

Step 9
1
2
4
5
5
6
7
3
2
4
10
9
B
BB
B
B
B
B
A
A
A
A
A
A
AA
AA
A
A
A
A
A
A
x16
A
x7
B
x7
2
9
B
B
AA9
x16
MODEL:159388A & 159388B
Page 8 - 8
