Declaration of Conformity
Mercury Marine declares that the following product to which this declaration relates is in conformity with the requirements of EU
directive 2014/30/EU (Electromagnetic Compatibility), and Section 182 of the Australian Radiocommunications
(Electromagnetic Compatibility) standard 2008, and satisfies all the technical regulations applicable.
The assessment has been carried out in accordance with Annex II of the above directive.
Product Mercury Marine VesselView 403
This product has been tested to the following standards.
Standard
Standard Description
EN 60945:2002
Clause 9 and 10
Maritime Navigation and Radiocommunication Equipment and Systems —
General Requirements — Methods of Testing and Required Test Results
Test Report
Laboratory Report Number
TÜV SÜD AMERICA INC. SD72119173‑0816 Rev.1
I, the undersigned, hereby declare that the equipment specified above conforms to the above Directives and standards for CE
marking for sale in the European and Australian communites.
Authorized Representative
Address Mercury Marine, W6250 Pioneer Road, P.O. Box 1939 Fond du Lac, WI 54936‑1939
Signature
John Pfeifer, President, Mercury Marine
Date 10/01/2017
The attention of the purchaser, installer, or user is drawn to special measures and limitations to use which must be observed
when the product is taken into service to maintain compliance with the above directives. Details of these special measures and
limitations to use are contained in the appropriate product manuals.
VesselView Overview
IMPORTANT: VesselView is a multifunction display (MFD) that is compatible with products manufactured by Mercury Marine
Outboards, Mercury MerCruiser, Mercury Diesel. In addition, the VesselView software can be installed on compatible display
devices from Lowrance® and Simrad®. Some of the functions explained in this manual will be disabled depending on the
power package it is connected to.
VesselView is a comprehensive boat information center that can display information for up to two gasoline or diesel engines. It
continuously monitors and reports operating data including detailed information such as water temperature and depth, trim
status, boat speed and steering angle, and the status of fuel, oil, water, and waste tanks. VesselView can be fully integrated
with a vessel’s global positioning system (GPS) or other NMEA‑compatible devices to provide up‑to‑the‑minute navigation,
speed, and fuel‑to‑destination information. VesselView is a display extension for autopilot and joystick operations. All
functionality of these piloting features are controlled through Mercury Marine's autopilot control area network (CAN) pad or
joystick piloting control. VesselView will show if a mode of control is active or in standby; pop‑ups will appear as the vessel
arrives at waypoints, prompting response to turns. Additional display text can be used to adjust the engines and drives to
achieve maximum efficiency.
Display resolution 320 x 240 – H x W
Display type LED‑backlit optically bonded full‑color transflective TFT‑LCD
Display size 104 mm (4.1 in.)
Display viewing angle 170 degrees
Operating temperature –25 °C to 65 °C (–13 °F to 149 °F)
Operating temperature stored –40 °C to 85 °C (–40 °F to 185 °F)
Water resistance IPX7
Section 1 - Getting Started
Page 2 90-8M0124182 eng DECEMBER 2017

Product width 118 mm (4.64 in.)
Product depth 36.5 mm (1.43 in.)
Product height 115 mm (4.52 in.)
Product weight 0.32 kg (0.7 lb)
Power consumption 2.2 W (maximum)
Power supply NMEA 2000®
NMEA 2000 load equivalency number 4 network loads
VesselView 403 Front Panel
VesselView 403 utilizes five hard buttons with no touchscreen functionality.
Front controls
a - Menu button
b - Down arrow button
c - Enter button
d - Up arrow button
e - Speed control button
•The Menu button provides access to the Mercury menu features.
•The Down arrow button provides downward navigation of on‑screen options or selections.
•The Enter button is used to select, engage, disengage, or to save a selection.
•The Up arrow button provides upward navigation of on‑screen options or selections.
•The Speed control button provides access to speed control features of the VesselView.
64768
a
b
c
d
e
Section 1 - Getting Started
90-8M0124182 eng DECEMBER 2017 Page 3

VesselView 403 Rear Panel
The wiring connection points on the rear panel of the VesselView allow for the connection of the Mercury SmartCraft network
communication cable, and for the unit to communicate over a NMEA 2000 network. There is also an USB port for utilizing a
wi‑fi dongle, as well as for connecting a portable storage device for updating software, uploading vessel personalities, or
downloading screen captures.
Rear panel
a - Mercury SmartCraft connection
b - NMEA 2000 connection
c - USB port
Wiring Architecture
The following image depicts a typical wiring architecture for incorporating VesselView into a boat's communication network.
a - Optional connection to a chartplotter or multifunction display
b - 120 ohm termination resistor, male
c - 120 ohm termination resistor, female
d - NMEA® 2000 fused power source
e - Power bus
f - NMEA® 2000 T‑connector
g - VesselView 403
h - Weather capped—unused
i - Junction box
a
b
c
64773
62802
a
bc
d
e
f
g
h
i
ENTER
Section 1 - Getting Started
Page 4 90-8M0124182 eng DECEMBER 2017

Device Maintenance
IMPORTANT: It is recommended that the supplied white plastic sun cover be installed for protection when the unit is not in
service.
Display Screen Cleaning
Routine cleaning of the display screen is recommended to prevent a buildup of salt and other environmental debris. Crystalized
salt can scratch the display coating when using a dry or damp cloth. Ensure that the cloth has a sufficient amount of fresh water
to dissolve and remove salt deposits. Do not apply aggressive pressure on the screen while cleaning. When water marks
cannot be removed with the cloth, mix a 50/50 solution of warm water and isopropyl alcohol to clean the screen. Do not use
acetone, mineral spirits, turpentine type solvents, or ammonia based cleaning products. The use of strong solvents or
detergents may damage the antiglare coating, the plastics, or the rubber keys. It is recommended that the sun cover be
installed when the unit is not in use to prevent UV damage to the plastic bezels and rubber keys.
Media Port Cleaning
The media port cap area should be cleaned on a regular basis to prevent a buildup of crystalized salt and other debris.
Electrical connections
Routine inspection of the electrical connections should be performed to prevent the buildup of crystalized salt and other debris.
Section 1 - Getting Started
90-8M0124182 eng DECEMBER 2017 Page 5

Section 1 - Getting Started
Notes:
Page 6 90-8M0124182 eng DECEMBER 2017

Section 2 - Initial Screens and Setup Wizard
Table of Contents
Splash Screen........................................................................ 8
Setup Wizard.......................................................................... 8
Overview.......................................................................... 8
Import Configuration........................................................ 9
Engine Setup................................................................... 9
Device Setup................................................................. 11
Joystick Installed............................................................11
Speed Setup.................................................................. 11
Units Setup.................................................................... 14
Tank Setup.................................................................... 14
Active Trim Setup.......................................................... 18
Finishing Setup Wizard.................................................. 19
Source Selection Notice................................................ 20
Creating Screen Captures.................................................... 20
2
Section 2 - Initial Screens and Setup Wizard
90-8M0124182 eng DECEMBER 2017 Page 7

Splash Screen
Upon startup, VesselView will display an initial splash screen. An image of an engine in the lower corner indicates that the
engine power on the vessel is emission controlled.
64808
Splash screen
Setup Wizard
Overview
The VesselView Setup Wizard guides you through the first steps of configuring the VesselView. The Setup Wizard can be
accessed at any time by pressing the Menu button. In the menu screen, use the Down Arrow button to navigate to the
Settings option. In the Settings menu, use the Down arrow to navigate to the System option and launch Wizard.
At the Welcome screen, press the Down arrow button to begin the Setup Wizard.
64813
Section 2 - Initial Screens and Setup Wizard
Page 8 90-8M0124182 eng DECEMBER 2017

Import Configuration
The setup wizard will begin by asking the operator if there is a configuration file that has been saved to the local storage in the
unit, or loaded on the USB storage device inserted into the back of the unit. This can be helpful and save setup time if the
settings and preferences to be used for this vessel are identical to a vessel which has already been used to create a
configuration file. If there is no file to import, press the Down arrow button to continue with the wizard. If there is a configuration
to import, use the file browser menu option to locate the configuration file. Refer to Section 3 ‑ File Browser.
65795
Engine Setup
In the engine setup section of the setup wizard, the operator can select the engine model, the number of engines on the vessel,
and the number of engines, up to two, which will be displayed on a particular VesselView.
NOTE: VesselView 403 will only display data for two engines. Vessels with three or more engines will require additional
VesselView 403 units.
Press the Enter button to bring up the selection of engines. Use the arrow buttons to navigate up and down the list. Press the
Enter button when the correct engine is highlighted.
64814
64815
Engine selection
Section 2 - Initial Screens and Setup Wizard
90-8M0124182 eng DECEMBER 2017 Page 9

Press the Enter button to bring up the Number of Engines screen. Use the up and down arrow buttons to select the correct
number of engines on the vessel.
64816
64817
Number of engines
Press the Enter button to bring up the Engines Shown selection screen. Depending on the number of engines selected in the
previous step, appropriate options will only be shown. For example, if three engines was selected, the operator would be given
the options of Port, Starboard, and Center. Use the arrow buttons to highlight an option and press the Enter button to activate
the check box of the engines that will be displayed on the VesselView. A maximum of two engines can be displayed on a single
VesselView 403.
When finished with the Engine Setup portion of the Wizard, press the Menu button to return to the Engine Setup screen. Press
the Down arrow button to continue to the next step of the Wizard.
64819
64820
Engines shown
Section 2 - Initial Screens and Setup Wizard
Page 10 90-8M0124182 eng DECEMBER 2017

Device Setup
In the Device Setup screen, use the up and down arrow buttons and the Enter button to confirm selection. If using multiple
VesselView devices, be sure to assign unique numbers to each unit to avoid data transmission problems. Helm numbers
should match the location of the individual VesselView unit. It is common to make the main helm 1 and the secondary helm 2.
Press the Down arrow button to continue with the Wizard.
64823
64824
Helm and device setup
Joystick Installed
For vessels equipped with Joystick Piloting, highlight and select the Joystick Installed check box option. This will ensure that
inputs to the system, initiated by the joystick, will be recognized by the VesselView unit.
65801
Speed Setup
The speed source determines how speed data is obtained. A strategy utilizes pitot and paddlewheel data to establish the
vessel's speed. When strategy is selected, the pitot and paddlewheel data source engine must be selected. GPS utilizes the
data coming from the GPS unit to determine speed. When GPS is selected, the proper network BUS must be selected as the
source of GPS data to the VesselView.
Use the Up arrow and Down arrow buttons and the Enter button to make selections in the Speed Setup screens.
Section 2 - Initial Screens and Setup Wizard
90-8M0124182 eng DECEMBER 2017 Page 11

Highlight and select the GPS Source.
64825
Speed source selection
For GPS speed data, select the CAN Bus that transmits the GPS data over the SmartCraft network.
65293
Highlight and select the Speed Source option.
65292
Section 2 - Initial Screens and Setup Wizard
Page 12 90-8M0124182 eng DECEMBER 2017

For a speed Strategy, highlight and select the Pitot source option and choose the engine PCM that will report the data from the
pitot sensor.
65294
64827
Engine position selection
Select the Paddle source option and choose the engine PCM that will report data from the paddlewheel sender.
65295
Section 2 - Initial Screens and Setup Wizard
90-8M0124182 eng DECEMBER 2017 Page 13

64827
Engine position selection
The PCM positions for vessels with multiple engines is shown in the following illustration.
a - PCM0 = starboard outer
b - PCM1 = port outer
c - PCM2 = starboard inner or center
d - PCM3 = port inner
When selections are completed in the Speed Setup portion of the Wizard, press the Down arrow button to continue to the next
step of the Wizard.
Units Setup
VesselView allows the operator to select the units of measure which are displayed. Use the Up Arrow and Down Arrow
buttons and the Enter button to make a selection.
64829
64830
Units of measure to display
When selections are completed in the Units Setup, press the Down Arrow button to continue with the Wizard.
Tank Setup
IMPORTANT: Check that all tank sensors and senders are connected properly to the network before attempting to configure
new tanks.
Tank setup allows the operator to select the tank type, set the volume of the tank, and name the tank.
a
a
a
b
b
b
c
c
d
60056
a
Section 2 - Initial Screens and Setup Wizard
Page 14 90-8M0124182 eng DECEMBER 2017

With Tanks highlighted, press the Enter button to continue.
65337
With the Configure new tank highlighted, press the Enter button.
65338
The tank configuration screen contains all of the information that VesselView will require to display accurate tank data.
Tank configuration screen
a - Detected tank sensor
b - Type of tank
c - The tank name
d - The tank capacity
e - Tank reading inversion
f - Tank calibration
g - Save option
NOTE: Selecting genset fuel as a tank type will not add the volume of the genset tank to the overall volume of the vessel
propulsion fuel tanks.
65339
a
b
c
d
e
f
g
Section 2 - Initial Screens and Setup Wizard
90-8M0124182 eng DECEMBER 2017 Page 15
