Mega H5 Hazer User manual

USER MANUAL
Table of Contents
Safety Information……………………………………...………………3
Specifications………………………………………...…………………4
Main Power Connection…………………………...…………………..5
DMX-512 Connection……………………………..…………………...5
Main Control Menu……………..…………………………………..….6
DMX Profile.....................................................................................8
Rigging the Fixture……………………………….…………………….8
Cleaning & Maintenance.................................................................9
Parts List.........................................................................................9

Check that the unit has not been damaged during transport
Protection Against Fire
1. Maintain a minimum of 1 foot distance from any type of flame.
3. Replace fuse only with the specified type and rating.
4. Do Not install the unit to close to a heat source.
5. Make sure cable are properly secured away from unit movement.
6. Maximum surface operating temperature 140º.
Protection Against Fire
1. Disconnect power before servicing.
2. For connection to main power supply proceed to page 5.
3. This unit must be earthed. (electronically grounded)
4. Do not expose unit to rain or moisture.
Protection Against Mechanical Hazards
1. Use safety chain when hanging unit.
2. Use quality clamps or bolts when positioning unit
3. Do not open unit risk of electrical shock.
3

4
Specifications
Part Numbers
Fixture Flight Case
2005 - H5 Hazer 2005-RC Road Case
Mechanical Specifications
Fixture Flight Case for Shipping
Size: 22.12” x 13.25” x 11.12”
Weight: 31 lb
DMX Connectors: 3 and 5-pin XLR connectors
Power Connectors: Nema 5-15 cable mounted
Thermal: Maximum ambient temperature 110° F
Maximum surface temperature 140° F
Fastening System: Single mounting yoke
Display: Digital
Tank Capacity: 1/2 Gal
Electrical Specifications
Power supply: 110V AC 60Hz
Power consumption: Amps 14
Watts 1619
Heater: 1600 Watt
Haze Output: 10,000 Cuft/Min
Size: 25” x 16” x 15.5”
Weight: 26 lb
22.12”
11.12”
11”
Control & Programming
Protocol: DMX 512
Wireless Handheld Controller: Yes on/off
13.25” With Knobs

5
Main Power Connection
Caution!
1. Do not connect fixture to a dimmer system.
2. This unit must be earthed. (electronically grounded)
3. Replace fuse only with the specified type and rating.(15Amp 250V, 20mm)
The occupation of the connection-cable is as follows:
DMX-512 Connection
The fixture is equipped with 3 and 5 pin XLR Sockets for DMX input and output. The sockets are wired in parallel. Only
use a shielded twisted pair cable designed for RS-485 3 and 5 pin XLR plugs and connectors in order to connect the
controller with the fixture or the fixture with another.
Caution!
At the last fixture the DMX signal needs to be terminated with a terminator. Solder a
120 Ohm resistor between the (-) and the (+) signal into a 3 or 5 pin XLR plug and
plug it in to the last fixture on the signal run. Pre-manufactured terminator plugs are
available for purchase from your Mega-FX dealer (P-DMX-T).
Cable (USA) Cable (EU) Pin 110V
Black Brown
White
Green
Light Blue
Yellow/Green
Live
Neutral
Ground
L
N
DMX—input DMX—output
1. Shield
2. Signal (-)
3. Signal (+)
5
3
4
2
11
2
3
4
5
4. N/A
5. N/A
2
3
11
2
3
LN

6
Main Control Menu
The control board on the fixture base is your interface to access and
control all the functions on the unit. Its LCD display gives you views
of the options and functions. The following will explain each func-
tion and its options. Press Menu Button to access control menu
Mega FX
H5
FUNCTION UP DOWN
TIMER VOLUME MANUAL
Interval Set 5s
Mega FX H5
Interval Set
Sets Interval time in Sec or Minutes the amount of time Between
hazer engaged. This function will only be engaged in Timer mode
Duration Set 5s
Mega FX H5
Duration Set
Sets duration time in Sec or Minutes, of the amount of time haze will
be released. This function will only be engaged in Timer mode.
Timer Out 1
Mega FX H5
Timer Output
Sets the output volume amount in Timer mode. This function will only
be engaged in Timer mode.
Ready to Use
Mega FX H5
FUNCTION UP DOWN
TIMER VOLUME MANUAL
Volume Out 1
Mega FX H5
Volume Out
Sets the volume of haze that will be released. This function will only
be engaged in Timer, Volume and Manual mode.
Fan Speed 99%
Mega FX H5
Fan Speed
Sets fan speed from 1% to 100% Fastest. This function will only be
engaged in Timer and Volume mode.
The Functions Below will adjust the hazer output when used in Timer, Volume
and Manual Mode.

7
Ready to Use
Mega FX H5
FUNCTION UP DOWN
TIMER VOLUME MANUAL
DMX 512 Add. 1
Mega FX H5
DMX Address
Use the up down button to give the fixture the DMX start
address channel
Fluid Sensor ON
Mega FX H5
Fluid Sensor
This function will engage the fluid sensor or shut off the fluid sensor
allowing you to by pass the sensor functions.
Timing Set Sec
Mega FX H5
Timing Set
Allows you to set the timing increments seconds or minutes for Inter-
vals and Duration. This function will only be engaged in Timer mode.
TIMER Timer
Press once to turn on press again to turn off. Timer mode will en-
gage Interval, Duration, Timer Out, Volume and Fan Speed settings.
VOLUME Volume
Press once to turn on press again to turn off. Volume mode will en-
gage Volume and Fan Speed settings.
Manual Manual
Press once and hold, release to turn off. Manual mode will engage
Volume and Fan Speed at 100%.

DMX Profile
8
H5 Hazer 2 Channel
DMX Channel Function Description Value Init Value
1Volume No Function 0-7255
Volume output from Low to Heavy 8-255
2Fan Speed Slow 0-2255
Slow to Fast 3-255
Note: (Fan speed will stay active only when Volume is
above value 7)
Wireless Controller
Press B to activate the Volume preset function. Press A to turn off
Rigging the fixture
Caution!
1. The installations must be carried out by an authorized dealer or trained professional.
2. Unit may cause severe injures if you have doubts concerning the safety do not install.
3. Unit is to be 24 inches away from flammable materials (decoration material)
4. Use high quality installation equipment to hang unit.
5. Do Not cover the air intake below the fixture.
When rigging a unit it is very important that you follow common safety procedures. Rigging requires extensive experi-
ence including but not limited to calculating working loads, material being used and periodic safety inspections. If you
lack these qualifications, do not attempt the installation yourself, instead use a professional structural rigger.
When rigging the unit always be secured with a secondary safety attachment. The installation location of the projector
has got to be built in the way that it can hold 10 times the weight for 1 hour with out any harming. Installation should be
checked at least one time a year by a skilled person.

Cleaning and Maintenance
Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installa-
tions and electronics checked by an expert every 2 years.
The following points have to be considered during the inspection:
1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded.
2) There must not be any deformations on the housing, fixation and installation spots (ceiling, suspension, trussing).
3) Mechanically moved parts like axles and other must not show any traces of wearing and must not rotate with unbal-
ances.
4) The electronic power supply cables must not show any damages, material fatigue (e.g. porous cables) or sediments.
Further instructions depending on the installation spot and usage have to be adhered by a skilled installer and any
safety problems have to be removed.
Disconnect from mains before starting maintenance operation!
Caution Danger to life!
The following points need to be addressed when doing maintenance on the H5 Hazer
1) The cooling-fans should be cleaned monthly. DO NOT blow high pressure air into fans as incorrect rotation can
damage the fans operation.
2) The fans input vents need to be cleared from debris and residue.
3) For internal cleaning of the piping system please send fixture to Mega Systems Service Department
Note: There is no serviceable parts inside the device. Maintenance and service operations are to be carried out
by authorized dealers.
Replacing the fuse: Only replace the fuse with the same type and rating.
Replacing the power cable: If the power cable of this device becomes damaged, it has to be replaced by author-
ized dealers only.
Should you have further questions , please contact your dealer.
9
Parts List
2005-DIS Display PCB
2005-HS Heat Sensor
2005-FH Fuse Holder
2001-PS Power Switch
2005-PCBM Main PCB
2005-TRA Transformer
2005-FAN Fan
2005-WC Wireless Controller
2001-WA Wireless Antenna
2005-FOA Foam Sponge
2005-TAN Tank
2005-FIL Brass Filter
2005-SEN Liquid Sensor
2005-PUM Pump
2005-RC Road Case
Accessories
9213 Haze Nectar

Mega-FX
18668 Highway 16N
Helotes, TX 78023
Ph 210-684-2600 Fax [phone]
www.megasystemsinc.com / [e-mail]
