HD1500T User Guide
Chapter 1 Introduction
Advanced Design
Meiji Techno America released the new generation scientific color
cameras--HD1500T With the amazing color fidelity, HD1500T
provides a perfect solution for the high definition scientific photography. To
meet the customer individual requirements, the flexible parameter settings
allow you to quickly get wonderful live images easily and freeze the screen
simply to observe the details.
HD1500T inherits all the advantages of the first generation HD1000T
cameras and significantly improve both the hardware and software, bring more
fluent visual experience and intuitive user interface.
To get more information about HD1500T, please read this document
completely.
Chapter 2 System Standard Items
One HD1500T camera,
One 12V2A power adapter,
One HDMI cable (2-meters length),
One SD card ( 8G capacity, class 10),
One mouse (with 1.5-meters cable),
One USB2.0 cable (gold plated connector).

1. USB interface：
A: Connect a mouse to the USB port. Use
the mouse to control the camera directly.
B: Connect the USB port to PC to make the
camera work as a Driver-Free camera. Use
ISCapture software to control it (similar as
using the other Tucsen cameras).
Note: No driver installation is needed when connecting HD1500T to PC via
USB port.
2. HDMI interface：
Use the HDMI cable to connect HD15000T to the monitor. Image data is
transferred and displayed on the monitor according to the HDMI protocol.
3. Power interface：
Please use the provided 12V2A power supply. When power is plugged in,
the red light is on. When switch on the camera, blue light is on.
4.ON/OFF key：
Press and hold ON/OFF key until the blue light is on or off to turn on or off the
HD1500T.
5.SD card：
To get faster and more stable data transfer, recommend to use Class10 SD
card.
6.C mount：
Standard C-mount optical port.
7. Anti-dust seal:
Please remove the seal when
first time use the camera.
The seal was placed on the
camera optical port when it left
the factory. It is used to avoid
the dust accumulating during
the transport.

Chapter 3 HDMI Operation
Step 1. Connect the camera.
1. Plug in the 12V2A power supply. Use HDMI cable to connect the camera to
the monitor. Press and hold ON/OFF key until blue light is on.
2. Connect the mouse to the USB port. Move the cursor to get the settings on
the screen.
3. Insert the SD card. Capture images or videos to the SD card.
Step 2. Move the cursor to the left of the screen.
When move the cursor to the left of the screen, ‘Capture’ and ‘Setting’ icons will appear
(See image on the left hand side). Click ‘Setting’ to get parameter setting menu (See
image on the right).
Capture
Setting
Capture
Setting
Step 3.Move the cursor to the right of the screen.

Step 4. Check the photo album and videos
1. Check the album and delete the pictures.
Picture 1 Picture 2 Picture 1 Picture 2
2. Check the video and delete the video. To delete the video successfully, be

sure this video is not in use.
Picture 1 Picture 2 Video 1Picture 1 Picture 2 Video 1
Step 5. Compare preview with the captured images.
Picture 1 Picture 2
Preview
Picture 1 Picture 2
Preview

Chapter 4 Connect HD1500T to PC
（1）Use USB cable to connect the HD1500T to the PC.
（2）Plug in the 12V2A power supply. Press and hold the ON/OFF key until
blue light is on to turn on the camera.
（3）No driver installation is needed when connected to PC. Install
ISCapture to adjust parameters and acquire images.
（4）
Fig.4-1. The left side of ISCapture
（1）Start the ISC. The parameter settings are shown on the left side of the
software. See Fig.4-1.
Note: When use ‘Lock WB’ , it takes 3 seconds to make sure the
camera finish the initialization.
（2）Switch the in ‘Exposure Control’ tab to get
different frame rate. In Normal mode, the image quality is better than
High mode. To get faster frame rate, please select High mode.
（3）Functions ‘Fluorescence’, ‘Temperature Control’ and ‘Fluorescence
Color’ are not available for HD1500T. These functions are gray
out when HD1500T camera is attached.

Fig.4-2. Function shortcuts on the right side of ISCapture
Fig.4-3. Captured image thumbnails
（1）Users can double click on one image thumbnail to display it. Click on
the little trangle button to get more captured image thumbnails.
（1）Further more, you also can select one or more images and delete them.
Fig.4-4. Imaging processing Fig.4-5. measurement

（1）Click on tab, get the image processing functions
(Fig.4-4).
（2）Provide Focus stacking, HDR, Fluorescence Combination functions
etc.
Note: When camera is disconnected, all the image processing functions will
be gray out.
（3）Click on tab to get measurement functions (Fig.4-5).
（4）It is allowed to apply measurements to the live and still images. To get
more details about measurement, please read the ISCapture software
manual.
Fig.4-6. About ISCapture
If have any questions, please Click on ‘Help’ to get Tucsen support
information.
All right reserved@Fuzhou Xintu Photonics Co., Ltd.

Cleanliness
When the camera is NOT in use, please screw in the dustproof cap to avoid
the dust from the environment accumulating on the optical port.
When get dust accumulated on surface of the optical port, recommend to use a
blower bulb to blow away the dust first. If it is still there, please use a very soft
lint free cloth (Micro Fiber cloth) with absolute ethyl alcohol or similar cleaning
agent to gently clean the surface.
If find the dust inside the camera, please DO NOT open the camera case by
yourself. Please contact Meiji Techno America support team to get further advice.
Maintain
Only Meiji Techno America reserve the right to open the camera
case for maintenance. If need repair, please contact the customer support
team.
CAUTION：Please DO NOT open the camera case and assemble it back by
yourself. If assemble the camera by yourself, it will easily bring dust and
moisture inside the cameras. Any sensor scratch or moisture issue brought by
opening the camera case by yourself is not covered by the warranty.
