Antari X FAZER User manual

High Efficiency Vaporizing System and Highly Durable Heaters Ensure 25% Increased Output.
Modular Design for Easy, Cost Effective Maintenance.
Standardized Interface Allows Interchangeable Control Modules on All Models.
Illuminated Fluid Tank for Easy Monitoring for the Level of Fog Fluid.
Electronic Low Fluid Monitoring Protects Pump from Running Dry
Heavy-Duty, Quiet Pump for Continuous, Silent Operation.
www.bluelight.at

Tableof Contents
Introduction
Important Safeguards
Unpacking &Inspection
Setup
Operation
Control ModuleOperation
ANTARIX-20 DMX Module Settings
Maintenance
Performance Notes
1
2
4
4
5
6
9
10
11
www.bluelight.at

1
Congratulations on thepurchase of your new
ANTARI X Fazer
Thank you for choosingan ANTARI X Fazer. You now own arugged and
powerful state-of-the-art machine. Priorto use, we suggestthat you
carefully read all ofthe instructions. By followingthe suggestions found
in this user manual,you can look forwardto the reliable andsatisfactory
performance of yourANTARIFog Machine for yearsto come.
Introduction
Please follow these operation, safety and maintenance
instructions to ensure a long and safe life for your fog machine.
Cautions
Risk of electric shock. Disconnect the appliance from the electric
supply before removing the cover. Note: there are no user
serviceable parts inside.
www.bluelight.at

2
Important Safeguards
Danger of Electric Shock
Danger of Burns
!Keep this device dry.
!For inside use only. Not designed for outside use.
!For the 110V models, use 3-prong grounded electrical
outlet only. Prior to use take care to determine that the
unit is installed at the rated voltage.
!Always unplug your ANTARI Fog Machine before filling
its tank.
!Keep fog machine upright.
!Unplug the machine when not in use.
!This machine is not water- or splash-proof. If
moisture, water, or fog liquid gets inside the housing,
immediately unplug the unit and contact aservice
technician or your ANTARI dealer before using it again.
!No user serviceable parts inside. Refer to your ANTARI
dealer or other qualified service personnel.
!For adult use only. Fog machine must be installed out
of the reach of children. Never leave the unit running
unattended.
!Never aim the output nozzle directly at people.
!Fog machine output area is very hot. Avoid coming
within 60 cm of the output nozzle during operation.
!Locate the fog machine in awell-ventilated area. Never
cover the unit's vents. In order to guarantee adequate
ventilation, allow afree air space of at least 20 cm
around the sides and top of the unit.
!Never aim the output nozzle at open flames.
www.bluelight.at

3
!If the supply cord is damaged, it must be replaced by
manufacturer or its service agent or similarly qualified
personnel in order to avoid ahazard.
!The output nozzle becomes very hot during operation
0
(300 C). Keep flammable materials at least 50 cm away
from the nozzle.
!Always allow your ANTARI X Fazer to cool down before
attempting to clean or service it.
!Never add flammable liquids of any kind (oil, gas,
perfume) to the fog liquid.
!Use only the high-quality, water-based ANTARI fog
liquid. Other fog liquids may cause clogging or
"spitting".
!Always make sure there is sufficient liquid in the fog
liquid tank. Operating this unit without liquid will
cause damage to the pump as well as over-heating of
the heater.
!If your ANTARI Fog Machine fails to work properly,
discontinue use immediately. Drain all fog liquid from
the tank, pack the unit securely (preferably in the
original packing material), and return it to your
ANTARI dealer for service.
!Always drain tank before mailing or transporting this
unit.
!Never drink fog liquid. If it is ingested, call adoctor
immediately. If fog liquid comes in contact with skin
or eyes, rinse thoroughly with water.
Danger of Explosion
Important:
Pay attention to allwarning labels and instructionsprinted on the
exterior of yourANTARIX Fazer.

4
Unpacking & Inspection
Setup
WARNING:
Use of any fluidother than ANTARI fog fluid ormodification or
attempted to unauthorized repairof the X Fazerwill immediately
invalidate the warranty.
Open the shipping carton and verify that all equipment necessary
to operate the system has arrived intact.
Before beginning initial setup of your ANTARI Fog Machine, make
sure that there is no evident damage caused by transportation.
In the event that the unit's housing or cable is damaged, do not
plug it in and do not attempt to use it until after contacting your
ANTARI dealer for assistance.
!Remove all packing materials from shipping box.
Check that all foam and plastic padding is removed,
especially in the nozzle area.
!Place fog machine on aflat surface and remove fog
liquid tank cap.
!Fill with only ANTARI Fog Fluid. ANTARI XFazer only
works with uncontaminated ANTARI Fog Fluid. Other
fluids may cause spitting and serious clogging problem
and could result in the production of an unhealthful
fog. The use of other fluids voids the warranty of the
ANTARI XFazer. When filled, place cap back on liquid
tank.
!Firmly attach the control module cable to the
connector inside the rear chamber of the machine.

5
Operation
Important:
Always monitor tank fluidlevel as you arefogging. Running a fog
machine with no fluidcan permanently damage theunit.
!Plug power cord into agrounded electrical outlet.
Turn power switch on rear of unit to " ON" position.
Warm-up is complete when the display on control
module shows " Readyto Faze."
!To emit fog, press the appropriate button on the
control module for the desired length of time.
!Loosen the screws onthe two sides ofthe vent to adjust
output angle as desired.
!The control unit's display will cycle " Warming up" and
" Ready to Faze" as the machine re-heats to the proper
operating temperature.
!When the fluid isrunning low, the LEDinside the tank
chamber starts blinking fortwo minutes and thenstop
operation to protect thepump from running dry..
!Always monitor liquid levelto prevent interrupted
operation.
!For further information on operating your ANTARI X
Fazer, see the section titled, "Control Module
Operation" on page 6.
If your model includes amounting bracket designed for overhead
installation, it may be installed at floor level or suspended
overhead. If the unit is to be mounted using the bracket, it is
important that the fog does not shoot directly at any one's face.
Whatever installation method you choose, do not allow the unit
to have more than a15 degree angle of inclination.

6
If you experience low output, pump noise or no output at all,
unplug immediately. Check fluid level, the external fuse, control
module connection, and power from the wall. If all of the above
appears to be O.K., plug the unit in again. If fog does not come
out after holding the control module button down for 30 seconds,
check the hose attached to the tank to make sure there is fluid
going through the hose. If you are unable to determine the cause
of the problem, do not simply continue pushing the control
module button, as this may damage the unit. Return the
machine to your ANTARI dealer immediately.
!X-10: 10 meter wired multi-function remote control
module with 5-pin XLR connector for ANTARI XSeries
models X-310, X-510, X-515, X-530. Its interface
allows the operator to customize fog machine functions
by adjusting fogging duration, interval and volume. Its
LCD displays current operating parameters, which are
automatically stored in non-volatile memory, allowing
the machine to be powered down without losing
function settings. Instructions below:
Control Module Operation
FUNCITON
VOLUME
ESC ENTER ON / OFF
TIMER MANUAL

1.Via the Function key, you can adjust the desired
settings. Pressing the Function keywill cycle through
different options including Volume, Timer, Heat &
Fan. The Enter (Volume) Keyis used to selectthe
desired option. To adjustfog output volume setting,
simply go into Volume option. Adjust the volume
percentage (within the rangeof 1% to nonstopburst) by
means of Up /Down keys. To adjusttimer setting, go
into Timer option. Cycle through Interval(within the
range of 1 to900 seconds), Duration (withinthe range
of 1 to 200seconds), and Volume (withinthe range of
1% to nonstop burst)by means of Up/ Down keys. Use
Enter (Volume) Key toselect each option andmake
changes as desired. Toturn off the heaterand fan, go
into Heat &Fan option. Use Enter (Volume)Key to
confirm the selection. UseOn/Off (Manual) Key toturn
it on.
2.Always press Enter(Volume) keyto confirm setting.
3.Press ESC(Timer) key toexit current menu leveland
move to an upper(previous)level.
4.Press the Timer key to activate the timer function.
The display shows the adjusted interval and the device
counts the seconds down to "0". After that, the fog
emission is triggered at the volume adjusted under "
Timer "Option. The duration depends on the settings
adjusted under "Duration". If you wish to deactivate the
7

timer function, press the Timer key once more.
5.Press the Volume keyfor immediate triggering of the
fog emission at the volume adjusted under "Volume "
Option. Press the Volume switch once more in order to
stop the fog emission.
6.Press the Manual keyfor immediate triggering of the
fog emission at 100 %volume. Let the Manual key loose
in order to stop the fog emission.
7.When in standby mode,press On/Off key toreactive
the machine.
!X-20: DMX Interface module. Please refer to the section
on Page 8titled X-20 DMX Module Settings.
!X-30: All the X-10 features plus wireless capability.
Wireless operation is possible up to adistance of 50
meters. The address can be set from 0to 8, which means
total 9different units can be controlled separately or in
any combination desired. Press functionto cycle to RF
mode to select desired address number. Make sure the
address setting on the X-30 matches theaddress
setting on the transmitter. There are two buttons on the
transmitter. Blue one is toemit fog and Redone is to
stop the operation.
8

ANTARIX-20 DMX Module Settings
If Channel has avalue from 0to 5, the unit is OFF.
If Channel has a value from 250 TO 255, the machine will operate
at maximum output.
On X Fazer suchas X-510, X-515 andX-530, X-20 uses only1
channel to control volumeoutput operation. On XFazer such as
X-310, X-20 uses 2channels to control bothfog volume and fan
volume. Whatever channel youselect on the unit,the channel
next to it willbe selected automatically forfan volume control.
Each channel has avalue range of 0to 225. Timer functionssuch
as duration and intervalcan be programmed usingthe DMX
controller or the DMXcontrol software being usedby lighting and
effects operator.
Between the values 6to 249 the volume of fog output is
regulated. With 6 being theminimum volume of fogproduced and
249 approaching the maximum. The volume output risesas the
DMX value is increased.
Note: In the exampleabove, if the machinewere assigned the
DMX address of 124,Channel would correspond toDMX address
124.
0 - 5
6 - 249
250 - 255
OFF
Volume Control( 5% - 95%)
Maximum VolumeOutput ( 100%)
Value Function
9

In general, ANTARI XFazer with X-20 DMXModule conform to
the following performance specifications:
0
1.Average Operating temperature = 250 C
2.XFazer can maintain maximumoutput for 60
seconds or more
Do not allow the fog liquid to become contaminated. Always
replace the caps on the fog liquid container and the fog machine
liquid tank immediately after filling.
After every 40 hours of continuous operation, it is recommended to
run acleaning solution composed of 80% distilled water and 20%
white vinegar through the system to prevent the accumulation of
particulate matter in the heating element. The recommended
cleaning regimen is as follows:
1.Empty all fog fluidfrom machine. Add cleaning
solution to tank. Plugunit in and beginwarm up.
2.Run unit in awell-ventilated area until tankis
empty.
3.Cleaning is now complete. Refill with fog liquid.
Maintenance
10

Note: All fog machines areprone to clogging dueto the thick
consistency of fog fluidand the high temperatureat which it
vaporizes. However, a properlymaintained fog machine should
provide years of reliableuse.
Clean with a drycloth only. Store dry.
!It is recommended thatyou set the Fanoutput at 100%
and Fog Volume output at 15-20%.Withsuch setting,
you will have continuousoutput of very finehaze effect
!Whenever enormouseffect isrequired, pressManual keyto
emit fogat 100%output instantly.
!For quietoperation, lowerdown Fanoutput asdesired.
!All fog machines havea recycling period afterlong
bursts when the machinewill shut itself downfor a
short period in orderto heat up again.During this time,
no fog can beproduced.
Cleaning your fog machine regularly will help reduce costly parts
replacement and repair charges.
Performance Notes
Please read and save these instructions
11

LIMITED WARRANTY
ANTARILighting andEffect Ltd.warrants tothe originalpurchaser that
theANTARIX Fazerwill befree fromoriginal defectsin workmanship
and materialfor aperiod ofsix monthsfrom thedate ofpurchase.
During thewarranty period,machines willbe repairedor replacedat
the optionofANTARIor itsdesignated dealer.
If thepurchaser returnsa completedregistration cardtoANTARIor its
designated dealerwithin 30days ofpurchase,ANTARIwill extendthe
limited warrantyon thepump assemblyand theheat exchanger
assembly toa FULLYEAR fromthe dateof purchase.If thewarranty
card isnot receivedbyANTARIor itsdesignated dealer, thewarranty
will remaineffective forsix months.
The warrantydoes notextend toany partsof theANTARI XFazer that
have beensubject tomisuse oraccident. Neitherdoes thewarranty
cover anyANTARI XFazer thathas beenopened, modifiedor repaired
other thanbyANTARIor itsdesignated dealer.
The warrantywill notapply ifprocedures describedin theInstruction
Manual arenot followed.It isthe user'sobligation toclean and
maintain theANTARI XFazer accordingto theseinstructions, andto
follow acceptablepractices forhandling electricaldevices with
heating elements.
NOTE: USE OF ANY FLUID OTHER THAN ANTARI FOG FLUID
WILL VOID WARRANTY.
