Owner’s Manual
SAFETY PRECAUTIONS:
• Readtheseinstructions.
• Keeptheseinstructions.
• Heedallwarnings.
• Followallinstructions.
• Donotusethisapparatusnearwater.
• Cleanonlywithdrycloth.
• Besuretouseonlyproperlyratedpoweradaptors or
universalpowersupplies(pedalboardpowersupplies)
withappropriate attention paid to propervoltage,am-
perageandgroundschemes.Impropervoltage/amper-
agebeingprovidedtothepedalmaycausepoortone,
inconsistentperformance,damagetotheunitor allof
the above. Proper voltage, amperage and grounding
specsaresuppliedattheendofthismanual.
• REPLACE THE BOTTOM LID after battery replace-
ment before the unit is used. Some electronic parts
inside are static sensitive and can be damaged from
evenasmallstaticchargefromcontactwithcarpetor
otherconductivesurfaces.DONOTSETAPOWERED
UNIT “CONTROLS UP” ON A METAL (or any) SUR-
FACEWITHTHEBOTTOMREMOVED!
CongratulationsonyourchoiceofMESA/Boogieandwel-
cometotheMESAFamily!Thesamepassionforexcel-
lence,commitmentto quality and dedicationto customer
satisfactionispresentineachandeveryproductwemake
inourone-and-onlyshop in Petaluma,California,U.S.A.
Rest assured that the very same people that hand-build
thenestampliersintheworldbuiltyourpedalandyou
have access to the same resources for help that all our
customersdo.Callonusanytimeandenjoy!
TONE BURST™
TheTONEBURSToffersavirtuallytransparentgainrange
usually associated with devices in the Clean Boost cat-
egory.Thereisenoughadditionalgainheretoboostthe
signalofyourguitartothethresholdofclipandbeyond.If
you are searching for an Overdr ive device that can sub-
stantiallyboostyourinstrument’sgain, auditionourGRID
SLAMMER™ or the more fully featured FLUX-DRIVE™
andTHROTTLEBOX™pedals.
TherangeoftheGAINcontrolontheTONEBURSTshines
forhelpingsingle-notelinespopoutofadensemixorfor
addingedgeandattitudetorhythmparts.Youcanalsouse
the LEVEL control to introduce additional gain and push
therststageinyouramplierforavintage-inspiredclip.
This device features separate Tone controls for TREBLE
and BASS regions and these can be used to color the
boosted signal and further accentuate your boosted or
showcasedparts.If you don’t wantadditional frequency
enhancement,simply set theTone controls to 12:00 and
theinstrument’ssignalwillremainvirtuallyunchangedand
provideanearlytransparentboost.
FEATURES & CONTROLS
IN: This¼”phonojackis theInstrumentInputforthe
device. Plug the Output of your guitar - or an upstream
pedal’s Output - into this jack with a shielded cable of
goodquality.The input jackisa switchingtype jackand
thecircuitisactivatedbyinserting a cable(evenwiththe
footswitchoff).Oncepluggedin,theinternalbatteryisbe-
ingusedtopowerit–sobesuretounplugthecablefrom
theINPUTwhenit’snotinuse.
NOTE: The internal battery is switched to an “ON” state
(drawing voltage) by a switching element in the INPUT jack.
To prolong battery life, disconnect the cable from the ¼”
INPUT jack whenever the unit is not in use.
NOTE: If you wish to leave the INPUT connected perma-
nently – as in a pedal board scenario – it is advisable to
power the unit with an external 9V power supply. When an
external (plug-in) AC 9-volt power supply is used to power
the unit, the DC jack on the pedal automatically discon-
nects the battery to avoid battery wear and preserve its
useful life. If you are going to use external AC power either
for long periods or permanently in a pedal board set-up,
remove the internal battery to prevent (forgotten) battery
corrosion.
OUT: This1/4”phonojackistheOUTPUTforthedevice.
ConnecttheOUTPUTtotheInputofyouramplier-orthe
INPUTofthenextdeviceinlineinyourpedalboard.
NOTE: A Word on Cables… Always use shielded instru-
ment cables of the best quality and shortest length possible
when connecting these types of devices. This will minimize
degradation of your sound, particularly high frequency
roll-off, due to the added capacitance in longer lengths of
cable. We recommend no more than 18-20 feet total (Input
and Output combined) between your instrument and the
termination at the INPUT of the amplifier. If you must use
longer cable lengths, you might consider the use of a Buffer
or Line Driver to keep the tonal integrity intact. While these
change the sound slightly, it will usually be preferable to
top end roll-off. And yes – those little 4” interconnects count
too, so count them in your cable length.
LEVEL: Thisisthemasteroutputlevelanditcontrolsthe
amountof signalprovidedto thehostamplier.Itcanbe
usedeithertobalancelevelstocompensateforhighGAIN
settings- so that no jump in leveloccurs when switched
outofBYPASS. AnotherapplicationishigherLEVELset-
tingstopurposefullysendahottersignaltothehostamp
and“slam”theinputstageforincreasedclip,driveorgain.
GAIN: Thiscontroldeterminestheamountofgain(over-
drive)inthesignalpath.
Set low (8:00 – 11:00) is the least useful of the GAIN
control’srange.LowGAINsettingswillrequiretheLEVEL
control be increased dramatically to achieve unity gain
comparedtothepedalbypassed.
Themiddlerange(11:00–1:30)offerssubtleandtasteful
increasesof boost and gain.GAIN settings in this range
canaddadynamicpunchthatkeepsnotesexpressiveand
tight.ThisworkswellforbothRhythmandSoloworkacross
manystylesofmusic.
ThehighrangeoftheGAINcontrol(1:30–5:30)offersthe
mostusefulandvariedboostanddriveoptions.Forchord-
ing, this region adds bite, attack and punch. For single
notes,higherGAINsettingsaddcutandhelpsolosstand
outinamix.Foranystyle,thisrangepushestheamplier’s
inputpastthethresholdofclip.
BASS: Thiscontrolworks in tandem with theTREBLE
controltoadjustlowfrequencies. Set low (7:30 – 12:00)
thesoundwillbeskinny,tightandpercussive.Thehigher
range (12:00 – 5:30) introduces rich, full low end that
rounds out the sound and adds low-end thump. Heavier
pickattackwithhigherBASSsettingsmayproduceaslow-
er,lessarticulatefeelasyou“dragaround”theextralows.
TREBLE: This controladjuststheamount of high fre-
quenciespresentinthemixand–unlikedeviceswithjusta
TONEcontrol-allowsyoutonetunethehighfrequencies
separatelyfromthelowfrequencies.TheTREBLEcontrol
makesuphalfofamorecomprehensivetonecontrolcircuit
thatoffersgreaterexibilityovertheentirefrequencyspec-
trum.Setlow(7:30–12:00)thesoundwillbedarker,more
rounded and seemingly compressed. The upper range
oftheTREBLE (12:00 –5:30)brings in the cut,biteand
moreopentop-end to create asoundthat is bright,tight
andaggressive.
AC POWER: This standard femaleDC Receptacle on
thepedalistheExternalPowerSupplyJackanditaccepts
themaleplugfromastandard9-Volt“wall-wart”ACpower
supply.Wheninstallingyourunitintoapedalboardutilizing
auniversalpowersupply(multi-outputpedalboardpower
®
®
supplies), connect the external power source here. The
internalbatteryisautomaticallydisconnectedbyaswitch-
ingelementintheExternal DC Receptacle on the pedal.
However,ifyouknowyouwill not beusingbattery power
foranextendedperiod–forexample,ifyouaremounting
theunittoyourpedalboardpermanently-itiswisetore-
movethebatterytoavoidpossibledamagefromlong-term
batterycorrosion.
INTERNAL BATTERY: Thisunitcanoperateoneithera
9-Voltbatteryorastandard9-Volt“wall-wart”powersupply.The
unitisshippedfrom the Factory with a long-life 9-VoltBattery
tofacilitateeasiertrialdemonstrationinamusicstoreenviron-
ment.
NOTE: The internal battery is switched to an “ON” state (draw-
ing voltage) by a switching element in the INPUT jack. Discon-
nect the cable from the ¼” INPUT jack whenever the unit is not
in use to prolong battery life.
BATTERY REPLACEMENT: Toaccessthe9-Voltbattery
for inspection, replacement or removal; make sure the Exter-
nalPowerJackisdisconnected,removethefourPhillips-head
screwsfromthe fourcorners ofthe bottom lid andremoveit.
Notetheorientation/directionof thebatteryand terminalsand
replaceitinthesameposition.
NOTE: Any type of 9-Volt battery will work in this device if it
is fully charged and functional. Carbon Zinc, Alkaline or even
Nickel Cadmium Rechargeable type batteries are all acceptable
replacements. Some pedal aficionados prefer the “sweetness”
they claim to hear from standard Carbon Zinc type batteries,
but you will have to decide what type best serves your needs.
SPECIFICATIONS:
• Dimensions (W/D/H): 2.87” x 4.77” x 2.28” (73mm x
122mmx58mm)
• Weight: 0.802lbs (364g) with batter y, 0.702lbs (319g)
withoutbattery
• TrueBypassSwitching
• BatteryType:9VDC(one)
• PowerConsumption(CurrentDraw):9VDC/15mA
• AC Adapter (Optional): Power Jack 2.1mm x 5.5mm,
9VDCwithNegativeCenter(RegulatedRecommend-
ed)
• InputImpedance:2MOhm(500kOhmminimum)
• OutputImpedance:10kOhm
SAMPLE SETTINGS: SAMPLE SETTINGS: USER SETTINGS:
TRANSPARENT BOOST PUSHED RHYTHM
SMOOTH SOLO OLD SCHOOL
