MegaTech Mega Missile Launcher User manual

Entire contents © Megatech
www.megatech.com

If you have questions about operating or installing your new Megatech
product, or if you are missing parts... Please Call Megatech First!
DO NOT RETURN THIS PRODUCT TO THE STORE
Call our Customer Service Department at:
[phone]
10:00am - 5:00pm, EST Monday through Friday (except holidays)
Technical assistance is also available on-line at www.megatech.com
or by e-mail to [email protected]
Greetings Commander. Your assignment is to protect the
neighborhood. To help assure the success of this mission, you will
be fully instructed in the proper use of your Mega Missile Launcher.
This new, top-secret weapon is part of the Peace Keeper series from
the arsenal of Megatech. It packs a ton of classifi ed technology,
enabling it to race forward or back, turn in either direction, make
360Ο turns, climb 30Ο slopes and cross rough terrain or obstacles.
Your turret elevates into position and rotates 350Ο to launch up to 10
missiles with realistic lights and sound effects.
Please read this entire manual carefully before your fi rst mission
with the Mega Missile Launcher.
If you experience any problems, DO NOT take your Mega Missile
Launcher back to the store! Call one of our MegaTechnicians at:
1-888-MEGA-911 or send an e-mail to: [email protected]
10:00am-5:00pm EST, Monday through Friday (except holidays)
Technical assistance is also available on-line at www.megatech.com
or by e-mail to: [email protected]
DO NOT RETURN THIS PRODUCT TO THE STORE
TABLE OF CONTENTS
Getting Acquainted with your Mega Missile Launcher .........................3
Safety Warnings ...................................................................................4
Charging the Batteries ..........................................................................4
Installing the Batteries .........................................................................5
Loading the Missiles ...........................................................................5
The Radio Transmitter ..........................................................................6
Operating the Vehicle ..........................................................................6
Maneuvering the Turret ........................................................................8
Ordering Spare Parts ...........................................................................9
Troubleshooting ..................................................................................10
Limited Warranty ................................................................................11
2
Table of Contents

Important! Before you begin, please read the warnings
listed on the following page. Failure to comply with the
following recommendations could lead to bodily harm or injury.
The Megatech Mega Missile Launcher is not intended for those
under 6 years of age without proper adult supervision.
Please read before operating your Mega Missile Launcher.
PACKAGE CONTENTS
Before going any further Commander, please check that your Mega
Missile Launcher package contains all of the following items, using
the picture below as a guide:
3
Package Contents
PACKAGE CONTENTS
Getting Acquainted with Your Mega Missile Launcher
A. Mega Missile Launcher D. Foam Missiles
B. Battery Pack E. Flag/Antenna Guard
C. Battery Charger F. Radio Transmitter
If any of these items are missing from your package, please contact
Megatech.
A. Mega Missile Launcher D. Foam Missiles
A
B
C
D
E
F
Launch
Pad/Turret
Flag with
Antenna
Guard
Treads
Missiles

4
Safety Warnings
• Do not touch the plug or socket with wet hands to avoid electric
shock.
• Unplug the charger when fi nished charging the battery.
• Improper use of battery may lead to overheating, breakage or
leakage.
• Do not expose battery to water, fi re or extreme temperatures.
• Do not overcharge the battery!
• When fi nished using the vehicle, turn the power switch to
the “off” position and take the battery out of the vehicle.
• Turn on the remote controller before turning on the vehicle.
• Turn off the vehicle before turning off the remote controller.
• Do not use the vehicle in the rain or on wet surfaces.
• Avoid operation on loose soil or fi ne sand.
• Do not store at extreme temperatures.
• Since your Mega Missile Launcher is controlled by a radio link it
is very important to always use fresh alkaline batteries in the
transmitter. We recommend Megatech’s Golden Power series,
designed for R/C products.
• Do not trim the antenna. It is cut to a specifi c frequency length and to do
so would drastically affect radio range.
• Plug the battery into the charger.
• Insert the charger plug into a household
power socket.
• The battery will charge in about 3-4 hours.
After this time, unplug the charger and
battery.
• IF THE BATTERY FEELS HOT
DURING CHARGING,
DISCONNECT THE BATTERY AND
ALLOW IT TO COOL.
YOUR BATTERY IS FULLY CHARGED.
• The Mega Missile Launcher uses the latest NiMH (nickel-metal-hydride)
battery technology available. While NiMH batteries offer the best
performance available, they don’t come up to full potential until they have
gone through 3 or 4 charge and discharge cycles. After that, you should be
prepared for longer missions.
YOUR BATTERY IS FULLY CHARGED.
• Plug the battery into the charger.
Charging the Battery
Do not touch the plug or socket with wet hands to avoid electric
Safety Warnings

5
Batteries and Missiles
Vehicle
• Make sure the power switch is in the OFF
position and open the battery box cover.
• Attach the connectors on the battery and
inside the vehicle and insert the
battery back into the battery box.
• Close and lock the battery cover.
*NOTE* If your vehicle slows down,
your battery charge may be getting
low. Recharging the battery should
return your vehicle to top speed. The
battery pack should last approximately
20 minutes per charge. Different
terrains may affect battery life.
Radio Transmitter
• Open the battery cover and install a
9V alkaline battery making sure the
+ and - polarities are correct.
• Replace the battery cover.
• When the switch is “ON”, the power light will glow to show that you have
correctly installed the battery.
• The transmitter battery will last for approximately 8 hours.
Loading The Missiles
Installing the Batteries
• Insert the plastic side of the missiles
into the turret’s holes. Press gently
and rotate them until they lock into
place.
• If there is diffi culty loading any of
the missiles, do not force them in.
Simply press the missile launching
button on the remote control and try
reloading the missiles again.
CAUTION
• When loading missiles, always face the turret away from yourself and
others.
• Do not use any of the missiles if the foam material has been removed.
• Additional missiles may be ordered if yours become damaged or lost.
CAUTION
• When loading missiles, always face the turret away from yourself and
CAUTION
• When loading missiles, always face the turret away from yourself and
• Make sure the power switch is in the OFF
position and open the battery box cover.
• Attach the connectors on the battery and
• When the switch is “ON”, the power light will glow to show that you have
Lock
Unlock

6
Operating the Vehicle
• Do not touch the plug or socket with wet
hands to avoid electric
shock.
• Unplug the charger when fi nished charging
the battery.
• Improper use of battery may lead to over-
heating, breakage or
leakage.
• Do not expose battery to water, fi re or ex-
•
Do not touch the plug or socket with wet
hands to avoid electric
Do not touch the plug or socket with wet
hands to avoid electric
Do not touch the plug or socket with wet
hands to avoid electric
Move Foward
Push both control sticks
forward.
Move Backward
Pull both control sticks
backward.
The Radio Transmitter
Operating The Vehicle
Easy to drive - For ease of use, the controls are non-proportional.
Simply press both control sticks all the way up or pull them both
all the way back to travel in a straight line.
Turret
Right Turn
Turret
Left Turn
Antenna
Power Switch
Right
Tread
Control
Left
Tread
Control
Missile
Launchers
Front Back

7
Turning the Vehicle
NOTE - The tread may slip out if it is hindered when the vehicle is doing
high-speed rotation on a rough surface or lawn. Avoid rotating the vehicle
on such surfaces.
• If the tread slips out, switch off the vehicle and gently slide it back into
place.
Forward & Turn Right
Push the left stick
forward.
Forward & Turn Left
Push the right stick
forward.
Forward & Turn Right
Forward & Turn Left
Forward & Turn Left
Forward & Turn Left
Backward & Turn Left
Pull the right stick
backward.
Backward & Turn Right
Pull the left stick
backward.

8
Maneuvering the Turret
Maneuvering the Turret
treme temperatures.
• Do not overcharge the battery!
• When fi nished using the vehicle, turn the power switch to
the “off” position and take the battery out of the vehicle.
• Turn on the remote controller before turning on the vehicle.
• Turn off the vehicle before turning off the remote controller.
• Do not use the vehicle in the rain or on wet surfaces.
• Avoid operation on loose soil or fi ne sand.
• Do not store at extreme temperatures.
• Since your Mega Missile Launcher is controlled by a radio link it
is very important to always use fresh alkaline batteries in the
transmitter. We recommend Megatech’s Golden Power series,
designed for R/C products.
• Do not trim the antenna. It is cut to a specifi c frequency length and to
do
so would drastically affect radio range.
• When fi nished using the vehicle, turn the power switch to
the “off” position and take the battery out of the vehicle.
• Turn on the remote controller before turning on the vehicle.
treme temperatures.
• Do not overcharge the battery!
• When fi nished using the vehicle, turn the power switch to
the “off” position and take the battery out of the vehicle.
• Turn on the remote controller before turning on the vehicle.
• When fi nished using the vehicle, turn the power switch to
the “off” position and take the battery out of the vehicle.
• Turn on the remote controller before turning on the vehicle.
• When fi nished using the vehicle, turn the power switch to
the “off” position and take the battery out of the vehicle.
• Turn on the remote controller before turning on the vehicle.
Turn-in-Place: Left
Pull the left stick
backward and press the
right stick forward.
Turn-in-Place: Right
Push the left stick
forward and pull the
right stick backward.
• Turn off the vehicle before turning off the remote controller.
• Do not use the vehicle in the rain or on wet surfaces.
• Avoid operation on loose soil or fi ne sand.
• Do not store at extreme temperatures.
• Since your Mega Missile Launcher is controlled by a radio link it
is very important to always use fresh alkaline batteries in the
transmitter. We recommend Megatech’s Golden Power series,
designed for R/C products.
• Turn on the remote controller before turning on the vehicle.
• Turn off the vehicle before turning off the remote controller.
designed for R/C products.
Turn-in-Place: Left
designed for R/C products.
Turn-in-Place: Right
• Turn off the vehicle before turning off the remote controller.
• Do not use the vehicle in the rain or on wet surfaces.
• Avoid operation on loose soil or fi ne sand.
• Do not store at extreme temperatures.
• Since your Mega Missile Launcher is controlled by a radio link it
is very important to always use fresh alkaline batteries in the
transmitter. We recommend Megatech’s Golden Power series,
• Turn on the remote controller before turning on the vehicle.
• Turn off the vehicle before turning off the remote controller.
Turn-in-Place: Right
• Turn off the vehicle before turning off the remote controller.
• Do not use the vehicle in the rain or on wet surfaces.
• Avoid operation on loose soil or fi ne sand.
• Do not store at extreme temperatures.
• Since your Mega Missile Launcher is controlled by a radio link it
is very important to always use fresh alkaline batteries in the
transmitter. We recommend Megatech’s Golden Power series,
• Turn on the remote controller before turning on the vehicle.
• Turn off the vehicle before turning off the remote controller.
Turn-in-Place: Right
Turret: Turn Left
Press the right button
on the back of the
controller.
Turret: Turn Right
Press the left button
on the back of the
controller.
Turret: Turn Left
Turret: Turn Right
Turret: Turn Right

9
Ordering Spare Parts
Raise the Turret
Press the left or right missile
launcher button on the front of
the controller while the turret is
horizontal.
NOTE: To return the turret to
horizontal position, simply press it
down gently.
Launching the Missiles
Press the left or right missile
launcher button on the front of the
controller once the turret has been
raised.
RAPID FIRE: Hold down the left or
right button to send multiple missiles
to the target.
Raise the Turret
Launching the Missiles
Launching the Missiles
Launching the Missiles
45Ο
Your Mega Missile Launcher is
capable of climbing 30O inclines
and crossing obstacles like
bumps and ditches.
Ordering Spare Parts
Spare Parts List
840201 Mega Missile Launcher Rocket 10 Pack Yellow
824101 Mega Missile Launcher Rocket 10 Pack Orange
840203-27 Transmitter Channel 27 Green
840203-49 Transmitter Channel 49 Green
8241-27 Transmitter Channel 27 Desert Camo
8241-49 Transmitter Channel 49 Desert Camo
840202 Track Set ( 2 Pcs)
840204 Transmitter Battery Cover Green
824103 Transmitter Battery Cover Desert Camo
840205 Transmitter Antenna
840206 Tank Battery Cover Green
824105 Tank Battery Cover Desert Camo

10 Troubleshooting
PROBLEM CAUSE RECOMMENDATION
No power to radio 1. Power switch is 1. Move switch to the
control transmitter. in the “off” position. “on” position.
2. Batteries are 2. Make sure batteries
incorrectly installed. are installed correctly.
3. Batteries are 3. Replace the batteries
exhausted. with new alkaline
batteries.
Battery pack is not 1. Charger is not 1. Double check the
charging. properly connected. connection.
Mega Missile 1. Radio control 1. Slide the switch to the
Launcher is not transmitter is not “on” position.
under control. turned on.
2. Transmitter 2. Fully extend the
antenna is not fully antenna.
extended.
3. Transmitter 3. Replace the batteries
batteries are with new alkaline
exhausted. batteries.
4. You have driven 4. Be careful not to let
out of range. your Mega Missile Launcher
get too far away from you.
Mission duration has 1. Battery pack 1. Charge the batteries.
grown short. is exhausted.
2. Battery pack is 2. Allow battery pack
overheating. time to cool.
Turret does not stay 1. Turret is in odd 1. Rotate turret and try
closed. position. again.
Missiles won’t fi re. 1. Battery pack is 1. Recharge the battery
running low. pack.
2. Missile isn’t 2. Gently wiggle the
seated correctly. missiles and try again.
Turret won’t stay 1. Last turret rotation 1. Rotate the turret and
down in horizontal stopped between try again.
position. gears.

11
• Plug the battery into the charger.
• Insert the charger plug into a household
power socket.
• The battery will charge in about 3-4 hours.
After this time, unplug the charger and
battery.
Limited Warranty
Megatech® International guarantees this item to be free from defects
for a period of 90 days from date of purchase. If any component of
this product fails to function properly due to defects in materials or
manufacturing process during this 90 day period, the manufacturer’s
obligations are limited and manufacturer can choose to either repair
or replace the item.
This warranty is void if the product in question has been altered or
repaired by anyone other than Megatech® International or an
authorized agent.
Under no circumstances will Megatech® International or any of its
representatives be held liable for injury to persons or property
damage resulting from assembly or use of the product. Megatech®
is not liable if any outside radio frequencies interfere with the
product’s frequency causing loss of control. Megatech®
International will not be held liable for any injury to persons or
property damage resulting from an out-of-control model caused
by use or misuse of the product. Megatech® International expressly
excludes any and all express warranties not specifi cally stated here
and all implied warranties of merchantability and fi tness for a
particular purpose. There are no warranties which extend beyond the
description of the warranties contained herein.
Contact the Megatech® International Service Department before return-
ing any item that is defective according to the limitations listed above.
Please be sure to pack the returned item(s) carefully. The customer must
return the product along with proof of purchase, a letter describing the
problem and the customer’s address and telephone number. At this point
in time we will either repair the defective part or replace it and return it to
the customer. Return shipping and handling in the 48 contiguous states is
$12.99. Shipping outside of the 48 states will be quoted by location.
This warranty does not cover any damage caused by use, misuse,
alteration, accident, or neglect, nor does it cover normal wear and tear of
the product. Product returned to us which falls under this category will
be submitted to our service department for repair. We reserve the right to
charge any service and parts fees incurred when repairing the item.
Megatech® International
8300 Tonnelle Avenue
North Bergen, NJ 07047
[phone]
www.megatech.com
Limited Warranty

Megatech International
8300 Tonnelle Avenue
North Bergen, NJ 07047
[phone]
Megatech International
