Mesa/Boogie SINGLE RECTIFIER RECT-O-VERB 50 2 Series Quick start guide

Series 2

SINGLE RECTIFIER - RECT O VERB (Series 2)
FRONT PANEL
CHANNEL 1 CHANNEL 2
Control Function Type Mesa Part# Control Function Type Mesa Part#
Clean/Pushed Switch 607101 Raw/Vin/Mod Switch 607303
Gain Pot 593792 Gain Pot 592794
Knob 408110 Knob 408110
Treble Pot 593148 Treble Pot 592738
Knob 408110 Knob 408110
Middle Pot 592378 Middle Pot 593737
Knob 408110 Knob 408110
Bass Pot 593148 Bass Pot 593739
Knob 408110 Knob 408110
Presence Pot 593737 Presence Pot 593150
Knob 408110 Knob 408110
Reverb Pot 593151 Reverb Pot 593151
Knob 408110 Knob 408110
Master Pot 592738 Master Pot 593739
Knob 408110 Knob 408110
Green LED LED 395438 Red LED LED 395753
Lens 703300 Lens 703300
REAR PANEL
MISC PARTS MISC PARTS
Control Function Type Mesa Part# Control Function Type Mesa Part#
Input Jack 610120 Slave Jack 618112
Output Pot 593148 Speaker Outs (3) Jack 618112
Knob 408110 Bias Select Switch 602000
Solo Pot 593148 FX Loop
Knob 408110 Mix Level Pot 593736
Pilot Light Knob 408110
Light 703047 Return Jack 618112
Lens 703782 Send Jack 618112
Light Holder 703822 External Swtch
Standby Switch 600631 Reverb Jack 618112
Power Switch 600631 Solo Jack " "
Channel Jack " "
Footswitch Jack 613615
Channel Select Switch 600631
Fuse Holder
Domestic Cap/Holder 790347
Fuse 790250
Export Cap/Holder 790346
Fuse 795101
AC Receptacle Jack 613713

SINGLE RECTIFIER - SOLO 50 (Series 2)
FRONT PANEL
CHANNEL 1 CHANNEL 2
Control Function Type Mesa Part# Control Function Type Mesa Part#
Clean/Pushed Switch 607101 Raw/Vin/Mod Switch 607303
Gain Pot 593792 Gain Pot 592794
Knob 408110 Knob 408110
Treble Pot 593148 Treble Pot 592738
Knob 408110 Knob 408110
Middle Pot 592378 Middle Pot 593737
Knob 408110 Knob 408110
Bass Pot 593148 Bass Pot 593739
Knob 408110 Knob 408110
Presence Pot 593737 Presence Pot 593150
Knob 408110 Knob 408110
Master Pot 592738 Master Pot 593739
Knob 408110 Knob 408110
Green LED LED 395438 Red LED LED 395753
Lens 703300 Lens 703300
REAR PANEL
MISC PARTS MISC PARTS
Control Function Type Mesa Part# Control Function Type Mesa Part#
Input Jack 610120 Slave Jack 618112
Output Pot 593148 Speaker Outs (3) Jack 618112
Knob 408110 Bias Select Switch 602000
Solo Pot 593148 FX Loop
Knob 408110 Mix Level Pot 593736
Pilot Light Knob 408110
Light 703047 Return Jack 618112
Lens 703782 Send Jack 618112
Light Holder 703822 External Swtch
Standby Switch 600631 Solo Jack 618112
Power Switch 600631 Channel Jack 618112
Footswitch Jack 613615
Channel Select Switch 600631
Fuse Holder
Domestic Cap/Holder 790347
Fuse 790250
Export Cap/Holder 790346
Fuse 795101
AC Receptacle Jack 613713
