Mega LED Lighting LED ZOOM PAR COB -200 User manual

7CH model
Channel Value Function
CH1
0-255
Zoom function
CH2
0-255
Zoom speed from quickly to slowly
CH3
0-255
Main dimming from dark to bright
CH4
0-255
Control strobe from slowly to quickly
CH5
0-255
Auto running choose
CH6 0-255 Auto running speed from slowly to quickly
CH7
0-10 No function
11-20 Linear 1
21-30 Linear 2
31-40
Linear 3
41-249
Linear 4
250-255
Reset
Important notice:
Before open the LED cob par light and if you want to do the repair work,
please make sure the power source is at the separation condition.
Unceasingly carries on the product improvement about our company
the policy, in this instruction booklet carries the data will have the
possibility to be able to change in the future, when no longer separate
notice change matters concerned. Our company retains when the
product improvement changes the related specification the authority.
This instruction booklet publisher cannot be responsible regarding this
instruction booklet in information accuracy, also cannot the related
consequence which causes regarding these information be responsible.
3
LED ZOOM PAR COB -200
MJ-3047A200-5700K
User Manual
======PROFESSIONAL STAGE LIGHTING ========
Thank you for choosing our LED cob par light. For the sake of your safety,
Please read and follow these instructions carefully and keep this manual in a
safe place for future reference

1. Installation
1. In order to secure the safe installation of the light, always use it in the
well-ventilated environment.
2. Always keep this light with a safe distance from any flammable
materials.
3. Never install, dismantle and maintain this light when it is powered; and
all work aforesaid must be conducted by professionals.
4. The packing list of this light is as follows:
1) Light --------------------------------------------1pcs
2) Power Cable----------------------------------1pcs
3) User Manual----------------------------------1pcs
2. Effect
1. This light operation is very simple, Attractive appearance, Humanized
design, Dim without flicker and shake, Energy-efficient, Durable. It is
suitable for photography, television stations, stage, dance hall, KTV, bar,
evening show.
2. The program of this light can automatically operate, sound, accept
DMX512 signal control and be connected for use.
3. Menu display function table
Please press “Menu” button to choose function , and press “Enter” button
to confirm.
Menu
Value
Function
d001 001-512 press “UP” and “Down” button change the
DMX address
CH01 CH03 3CH model
CH07 7CH model
Auxx
01 White color
02 Color fade
So01
Sound change by jumping
So02 Sound change by strobe
St00 St01-St16 Strobe from slow to fast
1
SP00 SP01-SP16 The speed of Auto model from slow to fast
for Au08 Au09 Au10 model
Sn00 Sn01-Sn16 Sound sensitivity form slow to fast
W000 000-255 White dimmer by dimming by hand
H000 000-255 Motor movement
RES Confirm to reset
4. Technical Parameters
Voltage: AC100-240V, 50Hz/60Hz
Power Consumption: 200W
LED: 200W white Citizen COB LED
Beam Angle: 10-90°
LED Lifetime: 80,000-100,000 hours
Color:White color
Dimming: 0-100% with regulated constant color control
Strobe: 10 Flashes per second (any color)
Operation Modes: DMX512, Manual, Sound, Internal Program
DMX Control: 3/7 Channels
Control Panel: Digital 4 Character Alphanumeric
Maximum Ambient Temperature: 40° C
Gross Weight: 6.2 kg
Package Size: 32 x 32 x 39cm
5. DMX function
3CH model
Channel Value Function
CH1
0-255
Zoom function
CH2
0-255
Main dimming from dark to bright
CH3
0-10
No function
11-20
Linear 1
21-30
Linear 2
31-40
Linear 3
41-249 Linear 4
250-255 Reset
2
