Medion AMBIANO MD17500 User manual

25 L MICROWAVE OVEN
WITH GRILL & CONVECTION
User Manual

Dok./Rev.-Nr. IMA MD17500 Cover V3.1
Overview ......................................................................................... 3
Use.................................................................................................... 3
Appliance parts ............................................................................... 4
About these operating instructions............................................... 7
Safety information .......................................................................... 9
About microwaves .........................................................................19
Cooking with the microwave ....................................................... 20
Package contents.......................................................................... 23
Display ........................................................................................... 24
Before first use .............................................................................. 25
Operation....................................................................................... 27
Cleaning and care ......................................................................... 39
Storage ..........................................................................................40
Troubleshooting.............................................................................41
Disposal...........................................................................................41
Technical specifications ................................................................ 42
Declaration of Conformity............................................................. 42
Service information ...................................................................... 43
Legal Notice ...................................................................................44
Contents

3
C
1 2 3 4 5
6
7
8
910
11
12
13
14
15
16
17
18
A
B

4
Appliance parts
1Viewing window
2Turntable
3Top grill
4Magnetron cover (DO NOT REMOVE!)
5Light
6Power cord
7Control panel
8Door lock
9Turntable shaft
10 Bottom grill
11 Grilling rack
12 Display: Shows cooking time, power, operating mode and time
13 Menu: Set auto program
14 Navigate up the menu, set weight/cooking time
15 Navigate down the menu, set weight/cooking time
16 Cancel input or reset appliance
17 Quick start / confirm input / start operation
18 Set mode

Contents
5
Contents
Overview ......................................................................................................... 3
Use ................................................................................................................... 3
Appliance parts ............................................................................................... 4
About these operating instructions ............................................................... 7
Key to symbols..................................................................................................... 7
Safety information .......................................................................................... 9
Proper use ............................................................................................................9
Safety of children and persons .........................................................................9
Hot surfaces ........................................................................................................13
Special safety instructions for handling microwaves ...................................15
Safety instructions for heating liquids ............................................................17
Cleaning and caring for the appliance ...........................................................17
About microwaves .........................................................................................19
Cooking with the microwave........................................................................ 20
Microwave-safe materials ...............................................................................20
Materials of limited suitability.......................................................................... 22
Unsuitable materials......................................................................................... 22
Package contents ...........................................................................................23
Display ........................................................................................................... 24
Before first use ...............................................................................................25
Setting up the appliance..................................................................................25
Heating the empty appliance .........................................................................26
Inserting the accessories ................................................................................. 26
Operation........................................................................................................27
Setting the time................................................................................................. 27
Setting the kitchen timer (countdown) ......................................................... 27
Child safety lock................................................................................................. 27
Cooking with microwave energy....................................................................28
Quick start...........................................................................................................29
Automatic defrosting by weight or time........................................................30
Grill or combination mode ...............................................................................30

Contents
6
Hot air...................................................................................................................31
Using several programs ................................................................................... 32
Automatic cooking ............................................................................................ 32
Cleaning and care.......................................................................................... 39
Storage .......................................................................................................... 40
Troubleshooting............................................................................................. 41
Disposal .......................................................................................................... 41
Packaging ............................................................................................ 41
Device................................................................................................... 41
Technical specifications................................................................................. 42
Declaration of Conformity............................................................................. 42
Service information....................................................................................... 43
Legal Notice ................................................................................................... 44

About these operating instructions
7
About these operating instructions
Thank you for choosing our product. We hope you enjoy using it.
Read the safety instructions carefully before using the appliance for
the first time. Note the warnings on the appliance and in the operating
instructions.
Always keep the operating instructions close to hand. If you sell the appliance or give
it away, please ensure that you also pass on these operating instructions. They are an
essential component of the product.
Key to symbols
If a block of text is marked with one of the warning symbols listed below, the hazard
described in that text must be avoided to prevent the potential consequences
described there from occurring.
DANGER!
This keyword denotes a high-risk hazard situation which results in death or serious
injury if it is not avoided.
WARNING!
This keyword denotes a medium-risk hazard situation which can result in death or a
serious injury if it is not avoided.
CAUTION!
This keyword denotes a low-risk hazard situation which can result in moderate or
minor injuries if it is not avoided.
NOTICE!
This keyword serves as a warning for possible damage to property.
This symbol provides useful additional information for assembling or
operating the appliance.

About these operating instructions
8
Warning: danger due to hot surfaces!
Comply with the notes in the operating instructions.
AC
Protective earthing symbol (For protection class I)
Electrical appliances in protection classI are electrical appliances that
have at least basic insulation throughout and have either a plug with
earth contact or a fixed power cord with protective earth. Electrical
appliances in protection class I can have parts with double or reinforced
insulation, or parts which are operated with safety extra-low voltage.
Indoor use
Appliances with this symbol are intended solely for indoor use.
Food-safe surface
The Australian Regulatory Compliance Mark (RCM) is a single compliance
mark used by suppliers after establishing compliance with all applicable
regulations, including EMC, telecoms, radio comms, electromagnetic
radiation (EMR) and electrical safety.

Safety information
9
Safety information
IMPORTANT SAFETY INSTRUCTIONS – READ CAREFULLY AND KEEP FOR
FUTURE REFERENCE!
Proper use
The microwave may only be used for heating up appropriate
foodstuffs in microwave-suitable containers and dishes. It may
not be used outside!
This appliance is designed for use in private households. The
appliance is not designed for use in commercial, industrial areas
or in laboratory environments.
− Please note that we shall not be liable in cases of improper use.
− Comply with all the information in these operating instructions,
especially the safety information. Any other use is considered
improper and can cause personal injury or property damage.
Safety of children and persons
WARNING!
Risk of injury!
Risk of injury for children and people with reduced physical,
sensory or mental capacity (for example, partially disabled people
or older persons with impaired physical and mental capacity) or
with a lack of experience and/or knowledge (for example, older
children).
− Keep the appliance and its accessories out of the reach of
children.
− This appliance can be used by children 8 years and older, and
by people with reduced physical, sensory or mental capacity,
or with a lack of experience and/or knowledge, but only with
proper supervision, or if they have been instructed about how
to use the appliance safely, and have understood the risks
involved.

Safety information
10
− Children must not be allowed to play with the appliance.
− Cleaning and user maintenance must not be carried out by
children without supervision.
− Do not allow children less than 8 years of age near the
appliance and its power cord, unless they are under constant
supervision.
DANGER!
Risk of injury!
Risk of choking and suffocation through swallowing or inhaling
small parts or plastic wrap.
− Do not store any of the packaging material used (bags,
polystyrene, etc.) within the reach of children.
− Do not allow children to play with the packaging material.
WARNING!
Warning – risk of electric shock!
There is a risk of electric shock due to live parts.
− Before using for the first time and after each use, check the
microwave and the power cord for damage.
− Do not use the microwave if the microwave or the power cord
shows signs of damage.
− Make sure that the power cord is not damaged and does not
run underneath the microwave or across hot surfaces or sharp
edges.
− Unwind the power cord completely.
− Do not kink or pinch the power cord.
− Contact the Service Centre without delay if the appliance has
been damaged during transport.
− Only connect the appliance to a properly installed earthed
power point that complies with electrical safety requirements.

Safety information
11
The supply voltage must match the technical specifications for
the appliance.
− The power point must be readily accessible so that you can
unplug the appliance from the power quickly if necessary.
WARNING!
Risk of injury!
There is a risk of injury from microwave radiation.
− If the appliance is damaged, microwave radiation can escape
through a leak. Damage to the power cord can cause an electric
shock.
− If there is damage to the housing, covers, door to the cooking
compartment or the door-closing mechanism, do not use the
microwave under any circumstances. If this happens, turn the
safety power point off immediately and pull the power cord out
by the plug. Do not operate the microwave again until it has
been repaired by a person trained to do so.
− WARNING! It is dangerous for all other people apart from a
specially trained person to carry out any service or repair work
requiring the removal of a cover that provides protection
against radiation exposure from microwave energy.
− Do not, under any circumstances, make any unauthorised
modifications to the appliance or try to open a component and/
or repair it yourself. Only have your microwave and power cord
repaired by a suitably qualified workshop, or contact Customer
Service in order to avoid hazards.
− Do not remove any covers in the interior compartment of the
microwave or the film on the inside of the viewing window, as
microwave radiation can otherwise escape.
− Only use replacement parts or accessories that we have
supplied or approved.

Safety information
12
The microwave must not be immersed in water or other liquids,
held under running water or used in damp rooms because this
can result in an electric shock.
− Switch the microwave off at the power point and pull out the
plug:
−when cleaning the appliance,
−if it is unsupervised,
−if the appliance is no longer in use.
− Protect the microwave from dripping or splashing water. Avoid
contact with water or other liquids. Keep the appliance, the
power cord and the plug away from basins, sinks or similar. If
liquid does get into the appliance, switch off the safety power
point immediately and pull the plug out. Have the appliance
checked by a suitably qualified workshop.
− Never touch the appliance or the power cord with wet hands.
DANGER!
Risk of explosion!
There is a risk of explosion when operating the appliance in
potentially explosive environments.
− Do not use the appliance in areas where there is a risk of
explosion. This includes, for example, fuel pumps, fuel storage
areas or areas in which corrosive agents are processed. This
appliance should also not be used in areas where the air is
contaminated with particles (e.g. flour or sawdust).
NOTICE!
Possible damage to property!
There is a risk that the appliance may be damaged if not set up
correctly.

Safety information
13
− Place the microwave on a level, stable surface that can bear the
weight of the appliance itself plus the maximum weight of the
quantity of food prepared in it.
− Only use the appliance indoors.
− Do not expose the appliance to extreme conditions. Avoid:
−high humidity or wet conditions,
−extremely high or low temperatures,
−direct sunlight,
−open flame.
− Do not set the microwave up near heat sources.
Chemical additives in furniture coatings can damage the material
of the appliance feet and leave residues on the surface of the
furniture.
− If necessary, place the appliance on a heat-resistant underlay.
Hot surfaces
DANGER!
Risk of explosion!
When water is mixed with oil, it can ignite or even explode.
− Do not heat any mixtures of water and oil or fat in the
microwave.
− Do not defrost any frozen fat or oil in the microwave.
WARNING!
Risk of injury!
The appliance and its accessible parts become hot during use.
There is a risk of injury from hot surfaces.
− Do not touch the housing.
− Avoid touching the heating elements inside the oven.

Safety information
14
− Do not allow children less than 8 years of age near the
appliance unless they are under constant supervision.
− In combination mode or grilling mode, children may only
use the appliance under adult supervision due to high
temperatures.
− The turntable becomes very hot after cooking with the grill!
Always use oven mitts or heat-resistant gloves when you
remove the turntable from the cooking compartment.
WARNING!
Risk of fire!
There is a risk of fire if very high temperatures/hot appliance
surfaces are not handled correctly.
− Do not place objects on top of the microwave. Ensure clearance
of 30 cm above and 20 cm on either side of the appliance for
adequate ventilation. The surface on which the appliance is
placed should be at a minimum height of 85 cm (see fig. C). Do
not cover or block the openings on the appliance.
− The appliance must be placed with its back wall against a wall.
− The microwave is designed as a free-standing appliance. Do
not operate it in a built-in cabinet or a cupboard.
− Never leave the appliance unattended while it is in use.
− The microwave is not designed to be operated with an external
timer switch or a separate remote control system.
− When heating or cooking foods in flammable materials such as
plastic or paper containers, check on the microwave frequently
due to the possibility of ignition.
− The microwave may only be used to heat food suitable for the
microwave in suitable containers and dishes.
− Do not use baking paper in grill or combination mode.
− The microwave is designed to heat food and drinks. Drying
food or clothing and heating heat packs, slippers, sponges,

Safety information
15
damp cleaning cloths or similar can result in injuries, ignition or
fire.
− Do not cook any dishes containing alcohol. Do not deep-fry or
heat oil with the appliance.
− In order to avoid sparking, load the turntable evenly so that it
does not touch the internal metal wall of the appliance during
operation.
− If smoke develops, it is crucial to keep the oven door closed to
prevent ignition or to smother any existing flames. Switch off
the appliance immediately by turning off the power point and
pulling out the plug.
− Only use the standard packs of popcorn labelled as being
intended for preparation in the microwave.
− Never exceed the cooking times specified by the manufacturer.
− Do not store any food or other objects in the cooking
compartment.
Special safety instructions for handling microwaves
WARNING!
Risk of injury!
There is a risk of injury from containers bursting.
− Do not heat any foods or liquids in firmly sealed containers.
They may explode in the appliance or result in injuries when
opened. Always remove the lids of sealable containers, such as
e.g. baby bottles.

Safety information
16
CAUTION!
Risk of injury!
There is a risk of injury from burns.
− Foods prepared in the microwave may heat unevenly. Test
the temperature of the heated food before consuming. When
heating baby food and baby bottles, always stir or shake the
infant food to avoid burns.
− Do not cook eggs in their shells or heat whole hard-boiled eggs
in the microwave, as they may explode while cooking and also
after they are taken out. Only cook eggs in microwave dishes
designed for that purpose.
− Prick food items with sealed skins, such as tomatoes, sausages,
eggplant or the like, before cooking in order to prevent them
from bursting.
− When cooking containers are opened (e.g. bags of popcorn,
containers with lids) hot steam will escape. Always keep the
opening away from your body when you open the container.
− When the cooking compartment is opened, hot steam will
escape. Keep your distance.
− During the cooking cycle, the surfaces of the microwave, the
accessories and the cooking dish become very hot. Use oven
mitts. Allow the items to cool before you clean them.
NOTICE!
Possible damage to property!
There is a risk that the appliance will be damaged if it is handled
incorrectly.
− Never operate the appliance without the turntable or without
food in the cooking compartment.
− Only use the accessories provided or those described as
suitable in these operating instructions.

Safety information
17
− Never use dishes with metal decoration or metal dishes in
the microwave because sparking can result in damage to the
appliance or to the dish.
− Use microwave-safe dishes. When buying dishes, look for labels
such as ‘microwave safe’ or ‘for microwave use’.
− Do not move the appliance when it is in use.
Safety instructions for heating liquids
CAUTION!
Risk of injury!
There is a risk of injury from burns.
− When heating liquids in the microwave, so-called boiling
delay can occur, meaning that the liquid is already at boiling
temperature without the typical bubbles occurring. If shaken,
e.g. when being taken out of the microwave, the liquid can
suddenly boil up. Liquid may suddenly spurt out.
− Do not use tall, narrow containers.
− When heating, place a glass or ceramic rod in the container
to prevent delayed boiling up of the liquid. Wait briefly after
heating, tap the container cautiously and stir the liquid before
removing the container from the cooking compartment.
Cleaning and caring for the appliance
NOTICE!
Possible damage to property!
There is a risk that the appliance will be damaged if it is handled
incorrectly.
− Incorrect use of cleaning products on the appliance can result
in the surfaces becoming damaged. Do not use aggressive

Safety information
18
chemical cleaning products, abrasive cleaners or hard
scourers/sponges.
− The appliance must not be cleaned with a steam cleaner. Steam
can penetrate the interior of the appliance and damage the
electronics and surfaces.
− Failure to clean the microwave adequately can result in the
surface being destroyed, which in turn affects its useful life and
may possibly result in dangerous situations.
− Clean the appliance regularly and remove food residues.
− When cleaning the cooking compartment and adjacent parts,
observe the cleaning instructions. See “Cleaning and care” on
page 39.

About microwaves
19
About microwaves
Microwaves are high-frequency electromagnetic waves that cause your food to heat
up in the cooking compartment. Microwaves heat all non-metal objects. For this
reason, do not use any metal objects when operating the microwave. The more water
is contained in the food, the better the heating works.
In order to achieve ideal heat distribution, leave meals in the microwave for one or
two minutes after you have finished heating them to allow them to continue to cook.
The effect of microwaves on food
• Microwaves penetrate the food to a depth of around 3 cm.
• They heat the water, fat and sugar molecules (foods with a high water content
are heated most intensely).
• This heat then slowly penetrates the entire meal and results in the defrosting,
heating and cooking of the food.
• The cooking compartment and the air in the cooking compartment are not
heated (the food container is heated mainly through the hot food).
• All food requires a certain amount of energy for cooking or defrosting –
according to the rule of thumb: High power – short time or low power – long
time.
The microwave appliance
• A microwave generator known as the magnetron produces the microwaves and
directs them into the cooking compartment.
• The cooking compartment walls and viewing window reflect the microwaves so
that they cannot escape from the cooking compartment.
• The microwave power and the cooking time can be set in several steps.
• After the time has elapsed or when the microwave door is opened, the
magnetron switches off immediately.

Cooking with the microwave
20
Cooking with the microwave
− In order to arrange the food correctly for cooking, place the thickest pieces on the
outside edge.
− Follow the exact cooking time.
− Select the shortest cooking time specified and extend it if necessary.
WARNING!
Risk of fire due to very high temperatures.
Very overcooked food can produce smoke or can ignite.
− Always supervise the cooking process.
− Cover foods with a microwave-safe cover during the cooking cycle. Covering the
food avoids spattering; the food is also cooked more evenly.
− Meals such as pieces of chicken and rissoles should be turned once during
preparation in the microwave to speed up cooking. Larger pieces such as roasts
or roast chicken must be turned at least once.
− It is also important to rearrange food, e.g. in the case of meat balls. After half the
preparation time, the items should be rearranged from the top to the bottom and
from the centre to outside.
− Mix the food through if possible after heating in order to distribute the heat
evenly, or leave it to continue to cook for a brief period.
− When preparing microwave popcorn, put the popcorn package on a microwave-
safe dish and place it on the turntable. Then proceed according to the microwave
popcorn manufacturer’s instructions.
Microwave-safe materials
You can buy special dishes and accessories for your microwave. Look for labels such
as ‘microwave safe’ or ‘for microwave use’. However, you can also use your existing
dishes if they are made of suitable material.
Suitable material
• china, glass ceramic and heat-resistant glass
• plastic that is heat resistant and microwave safe (note: plastic can still be
discoloured by food or deformed by heat)
• baking paper.
