Mega LED Lighting LED COB PAR LIGHT-100 User manual

5. DMX function
Channel Value Function
CH1 0-255 Main dimming from dark to bright
CH2 0-255 Control strobe from slowly to quickly
CH3
0-50
DMX channel control
51-100
Color change by Snapping
101-150
Color change by Fade
151-200
Color change by Pulse
201-255
Sound control
CH4 0-255 The speed of function from slowly to quickly
CH5
0-255
R dimming from dark to bright
CH6 0-255 G dimming from dark to bright
CH7 0-255 B dimming from dark to bright
CH8 0-255 w dimming from dark to bright
CH9 0-255 A dimming from dark to bright
CH10
0-255
P dimming from dark to bright
Important notice:
Before open the LED cob par light and if you want to do the repair work,
please make sure the power source is at the separation condition.
Unceasingly carries on the product improvement about our company
the policy, in this instruction booklet carries the data will have the
possibility to be able to change in the future, when no longer separate
notice change matters concerned. Our company retains when the
product improvement changes the related specification the authority.
This instruction booklet publisher cannot be responsible regarding this
instruction booklet in information accuracy, also cannot the related
consequence which causes regarding these information be responsible.
3
LED COB PAR LIGHT-100
MJ-3001C200-6IN1
User Manual
======PROFESSIONAL LED LIGHTING ========
Thank you for choosing our LED cob par light. For the sake of your safety,
Please read and follow these instructions carefully and keep this manual in a
safe place for future reference

1. Installation
1. In order to secure the safe installation of the light, always use it in the
well-ventilated environment.
2. Always keep this light with a safe distance from any flammable
materials.
3. Never install, dismantle and maintain this light when it is powered; and
all work aforesaid must be conducted by professionals.
4. The packing list of this light is as follows:
1) Light --------------------------------------------1pcs
2) User Manual----------------------------------1pcs
2. Effect
1. This light operation is very simple, Attractive appearance, Humanized
design, Dim without flicker and shake, Energy-efficient, Durable. It is
suitable for photography, television stations, stage, dance hall, KTV, bar,
evening show.
2. The program of this light can automatically operate, sound, accept
DMX512 signal control and be connected for use.
3. Menu display function table
Please press “Menu”button to choose function , and press
“Enter”button to confirm.
No. Display Function
1 A001
A001—A512 (10 channel) press “UP” and “Down”
button change the DMX address
2 d001
d001—d512 (6 channel) press “UP” and “Down”
button change the DMX address
1
3 CC50
CC01—CC99 (Color change by jump), press “UP” and
“Down” button change the jump speed
4 EE50
EE01—EE99 (Color change by gradual), press “UP”
and “Down” button change the gradual speed
5 FF50 FF01—FF99 (Color change by Pulse), press “UP”
and “Down” button change the pulse speed
6 dEdF Sound mode
7 R000 R000—R255 (Red dimming by hand)
8 G000 G000—G255 (Green dimming by hand)
9 B000 B000—B255 (Blue dimming by hand)
10 W000 W000—W255 (White dimming by hand)
11 Y000 Y000—Y255 (Amber dimming by hand)
12 P000 P000—P255 (Purple dimming by hand)
4. Technical Parameters
Voltage: AC100-240V, 50Hz/60Hz
Power Consumption: 200W
LED: 200W 6in1 RGBWA+UV COB LED
LED Beam Angle: 60°
LED Lifetime: 80,000-100,000 hours
Color: RGBWA+UV color mixing
Dimming: 0-100% with regulated constant color control
Strobe: 10 Flashes per second (any color)
Operation Modes: DMX512, Master-slave, Sound, Auto running.
DMX Control: 6/10 Channels
Control Panel: Digital 4 Character Alphanumeric
Maximum Ambient Temperature: 40° C
Gross Weight: 4 kg
Package Size: 25.5 x 25.5 x 36.5cm
