medalounger Modulax User manual

1 of 19
User Manual

03 of 19
Your Modulax recliner is built to last, using the nest materials
available on the market. That said, there are a number of points
that must be followed to ensure your new purchase lasts for as
long as possible. Some of these might seem obvious but we don’t
like to leave anything to chance when it comes to our products.
Further to this, we cannot accept claims if the directions of use and
maintenance are not followed.
GUIDANCE FOR USE OF YOUR
‘MODULAX’ RECLINER

05 of 19
How to open/unpack?
At all times when moving the recliner, make sure to take your time
and be very careful. It is best to do this with at least 2 people.
Setup
Starting with the box in its
upright position, carefully lay
the box onto its side.
Open the bottom of the
box so the aps are facing
outwards.
Push the recliner back to its
original upright position.
Lift the box up and put aside.
Then remove the plastic
wrapped around the recliner,
as well as the cardboard
protection on the feet.
Unpack the charger and
cables.
Connect the end of the cable
to the charging point on the
back of your recliner, and
plug the other end of the
cable into a socket **
01
02
04
05
06
03
* Please note: do not remove or change the position of the wiring underneath the
recliner. This is assembled in a specic way that should not be altered.
** If your recliner contains a chargeable battery, remember to remove the cable
once it is fully charged.

07 of 19
• Your recliner is made for indoor use only; make sure it is set up
in a suitable location inside your home.
• Ensure the room you choose has a normal level of humidity. A
room that is too dry or too humid can be detrimental to the
integrity of the material.
• Ensure the recliner is not exposed to direct sunlight or placed
too close to a heat source (e.g. a radiator or heater). Direct sunlight
can cause discolouration in the leather of fabric.
• Ensure there is enough space for the recliner to be fully
extended in all directions, bearing in mind the swivel function.
• Ensure the recliner is placed close enough to a power source so
the cable is not pulling. Also make sure it is in a place where there
is no danger of someone tripping over the cable when plugged in.
General UsageWhere to place your recliner?
•Do not sit down
heavily in the
recliner.
•Do not rest your full
weight on the foot-
rest when it is in the
extended
position.
•Do not sit on the
armrests.
•Do not allow
children of 14 years
or younger to use the
recliner unless
supervised by an
adult.
•Do not pull on the
armrests to assist
you in getting in or
out of the recliner.
•Do not push or pull the
recliner across the oor.
If you wish to move the
recliner, it must be care-
fully lifted by 2 or more
persons.

09 of 19
Maintenance
Moving parts always need to be well lubricated to help them move
smoothly and function correctly. It is possible that during transpor-
tation the lubricant applied can get slightly dried out. Before using
your recliner for the rst time we therefore recommend to apply
a lubricant to the footrest. This is something that is good to do for
your recliner approximately once every six months.
Please see below for the areas of application:
Charging
• It takes approximately 8 hours to fully charge the battery from
empty.
• PLEASE NOTE ONCE YOUR RECLINER IS FULLY CHARGED,
YOU MUST TAKE OUT THE CABLE! DO NOT LEAVE THE RECLINER
PERMANENTLY CHARGING!
(for recliners with chargeable battery only)
All 3-motor Modulax recliners are also available with a power lift
mechanism! This raises the whole chair to help you stand up with
minimum stress to your body.
Please note:
1. When the lift function is activated, the turning base will
automatically stop rotating for your safety.
2. The usual 3rd motor function with ‘heart balance position’ is
replaced by the lift function. It is not possible to have both in the
same recliner.
Power Lift Mechanism

11 of 19
It is then important to carry out a more thorough cleaning of the
recliner at least once every 3-6 months. We strongly advise to keep
it simple when choosing your cleaning materials and avoid using
any DIY creations that you might read about online or elsewhere.
(Please note: If you wish to use a specic leather-cleaning product,
we suggest you ask your retailer for guidance on which products
they recommend).
We recommend the following steps for a complete clean:
1. Remove dirt with a microber cloth, or use a vacuum cleaner
with a soft brush/upholstery attachment.
2. Create a cleaning solution using a few drops of a PH-neutral,
non-detergent liquid soap, and mix this with distilled water.
Dampen a clean microber cloth with this solution and lightly wipe
down the recliner, from top to bottom.
3. Dampen another microber cloth with distilled water
only and wipe down the recliner again.
4. Finally, lightly dry the recliner with a clean towel.
We also recommend using a good leather conditioner every 6 to 12
months. This will help keep the leather soft and supple. Ask your
retailer for recommendations on suitable products.
Any new product you wish to use for cleaning your leather recliner,
we suggest you test a small amount rst in an inconspicuous place,
e.g. somewhere on the back, just to see how the leather reacts and
ensure there are no adverse eects.
Leather can be damaged slowly over time by exposure to all the
usual substances that one might expect in the home: humidity,
perspiration, tobacco smoke, bacteria and other sources of dirt.
Fortunately, it is quite low-maintenance so make sure to follow the
guidance given here to protect your recliner.
It is important to give your recliner a regular light clean, ideally
once a week. This can be as simple as a light dusting to remove
dirt, followed by a wipe down with a damp, microber cloth (only
use distilled water, or boiled water that has cooled to room
temperature). Leave to air dry or dry with a clean towel.
Cleaning Guidance:
Leather is a wonderful, natural material that is extremely long
lasting, as long as it is cared for in the correct manner. There are a
few points that it is important to remember when it comes to your
leather recliner:
• Since leather is a natural material, it is normal for it to stretch
slightly after a while.
• It can happen that leather bears scars from insect bites, scratch-
es, small wrinkles in the skin or other natural marks. These small
aesthetic defects do not aect the quality of the leather. This is
also part of what gives leather a specic and unique character
when compared to synthetic materials.
• The original density/rmness of the foam can also decrease with
time.
Leather

13 of 19
For spills and stains:
To minimise damage done by any spills, it is best to clean as soon
as possible. The longer you wait, the more likely it will be to leave a
permanent stain.
If you nd a stain cannot be removed, try to clean it with the mix
of PH-neutral, non-detergent liquid soap and distilled water, as
described above.
In general, if you’re not sure how to clean your leather recliner, or
you have a particularly dicult stain, contact a leather cleaning
professional or your retailer for advice.
Oil-based spills
dab the stain with a dry,
white, microber cloth.
Do not use water.
Water-based spills
e.g. soda, tea, juice: quickly wipe o
the spill with a clean, white cloth lightly
dampened in distilled water, and then
leave it to air-dry (never use a hair
dryer or similar to dry the product after
cleaning).
All of our fabrics are carefully selected not only for their design
and touch but also their durability. There are a few points that it is
important to remember when it comes to your fabric recliner:
• Certain objects and materials, for example wristwatches, jeans
or anything with a rough surface, can cause damage to the fabric
upholstery.
• The elasticity of the seat may decrease slightly with time,
depending on the intensity of use.
• The original density/rmness of the foam can also decrease with
time.
To care for your fabric recliner we recommend a regular
cleaning every 3-6 months, taking the following steps:
1. Remove dirt with a microber cloth, or use a vacuum cleaner
with a soft brush/upholstery attachment.
2. Create a cleaning solution using a few drops of a PH-neutral,
non-detergent liquid soap, and mix this with distilled water.
Dampen a clean microber cloth with this solution and lightly wipe
down the recliner, from top to bottom.
3. Dampen another microber cloth with distilled water only and
wipe down the recliner again.
4. Finally, lightly leave the recliner to air dry or dry with a clean
towel.
Fabric

15 of 19
For spills and stains:
*To minimise damage done by any spills, it is best to clean as soon
as possible. The longer you wait, the more likely it will be to leave a
permanent stain.
If you nd a stain cannot be removed, try to clean it with the mix
of PH-neutral, non-detergent liquid soap and distilled water, as
described above.
In general, if you’re not sure how to clean your fabric recliner, or
you have a particularly dicult stain, contact a cleaning
professional or your retailer for advice.
* The guidance provided in this instruction manual is to be used at your
own discretion and no claim may be made based on the information
provided. All content is subject to change.
Oil-based spills
dab the stain with a dry,
white, microber cloth.
Do not use water.
Water-based spills
e.g. soda, tea, juice: quickly wipe o
the spill with a clean, white cloth lightly
dampened in distilled water, and then
leave it to air-dry (never use a hair
dryer or similar to dry the product after
cleaning).
MODULAX RECLINERS
BUTTON FUNCTIONS GUIDE
Remote Type A Button Functions
Recline the backrest
Return backrest
to upright position
a) In starting position, raise the
seat height by 8 degrees.
b) In a relaxed position, incline
an extra 8 degrees.
Reverse the function of
button 3, returning seat
to original position
Raise the footrest
Lower the footrest
01
02
03
04
05
06
Recline the backrest
01
02
03
04
05
06
(Please refer to the guide relevant to your recliner)

17 of 19
Remote Type C FunctionsRemote Type B Functions
USB charging port
07
Warning!
**For safety purposes, be careful
when using the memory button that
the area around the recliner is clear of
any possible obstructions. **
Recline the backrest
Return backrest to upright
position
a) In starting position, raise
the seat height by 8 degrees.
b) In a relaxed position,
incline an extra 8 degrees.
Reverse the function of
button 3, returning seat to
original position
Recline the backrest
Raise the footrest
Press and hold to return
all functions to the original
upright position Memory Function 2
This works exactly the same as S8, so
you can use S9 to save a second
position. Follow the instructions as
above to save your second position
USB charging point
01 01
01
01
01
01
01
01
01
01
Memory Function 1
This button allows you to save your favourite
position for the recliner functions.
Step 1: Starting from the original upright
position, use buttons S1-S6 to reach the
position that you would like to save. For
example, you may want to have the
footrest completely raised and the
backrest halfway reclined.
Step 2: Once you have reached your
desired position, press S8 and hold it for
3-5 seconds. You should hear a small
“beep” sound, this means that your
position is saved.
Now, any time that you press S8
(just press, don’t hold), the recliner will
automatically go to your saved position
S1 S8
S9
S10
S2
S3
S4
S5
S6
S7
03
01
02
03
04
05
06
Return backrest
to upright position
a) In starting position, raise the
seat height by 8 degrees.
b) In a relaxed position, incline
an extra 8 degrees.
Reverse the function of
button 3, returning seat
to original position
Raise the footrest
Lower the footrest
Recline the backrest

19 of 19
[email protected]
Copyright © 2020 Up2date – Medalounger Ltd
Lift Remote Functions
Recline the backrest
Return backrest to upright
position
Lift the recliner
(power lift function)
Return recliner to starting
position
Raise the footrest
Lower the footrest
01
01
01
01
01
01
L1
L2
L3
L4
L5
L6
**Please note: recliner will automatically stop rotating when in power lift mode. Only when recliner is completely
back in the starting position will it be possible to rotate.**
