MEGAREVO R6KH5 User manual

I
User Manual
DECLARATION
SHENZHEN MEGAREVO TECHNOLOGY CO., LTD. ( hereinafter
"MEGAREVO" ) reserves the right to modify the frame dimensions,
functionality, technical data, parameters, standards without prior notice.
The contents of this manual have been checked for accordance with its
described hardware and software. However, the contents of this manual
may be subject to appropriate modification as a result of product upgrade,
specification change and update of the manual, we cannot guarantee full
accordance all the time. But the data in this manual are reviewed regularly
and any necessary corrections are included in subsequent editions.
Suggestions for improvement from readers are appreciated.
No part of this manual may be reproduced in any form, or by any means,
without prior written permission of Megarevo.
All rights © SHENZHEN MEGAREVO TECHNOLOGY CO., LTD.

II
User Manual
and other MEGAREVO trademarks used in this manual are owned
by MEGAREVO.
Using data contained in firmware or software developed by MEGAREVO, in
part or in full, for commercial purposes by any means is prohibited.
Reverse engineering, cracking or any other operation that destroys the
original programming design of software developed by MEGAREVO is
prohibited.
OTHER RIGHTS

III
User Manual
PREFACE
Thank you for choosing REVO Series Hybrid Inverter ( hereinafter
"inverter" ) .
This user manual presents a detailed description of REVO series with
respect to product features, structural characteristics, functions,
installation, parameter settings, troubleshooting, commissioning and daily
maintenance, etc. Be sure to carefully read through the safety precautions
before use and keep it properly at a place for easy access.
• Please assure the intactness of product enclosure and all safety
covers before installation. Operation must conform to the
requirements of this manual and local industrial safety regulations
and/or electrical codes.
• In the event of damage or loss of user manual, users may ask local
distributors, offices or our Technical Service Department for a new
one.
• Contents of this manual may be subject to appropriate modification
as a result of product upgrade, specification change and update of
the manual.
• If any item as stated in this manual is not clear, please contact our
Technical Service Department.
• If any anomaly occurs after power up or during the operation, it is
essential to stop the machine and identify the fault or seek technical
services as soon as possible.
IMPORTANT NOTES

IV
User Manual
This manual is valid for the following model of hybrid inverters:
• R6KH3
• R8KH3
• R10KH3
• R12KH3
• R15KH3
It will be referred to as "inverter" hereinafter unless otherwise specified.
The inverter must only be installed by professional technicians. The
professional technician is required to meet requirements as follows:
• Know electronic, electrical wiring and mechanical expertise, and be
familiar with electrical and mechanical schematics.
• Be familiar with local standards and relevant safety regulations of
electrical systems.
• Have received professional training related to the electrical equipment
installation and commissioning.
• Be able to quickly respond to hazards or emergencies that occur
during installation and commissioning.

V
User Manual
TECHNICAL SUPPORT
Before installation, wiring, operation, and repair to the inverter, please read
carefully and strictly comply with all its Safety Precautions in this manual.
Please ensure all the warning marks on the inverter are clear and distinct.
Replace or add the obscure or missed warning marks.
The information from following sources is all effective.
Scan the QR codefor the latest information and services:
Service time: 24/7
Users may acquire general technical data and information through
MEGAREVO official website: http://www.megarevo.com
If you have any question, or anything that it is not clear for you, or
have some troubles during installation, wiring, and/or operation, you
are suggested to contact MEGAREVO via its recommended contact
information in this manual or contact its sales representatives or service
engineers.

VI
User Manual
Content
1 Safety Precautions 001
1.1 Important Safety Instructions 001
1.2 Important Safety Instructions 008
1.3 CE Directives 009
2 Introduction 011
2.1 Model Description 011
2.2 Basic features 011
2.3 Work Modes 014
2.4 Dimensions 018
2.5 Terminals 019
2.6 Parameters 021
3 Installation 026
3.1 Check for Physical Damage 026
3.2 Packing List 026
3.3 Mounting 027
4 Electrical Connection 031
4.1 PV connection 031
4.2 Grid connection 033
4.3 EPS Connection (apply to I Version and E Version only) 035
4.4 Battery Connection 042
4.5 CT Connection and Phase instruction 045
4.6 DRM Connection (Function temporarily retained) 046
4.7 WiFi Connection (optional) 048
4.8 GPRS Connection (optional) 049
4.9 Inverter Manipulation 050
5 Setting 052

VII
User Manual
5.1 Control Panel 052
5.2 Instructions for LED Indicator 052
5.3 Instructions for the use of three modes 053
6 LCD Operation 056
6.1 LCD Interface 056
6.2 Setting 060
6.3 Inquire 071
6.4 Statistic 072
7 Fault Diagnosis and Solutions 073

VIII
User Manual
Figure
Table
Figure 2-1 Symbols on the Product 011
Figure 2-2 E-Version system diagram 012
Figure 2-3 I-Version system diagram 013
Figure 2-4 Dimensions 018
Figure 2-5 Terminals 019
Figure 3-1 Space Requirement 028
Figure 4-1 E-Version system diagram 037
Figure 4-2 I-Version system diagram 038
Figure 4-3 Battery connection 043
Figure 4-4 BMS PIN definition 043
Figure 4-5 CT connection and phase wiring diagram 045
Figure 4-6 DRM PIN definition 047
Figure 4-7 WIFI connection diagram 048
Figure 4-8 GPRS connection diagram 049
Figure 5-1 Control panel 052
Table 1-1 Symbols on the Product 008
Table 2-1 Terminals 020
Table 2-2 Parameters 021
Table 2-3 Parts list 026
Table 4-1 Max. DC Voltage Limitation 031
Table 4-2 Recommended cables and micro-breakers 033

IX
User Manual
Table 4-3 Recommended cables and micro-breakers 039
Table 4-4 Common feasible loads for reference 041
Table 4-5 Recommended non-polar DC breakers 042

X
User Manual
History
Version Release Date Description
V1.00 Jan. 2021 First edition
V2.10Jan. 2023 Update
V2.20Apr. 2023 Update

001
User Manual
01 Safety Precautions
1 Safety Precautions
1.1 Important Safety Instructions
Safety signs in this manual:
DANGER indicates high-risk potential hazards that, if not avoided, may
lead to death or serious injury.
WARNING indicates moderate-risk potential hazards that, if not avoided,
may lead to death or serious injury.
CAUTION indicates low-risk potential hazards that, if not avoided, may
lead to minor or moderate injury.
NOTE provides valuable tips on the best operation of our products.
Danger to life due to a high voltage inside the inverter!
• All work must be performed by a qualified electrician.
• Children and persons with reduced physical sensory abilities, mental
capabilities, or lack of experience and knowledge should not use this
equipment unless supervised or instructed.
WARNING
CAUTION
DANGER
DANGER

002
User Manual
01 Safety Precautions
Radiation may cause damage to health.
• Do not stay at a place less than 20cm away from the inverter for a
long time.
Ground the PV generator.
• Comply with the local requirements for grounding the PV modules
and the PV generator.
• It is recommended that generator frames and other conductive
surfaces be connected in a manner that ensures continuous
conduction and grounding for optimum protection of the system
and personnel.
Make sure the input DC voltage is less than the maximum value. Over-
voltage may cause permanent damage to the inverter or other losses,
which will not be covered by the warranty!
Before attempting any maintenance, cleaning or working on any circuits
connected to inverter, authorized service personnel must disconnect
both AC and DC power from inverter.
CAUTION
Danger of burns
• When the product is working, the upper of the enclosure and the
enclosure body may become hot.
• During operation, only the touch screen needs to be operated.
CAUTION
WARNING
WARNING

003
User Manual
01 Safety Precautions
Do not operate the inverter while the equipment is running.
Risk of electric shock!
WARNING
WARNING
• It is recommended to use only accessories that are compatible with
the inverter, otherwise it may lead to the risk of fire, electric shock or
personal injury.
• Make sure the existing wiring is in good condition, and the wires are
not undersized.
• Do not disassemble any parts of inverter which are not mentioned in
installation guide. It contains no user-serviceable parts. See Warranty
for service. Unauthorized repairs may result in a risk of electric shock
or fire and will void your warranty, and will void the warranty.
• Keep away from flammable, explosive materials to avoid fire disaster.
• The installation location should be away from humid or corrosive
substance.
• Authorized service personnel must use insulated tools when installing
or working with this equipment.
• PV modules should have IEC 61730 Class A rating.
• Do not touch either the positive or negative pole of PV connecting
device. Strictly prohibit touching both of them at the same time.
• The unit contains capacitors that remain charged to a potentially
lethal voltage when the MAINS , battery and PV supply has been
disconnected.
• Hazardous voltages may remain present for up to 5 minutes after
disconnection.

004
User Manual
01 Safety Precautions
1.1.1 Install surge protection devices (SPDs) for PV
• CAUTION-The energy stored in the capacitor is a shock hazard, do
not operate the inverter, coupler, power cable, battery cable, PV cable
or PV generator while energized. After turning off the PV, battery and
power supply, always wait 5 minutes to allow the intermediate circuit
capacitors to discharge before unplugging the DC, battery and power
coupler.
• When accessing the internal circuit of inverter, it is very important
to wait 5 minutes before operating the power circuit or demounting
the electrolyte capacitors inside the device. Do not open the device
beforehand since the capacitors require time sufficiently discharge!
• Measure the voltage between terminals UDC+ and UDC- with a multi-
meter(impedance at least 1Mohm) to ensure that the device is
discharged ( <35VDC ) before starting to work inside the device.
• Lightning will cause a damage either from a direct strike or from
surges due to a nearby strike.
• Induced surges are the most likely cause of lightning damage in
majority or installations, especially in rural areas where electricity
is usually provided by long overhead lines. Surge may be included
on both the PV array conduction and the AC cables leading to the
building.
• Specialists in lightning protection should be consulted during the end
• Over-voltage protection with surge arresters should be provided
when installing PV power generation system.
• The grid connected inverter does not have SPDs installed on both
PV input side and MAINS side.
WARNING

005
User Manual
01 Safety Precautions
1.1.2 Anti-Islanding Effect
use application.
• Using appropriate external lightning protection, the effect of a direct
lightning strike into a building can be mitigated in a controlled way,
and the lightning current can be discharged into the ground.
• Installation of SPDs to protect the inverter against mechanical
damage and excessive stress include a surge arrester in case of
a building with external lightning protection system (LPS) when
separation distance is kept.
• To protect the DC system, surge suppression device (SPD type2)
should be fitted at the inverter end of the DC cabling and at the array
located between the inverter and the PV generator, if the voltage
protection level (VP) of the surge arresters is greater than 1100V,
an additional SPD type 3 required for surge protection for electrical
devices.
• To protect the AC system, surge suppression devices (SPD type2)
should be fitted at the main incoming point of AC supply (at the
consumer’s cutout), located between the inverter and the meter/
distribution system; SPD (test impulse D1) for signal in according l to
EN 61632-1.
• All DC cables should be installed to provide as short a run as possible,
and positive and negative cables of the string or main DC supply
should be bundled together. Avoiding the creation of loops in the
system.
• Spark gap devices are not suitable to be used in DC circuits once
conducting, they won’t stop conducting until the voltage across their
terminals is typically more than 30 volts.
The islanding effect is a special phenomenon where a grid-connected PV
system still delivers power to the nearby grid when voltage losses occur in
the power system. This can be dangerous for maintenance personnel and

006
User Manual
01 Safety Precautions
the public.The Revo series inverters offer Active Frequency Drift (AFD) to
prevent the islanding effect.
• The end-use application shall monitor the protective conductor by
residual current operated protective device (RCD) with rated fault
current Ifn≤240mA which automatically disconnects the device in
case of a fault.The device is intended to connect to a PV generator
with a capacitance limit of about 700nf.
• Incorrect grounding can cause physical injury, death or equipment
malfunction and increase electromagnetic.
• Make sure that grounding conductor is adequately sized as required
by safety regulations.
• Do not connect the ground terminals of the unit in series in case
of a multiple installation. This product can cause current with a DC
component, Where a residual current operated protective (RCD) or
monitoring (RCM) device is used for protection in case of direct or
indirect contact, only an RCD or RCM of type B is allowed on the
supply side of this product.
• The installation that connects the equipment to the supply terminals
shall comply with the requirements of BS 7671.
1.1.3 PE Connection and Leakage Current
1.1.4 For United Kingdom
High leakage current!
Earth connection essential before connecting supply.
WARNING

007
User Manual
01 Safety Precautions
1.1.5 For Australia and New Zealand
1.1.6 Battery Safety Instructions
• Electrical installation of PV system shall comply with requirements of
BS 7671 and IEC 60364-7-712.
• No protection settings can be altered.
• User shall ensure that equipment is so installed, designed and
operated to maintain at all times compliance with the requirements of
ESQCR22(1)(a).
• Make sure that grounding conductor is adequately sized as required
by safety regulations.
• Do not connect the ground terminals of the unit in series in case
of a multiple installation. This product can cause current with a DC
component, Where a residual current operated protective (RCD) or
monitoring (RCM) device is used for protection in case of direct or
indirect contact, only an RCD or RCM of type B is allowed on the
supply side of this product.
Electrical installation and maintenance shall be conducted by licensed
electrician and shall comply with Australia National Wiring Rules.
Revo hybrid Series inverter should be worked with high voltage battery, for
the specific parameters such as battery type, nominal voltage and nominal
capacity etc., please refer to section 4.
As accumulator batteries may contain potential electric shock and short-
circuit current danger, to avoid accidents that might be thus resulted, the
following warnings should be observed during battery replacement:
1: Do not wear watches, rings or similar metallic items.
2: Use insulated tools.
3: Put on rubber shoes and gloves.
4: Do not place metallic tools and similar metallic parts on the batteries.
5: Switch off load connected to the batteries before dismantling battery
connection terminals.

008
User Manual
01 Safety Precautions
6: Only personal with proper expertise can carry out the maintenance of
accumulator batteries.
This section gives an explanation of all the symbols shown on the inverter
and on the type label.
1.2 Important Safety Instructions
Table 1-1 Symbols on the Product
Symbol Explanation
CE mark.
The inverter complies with the requirements of the applicable
CE



TUV
RCM remark
SAA certification
Beware of hot surface.
The inverter can become hot during operation. Avoid contact
during operation.
Danger to life due to high voltages in the inverter!
Danger.
Risk of electric shock!
Please note the provisions of the instruction manual.

009
User Manual
01 Safety Precautions
This chapter follows the requirements of the European Low Voltage
Directive, which contains safety instructions and conditions of acceptance
for imported systems that you must follow when installing, operating
and servicing the equipment. If ignored, it may result in personal injury or
death, or damage to the equipment. Please read this before you perform
work on the equipment. If you cannot understand these hazards, warnings,
cautions, or instructions, contact an authorized service dealer to operate
and maintain the equipment prior to installation.
The grid-connected inverter meets the requirements of IEC 62109-1/-2;
IEC 62477-1; IEC 61000-6-1/-3.
If installed in a PV system, it is forbidden to start the unit (i.e. to start the
specified operation) until it has been established that the entire system
complies with the requirements specified in the CE Directive), that the grid-
connected inverter is shipped with the connection device completed and
ready for connection to the mains and PV power supply, and that the unit
is installed in compliance with the national wiring regulations. Compliance
1.3 CE Directives
Symbol Explanation
The inverter can’t be disposed together with the household
waste. Disposal information can be found in the enclosed
documentation.
Do not operate inverter until it is isolated from battery, mains
and on-site PV generation suppliers.
Danger to life due to high voltage.
There is residual voltage existing in the inverter after powering
off.
Which needs 5 min to discharge.
Wait 5 min before you open the upper lid or the DC lid.
