FXLD2512B5I6 LED FIXTURE
Version 1.1 OWNER’S MANUAL 05/11/2022
www.lightronics.com
Lightronics Inc. 509 Central Drive, Virginia Beach, VA 23454 757 486 3588
FEATURES AND SPECIFICATIONS
LEDS: 12, 25W each (RGBWA, 5 in 1)
Beam angle: 60ᵒ
Control system: DMX-512 + Stand Alone Modes
DMX channels: 5/9
DMX connectors: 3 pin XLR I/O
Refresh Rate: >3000 Hz
Voltage: 100 - 240 VAC 50/60Hz
Max power consumption: 330 Watts
Ingress Protection: IP20 - Indoor Use Only
Cooling: Intelligent Fans (2)
Body material: Sheet steel
Body color: Black
Size: 39.4"L x 5"W x 3.4"H
DESCRIPTION
The FXLD2512B5I6 is an RGBWA LED lighting fixture.
It is suitable for stage, houses of worship,
entertainment venues, and other artistic applications.
It has several stand-alone control modes and can
operate via a DMX-512 external signal.
INSTALLATION
LOCATION
Locate the unit indoors in a well ventilated area away
from moisture and heat. Keep the vent holes clear.
Holes are provided on the brackets to install a lighting
bar pipe clamp. Use a safety cable when hanging the
fixture.
POWER CONNECTIONS
The FXLD2512B5I6 has a blue turn and lock connector
for power input. A compatible power cable is provided
for connection to a 120 VAC, 15 Amp, 60Hz, grounded
service. Push the blue connector on the cable straight
into the blue connector on the unit and twist approx.
1/8 turn clockwise to latch it. The white turn and lock
connector on the unit is used to pass power on to
another FXLD2512B5I6 unit. A mating white connector
is also provided.
THE LINE CORD IS RATED FOR 7 AMPS MAXIMUM
THE SAFETY GROUND TERMINAL ON THE POWER
CABLE MUST BE USED.
DMX CONNECTIONS
A system using DMX control must be connected as a
chain of devices. In other words, the control signal
cable should proceed from the controller to the first
receiving device and then to others in one continuous
chain.
The fixture has a DMX IN and a DMX OUT connector
to be used to connect the chain. The control cable
should NOT be split into a multiple run star
arrangement with a cable running from the controller
directly to each receiving device pack.
DMX CONNECTOR PIN ASSIGNMENTS
This unit uses 3 pin XLR type connectors. The
FXLD2512B5I6 receives DMX on the 3 pin MALE
connector on one side of the unit. On the other side of
unit, the 3 pin FEMALE connector is used to connect to
the next DMX device on the control chain.
PIN #
SIGNAL NAME
1
DMX COMMON
2
DMX DATA -
3
DMX DATA +
DMX TERMINATION
A DMX chain should be terminated at the last receiving
device on the chain. This is done by installing a
commonly available 1/4 Watt, 120 Ohm resistor across
the DATA - and DATA + wires at the last device. If you
have only a few fixtures very close together and a very
short run to the controller, then you may be able to
operate without the terminator.
OPERATION
A control panel on the back of the unit is used to set
the operating options. It consists of an LED display
and four buttons (MENU, UP, DOWN, and ENTER).
CAUTION
RISK OF ELECTRIC SHOCK

Page 2 of 4
FXLD2512B5I6 LED FIXTURE
Version 1.1 OWNER’S MANUAL 05/11/2022
www.lightronics.com
Lightronics Inc. 509 Central Drive, Virginia Beach, VA 23454 757 486 3588
Push MENU to access the operating options. Push UP
or DOWN to cycle through options. When you reach
the option you want to set or change use the ENTER
button to select the option to change. Then use the UP
and DOWN buttons to modify the values. Push ENTER
to save your changes and activate the option. See the
"MENU NAVIGATION" diagram for additional details.
There are 8 operation modes: DMX 5 channel, DMX 9
channel, Color Fade, Color Change, Color Select,
Manual Level (5 selections), Demo, and Sound.
Pushing MENU alternates to display 0XXC for current
LED plate temperature. The fan turns on at low speed
when temperature is at or above 45° C and will turn
back off at or below 34° C. The fan shifts to high speed
if temperature increases to 55° C and back to low
speed once temperature reaches 49° C.
DMX OPERATION
For DMX operation the FXLD2512B5I6 fixture can be
configured as a 5 channel or 9 channel unit.
Use the dXXX (5 ch) or AXXX (9 ch) menu to set the
starting address of the unit. You can select the starting
address of the unit with the UP and DOWN buttons.
The unit has an LED on the menu display (decimal
point). If the LED is flashing, the unit is not receiving
signal either from a DMX controller or from a master
fixture. LED will disappear once DMX is present.
Detailed information on DMX channel operation is
given in the tables DMX VALUES AND FUNCTIONS.
MANUAL OPERATION
If there is no DMX signal provided to the unit, then
setting any of these will result in the unit that was set
acting as a master. DMX signals will override all
manual settings.
Color Fade (CFXX)
The Color Fade mode cycles smoothly through a
sequence of colors. Use the CFXX menu to set the
speed and activate the option. The range is from 00 to
99 with 99 as the fastest.
Color Change (CCXX)
The color change mode cycles through a variety of
colors at a user defined speed. Use the CCXX menu to
set the rate of speed at which the colors change. The
range is from 00 to 99 with 99 as the fastest.
Color Select (CSXX)
For additional manual operations you can use the
Color Select menu CSXX to select one of 16 colors
and levels. Options from 00-99.
R, G, B, W, A Manual Level Control
You can operate the individual color levels manually
using the r000, G000, b000, E000, and Y000 menus.
Use the UP and DOWN buttons to change the level,
push ENTER when done. The range is 000 - 255 with
255 as the maximum.
Demo Mode (dENo)
The unit cycles through a fixed series of colors and
fades. There are no adjustments or settings in this
mode. Return to Channel mode to exit Demo.
Sound Mode (Soun)
The unit reacts to sounds by changing colors
randomly. There are no other settings within this mode.
Sound mode can also be activated in 9 channel mode
with DMX channel 9 set to 240-255. Intensity can be
controlled with DMX channel 1 (0-255).
Dimmer Delay (dEL0)
The operation of this function has been discontinued.
MAINTENANCE AND REPAIR
TROUBLESHOOTING
Check that you have power applied to the unit.
Check the DMX control cable.
Check the address settings of the unit and the
controller.
CLEANING
Do not use harsh chemicals or solvents when cleaning
the fixture. A mild detergent can be used sparingly if
needed. Use a cloth, do not spray or apply direct to
fixture. Ensure the unit is completely dry before re-use.
CAUTION DO NOT OPEN UNIT
RISK OF ELECTRIC SHOCK
RISK OF FIRE

Page 3 of 4
FXLD2512B5I6 LED FIXTURE
Version 1.1 OWNER’S MANUAL 05/11/2022
www.lightronics.com
Lightronics Inc. 509 Central Drive, Virginia Beach, VA 23454 757 486 3588
REPAIR
The fixture contains a 2 Amp 250VAC, fast acting,
5mm x 20mm externally accessible fuse. Replace the
fuse ONLY with the same size and type.
The FXLD2512B5I6 does not contain any other user
serviceable parts. Internal service on the unit by other
than Lightronics authorized agents will void the
warranty.
If service is required, contact the dealer from whom
you purchased the item, or contact the Lightronics
Service Department, 509 Central Drive, Virginia Beach,
VA 23454. Tel: [phone].
WARRANTY INFORMATION AND
REGISTRATION – CLICK LINK BELOW
www.lightronics.com/warranty.html
DMX VALUES AND FUNCTIONS
5 CHANNEL MODE (MODE dXXX)
9 CHANNEL MODE (MODE AXXX)
*Channel 9 additional characteristics.
If DMX is raised to 64-127, then back
down, 10-63 colors become Red &
Green.
If DMX is raised to 128-191, then back
down, 64-127 colors become Blue &
Green.
If DMX is raised to 192-239, then back
down, 128-191 colors become Cool
White/Warm White.
If DMX is raised to 240-254, then back
down, 192-239 colors become Cool
White/Warm White
CHANNEL
VALUE
FUNCTION
1 0-255 Red Level
2
0-255
Green Level
3 0-255 Blue Level
4 0-255 White Level
5
0-255
Amber Level
CHANNEL FUNCTION VALUE DESCRIPTION
1 Master Dimmer 0-255 Master Dimmer
2 Strobe Control 0-255 Strobe slow to fast
3 Red 0-255 Red Intensity
4
Green
0-255
Green Intensity
5 Blue 0-255 Blue Intensity
6 White 0-255 White Intensity
7 Amber 0-255 Amber Intensity
8 Color Macro
0-9 Applicable to CH2-CH7
10-34
Red Fade In
35-64 Red Full, Green Fade In
65-96 Green Full, Red Fade Out
97-127 Green Full, Blue Fade In
128-159 Blue Full, Green Fade Out
160-190
Blue Full, Red Fade In
191-225 Red, Blue Full, Green Fade In
226-255 RGBW Full, Amber Fade In
9*
Color Effect
Raising DMX
Value
0-9 CH2-CH7 functions
10-63 Red & Blue (slow to fast)
64-127
Red & Blue (slow to fast)
128-191 Red & Green (slow to fast)
192-239 Blue & Green (slow to fast)
Color Effect
Lowering DMX
Value
239-192 Blue & Green (fast to slow)
191-128 Cool/Warm White (fast to slow)
127-064
Blue & Green (fast to slow)
63-10 Red & Green (fast to slow)
9-0 CH2-CH7 functions
Sound Control
240-255
Sound Control Activate

Page 4 of 4
FXLD2512B5I6 LED FIXTURE
Version 1.1 OWNER’S MANUAL 05/11/2022
www.lightronics.com
Lightronics Inc. 509 Central Drive, Virginia Beach, VA 23454 757 486 3588
MENU NAVIGATION
