Metal Fusion 2290 User manual

ASSEMBLY INSTRUCTIONS
AND
USE AND CARE MANUAL
THE INSTRUCTION MANUAL CONTAINS IMPORTANT INFORMATION NECESSARY
FOR THE PROPER ASSEMBLY AND SAFE USE OF THE APPLIANCE.
READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS BEFORE ASSEMBLING
AND USING THE APPLIANCE. FOLLOW ALL WARNINGS AND INSTRUCTIONS WHEN
USING THE APPLIANCE.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
METAL FUSION, INC.
712 St. George Avenue.
Jefferson, LA 70121
If you have any problems or questions
Call Us Toll Free at
1-800-783-3885
7:30 AM to 3:30 P.M. CST • Monday through Friday
[phone]
www.kingkooker.com
OUTDOOR COOKERS
2290/22CAB
MODEL/SERIAL # __________
FAILURE TO FOLLOW THESE INSTRUCTIONS
AND WARNINGS COULD RESULT IN FIRE, EXPLOSION, BURN HAZARD OR CARBON
MONOXIDE POISONING WHICH COULD CAUSE PROPERTY DAMAGE, PERSONAL
INJURY OR DEATH.
English

FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and immediately
call your Fire Department.
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN FIRE OR EXPLOSION
WHICH COULD CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
1. Never operate this appliance unattended.
2. Never operate this appliance within 10 feet (3.05m) of any structure,
combustible material or other gas cylinder. Do not locate this
appliance under ANY overhead construction.
3. Only use propane burning units outdoors. Risks include fire and
carbon monoxide fumes. Lack of ventilation can cause injury or
death.
4. Never operate this appliance within 25 feet (7.5 m) of any flammable
liquids or vapors.
5. Do not fill cooking vessel beyond maximum fill line.
6. When cooking with oil/grease, always use the thermometer
provided and never allow the oil/grease to get hotter than 350°F
(177°C). If the temperature exceeds 350°F (177°C) or if oil begins
to smoke, immediately turn the burner or gas supply OFF.
7. Heated liquids and equipment remain at scalding temperatures
long after the cooking process. Never touch cooking appliance
until liquids have cooled to 100°F (38°C) or less.
8. If a fire should occur, keep away from the appliance and immediately
call your Fire Department. Do not attempt to extinguish an oil/
grease fire with water. When cooking, have a Type BC or ABC fire
extinguisher readily available. A Type BC or ABC fire extinguisher
may, in some circumstances, contain the fire.
2
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD
RESULT IN FIRE, EXPLOSION, BURN HAZARD OR CARBON MONOXIDE
POISONING WHICH COULD CAUSE PROPERTY DAMAGE, PERSONAL
INJURY OR DEATH.
DANGER
DANGER

3
1) This is an ATTENDED appliance. Do NOT leave this appliance unattended
while the burner is lit or while heating oil, grease, water or cooking food.
Monitor the appliance when hot after use [oil, grease or water above 100 ° F
(38 ° C)]. Heated liquid and equipment can remain at scalding temperatures
long after cooking has ended.
2) Keep children, pets and unauthorized persons away from the appliance at
all times.
3) The use of alcohol, prescription or non-prescription drugs may impair
your ability to properly assemble or safely operate this appliance. Do NOT
assemble or operate this appliance if using alcohol, prescription or non-
prescription drugs.
4) This appliance is for OUTDOOR use only. Do NOT use in a building, garage,
tent or any other enclosed area. Do NOT use in or on a recreational vehicle
or boat. NEVER use this appliance as a heater.
5) Do not locate this appliance under ANY overhead construction. Keep a
minimum clearance of 10 ft. (3.05m) from the sides, front and back of the
appliance to ANY construction. Keep the area clear of ANY combustible
material. Do not use on or under ANY apartment or condo balcony or
deck.
6) When cooking, the fryer/boiler must be on a level, stable, noncombustible
surface such as brick, concrete or dirt. Not suitable are surfaces such as
wood, asphalt or plastic which may burn, blister or melt.
7) Check all cooker fittings for leaks before each use. Keep the fuel supply
hose away from any heated surfaces. Only the LP hose/regulator assembly
specified by Metal Fusion, Inc. should be used with this appliance.
8) This appliance is not for frying turkeys.
9) When cooking with oil or grease, the thermometer provided MUST be
used. Follow instructions in this manual for proper installation and use of
thermometer. If the thermometer supplied with the fryer/boiler has been
lost or damaged, a replacement thermometer specified by Metal Fusion,
Inc. shall be obtained before using the appliance.
10) If the temperature of cooking oil exceeds 350 ° F (177 ° C) or if oil begins to
smoke, immediately turn the burner or gas supply OFF and wait for the
temperature to decrease to less than 350 ° F (177 ° C) before relighting burner
according to the instructions in this manual.
11) When cooking with oil/grease, have a Type BC or ABC fire extinguisher
readily available. In the event of an oil/grease fire, do not attempt to
extinguish with water. Immediately call the Fire Department. A Type BC or
ABC fire extinguisher may, in some circumstances, contain the fire.
12) NEVER overfill the cooking pot with oil, grease or water. Follow instructions
in this manual for establishing proper oil, grease or water levels.
READ AND UNDERSTAND BEFORE USING THIS PRODUCT
Throughout this manual the words appliance, cooker, fryer/boiler, burner and stove
will be used interchangeably to refer to the King Kooker® Outdoor Cooker.
3
1) This is an ATTENDED appliance. Do NOT leave this appliance unattended
while the burner is lit or while heating oil, grease, water or cooking food.
Monitor the appliance when hot after use [oil, grease or water above 100 ° F
(38 ° C)]. Heated liquid and equipment can remain at scalding temperatures
long after cooking has ended.
2) Keep children, pets and unauthorized persons away from the appliance at
all times.
3) The use of alcohol, prescription or non-prescription drugs may impair
your ability to properly assemble or safely operate this appliance. Do NOT
assemble or operate this appliance if using alcohol, prescription or non-
prescription drugs.
4) This appliance is for OUTDOOR use only. Do NOT use in a building, garage,
tent or any other enclosed area. Do NOT use in or on a recreational vehicle
or boat. NEVER use this appliance as a heater.
5) Do not locate this appliance under ANY overhead construction. Keep a
minimum clearance of 10 ft. (3.05m) from the sides, front and back of the
appliance to ANY construction. Keep the area clear of ANY combustible
material. Do not use on or under ANY apartment or condo balcony or
deck.
6) When cooking, the fryer/boiler must be on a level, stable, noncombustible
surface such as brick, concrete or dirt. Not suitable are surfaces such as
wood, asphalt or plastic which may burn, blister or melt.
7) Check all cooker fittings for leaks before each use. Do not use a flame
to check for gas leaks. Keep the fuel supply hose away from any heated
surfaces. Only the LP hose/regulator assembly specified by Metal Fusion,
Inc. should be used with this appliance.
8) This appliance is not for frying turkeys.
9) When cooking with oil or grease, the thermometer provided MUST be
used. Follow instructions in this manual for proper installation and use of
thermometer. If the thermometer supplied with the fryer/boiler has been
lost or damaged, a replacement thermometer specified by Metal Fusion,
Inc. shall be obtained before using the appliance.
10) If the temperature of cooking oil exceeds 350 ° F (177 ° C) or if oil begins to
smoke, immediately turn the burner or gas supply OFF and wait for the
temperature to decrease to less than 350 ° F (177 ° C) before relighting burner
according to the instructions in this manual.
11) When cooking with oil/grease, have a Type BC or ABC fire extinguisher
readily available. In the event of an oil/grease fire, do not attempt to
extinguish with water. Immediately call the Fire Department. A Type BC or
ABC fire extinguisher may, in some circumstances, contain the fire.
12) NEVER overfill the cooking pot with oil, grease or water. Follow instructions
in this manual for establishing proper oil, grease or water levels.
READ AND UNDERSTAND BEFORE USING THIS PRODUCT
Throughout this manual the words appliance, cooker, fryer/boiler, burner and stove
will be used interchangeably to refer to the King Kooker® Outdoor Cooker.

4
13) Introduction of water or ice from any source into the oil/grease may cause
overflow and severe burns from hot oil and water splatter. When frying with oil/
grease, all food products MUST be completely thawed and towel dried before
being immersed in the fryer.
14) Never drop food or accessories into hot cooking liquid. Lower food and
accessories slowly into the cooking liquid in order to prevent splashing or
overflow. When removing food from the appliance, care shall be taken to avoid
burns from hot cooking liquids.
15) This appliance and pot, including handles and lids, gets dangerously hot in use.
Use well-insulated pot holders or oven mitts for protection from hot surfaces or
splatter from cooking liquids. Safety goggles are also recommended to protect
you from oil splatter. The oil remains dangerously hot hours after use.
16) Do NOT place an empty cooking vessel on the appliance while in operation.
Use caution when placing anything in the cooking vessel while the appliance is
in operation. Never use a cooking vessel larger than the capacity and diameter
specified in this manual.
17) In the event of rain, snow, hail, sleet or other forms of precipitation while
cooking with oil/grease, cover the cooking vessel immediately and turn off the
appliance burners and gas supply. Do not attempt to move the appliance or
cooking vessel.
18) Do NOT move the appliance when in use. Allow the cooking vessel to cool to
100 ° F (38 ° C) before moving or storing.
19) Avoid bumping of or impact with the appliance to prevent contact with hot
appliance, spillage or splashing of hot cooking liquid.
20) See Use and Care section for LP Gas Cylinder Information. A 20 pound
(9 kg) cylinder should be used with this cooker. The LP-gas supply cylinder
used must have a protective collar and must be constructed and marked in
accordance with the specifications for LP-gas cylinders of the U. S. Department
of Transportation (DOT) or the National Standard of Canada, CAN/CSA-B339,
Cylinders, Spheres and Tubes for the Transportation of Dangerous Goods. Do
not store a spare LP-gas cylinder under or near this appliance. Never fill the
cylinder beyond 80% full. For proper vapor withdrawal, the 20 lb. (9 kg) cylinder
should be used in the proper upright position. Cylinder must be turned off while
not in use. Failure to follow these instructions and warnings could result in fire
or explosion which could cause property damage, personal injury or death.
21) This appliance is not intended for commercial use.
22) Use King Kooker
®
appliances only in accordance with state and local ordinances,
or in the absence of local codes, with the National Fuel Gas Code, ANSIZ223.1/
NFPA 54, Storage and Handling of Liquefied Petroleum Gases, ANSI/NFPA 58 or
CSA B149.1, Natural Gas and Propane Installation Code.
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD RESULT IN
FIRE, EXPLOSION, BURN HAZARD OR CARBON MONOXIDE POISONING WHICH
COULD CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.

READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE
USING YOUR KING KOOKER®PRODUCT
TABLE OF CONTENTS
Warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
Table of Contents .......................................................................................................................5
Warranty...............................................................................................................................6
Owner’s Registration ..................................................................................................................7-8
Section I - King Kooker®Outdoor Cooker Assembly .........................................................................................9
Outdoor Cooker Assembly Instructions .............................................................................................9-11
Section II - Use and Care of King Kooker®Outdoor Cookers and Accessories ..................................................................12
Thermometer Instructions and Safety Precautions for Deep Frying with Outdoor Cookers ......................................................12
Determining Proper Fill Levels for Cooking Vessels .....................................................................................13
LP Gas Cylinder Information........................................................................................................13
Connection Instructions ...........................................................................................................14
Leak Test Instructions.............................................................................................................14
Placement Instructions ............................................................................................................15
Lighting and Operating Instructions ...............................................................................................16-17
Turning Off and Storing the Cooker after Use ..........................................................................................18
Maintenance Of Outdoor Cookers And Accessories..................................................................................18-19
Tips for Caring for the V-Bottom Pot .................................................................................................19
Information Regarding Cooking Oil ..................................................................................................19
Operation of Spigot...............................................................................................................20
Section III - Cooking Specialties..........................................................................................................21
Use of Baskets for Deep Frying .....................................................................................................21
Section IV - Recipes ....................................................................................................................22
Fried Seafood ...................................................................................................................22
King Kooker®Wings .............................................................................................................22
Southern Fried Chicken ...........................................................................................................23
Fried Onion Rings ................................................................................................................23
Fried Mushrooms ................................................................................................................23
Section V - Frequently Asked Questions ....................................................................................24
5

6
METAL FUSION, INC.
LIMITED ONE-YEAR WARRANTY
WHAT THIS WARRANTY COVERS
This warranty covers all components of this outdoor cooker to be free from defects in materials and
workmanship, with the exceptions stated below.
HOW LONG COVERAGE LASTS
This warranty runs for one year from the date of purchase. Please keep your receipt with this manual
for future reference.
WHAT IS NOT COVERED
This warranty does not cover the following:
Incidental and Consequential Damages. This warranty does not cover incidental and
consequential damages arising in any way out of the use of this outdoor cooker. The liability of
Metal Fusion, Inc. is, in any event, limited to the amount of the original purchase price of this
outdoor cooker, and remains in force only as long as the product remains in its original, as-built
configuration. Some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you.
Neglectful Operation. This warranty does not cover any loss or damage arising in any way
due to the negligent operation of this outdoor cooker.
Altered, Repaired or Misused Equipment. This warranty does not cover any loss or
damage arising in any way out of the use of this outdoor cooker when it has been altered, repaired
by persons other than Metal Fusion, Inc., or when it has been abused or misused, or when it has
been used other than in accordance with the manufacturer’s operating instructions, including,
without limitation, any damage to the consumer’s pots because they were placed on a lit cooker
while the pot is empty.
Other Assumed Responsibilities. Unless otherwise provided by law, this warranty does
not cover any responsibility or liability arising in any way out of the use of this product where that
responsibility or liability was purportedly assumed by any other person or agent.
Paint, Discoloration, Rust and Corrosion. This warranty does not cover the paint on the
outdoor cooker, as in a normal use of the outdoor cooker, the paint will be burned off. Nor does
this warranty cover discoloration, rust or corrosion to the cooker as these occurrences are part of
the cooker’s normal wear and tear.
WHAT METAL FUSION, INC. WILL DO
Metal Fusion, Inc. will repair or replace any outdoor cooker that proves to be defective in materials
or workmanship. In the event repair is not possible or economically feasible, Metal Fusion, Inc. will
replace your outdoor cooker with an identical or substantially equivalent outdoor cooker. Metal
Fusion, Inc. will perform this service at no charge to you, except for the actual cost of shipping and
handling the outdoor cooker or replacement parts.
HOW TO GET SERVICE
In the event you have a problem or malfunction with your outdoor cooker, simply call Metal Fusion,
Inc. at [phone].
HOW STATE LAW APPLIES
This warranty gives you specific rights, and you may have other rights which vary from state to
state.

7
OWNER’S REGISTRATION
Dear Customer,
Thank you for purchasing a King Kooker®! Please take a moment to fill
out your registration form and return it to us. We are always happy to hear
suggestions and comments from our customers about our products. Completion
of this registration allows us to contact you if the need arises. Please keep your
receipt with your instruction manual. It will be necessary as a proof of purchase
for us to help you if there is a problem with your cooker.
Name:__________________________________________________________________
E-Mail: _________________________________________________________________
Address:________________________________________________________________
________________________________________________________________________
________________________________________________________________________
Telephone: _____________________________________________________________
Model# ________________________________________________________________
Date of Purchase ________________________________________________________
Place of Purchase _______________________________________________________
Price Paid ______________________________________________________________
Was this a gift _____ or did you _____ purchase it yourself?
________________________________________________________________________
________________________________________________________________________
Comments:
________________________________________________________________________
________________________________________________________________________
A SATISFIED CUSTOMER IS OUR MAIN GOAL. If you have any questions or
problems, please call us at 1-800-783-3885 before returning the product to the
point of purchase. Please have your receipt available when calling.
THANK YOU,
ENJOY YOUR COOKING EXPERIENCE.
CUT HERE

8
________________________
________________________
________________________
METAL FUSION, INC.
712 St. George Avenue
Jefferson, LA 70121
Place
Stamp
Here
FOLD
FOLD
TAPE HERE

TOOLS REQUIRED:
TORQUE WRENCH or ADJUSTABLE WRENCH, SCREWDRIVER, LEAK TESTING SOLUTION
1. Before assembling, check that all cooker components are included in the shipping carton. Identify
these cooker parts from the assembly drawing. The following parts are considered essential and
should be included in your package regardless of model number.
Required Parts List:
(1) Cooker Body
(4) Legs
(1) Burner (with 2 screws/lockwashers/nuts to attach to cooker body)
(1) LP Hose and Regulator
(1) V-Bottom Pot with Spigot
(2) Small Baskets/Short Handles
(8) Bolts(for handle attachments to baskets)
(1) Thermometer/Nut
If any of the above parts are missing, contact Metal Fusion, Inc. at 1-800-783-3885 between the hours
of 7:30 a.m. and 3:30 p.m. CST Monday through Friday for replacements.
2. Read assembly instructions, and understand sequence of assembly, before commencing to assemble
your cooker. Remove all plastic and paper packaging materials from the cooker and pot before
assembly and use.
9
SECTION I
OUTDOOR COOKER ASSEMBLY
THE USE AND CARE MANUAL MUST BE READ AND UNDERSTOOD
BEFORE USING THE APPLIANCE
Throughout this manual the words appliance, cooker, fryer/boiler, burner and stove will be
used interchangeably to refer to the King Kooker® Outdoor Cooker.
Leg
V-Bottom
Pot with
Spigot
Cooker Body
LP Hose and
Regulator
* Model May
Vary From
Thermometer

10
3. Locate the cooker body and four legs. Install the four legs into the cooker body by matching the
letters on the legs to the letters on the leg receivers (for example: A to A, B to B, etc...). Snap in
leg bolts through receiving holes on frame. Make sure the leg bolts pop completely out and legs
are locked in position.
4. Make sure that the adjustable heat plate located on the front of the cooker body is raised to the
uppermost position in preparation of the installation of the burner. Locate the end of the burner
with the venturi. Insert the venturi end of the burner through the hole located on the front of the
cooker body (insert from inside cooker body to outside.) The end of the burner with the venturi
should stick out of the front of the cooker body. Attach the burner to the inside of the cooker body
by inserting the two supplied bolts through the supplied holes in the burner and cooker body
as pictured in Figure 1 below. Tighten with supplied lockwashers and nuts. Once the burner is
installed, the adjustable heat plate located on the front of the cooker frame must be lowered into
position before use. Loosen the bolt and lower the heat plate to close the hole above the venturi.
Tighten bolt when finished. See below Figure 2.
5. Place the V-Bottom Pot onto the cooker body as pictured below in Figure 3.
6. Check that the venturi tube is free of obstruction. Tighten the hose fitting into the venturi with a
torque wrench, up to a torque of 95 to 105 lb.in. Alternatively, hand tighten securely and then,
using a wrench, tighten an additional 1-1 1/2 turns. See below Figure 3.
20 lb. LP
Gas Cylinder
TOP VIEW
COOKING POT
VENTURI TUBE/
AIR SHUTTER ADJUSTABLE REGULATOR
TYPE 1
CONNECTION
1/8 MALE PIPE
THREAD WITH
ORIFICE
Figure 1
Figure 3
Venturi
Figure 2
Heat
Plate
Bolt
Venturi/
Air Shutter
Spigot
Hole
Burner
Bolt
Attachment
Bolt
Attachment
SPIGOT

11
7. Install the provided thermometer into the front of the V-Bottom pot by inserting stem of
thermometer into the hole provided. Hand tighten brass nut to secure. See below Figure 4 for
picture of correct assembly.
8. Assembly of Baskets
Required Tools: Adjustable Wrench and Screwdriver
The baskets supplied with this appliance provides you with a wide array of cooking options.
Read and understand the following instructions for correct assembly of baskets.
Locate the two handles and baskets. Repeat the below steps for each basket/handle. Align the
four holes on the handle to the four holes on the mounting plates located on the front of
the basket. Attach using four bolts/washers. See Figure 5 below for picture of correct assembly.
9. Go to the Use and Care section of this manual for further instructions.
Figure 4
Figure 5

READ AND UNDERSTAND BEFORE USING THIS APPLIANCE
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD RESULT IN FIRE,
EXPLOSION, BURN HAZARD OR CARBON MONOXIDE POISONING WHICH COULD CAUSE
PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
THERMOMETER INSTRUCTIONS AND SAFETY PRECAUTIONS FOR
DEEP FRYING WITH OUTDOOR COOKERS
1. Always use the deep fry thermometer when using this appliance as a fryer/boiler.
a. Before each use of the appliance make sure that the thermometer is properly calibrated by
placing the tip in a pot of boiling water. The thermometer should register within +/-20°of
212°F or +/-10°of 100°C. If the thermometer is miscalibrated, contact Metal Fusion, Inc.
to obtain a replacement before using the appliance.
b. Make sure that the thermometer is correctly installed according to the assembly
instructions located on page 13. Always fill to the minimum fill line when cooking with oil.
Never place a lid over a pot when monitoring the temperature of oil.
c. Once the fire has been lit monitor the temperature on the thermometer at all times. Water
boils at 212°F(100°C). The temperature of hot oil should never be allowed to exceed
350°F(177°C).
IMPORTANT: Oil can ignite at high temperatures. Most King Kooker® thermometers have a Red
Zone above 350°F(177°C) to signify Danger. Never allow the temperature to exceed 350°F(177°C).
If the temperature goes above 350°F(177°C) immediately turn the burner and gas supply OFF
and wait for the temperature to decrease to below 350°F(177°C) before relighting according to
instructions in the manual. If at any point during the cooking process the oil begins to smoke,
immediately turn the burner and gas supply OFF regardless of the reading on the thermometer.
Allow time for the oil to cool, then contact Metal Fusion, Inc. for further instructions.
d. When the cooking is complete and the cooker has been turned off, allow the temperature
of the oil to fall below 100°F(38°C) before moving the pot, cooking oil, or cooker.
e. Please call Metal Fusion, Inc. at [phone] with any questions concerning the use or
operation of the thermometer.
2. Never cover the pot when cooking with oil.
3. Always thaw and dry food completely before placing it into hot oil. Frozen or wet food may cause
oil or grease to overflow.
4. Never put an empty pot over an open flame.
5. In the event of rain, snow, hail, sleet or other forms of precipitation while cooking with oil/grease,
cover the cooking vessel immediately and turn off the appliance burners and gas supply. Do not
attempt to move the appliance or cooking vessel.
6. When cooking with oil or grease, fire extinguishing materials shall be readily accessible. In the
event of an oil or grease fire do NOT attempt to extinguish with water. Immediately call your Fire
Department. A Type BC or Type ABC fire extinguisher may, in some circumstances, contain the
fire.
12
SECTION II
USE AND CARE
Throughout this manual the words appliance, cooker, fryer/boiler, burner and stove will be used
interchangeably to refer to the King Kooker® Outdoor Cooker.

LP GAS CYLINDER INFORMATION
Your King Kooker® Outdoor Cooker is manufactured for use with 20lb. (9 kg) LP Gas Cylinders.
Important information to remember about LP Gas cylinders include:
1. Always read and follow the cylinder manufacturer’s instructions.
2. Make sure that the gas cylinder is not overfilled. The maximum weight of a properly filled 20 lb. (9
kg) LP gas cylinder is approximately 38 lbs (17 kg). Never fill the cylinder beyond 80% full.
3. Make sure that the cylinder valve has the proper connection for a Type 1 appliance fitting.
4. Do not store a spare LP gas cylinder under or near this appliance.
5. Disconnect the cylinder from the cooker for storage.
6. Store the cylinder out of the reach of children.
7. Do not use or store the cylinder in a building, garage or enclosed area.
8. Always use a 20 lb. (9 kg) cylinder in the proper upright position for the proper vapor withdrawal.
It should also be stored and transported in the upright position.
9. The cylinder must have a protective collar to protect the cylinder valve.
10. Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of
dust cap on the cylinder valve outlet that is provided with the cylinder valve. Other types of caps
or plugs may result in leakage of propane.
11. Cylinder must be turned OFF while not in use.
ALWAYS READ AND FOLLOW THESE AND THE CYLINDER MANUFACTURER’S INSTRUCTIONS. FAILURE TO
FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD RESULT IN FIRE, EXPLOSION, BURN
HAZARD OR CARBON MONOXIDE POISONING WHICH COULD CAUSE PROPERTY DAMAGE,
PERSONAL INJURY OR DEATH.
DETERMINING PROPER FILL LEVELS FOR COOKING VESSELS
Your cooker includes a pot which has been stamped with a line which indicates the exact level
to which the oil should be filled before it is heated and food is added. Approximately 4.5 gallons
of cooking liquid is required to reach the fill line.
Fill the pot with oil to the fill line before lighting the cooker or adding food. Never overfill the
cooking vessel with oil, grease or water. Never fill a pot beyond the maximum fill line. Always fill
to the minimum fill line when cooking with oil.
13

14
CONNECTION INSTRUCTIONS
1. Checkthatyour hoseassemblyis settonot allowgasflow. Turntheregulator controlcounterclockwise
until it stops. This is the OFF position.
2. Attach the regulator to the cylinder valve by turning the Type 1 fitting clockwise. Hand tighten with
the regulator positioned upright. Refer to the assembly diagram for the appliance below.
3. Perform the Leak Test:
4. Before lighting the cooker, check that the venturi tube is free of obstruction and that the orifice is
properly threaded into the venturi tube as per the hose connection instructions on pg. 10. Both
situations must be corrected if necessary before lighting to prevent flashback.
LEAK TEST
Before lighting the appliance, a thorough leak test must be satisfactorily completed using
a non-ammonia soapy water solution (50% non-ammonia soap and 50% water). This is to be
applied with a small brush to all gas joints after the cylinder valve is opened (no more than
1/2 turn). If bubbles are seen, indicating a leak, turn off the cylinder and tighten the leaking
connection until a further leak test shows no leaks.
If tightening the connection does not stop the leak, call Metal Fusion, Inc. [phone],
for assistance.
NEVER USE HOSE/REGULATOR ASSEMBLY IF LEAKING.
TYPE 1
CONNECTION
* Model May Vary From Picture
20 lb. LP
Gas Cylinder

1. Never operate this appliance within 10 feet (3.05m) of any structure, combustible material or other gas
cylinder. Never operate this appliance within 25 feet (7.5m) of any flammable liquids or vapors.
2. There must be no combustibles or roof overhead.
3. Keep 24” (.61m) of space between the LP gas cylinder and the appliance.
4. The LP gas cylinder and appliance must be located so that any wind is blowing the heat of the appliance
away from the propane cylinder. This also helps fire prevention by blowing the flames of a grease fire
away from the propane cylinder.
5. ONLY use the pot provided with your appliance.
15
PLACEMENT INSTRUCTIONS
Keep twenty-four inches between the cylinder and the appliance.
Placing the cylinder too close to the appliance could result in fire or
explosion which could cause property damage, personal injury or
death.
The hose connecting the appliance to the tank poses a trip hazard.
Do not step over the hose or walk between the cylinder and
appliance. Tripping could cause the appliance or cylinder to tip over,
leading to fire or explosion which could cause property damage,
personal injury or death.
WIND DIRECTION
CLEAR OVERHEAD
10 FEET
to
NEAREST
COMBUSTIBLE
(All Directions)
(3.05m)
GROUND LEVEL
(3.05m)
10 FEET
LP
GAS
TANK
(.61m)
24 INCHES

16
LIGHTING AND OPERATING INSTRUCTIONS
THE COOKER MUST NOT BE LIT UNTIL THE PRECEDING
PLACEMENT INSTRUCTIONS HAVE BEEN COMPLETELY FOLLOWED.
(ILLUSTRATIONS PAGE 17)
1. For optimum performance it is necessary to adjust the flame quality without the pot installed onto the
frame to more easily view that all of the burner ports are lit. Follow the below instructions without the
V-Bottom pot installed onto the frame to properly prepare the appliance for cooking. NEVER put hands
or face directly above burner while lighting or while the appliance is lit. NEVER place an empty pot
over a lit burner. A hole will be burned into the bottom of the pot. After following steps #2 through #7
below without the pot installed onto the cooker frame, you will be directed to follow these lighting steps
again, this time with the pot installed and the cooking liquid added.
2. Check the burner to make sure it is set up as per the illustration (Figure 1).
3. Make certain that the regulator control is turned to OFF by turning it counterclockwise until it reaches
the stop.
4. Open cylinder control valve by turning it counterclockwise as per the diagram (Figure 2).
5. Insert a multipurpose lighter through the hole in the side of the cooker body as per Figure 3, or paper
book match through the hole in the side of the cooker body as per Figure 4.
Turn the regulator control toward the “ON” position until ignition occurs. Turning the regulator control
clockwise increases the gas pressure to the burner and hence the flame size (Figure 2).
When lighting the stove, if ignition does not occur in 3 to 5 seconds, turn the regulator and cylinder
valve off. Wait 5 minutes for gas to disperse. Repeat procedure.
6. Check that the flame is blue and that the flames are emitted from every port in the casting (Figure 5).
If not, loosen the air shutter with the aid of a screwdriver and rotate the air shutter position until there
is a blue flame. Tighten. Opening the shutter too much will cause the flame to “Lift” off the burner.
If there is a yellow flame, or if some ports have no flame, this indicates there may be an obstruction
in the venturi tube or ports. Check the maintenance instructions on page 18 for more information
regarding a yellow flame.
7. Once the flame quality has been properly adjusted, turn the flame OFF according to the instructions
for turning off gas to the appliance located on pg. 18. Install the pot onto the cooker frame and add
cooking liquid to the fill line. Light the appliance according to lighting directions above (#2 through
#6.)
8. Always monitor the flame throughout the cooking process (flame can be viewed through the viewing
holes located on each side of the appliance.) If at any point in the cooking process the flame is
accidentally extinguished, immediately turn the regulator and cylinder valve OFF. Wait 5 minutes for
gas to disperse and relight the cooker according to the directions in this section.
Lighting and Operation Instructons continued on pg. 17

17
NEVER PUT HANDS OR FACE DIRECTLY OVER BURNER WHILE LIGHTING OR
WHILE THE APPLIANCE IS LIT.
ADJUSTABLE REGULATOR
Turn Cylinder Handle
toward ON
(Counterclockwise)
Next
Turn Regulator Control
toward ON
(Clockwise)
20LB. LP
GAS
CYLINDER
GROUND LEVEL
FIGURE 2
FIGURE 1
(.61m)
24”
* Model may
vary from
picture.
FIGURE 5
Viewing Hole
Viewing Hole
FIGURE 3
FIGURE 4

TURNING OFF AND STORING THE COOKER AFTER USE
NEVER MOVE THE COOKER OR POT WHILE IN USE OR STILL HOT [ABOVE 100°F (38°C)].
1. After each use turn OFF the King Kooker® at the regulator first, then at the gas cylinder valve.
Check to make sure there is no flame and all valves are off. Do not leave the cooker until it
has cooled completely. When removing food from the cooker wear protective mitts.
2. Disconnect the regulator from the cylinder by turning the Type 1 fitting counterclockwise until
the regulator is separated from the tank.
3. Storage of this cooker indoors is permissable only if the cylinder is disconnected and removed
from the cooker. Do not use or store cylinder in a building, garage or enclosed area. Read and
follow all cylinder manufacturer’s instructions. The cylinder must be stored out of the reach of
children at all times. Keep entire unit in area to avoid insects and contamination that can clog
the venturi tube.
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD RESULT IN FIRE,
EXPLOSION, BURN HAZARD OR CARBON MONOXIDE POISONING WHICH COULD CAUSE
PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
MAINTENANCE OF OUTDOOR COOKERS AND ACCESSORIES
1. The area where the cooker will be used must be kept clear and free from combustible materials,
gasoline and other flammable vapors and liquids. Before each use of the cooker inspect and
remove any combustible items.
2. The flow of combustion and ventilation of air must not be obstructed. The cooker must be set in
an open area with 10 ft. (3.05m) of space on all sides and no roof or overhang overhead. Check
the location and placement of the cooker before each use.
3. Before each use of the appliance check the burner/venturi tube for insects, insect nests, and
other obstructions. A clogged tube can lead to a fire beneath the appliance.
4. Follow all Lighting Instructions in the Use and Care Manual each time the cooker is used. Check
the flame for proper color and appearance. The flame should burn with a primarily blue color. If
a strong yellow flame is present, this could indicate an obstruction in the burner/venturi tube.
If there is any obstruction or a yellow flame, and the air shutter adjustment has not solved the
problem, turn off the cooker and allow time for it to cool. Disconnect the hose from the cooker.
Remove the air shutter using a phillips head screwdriver. Check the venturi tube with a flashlight
to see if there is a blockage. If a blockage is present use a wire such as a coat hanger to slide
into the venturi tube to remove the blockage. Reattach the air shutter to the venturi tube using
the phillips screwdriver. Assemble and light the cooker again as per the instruction manual. If
this does not resolve the problem, please call Metal Fusion, Inc. at [phone].
5. Always use the LP hose/regulator assembly supplied with the appliance. Before each use of
the appliance check the LP hose for evidence of abrasion, wear, cuts or leaks. If there is any
damage to the hose, the hose/regulator assembly must be replaced prior to using the appliance.
Contact Metal Fusion, Inc. at [phone] for information regarding a replacement hose
assembly. Only the LP hose/regulator assembly specified by Metal Fusion, Inc. should be used
with the appliance.
6. For purchase of any replacement parts which may have become damaged or lost, please
contact Metal Fusion, Inc. at [phone] between the hours of 7:30am-3:30pm (CST)
Monday through Friday.
18

19
7. Cleaning of the appliance:
Cooker Frame and LP Hose/Regulator: If neccessary, remove any oil or liquid which
has spilled onto the unit during cooking with mild soapy water on a rag and towel dry. Do not
immerse the burner unit or hose and regulator into water as this will cause rust. V-Bottom
Pot: Clean after each use according to the directions below.
Thermometer: Clean after each use with mild soapy water and towel dry. Do not submerge in
liquid or put in dishwasher.
TIPS FOR CARING FOR
THE V-BOTTOM POT
ONLY use the pot provided with your appliance. It is not necessary to season the aluminum pot
before cooking. Wash with a liquid dish washing detergent and towel dry.
After cooking, wash the aluminum pot in hot, sudsy detergent. If grease or black soot has cooked
to the outside of the pot while cooking with your outdoor cooker, scrub the outside of the pot with a
steel wool scouring pad.
DO NOT SPRAY OVEN CLEANER ON ALUMINUM POTS TO REMOVE GREASE OR SOOT. OVEN
CLEANER WILL CAUSE THE FINISH TO BECOME DULL.
If food remains stuck in the pan after cooking, add hot water and let soak. Then scrub the pan with
soap and steel wool to loosen the food.
If hard water causes darkening on the interior of your pot, fill to the level of the darkened area with a
water and cream of tartar or vinegar solution (mixed with the concentration of three cups of water to
one tablespoon cream of tartar, or vinegar). Boil five to ten minutes.
NEVER PLACE AN EMPTY ALUMINUM OR STAINLESS STEEL POT ON A LIT COOKER. A hole
will be burned in the bottom of the pot. Discoloration, scratching, and dimpling may occur with the
use of pots on outdoor cookers. This does not affect the performance of the pot.
Do not store used oil inside your aluminum pot. The salt used in cooking can corrode the pot causing
the pot to leak. Wash the pot after each use with hot, soapy water and rinse.
INFORMATION REGARDING COOKING OIL
A good liquid vegetable oil must be used for deep frying.
SUGGESTIONS FOR KEEPING USED COOKING OIL:
After initial use, let the oil cool. While slightly warm, filter out particles before storing in original container or
similar sturdy plastic or glass container.This can be accomplished by using filter paper (coffee filters) or a clean
cloth (dishtowel). Never pour hot oil into a container. For best results store oil in a cool place. It can be reused
within 30 days. Discard after second use or when the flavor of reheated oil becomes objectionable to taste.
Helpful Hint: Try frying a batch of french fried potatoes after frying your turkey, chicken or fish. This aids in
improving the flavor of the oil for the next use.

20
OPERATION OF SPIGOT
READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING THIS PRODUCT.
ALWAYS ALLOW COOKING LIQUID TO COOL BEFORE OPERATING VALVE (BELOW
100°F (38°C)). COOKING LIQUID CAN REMAIN DANGEROUSLY HOT HOURS AFTER USE.
ALWAYS USE A THERMOMETER TO CHECK TEMPERATURE OF THE COOKING LIQUID BEFORE
OPERATING THE SPIGOT.
OPERATING INSTRUCTIONS FOR SPIGOT POT:
1. Before adding cooking liquid, turn valve clockwise until it stops. This is the OFF/CLOSED
position. Also make sure that the removable cap is attached and tight at the base of the spigot.
2. NEVER open the valve during use or before the oil has cooled below 100°F (38°C).
3. Upon completion of cooking, allow cooking liquid to cool before operating the valve (below
100°F (38°C)).
4. To operate valve, remove the cap at the base of the spigot. To open spigot, turn
counterclockwise to the ON/OPEN position.
5. Clean the pot as per instructions on pg 19.
6. Always close the spigot valve after cleaning and attach the cap back to the end of the spigot.
For Outdoor Use Only!
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD RESULT IN FIRE,
EXPLOSION, BURN HAZARD OR CARBON MONOXIDE POISONING WHICH COULD CAUSE
PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH.
Valve
Spigot
Removable
Cap
