Ergolux MANHATTAN ELMAOFCHRBA User manual

MANHATTAN OFFICE
CHAIR
ELMAOFCHRBA, ELMAOFCHRWA

Hardware
IM8 20mm screw (x2)
JM8 25mm screw (x2)
KM6 25mm screw (x8)
L Cover (x8)
M Allen key (x1)
ACastor (x5)
BBase (x1)
CGas lift (x1)
DGas lift cover (x1)
ESeat (x1)
FMechanism (x1)
GArmrests (x2)
HBack (x1)
COMPONENTS
G-L
G-R

Step 1: Secure the castors (A) into the base (B). Place the gas lift (C) onto the base (B), then
place the gas lift cover (D) over the gas lift (C).
Step 2: Align the mechanism (F) with the seat (E). Using the Allen key (M), secure the
mechanism (F) with two M8 25mm screws (J) and two M6 25mm screws (I) to
approximately 80%. Do not fully tighten at this stage.
I(x2)
J(x2)
M(x1)
ASSEMBLY
D
C
B
A
J
I
F
E
80%
Front

Step 3: Secure the mechanism (F) and seat (E) onto the gas lift (C).
Step 4: Using the Allen key (M), secure the armrests (G) to the seat (E) with four M6 25mm
screws (K).
Fully tighten the M8 20mm screws (I) and M8 25mm screws (J) installed in step 2.
K(x4)
M(x1)
E
C
F
K
G
K
I
J
100%

Step 5: Using the Allen key (M), secure the base of the back (H) to the armrests (G) with two
M6 25mm screws (K).
K(x2)
M(x1)
Step 6: Lift the back (H) to an upright position and using the Allen key (M), secure it in place
with two M6 25mm screws (K).
K(x2)
M(x1)
K
K
H
K
K
H
G
G
G

Step 7: Insert the covers (L) over the armrests (G).
L (x8)
Assembly is complete.
L
L
G
G

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
