Merit Blinds Powershade Installation manual

SINGLE
CHANNEL
REMOTE
PROGRAMMING INSTRUCTIONS
MULTI
CHANNEL
REMOTE
UP DOWN
C
L
LEFTSTOP RIGHT
FRONT
INITIAL SET UP
LINK REMOTE TO MOTOR
1. Tostartyouwillneedaninstalledmotorised 
 blind,remotecontrolandpushpin/paperclip/
 pen.Forinstallation,pleasefollowPowershade
 AssemblyInstructions.
2. Makesurewhenttingtheblindintothe 
 bracketsthatthemotorwithRED button 
 &chargeportarefacingdownwards
 (towardsyou).
3. Resetthemotorbypressingandholdingthe
RED buttonintheheadrailforapprox
8 SECONDSuntilthemotorJOGS TWICE.
4. Tolinktheremotecontroltothemotor,rstpressandholdtheRED buttononthemotoruntil
 themotorJOGS ONCE.
5. Ifusingamulti-channelremotecontrol,selectthedesiredchannel.Usethebuttons
 toselectchannel.Ifnotusingmulti-channelremote,continuetostep6.
6. Press“C”onthebackofremotecontroluntilthemotorJOGS ONCE.Theremotecontrol
 isnowlinkedandreadytobeset.
BACK
7. Checkwhetherthemotoristurninginthecorrectdirection.Todothis,pressthebutton
 ontheremotecontrol.Iftheblindmovesdown,themotordirectiondoesnotneedtobe
 adjusted.Ifpressingthebuttonraisestheblind,youneedtoadjustthemotordirection.
8. Tochangethemotordirection:pressandholdboth“L”andbutton(TIP: Press “L” button
on the back of the remote rst).ThemotorwillJOG ONCEtoconrmchange.Checktheblind
 isnowmovinginthecorrectdirectionforthearrows.Ifnot,pleaserepeatstep8.
CHANGING MOTOR DIRECTION
SET BLIND LOWER LEVEL
9. Pressandhold“L”onthebackoftheremotecontroluntilthemotorJOGS THREE TIMES.
 ThemotorisnowinLEVEL SETTING MODE.
10.Pressthebuttonontheremotecontrol.Theblindwillbegintolower.
11.Whentheblindisnearingthepreferredlowerlevel,pressthebuttonontheremotecontrol.
12.Pressbuttonstoaccuratelypositionthelowerlevel.
13.Whentheblindhasreachedthecorrectposition,press“C”onthebackofremotecontrol.
14.ThemotorwillJOG ONCEtoconrmlevelpositionisset.Thisconcludesthelowerlevel
 settingbutthemotorisstillinLEVEL SETTING MODE.

SET MID LEVEL
1. Yourblindbatteryrequireschargingapproxevery6months*.Whenyourblindstartstorun
 slowly,thebatteryneedstobecharged.
*This can vary depending on size of the blind, weight of the fabric and the amount of useage.
2. Connectthesuppliedrecharger,andchargethebatteryfor5-6hours.
3. TherechargerlightwillturnfromREDtoGREEN whencharged.Whenthelightturnsgreen
 werecommendchargingforafurtherhourtoensureafullcharge.
CHARGING
GROUPING
20.Tosetamidlevel,runtheblindtothedesiredpositionusingthebuttonsonthe
 remotecontrol.
21.Pressandholdboth“L”anduntilthemotorJOGS ONCE(TIP: Press “L” button on the
back of the remote rst).Themidlevelpositionisnowset.
22.Whentheblindisintheupperorlowerlevelpositionsonly,pressthebuttonfortheblind
 tocycletothemidlevelposition.
23.Programeachblindasperstandardprogramminginstructions(steps1-22).
 Selectwhichblindsaretobegrouped.(We recommend grouping a maximum
 of5blinds per channel).
Foreachblindtobegrouped:
24. Firstly,pressandholdtheRED buttononthemotoruntilthemotorJOGS THREE times.
 Thisbreaksanylinktoaremote,butkeepsthelimitsalreadyprogrammed.
25. PressandholdtheRED buttononthemotoruntilthemotorJOGS ONCE.
26. Ifusingamultichannelremote,selectwhichchannelistobeused.
 (Skipthisstepifusingasinglechannelremote).
27.Pressthe“C” buttononthebackoftheremotetolinktheremotetothemotor.
28.Repeatsteps24-27forremainingblindsthataretobegrouped.
29.Onceyouhavegroupedallyourblinds,usingtheorbuttonsonyourremotecontrol
 willoperateallselectedblindstogether.Theindividuallimitpresetsofeachblindwill
 beretained.
SET UPPER LEVEL
15.Pressbuttonontheremotecontrol.Theblindwillbegintorise.
16.Whentheblindisnearingthepreferredupperlevelpressthebuttonontheremotecontrol.
17.Pressthebuttonstoaccuratelypositiontheupperlevel.
18.Whentheblindhasreachedthecorrectposition,press“C”onthebackoftheremotecontrol.
19.ThemotorwillJOG ONCEtoconrmlevelpositionisset.Thisconcludestheupperlevel
 setting.ThemotorhasnowexitedLEVEL SETTING MODE.
PROGRAMMING INSTRUCTIONS
