MEFA SPEDYTOR User manual

MEFA SPEDYTOR
INCLUDED
PRINTER COMPONENTS CONTROL PANEL
SIGNALING PRINTER STATUS
LFONBAT
Pressing the button and holding it down for more than 1 second while the
printer is on turns off the printer. After proper configuration, the printer can also
turn off automatically after a certain period of inactivity.
Paper eject button.
Briefly pressing the button in normal operation mode ejects the paper one line.
Holding the button down causes a continuous stroke, lasting until the button is
released.
Printer status indicator (multicolor LED).
With normal and correct operation of the printer, the indicator lights up steadily
and its color indicates the active interface through which the printer receives
data
- BLUE / GREEN : USB
- BLUE : Bluetooth.
Printer sleep
After proper configuration, the printer can be put to sleep to save energy while
being ready for use. In sleep mode, the status indicator goes off.
The printer wakes up when one of the selected data sources is activated.
SIGNALLING
NAME
DESCRIPTION
WHITE / GREEN
PRINT TEST
Printing, print test.
WHITE / BLUE
DATA DUMP
Storing printed data in a file.
WHITE / RED
MASS
MEMORY
Access to configuration files and data dump,
software update.
WHITE /
ORANGE
SETTINGS
Basic settings menu.
The signaling diode flashes alternately white and the color indicating the mode.
To change the mode, press the power button briefly. To confirm the selection,
briefly press the paper feed button. To turn off the printer, press and hold the
power button for longer.
PAPER
CONTAINER
COVER
OPENING
BUTTON
FOR PAPER
CONTAINER
POWER SOCKET
USB INTERFACE
The panel has two buttons and three LEDs.
Power on indicator (left green LED - ON).
The indicator lights when the printer is on.
Printer power button (on / off).
Briefly pressing the button when the printer is turned off turns the
printer on. If the eject button is released during power up, the printer
enters normal operation mode. Turning the printer on with the paper
feed button pressed will activate the special mode.
POWER ON INDICATOR BATTERY STATUS INDICATOR
(ONLY FOR PRINTER WITH BATTERY)
LF
PRINTER STATUS INDICATOR
CONTROL PANEL
1. Printer
2. Power supply
3. USB cable
4. Roll of 105mm x 40mb label paper
5. Stand for the JUMBO roller
6. User manual and warranty card
THERMAL PRINTER
USER’S MANUAL

USING THE PRINTER
PRINTER PREPARATION FOR WORK
SIGNALING PRINTER STATUS
If an error occurs, the printer status indicator lights red and the
number of consecutive dims in a 4-second cycle indicates the
cause of the error.
The following events are signaled:
Insert the paper into the
gap between the cabinet
and the paper cover.
Open the cover and drag the
paper until it protrudes
outside.
Close the cover and tear
off any unnecessary
paper.
Finished.
The printer is ready for
work.
*
*
continuous
paper
11cm x
160m
self-adhesive
continuous
paper with
undercut
undercut 10,5
cm x 40 m
10cmx15
cm
lub
Self-
adhesive
label of any
length
backed
labels
Letter + self-
adhesive shirt
Self-adhesive
label
Printer connection
USB interface
1. Connect the USB cable.
2. Turn the printer power on. The green status indicator lights up.
After setting up the printer, we send print data. Indicator color
the status changes to blue-green.
After printing, the printer automatically goes to sleep when it elapses
programmed delay time which is indicated by the indicator
(blinking purple).
Transferring print data from an external device via the interface
USB will automatically turn on the printer (it will light up
blue-green indicator and printout follows).
Installing the printer driver on Windows systems:
USB / Bluetooth interface drivers are available at:
printers.mefa.com.pl or mefa.com.pl
After downloading, unpacking and running the installation file you
should
handle the on-screen messages.
After installation, it is recommended to restart your computer.
The printer's mass storage is visible through the PC when the printer
is turned on in mode
mass storage.
ATTENTION ! The printer does not work with iOS,
osX, MacOS
Numer of LED blinks Description
1
3
4
5
6
7
8
Data buffer overflow
Out of paper - end of roll
Printer cover open
Temperature too low
Head temperature too high
Completely discharging the battery
Supply voltage too high
