MEN Mikro Elektronik F602 User manual

®
Embedded Solutions
F602 – 3U CompactPCI®
Express Side Card
20F602-00 E2 – 2010-03-30
User Manual
Configuration example

F602 - 3U CompactPCI Express Side Card
MEN Mikro Elektronik GmbH 2
20F602-00 E2 – 2010-03-30
F602 - 3U CompactPCI Express Side Card
The F602 is a 4HP CompactPCI® Express extension card for 3U Intel®-based
CompactPCI® single-board computers such as F14 and further boards of the Intel®
low power family. That way, these CPU boards can be used both as system-slot
cards in a CompactPCI® environment and as system-slot cards on a CompactPCI®
Express backplane.
The F602 supports 4 PCI Express® links with 1 lane each to the backplane via its
XJ2 and XJ3 connectors. In a standard 8-slot hybrid backplane from Schroff® the
CompactPCI® Express single-board computer sits in the middle, with the
possibility to plug another three legacy CompactPCI® cards to the left and three
CompactPCI® Express cards to the right.
In addition to the CompactPCI® Express functionality the F602 provides one USB
2.0, one COM (RS232, RS422/485, with or without optical isolation via SA-
Adapter™) and one DVI port at its front panel.
On top of that an onboard 2.5" SATA hard-disk slot is available on the F602.
The F602 is directly plugged to the right side of the respective single-board
computer. A robust connector makes for high mechanical stability. It is delivered
with an 8HP front panel, replacing the 4HP front panel of a 3U single-board
computer and thus resulting in a solid one-piece front panel.

Technical Data
MEN Mikro Elektronik GmbH 3
20F602-00 E2 – 2010-03-30
Technical Data
CompactPCI® Express
• Compliance with CompactPCI® Express PICMG EXP.0 R1.0 Specification
• CompactPCI® Express connector XP1 for power supply
• CompactPCI® Express connectors XJ2 and XJ3 for 4 CompactPCI® Express
links with 1 lane each
- CPU board F14 only supports 2 or 3 CompactPCI® Express links with 1 lane
each
• CompactPCI® Express connector XJ4 for control signals and ground
I/O
•DVI
- One DVI-D connector at front panel
- SDVO PanelLink transmitter
- Maximum resolution: 1600 x 1200 pixels
- 60Hz refresh rate
- Dual monitor support
•USB
- One USB 2.0 port
- Series A connector at front panel
- UHCI implementation
- Data rates up to 480Mbits/s
- High current up to 1A
•UART
- One at front panel
- Physical interface using SA-Adapter™ via 10-pin connector
- RS232..RS422, isolated or not
- Only full duplex operation for RS422
- Data rates up to 1 Mbit/s
- FIFO receive and transmit buffers for high data throughput
- Handshake lines: full support; lines depend on SA-Adapters™
Mass Storage
• Serial ATA (SATA)
- One port for onboard 2.5" hard-disk drive
- Transfer rates up to 150MB/s (depends on hard disk)
- RAID level 0/1 support (depends on CPU board)
Electrical Specifications
• Supply voltage/power consumption:
- +5V (-3%/+5%), tbd typ. (w/o hard disk)
- +3.3V (-3%/+5%), tbd typ. (w/o hard disk)

Technical Data
MEN Mikro Elektronik GmbH 4
20F602-00 E2 – 2010-03-30
Mechanical Specifications
• Dimensions: conforming to CompactPCI® specification for 3U boards
• Mountable on right side of the CPU
• Weight: 150g (w/o hard disk)
Environmental Specifications
• Temperature range (operation):
- 0..+60°C up to -40..+85°C (depending on hard disk; please refer to the hard
disk specifications for possible limits)
- Airflow: min. 10m³/h
• Temperature range (storage): -40..+85°C
• Relative humidity (operation): max. 95% non-condensing
• Relative humidity (storage): max. 95% non-condensing
• Altitude: -300m to + 3,000m
• Shock: 15g/11ms
• Bump: 10g/16ms
• Vibration (sinusoidal): 2g/10..150Hz
• Conformal coating on request
MTBF
• MTBF: 1,861,103h @ 40°C according to IEC/TR 62380 (RDF 2000)
Safety
• PCB manufactured with a flammability rating of 94V-0 by UL recognized manu-
facturers
EMC
• Tested according to EN 55022 (radio disturbance), IEC1000-4-2 (ESD) and
IEC1000-4-4 (burst)
Software Support
• Driver software can be found in the data sheet of the CPU board that you use.

Block Diagram
MEN Mikro Elektronik GmbH 5
20F602-00 E2 – 2010-03-30
Block Diagram
CPU Board
Board-to-
Board
Connector
BSA
USB-to-UART
Bridge F
USB 2.0 F
DVI F
Onboard
HDD
F
B
Front Panel connector
Onboard connector
SA SA-Adapter
Front
Panel
XJ2
XJ3
4x1
PCI Express
Links
CompactPCI
Express
Backplane
Connectors
RRear connector
R
SDVO
USB 2.0
SATA B

Configuration Options
MEN Mikro Elektronik GmbH 6
20F602-00 E2 – 2010-03-30
Configuration Options
Mass storage
• CompactFlash® interface instead of SATA hard disk
- Via AD95 adapter
Operation Temperature
• 0..+60°C
• -40..+85°C
Please note that some of these options may only be available for large volumes.
Please ask our sales staff for more information.
For available standard configurations see online data sheet.

Product Safety
MEN Mikro Elektronik GmbH 7
20F602-00 E2 – 2010-03-30
Product Safety
Electrostatic Discharge (ESD)
Computer boards and components contain electrostatic sensitive devices.
Electrostatic discharge (ESD) can damage components. To protect the board and
other components against damage from static electricity, you should follow some
precautions whenever you work on your computer.
• Power down and unplug your computer system when working on the inside.
• Hold components by the edges and try not to touch the IC chips, leads, or cir-
cuitry.
• Use a grounded wrist strap before handling computer components.
• Place components on a grounded antistatic pad or on the bag that came with the
component whenever the components are separated from the system.
• Store the board only in its original ESD-protected packaging. Retain the original
packaging in case you need to return the board to MEN for repair.
!

About this Document
MEN Mikro Elektronik GmbH 8
20F602-00 E2 – 2010-03-30
About this Document
This user manual describes the hardware functions of the board, connection of
peripheral devices and integration into a system. It also provides additional
information for special applications and configurations of the board.
The manual does not include detailed information on individual components (data
sheets etc.). A list of literature is given in the appendix.
History
Conventions
This sign marks important notes or warnings concerning proper functionality of the
product described in this document. You should read them in any case.
Folder, file and function names are printed in italics.
Bold type is used for emphasis.
A monospaced font type is used for hexadecimal numbers, listings, C function
descriptions or wherever appropriate. Hexadecimal numbers are preceded by "0x".
Hyperlinks are printed in blue color.
The globe will show you where hyperlinks lead directly to the Internet, so you can
look for the latest information online.
Signal names followed by "#" or preceded by a slash ("/") indicate that this signal is
either active low or that it becomes active at a falling edge.
Signal directions in signal mnemonics tables generally refer to the corresponding
board or component, "in" meaning "to the board or component", "out" meaning
"coming from it".
Vertical lines on the outer margin signal technical changes to the previous issue of
the document.
Issue Comments Date
E1 First issue 2007-04-18
E2 General update, minor errors corrected 2010-03-30
!
italics
bold
monospace
hyperlink
IRQ
#
/IRQ
in/out

About this Document
MEN Mikro Elektronik GmbH 9
20F602-00 E2 – 2010-03-30
Legal Information
MEN Mikro Elektronik reserves the right to make changes without further notice to any products herein. MEN makes no
warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does MEN assume
any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability,
including without limitation consequential or incidental damages.
"Typical" parameters can and do vary in different applications. All operating parameters, including "Typicals" must be
validated for each customer application by customer's technical experts.
MEN does not convey any license under its patent rights nor the rights of others.
Unless agreed otherwise, MEN products are not designed, intended, or authorized for use as components in systems intended
for surgical implant into the body, or other applications intended to support or sustain life, or for any other application in which
the failure of the MEN product could create a situation where personal injury or death may occur. Should Buyer purchase or
use MEN products for any such unintended or unauthorized application, Buyer shall indemnify and hold MEN and its officers,
employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable
attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or
unauthorized use, even if such claim alleges that MEN was negligent regarding the design or manufacture of the part.
Unless agreed otherwise, the products of MEN Mikro Elektronik are not suited for use in nuclear reactors or for application in
medical appliances used for therapeutical purposes. Application of MEN products in such plants is only possible after the user
has precisely specified the operation environment and after MEN Mikro Elektronik has consequently adapted and released the
product.
ESM™, ESMini™, MDIS™, MDIS4™, MENMON™, M-Module™, M-Modules™, SA-Adapter™, SA-Adapters™,
UBox™, USM™ and the MBIOS logo are trademarks of MEN Mikro Elektronik GmbH. PC-MIP® is a registered trademark
of MEN Micro, Inc. and SBS Technologies, Inc. MEN Mikro Elektronik®, ESMexpress®, MIPIOS® and the MEN logo are
registered trademarks of MEN Mikro Elektronik GmbH.
COM Express™ is a trademark of PCI Industrial Computer Manufacturers Group. CompactPCI® is a registered trademark of
PCI Industrial Computer Manufacturers Group. Microsoft® and Windows® are registered trademarks of Microsoft Corp.
Windows® Vista™ is a trademark of Microsoft Corp. PCI Express® and PCIe® are registered trademarks of PCI-SIG. PXI™ is
a trademark of National Instruments Corp. Phoenix® is a registered trademark of Phoenix Technologies Ltd. QNX® is a
registered trademark of QNX Ltd. CompactFlash® is a registered trademark of SanDisk Corp. Tornado® and VxWorks® are
registered trademarks of Wind River Systems, Inc.
All other products or services mentioned in this publication are identified by the trademarks, service marks, or product names
as designated by the companies who market those products. The trademarks and registered trademarks are held by the
companies producing them. Inquiries concerning such trademarks should be made directly to those companies. All other brand
or product names are trademarks or registered trademarks of their respective holders.
Information in this document has been carefully checked and is believed to be accurate as of the date of publication; however,
no responsibility is assumed for inaccuracies. MEN Mikro Elektronik accepts no liability for consequential or incidental
damages arising from the use of its products and reserves the right to make changes on the products herein without notice to
improve reliability, function or design. MEN Mikro Elektronik does not assume any liability arising out of the application or
use of the products described in this document.
Copyright © 2010 MEN Mikro Elektronik GmbH. All rights reserved.
Please recycle
Germany
MEN Mikro Elektronik GmbH
Neuwieder Straße 5-7
90411 Nuremberg
Phone [phone]
Fax [phone]
E-mail [email protected]
www.men.de
France
MEN Mikro Elektronik SA
18, rue René Cassin
ZA de la Châtelaine
74240 Gaillard
Phone [phone]
Fax [phone]
E-mail [e-mail]
www.men-france.fr
USA
MEN Micro, Inc.
24 North Main Street
Ambler, PA 19002
Phone [phone]
Fax [phone]
E-mail [email protected]
www.menmicro.com

Contents
MEN Mikro Elektronik GmbH 10
20F602-00 E2 – 2010-03-30
Contents
1 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.1 Map of the Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.2 Configuring the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.3 Integrating the Board into a System . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.4 Installing Driver Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.1 Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.2 Board-to-Board Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.2.1 Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.3 DVI Connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.4 USB Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.5 UART Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.5.1 Connection via 10-pin SA-Adapter Connector . . . . . . . . . . . 25
2.6 Serial ATA (SATA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.6.1 On-Board Hard-Disk Connector (SATA) . . . . . . . . . . . . . . . 29
2.7 CompactPCI Express Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
2.7.1 PCIExpress . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
2.7.2 CompactPCI Express Backplane Connectors . . . . . . . . . . . . 35
3 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3.1 Literature and Web Resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3.1.1 SATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3.1.2 CompactFlash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3.1.3 USB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3.1.4 DVI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3.2 Finding out the Board’s Article Number, Revision and Serial Number38

MEN Mikro Elektronik GmbH 11
20F602-00 E2 – 2010-03-30
Figures
Figure 1. Map of the board—front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Figure 2. Map of the board – top view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Figure 3. Labels giving the board’s article number, revision and serial number. 38

MEN Mikro Elektronik GmbH 12
20F602-00 E2 – 2010-03-30
Tables
Table 1. Pin assignment of the 114-pin board-to-board connector, pins 1..38. . 17
Table 2. Pin assignment of the 114-pin board-to-board connector, pins 39..76. 18
Table 3. Pin assignment of 114-pin board-to-board connector, pins 77..114. . . 19
Table 4. Signal mnemonics of 114-pin board-to-board connector . . . . . . . . . . . 20
Table 5. Pin assignment of DVI-I receptacle connectors . . . . . . . . . . . . . . . . . . 22
Table 6. Signal mnemonics of DVI connectors . . . . . . . . . . . . . . . . . . . . . . . . . 22
Table 7. Pin assignment of USB front-panel connector . . . . . . . . . . . . . . . . . . . 23
Table 8. Signal mnemonics of USB front-panel connector . . . . . . . . . . . . . . . . 23
Table 9. Signal mnemonics of UART interfaces . . . . . . . . . . . . . . . . . . . . . . . . 24
Table 10. Pin assignment of 10-pin SA-Adapter UART connector . . . . . . . . . . . 25
Table 11. Signal mnemonics of SATA connectors . . . . . . . . . . . . . . . . . . . . . . . 28
Table 12. Pin assignment of SATA connector for on-board hard disk . . . . . . . . 29
Table 13. Pin assignment of the two 3-pin power supply connectors
XP1 (board revisions <R00.03.xx). . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Table 14. Pin assignment of 7-pin power supply connector XP1 (board
revisions R00.03.xx and higher). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Table 15. Pin assignment of CompactPCI Express connector XJ2 . . . . . . . . . . . 36
Table 16. Pin assignment of CompactPCI Express connector XJ3 . . . . . . . . . . . 37
Table 17. Pin assignment of CompactPCI Express connector XJ4 . . . . . . . . . . . 37

Getting Started
MEN Mikro Elektronik GmbH 13
20F602-00 E2 – 2010-03-30
1 Getting Started
This chapter gives an overview of the board and some hints for first installation in a
system.
1.1 Map of the Board
Figure 1. Map of the board—front panel
DVI COM USB

Getting Started
MEN Mikro Elektronik GmbH 14
20F602-00 E2 – 2010-03-30
Figure 2. Map of the board – top view
Hard-disk guide rail
On-board SATA
2.5" hard disk drive
Standoff screw
Board-to-Board Connector
X1
SATA (on-board HDD)
SA-Adapter
Hard-disk guide rail
USB
port
USB
DVI
CompactPCI Express
Connectors

Getting Started
MEN Mikro Elektronik GmbH 15
20F602-00 E2 – 2010-03-30
1.2 Configuring the Hardware
You should check your hardware requirements before attaching the F602 to a
CPU board, since most modifications are only possible when the boards are
disconnected. You should also stick to the following order.
The following check list gives an overview on what you might want to configure.
;SATA hard disk on board
You can easily install a 2.5" SATA hard disk. MEN offers a suitable hard disk.
Installation material is already supplied with F602.
See MEN’s website for ordering information.
Refer to Chapter 2.6.1.1 Installing a Hard Disk on page 30 for a detailed
installation description.
;SA-Adapter on board
The board is shipped without SA-Adapter installed. To use the UART, you can
install an SA-Adapter directly on the board.
See MEN’s website for ordering information.
Refer to Chapter 2.5.1.1 Installing SA-Adapter Directly on F602 on page
25 for a detailed installation description.
;CompactFlash instead of hard disk
The hard disk can be exchanged for a CompactFlash on a special adapter card.
See MEN’s website for ordering information.
Refer to Chapter 2.6.1.2 Installing CompactFlash Adapter on page 33 for
a detailed installation description.
1.3 Integrating the Board into a System
The F602 is suited as a side card for different MEN CPU boards. If you are not sure
if your CPU board is supported, please check the CPU’s data sheet.
If the F602 can be used with your CPU, attach it to the CPU board as is described in
the CPU board’s user manual.
1.4 Installing Driver Software
For a detailed description on how to install driver software please refer to the
respective documentation.
You can find any driver software available for download on MEN’s website.
!

Functional Description
MEN Mikro Elektronik GmbH 16
20F602-00 E2 – 2010-03-30
2 Functional Description
2.1 Power Supply
The board is supplied with +5V, +3.3V and +12V via the CPU board (board-to-
board connector) and via the CompactPCI Express backplane connector XP1.
2.2 Board-to-Board Connector
The F602 side card is attached to a CPU board using a board-to-board connector.
This connector supports special I/O functions from the CPU.
The board-to-board connector is located at the bottom side of the board, so that the
F602 can be attached to the right side of a CPU board.
The board-to-board connector on F602 supports the following interfaces:
• Four PCI Express links with one lane each
• One SATA channel
•OneUSB
• One USB-to-UART interface
• One SDVO-to-DVI bridge
See MEN’s website for available board versions.
2.2.1 Connection
Connector types:
• 114-pin matched impedance plug connector, MICTOR 0.64 mm grid
• Mating connector:
114-pin matched impedance receptacle connector, MICTOR 0.64 mm grid

Functional Description
MEN Mikro Elektronik GmbH 17
20F602-00 E2 – 2010-03-30
Table 1. Pin assignment of the 114-pin board-to-board connector, pins 1..38
1GND
GND
2GND
3SATA_TX+ 4 -
5SATA_TX- 6 -
7GND 8GND
9SATA_RX+ 10 -
11 SATA_RX- 12 -
13 GND 14 GND
15 PCIE1_TX+ 16 PCIE3_TX+
17 PCIE1_TX- 18 PCIE3_TX-
19 GND 20 GND
21 PCIE1_RX+ 22 PCIE3_RX+
23 PCIE1_RX- 24 PCIE3_RX-
25 GND 26 GND
27 PCIE0_TX+ 28 PCIE2_TX+
29 PCIE0_TX- 30 PCIE2_TX-
31 GND 32 GND
33 PCIE0_RX+ 34 PCIE2_RX+
35 PCIE0_RX- 36 PCIE2_RX-
37 GND 38 GND
12
39 40
77 78

Functional Description
MEN Mikro Elektronik GmbH 18
20F602-00 E2 – 2010-03-30
Table 2. Pin assignment of the 114-pin board-to-board connector, pins 39..76
39 +3.3V
+5V
40 +3.3V
41 USB_2_3_OC# 42 -
43 - 44 -
45 GND 46 -
47 USB_D3- 48 -
49 USB_D3+ 50 -
51 GND 52 GND
53 USB_D2- 54 PCIE_WAKE#
55 USB_D2+ 56 PLT_RST#
57 GND 58 LINKCAP
59 - 60 SMB_CLK
61 - 62 SMB_DATA
63 GND 64 GND
65 - 66 SDVOCTRL_CLK
67 - 68 SDVOCTRL_DATA
69 GND 70 GND
71 PCIE_CLK_A_REF+ 72 -
73 PCIE_CLK_A_REF- 74 -
75 GND 76 GND
39 40
77 78

Functional Description
MEN Mikro Elektronik GmbH 19
20F602-00 E2 – 2010-03-30
Table 3. Pin assignment of 114-pin board-to-board connector, pins 77..114
77 GND
GND
78 GND
79 - 80 -
81 - 82 -
83 GND 84 GND
85 SDVOB_BLUE- 86 -
87 SDVOB_BLUE+ 88 -
89 GND 90 GND
91 SDVOB_GREEN- 92 -
93 SDVOB_GREEN+ 94 -
95 GND 96 GND
97 SDVOB_RED- 98 -
99 SDVOB_RED+ 100 -
101 GND 102 GND
103 SDVOB_CLK- 104 -
105 SDVOB_CLK+ 106 -
107 GND 108 GND
109 SDVOB_INT- 110 -
111 SDVOB_INT+ 112 -
113 GND 114 GND
113 114
39 40
77 78

Functional Description
MEN Mikro Elektronik GmbH 20
20F602-00 E2 – 2010-03-30
Table 4. Signal mnemonics of 114-pin board-to-board connector
Signal Direction Function
Power +3.3V in +3.3V power supply
+5V in +5V power supply
GND -Digital ground
SATA SATA_RX+,
SATA_RX-
out Differential pair of SATA receive lines, port 0
SATA_TX+,
SATA_TX-
in Differential pair of SATA transmit lines, port 0
PCI
Express
PCIE_CLK_A_REF
+,
PCIE_CLK_A_REF-
in Reference clock A 100 MHz
PCIE0_RX+,
PCIE0_RX-
out Differential pair of PCIe receive lines, port 0
PCIE0_TX+,
PCIE0_TX-
in Differential pair of PCIe transmit lines, port 0
PCIE1_RX+,
PCIE1_RX-
out Differential pair of PCIe receive lines, port 1
PCIE1_TX+,
PCIE1_TX-
in Differential pair of PCIe transmit lines, port 1
PCIE2_RX+,
PCIE2_RX-
out Differential pair of PCIe receive lines, port 2
PCIE2_TX+,
PCIE2_TX-
in Differential pair of PCIe transmit lines, port 2
PCIE3_RX+,
PCIE3_RX-
out Differential pair of PCIe receive lines, port 3
PCIE3_TX+,
PCIE3_TX-
in Differential pair of PCIe transmit lines, port 3
PCIE_WAKE# out Wake signal from PCIe device to wake F602
from sleep state
USB USB_D[2]+,
USB_D[2]-
in/out Differential pair of USB lines, port 2
USB_D[3]+,
USB_D[3]-
in/out Differential pair of USB lines, port 3
USB_OC23# out USB overcurrent, ports 2 and 3
