MegaTech CC Flyer Technical specifications

Entire contents © Megatech 2005
Flight
Manual
Manual
www.megatech.com

2
Congratulations! You have just purchased one of the EASIEST to fl y planes in
the world! Learning to fl y has never been so fun! Get ready to launch into gravity-
defying action with Megatech’s CC Flyer! Climb to heights up to 500 feet... no
experience needed! CC Flyer’s clever design and easy-to-use controller make it
simple to go from beginner to expert in minutes!
READ ENTIRE MANUAL FIRST
BEFORE ATTEMPTING TO FLY
If you have questions about operating or assembling your new Megatech product...
Please Call Megatech First!
DO NOT RETURN THIS PRODUCT TO THE STORE
Call our Customer Service Department at:
(888) MEGA-911 or send an e-mail to:
[email protected]
10:00am - 4:00pm, EST Monday through Friday (except holidays)
Technical assistance is also available on-line at www.megatech.com
or by e-mail to [email protected]
TABLE OF CONTENTS
SAFETY PRECAUTIONS ......................................................................................................3
PACKAGE CONTENTS ......................................................................................................... 4
ASSEMBLY ........................................................................................................................... 4
CHARGING ONBOARD BATTERY PACK ............................................................................ 6
PRE-FLIGHT CHECK ............................................................................................................7
FLIGHT SCHOOL .................................................................................................................. 8
FLYING TIPS ....................................................................................................................... 10
TROUBLESHOOTING ........................................................................................................ 11
REPAIR, REPLACEMENT & SPARE PARTS LIST ............................................................. 11
WARRANTY ........................................................................................................................ 12
TABLE OF CONTENTS

3
Important! Before you begin, please read all safety precautions and warnings.
Failure to comply with any of the following could lead to bodily harm or injury.
The Megatech CC Flyer is not intended for those under 12 years of age without
proper adult supervision.
SAFETY PRECAUTIONS
TRANSMITTER SAFETY
This devise complies with part 15 of FCC rules.
Operation subject to the following two conditions:
(1)This device may not cause harmful interference and
(2)This device must accept any interference received,
Including interference that may cause undesired operation.
SAFETY GUIDELINES
• Before you begin to fl y, look at the frequency sticker on the back of your transmitter & make
sure no one in the area is on the same frequency.
• You alone are responsible for operating your model in a safe manner. When fl ying, you are
responsible for your own safety and the safety of others around you. Follow these basic safety
guidelines at all times.
• When operating always be aware of the spinning propeller. Be careful not to let it come close to
your person, others and/or loose clothing.
• Always fl y your airplane in a wide-open area, at least the size of a soccer fi eld. Make sure that
the area is free from obstructions such as buildings, electric power lines, trees, roads, other
people and vehicles. Do not fl y around people who are unaware that you are fl ying a model
airplane, and never fl y over people’s heads.
• Do not attempt to disassemble any of the model’s components or allow them to get wet.
Electrical damage may occur.
• Never fl y your model from roadways or after dark.
• Keep spectators behind you when fl ying.
• Before fl ying, make sure you perform a range check to be sure you can maintain control at least 25-feet
from transmitter to model with the transmitter antenna extended.
• Since your model is controlled by a radio link it is very important to always keep a fresh alkaline battery in
the transmitter.
• Never use solvents or liquid cleaners to clean this model. Doing so may damage the unit or electronics.
Only use a dry, soft cloth for cleaning.
RECHARGEABLE BATTERY WARNINGS AND PRECAUTIONS
• ALLOW BATTERY TO COOL COMPLETELY BEFORE ATTEMPTING TO CHARGE
• Only use the included charging cable or charger that is approved for use with this battery.
• Never leave battery unattended while charging.
• Never attempt to charge a battery that appears damaged.
• Never charge longer than 10 minutes.
• Place a charging battery on a fl ame & heat resistant material such as an oven mitt.
Nickel-metal hydride batteries must be disposed of properly. For current
regulations in your area and proper disposal sites please call 1-800-822-8837 or
visit www.rbrc.org
If you have questions about operating or assembling your new Megatech product...
Please Call Megatech First!
DO NOT RETURN THIS PRODUCT TO THE STORE
Call our Customer Service Department at:
(888) MEGA-911 or send an e-mail to:
[email protected]
10:00am - 4:00pm, EST Monday through Friday (except holidays)
Technical assistance is also available on-line at www.megatech.com
or by e-mail to [email protected]
SAFETY PRECAUTIONS

4PACKAGE CONTENTS
Before getting started you will need:
8 ‘AA’ Alkaline batteries (sold separately)
First make sure the
contents of your
package are complete:
A. Fuselage
B. Main Wing
C. Transmitter
D. Transmitter Antenna
E. Battery Flight Pack
F. Charging Cord
G. Wind Detection
Ribbon
H. Wing Bands
I. Propeller & Spare
J. Landing Gear
K. Center Wing Support
ASSEMBLY
ATTACHING THE WINGS
1) Place the Main Wing onto the fuselage with wingtips angled upwards.
2) Line up the arrows on the center of the wing so they are pointing to the seam on the
fuselage (Fig. 1). Snap down into place.
3) Place the Center Wing Support directly over the center of the wing. Make sure the
rounded edge is towards the front of the plane and gently snap down into place. (Fig. 2)
4) Connect the Wing Bands to the posts on the fuselage and wrap them across the wing fi rst
in an “X ”pattern and then a “II ”pattern (Fig. 3).
PACKAGE CONTENTS / ASSEMBLY
A.
B.
C.
D.
E.
F.
G.
H. I.
J.
K.
Fig. 1 Fig. 2 Fig. 3
Decal
Towards
Front
Rounded
Edge

5
ATTACHING THE PROPELLER
1) Push propeller onto fuselage prop shaft
IMPORTANT: Make sure there is approx 1/8in.
between the propeller and the fuselage. The
propeller should not be touching the screws on
the front of the fuselage.
ATTACHING LANDING GEAR
• Squeeze wheels together
• Continue holding wheels together and insert
landing gear into slot on bottom of fuselage
behind the battery hatch
• Release the wheels and gently spread apart
PREPARING TRANSMITTER
Transmitter requires 8 ’AA’ Alkaline batteries (sold seperately)
a) Remove the battery compartment cover located on the back of the transmitter by
sliding it down.
b) Insert 8 “AA” Alkaline batteries. Be sure to match the ‘+’ and ‘-’ polarity symbols
in the transmitter with each battery.
c) Replace battery hatch cover.
d) Locate transmitter antenna, insert and screw into the top of the transmitter.
DO NOT over tighten!
e) Turn the transmitter ‘Power’ switch to ‘ON’ position. The red and green LED
lights will illuminate.
NOTE: If the LED does NOT illuminate, do NOT attempt to fl y your CC Flyer. Make sure
you are using all fresh alkaline batteries and check the batteries for correct polarity
placement. If LED still fails, contact Megatech at 1-888-634-2911.
ASSEMBLY
+ + + +
+ + + +
- - - -
- - - -
Twist
to
Attatch
Leave
Space

6CHARGING ONBOARD BATTERY PACK
MAKE SURE BATTERY IS COMPLETELY COOL BEFORE
ATTEMPTING TO CHARGE. FAILURE TO DO SO WILL
CAUSE PERMANENT DAMAGE TO THE BATTERY AND
POSSIBLE BODILY HARM
1) Remove battery from airplane. (Do NOT leave battery
inside airplane while charging)
2) Make sure transmitter is switched to ‘OFF’.
3) Plug the charging cord into the transmitter
4) Red LED will illuminate indicating the battery is being
charged. LED will turn off in approximately 10 minutes
indicating charging is complete.
5) Always monitor the charging process. When the battery
becomes warm to the touch it is completely charged.
IMPORTANT: If battery does NOT become warm after the 10 minute charge
cycle, replace the ‘AA’ alkaline batteries in your transmitter and try charging
again.
CAUTION!!
DO NOT CHARGE BATTERY MORE THAN 10 MINUTES.
CHARGING LONGER MAY DAMAGE THE BATTERY
AND REDUCE PERFORMANCE.
INSTALLING THE FLIGHT PACK INTO THE FUSELAGE
• Unlock and remove the battery hatch on the bottom of the fuselage.
• Leave all foam pieces inside of the
fuselage to ensure proper placement
of the fl ight pack.
• Attach the battery connector to the
connector inside the fuselage
• Place battery into fuselage with the
wide section of the battery going fi rst
• Attach battery hatch and switch to the
‘Lock’ position.
NOTE: If you do not put the hatch in
the ‘lock’ position it will fall off during fl ight.
CYCLING BATTERY PACK
For peak performance and optimum fl ight duration, it is important to cycle the
rechargeable fl ight battery pack 3 times before fl ying.
1) Charge the battery pack according to manual
2) Make sure airplane & transmitter are switch to ‘OFF’ & connect battery to airplane.
CHARGING BATTERY
LOCK
UNLOCK
Battery
Pack
Transmitter
LED
Charger
Cord

7
3) Securely hold the airplane’s fuselage underneath the wings with the nose facing
away from you. Be sure it is as far away as possible from your person and any
loose clothing or jewelry.
4) Turn the transmitter to the ‘ON’ position.
5) Switch the plane to the ‘ON’ position.
6) Push the left hand stick of the transmitter (the throttle stick) completely forward
until the battery runs out
7) Allow battery to cool COMPLETELY
8) Recharge the battery and repeat process 2 more times
PRE-FLIGHT CHECK
Important Tip: Always perform the motor-check and radio-range check with
the help of a friend or parent. Doing so alone may cause the model to get
away from you and cause damage.
RADIO RANGE CHECK
1) Make sure both the airplane and transmitter are in the ‘OFF’ position and plug
a charged battery into the airplane battery hatch.
2) Turn the switch on transmitter to the ‘ON’ position & extend the antenna fully
3) Switch the power switch on the airplane to the ‘ON’ position.
Note: The transmitter is always the fi rst thing on, and the last thing off.
4) Have a friend/parent hold the airplane’s fuselage under the wings with the nose
pointing away from him/her and away from their person and loose clothing.
5) Walk 25-ft away from airplane.
MOTOR CHECK
• Move the left-hand stick forward—the motor should run.
• Release the left-hand stick—the motor should stop.
RUDDER CONTROL CHECK
• Move the right-hand stick to the right—the rudder should move to the right
• Move the right-stick to the left—the rudder should move to the left.
If your airplane does not respond from 25 feet away do NOT attempt to fl y.
Contact Megatech at 1-888-634-2911 for further assistance
PRE-FLIGHT CHECK
25 FEET
MOTOR CHECK
Move
Throttle
Up






RUDDER CHECK

8FLIGHT SCHOOL
If you are under the age of 12, be sure to fl y with adult supervision.
1) Choose a Flying Site & Weather Conditions
• Choose a wide open area to fl y in such as
a football or baseball fi eld. Do not fl y in a
street or parking lot.
• Never fl y near cars, people, pets, power
lines, trees, houses, buildings or water.
• Be sure to keep your hands, eyes and face
away from propeller.
• Choose a day with little or no wind. Do not fl y in wind greater than 5mph.
• Humidity and temperature must be comfortable (around 55F-85F degrees) so
that the air is fairly dense.
• Your altitude should be less than 2,000-feet above sea level.
2) Pre-Flight Checklist (Perform in order listed)
• Fully extend transmitter antenna
• Install fully charged battery pack into fuselage
• Turn transmitter ‘ON’
• Switch airplane ‘ON’
REMEMBER: Your transmitter is always the fi rst thing on and the last thing off.
• Holding the plane away from you, move the right transmitter stick to ensure that the
rudder moves left and right accordingly.
3) Launching Airplane
• First attach the Wind Indicator Ribbon to the
end of your transmitter antenna to determine
the direction the wind is blowing.
• Always launch your airplane INTO the wind, so
begin with the wind blowing into your face.
• Hold plane’s fuselage directly under the wings
• Start with plane above your shoulders.
• Push left hand control stick all the way forward
• Using the horizon as a 0-degree point of reference, take 5 steps & toss plane at a 5 degree
upward angle into the wind. Use the same force it take to throw a dart at a dart board.
• Once you have let go of the plane continue to hold the left hand control stick up/forward.
DO NOT TOUCH THE RIGHT CONTROL STICK OR PLANE WILL CRASH. Allow the
plane to reach suffi cient altitude before attempting to turn (about 50 feet)
FLIGHT SCHOOL
CORRECT
WRONG
WRONG
Use only throttle
until reaching 50 ft.
Do not touch the
right control stick!
WIND
Proper way to hold airplane
WIND
0-5 MPH
TEMP
55˚F
to
85˚F

9
4) Turning
• Once your airplane has reached 50 feet above the ground you are ready to begin
turning. You want to keep the model within 100 feet of you at all times.
Beginners: Start with large oval circle patterns while learning.
Left Turn: Keep the throttle/left hand stick forward. Gently pulse/tap the right hand stick to
the LEFT 1-2 times, allowing it to return to the center.
Right Turn: Keep the throttle/left hand stick forward. Gently pulse/tap the right hand stick
to the RIGHT 1-2 times, allowing it to return to the center
WARNING: Holding right control stick to the right or left for more than 1-2 seconds
at a time will cause the airplane to crash
• Flying toward you can be very tricky because the airplane will appear to be turning in
the wrong direction. To regain orientation, imagine you are sitting in the pilot seat of the
airplane.
• If the airplane gains too much altitude, try releasing the throttle and continue gliding
and turning until you reach a more comfortable altitude.
5) Landing
When you notice the nose of the airplane drop slightly or it is unable to climb, it is time to land. You
will still have enough power over the controls to set the airplane up for a landing.
• Always land with the airplane nose going into the wind
• Set your plane up to face into the wind by making very gentle shallow turns.
• IMPORTANT: DO NOT
ATTEMPT TO MAKE
ANY TURNS WHEN
THE PLANE IS UNDER
25 FEET FROM THE
GROUND, THIS WILL
RESULT IN A CRASH.
• Once you are on the
fi nal landing approach
and your plane is facing
into the wind, gently let
the airplane glide to the
ground on it’s own. Only
use minor controls to keep
the wingtips level until the
plane touches down.
LEFT TURN RIGHT TURN
TAP TAP
WIND
LANDING
FLIGHT SCHOOL

10
6) Rise Off Ground (ROG)
For beginners we recommend hand launching your airplane until you become
comfortable with fl ying. Once you become more advanced, your CC Flyer is
capable of rising off the ground like a real airplane.
• First choose the proper take off strip. Make sure you have at least 30 feet of
smooth hard surface to use as a runway.
• Place airplane facing into the wind
• Stand behind the airplane and push throttle/left hand stick all the way forward.
• Apply ONLY throttle until the airplane reaches an altitude of at least 50 ft.
FLYING TIPS
• Always keep the plane in front of you. Do not fl y your CC Flyer directly overhead, as it
is easy to lose your sense of direction.
• Learn to fl y oval circuits out in front of you in both directions while maintaining
altitude—then, advance to fi gure-8s.
• As your fl ying skill improves, you will recognize air thermals (rising pockets of air) that
will greatly increase your fl ight time
• Always use fresh alkaline batteries in your transmitter to ensure solid radio signal.
• After each fl ight, make sure the airplane is turned ‘OFF’ and examine for any trapped
debris
• Wearing sunglasses will help you be able to locate the airplane at all times
• Make sure both LEDs on transmitter are illuminated. If Green LED is dim, change all 8
“AA” transmitter batteries before attempting to fl y. If it becomes dim during fl ight, land
as soon as possible to avoid losing control, then change all batteries in transmitter.
• The airplane’s antenna appears as a wire hanging out of the fuselage. Do NOT trim
the antenna. It is cut to a specifi c frequency length. To do so would drastically affect
radio range.
FLYING TIPS
WIND



11
TROUBLESHOOTING
If you are experiencing trouble, please follow these guidelines or call one of our
MegaTechnicians at 1-888-634-2911. We will have you up and fl ying in no time!
Q1) Dive
A1) Hand launch straight
toward horizon
A2) Wing not secured
properly
Q2) Climb and stall
A) Release throttle and let plane glide until the nose becomes parallel with
the ground, then apply throttle again.
Q3) No power/short fl ight duration
A) Cycle battery
Q4) Too much altitude
A) release the left control stick and continue making turns until the CC Flyer
glides to a more comfortable level.
Q5) Too low to ground
A) Keep right hand stick in the center and add motor thrust by pushing the left
control stick forward.
REPAIR, REPLACEMENT & SPARE PARTS LIST
• Fix and minor wing tears with clear packing tape
• Your CC Flyer comes with a replacement propeller. Remove the broken propeller and
replace with the new one following the instructions on page 5 of this manual.
PART# DESCRIPTION
MTC995001 VERTICAL & HORIZONTAL TAIL SET
MTC995002 PROPELLER SET (3PCS)
MTCSV-024 RUBBER WING BANDS
MTC995003 LANDING GEAR
MTC995004 MAIN WING SET (W/ STRUT, SUPPORT & SCREWS)
MTC995005 WING SUPPORT TUBES
MTC995008 BATTERY HATCH & MOUNT
MTC735001 TRANSMITTER ANTENNA
MTC735002 TRANSMITTER BATTERY HATCH
MTC3910 6V 5-CELL NIMH HIGH PERFORMANCE BATTERY PACK
MTC3850 CHARGING CABLE
MTC38040 DC QUICK CHARGER
TROUBLESHOOTING
2
1

WARRANTY
Megatech® Limited Warranty
Megatech® International guarantees this item to be free from defects for a period
of 90 days from date of purchase. This warranty does not extend beyond the initial
prefl ight testing. Carefully check parts and operation BEFORE your fi rst fl ight.
Damage incurred during fl ying, landing, crashing or modifi cation is not covered
under the warranty.
If you discover defects during the very fi rst prefl ight testing (pg. 7 of this manual)
during this 90 day period, please call our Support Team toll free at 1-888-634-2911
for Return Authorization. If in our opinion after inspecting the product, we determine
it to be defective; we will repair or replace it at our discretion.
Contact the Megatech® International Service Department before returning any item
that is defective according to the limitations listed above.
If you are issued return authorization and asked to send the item to our Service
Department please follow these steps:
• Remove the battery pack from the airplane and the alkaline batteries from
the transmitter.
• Pack the returned item(s) carefully and place in a sturdy shipping carton
• Return the product along with proof of purchase
• Include a letter describing the problem
• Include your address and telephone number
Megatech International
ATTN: Service Department
8300 Tonnelle Avenue
North Bergen, NJ 07047
[phone]
This warranty does not cover any damage caused by use, misuse, alteration, accident, or
neglect, nor does it covaer normal wear and tear of the product. Product returned to us which
falls under this category will be submitted to our service department for repair. We reserve
the right to charge any service and parts fees incurred when repairing the item.
Although this warranty does not cover and damage caused to the plane after the initial
prefl ight testing, spare parts and service are available. Please see pg. 11 of this manual.
Under no circumstances will Megatech® International or any of its representatives be held liable for injury to persons or property damage
resulting from assembly or use of the product. Megatech® is not liable if any outside radio frequencies interfere with the product’s frequency
causing loss of control. Megatech® International will not be held liable for any personal injury or property damage resulting from an out-of-
control model caused by use or misuse of the product.
This warranty is void if the product in question has been altered or repaired by anyone other than Megatech International or an authorized agent.
