Meridian DSP5000C User manual

Background
Meridian has led the market with their highly acclaimed DSP loudspeaker
designs. These combine excellent acoustic and drive-unit technology, with
multiple built-in power amps and unique performance-enhancing DSP and
digital conversion systems. The Meridian DSP loudspeaker is the ultimate
expression of the speaker builder’s art.
Meridian DSP5000C
The centre channel supplies dialogue in movies, and sharpens the musical
stage. It can also add tremendous energy and should not be dismissed lightly
when assembling a surround system.
The DSP5000C is a single-box DSP loudspeaker in a front-facing format that
can be effectively built into system cabinets.
The DSP5000C is heavily shielded for use near the largest television screens.
Like every Meridian digital active speaker, it carries all necessary electronics on
board, including three 75-watt amplifiers, two converters, digital crossovers and
a complement of powerful computers.
Using Digital Signal Processing (DSP), internal computers adjust bass, treble
and absolute phase while remaining sonically transparent. The same DSP
system also provides equalisation settings to allow optimum performance
when installing a DSP5000C in one of five common room positions: free-
standing, wall-bound, above or belowa TV, or behind a projection screen.
The DSP5000C uses linear-phase digital crossovers. With no phase shift, a
digital crossover brings voices and instruments into sharp relief.
The DSP5000C blends seamlessly with other Meridian equipment, but can also
be adjusted, using its powerful DSP, to match any high quality stereo system.
Although horizontally disposed, the DSP5000C is not only a centre speaker. If
you prefer the horizontal or shelf-mounting format, it can be used in stereo
pairs, or for any position in a surround system.
Acoustic system and format
The DSP5000C is a powerful 2.5-way active acoustic reflex design. The bass
system uses two 160mm long-throw composite bass drivers. This
configuration, along with the active and DSP correction, delivers a combination
of smooth powerful bass and very low mid-range colouration.
The tweeter is the Meridian 25mm aluminium-dome, silver-wire tweeter used in
all the DSP loudspeakers.
DSP5000C
DSP Centre-channel Loudspeaker
Sales information
1st December 2001
•2.5-way active loudspeaker with
DSP crossover
•Self-contained audio system, each
comprising three custom drivers,
three amplifiers, two digital
converters, digital crossovers
and advanced sound-shaping DSP
computers
•Remote controlled and requiring
no unsightly speaker cables
•Listener control over features
including bass, treble tilt,
listening axis, volume, time-
compensated balance and
absolute phase
•Cabinet constructed from MDF,
braced and damped and finished
with wood veneer
•DSP for correcting response to
speaker placement
•Maximum output level up to
108dB spl
Meridian Audio Limited
Stonehill, Stukeley Meadows
Huntingdon
Cambridgeshire PE29 6EX
T [phone]
F+44 (0) 1480 445686
Meridian America Inc.
Suite 122, Building 2400
3800 Camp Creek Parkway
Atlanta GA 30331
T [phone]
F [phone]
www.meridian-audio.com

Technical Specification
Performance: Frequency response in-room within 3dB from 35Hz to over
20kHz.
Output >108dB spl @ 1m on music material.
Noise less than 15dB spl.
Overall distortion typically <0.02% at any frequency or level.
Inputs: Two digital inputs to SPDIF standard; 32kHz–96kHz sampling
rates at up to 24 bit; MHR support. (A future software update
will enable support for 192kHz.)
Construction: 2.5-way acoustic reflex system.
2 x 160mm polypropylene high-efficiency long-throw custom
drivers.
1 x 25mm aluminium-dome tweeter, silver wire, short horn-
loaded with protective grille.
Cabinet constructed from high-density MDF. Integral magnetic
shielding and user-changeable real wood veneer acoustic
damping side panels.
FIFO memory buffer input for the lowest possible jitter from
almost any source.
Two precision 128x oversampling converters for bass, mid
and tweeter signals.
Analogue gain and filtering using proprietary Meridian Class-A
discrete amplification.
Digital and conversion electronics constructed using
advanced surface-mount techniques and partitioned 4-layer
printed-circuit boards.
Three 75W power amplifiers, one for each of the drivers.
Power amplifiers use a unique feedback topology and
precision local error-correction systems to achieve a
performance equivalent to the conversion system.
Dimensions: 195mm (7.7in) H, 670 (26.38) W, 275 (10.83) D
Weight 32kg (71lb) each
DSP: 100MHz Motorola digital signal processor.
Digital crossover at 2.6kHz.
Response correction for the whole system.
Bass protection.
User tone controls.
Volume and phase control.
Controls: Rear-panel controls for power On/Off.
MSR and RS232 port provide controlover bass, treble tilt,
listening axis, volume, time-compensated balance and
absolute phase.
Front display: Eight-character display with system lights, can be blank.
