Micasa MA0080MO User manual

30L Mini Oven with Twin Hotplates
Model: MA0080MO
READ AND FOLLOW THESE INSTRUCTIONS. RETAIN FOR FUTURE REFERENCE

Electrical Safety and You
Before using this appliance please read and fully understand the
safety directions in this manual. Ensure that you know how to
operate the appliance. All electrical equipment presents a risk to
the end user. We ask that you use this appliance in a sensible
safe manner in accordance with the instructions supplied for
your own safety.
If for any reason the appliance does not function correctly or
shows signs of damage please return it immediately to the
retailer or contact the help line.
New Zealand toll free 0508 ASIAPAC (274 2722)
Australia call [phone]
Web www.micasa-appliances.com
Visit our website to view more MICASA
quality products, retail locations and
customer support.
Features
•30 Litre Capacity Oven
•1400 watt Convection Oven
•Perfect for grilling, roasting, baking and toasting
•60 min te timer with bell
•100°-250°C Temperat re selection range
•7 Stage cooking options selector
•Rotisserie f nction
•Power On indicator
•Do ble glass door
•Stainless steel oven door handle
•D al hotplates: Left – 185mm – 1000W, Right –
155mm – 600W
•Incl des enamel bake tray, bake tray handle, wire
rack, cr mb tray, Rotisserie rod with 2 prongs &
rotisserie rod holder
Please note: The small hotplate and oven will only work
conc rrently if yo are wanting to se the oven and hotplate
at the same time. The twin hotplates and oven do not
operate at the same time d e to the high wattage generated
by both cooking methods. This is normal for prod cts of this
type. Oven req ires 10cm free space on all sides aro nd the
appliance for adeq ate air circ lation.
Operation Guide
Power Connection
Connect the appliance to a suitable 220-240V ~50Hz power
supply only. This appliance is designed to operate safely across
both New Zealand and Australian power supplies.
This appliance must be earthed. It is a
class 1 appliance.
Power Consumption
This appliance is designed to work within the NZ power system
constraints and maximum loading requirements. The maximum
available power usage on any standard 10A 240V outlet supply
is 2400 watts. Therefore the appliance can only be used with
combinations that require a power input below this power level.
This appliance allows for the oven to be used in conjunction with
the small element only. The large element cannot be used with
the main oven function in combination.
Heating Selection Options
The mini oven has a seven position selector switch as follows
Grill + Rotisserie + Fan
Bake
Bake + Grill + Rotisserie + Fan
Bake + Grill + Rotisserie + Fan + Small Element
Large Element
Small Element
Large +Small Element
First time Use
First Time Use – Vapours!
When first used there may be a small amount of
smoke or vapours, this is normal. The heating
elements are coated with a protected coating
during transit to protect them from possible
corrosion. Plug the appliance in, select Bake option
and run for a 5 minute period without food.

Location
Place the appliance on a secure heat resistant bench or table
top away from combustible material such as curtains and walls.
Connect to the mains supply. Do not place or store objects on
the appliance
Allow a gap around the appliance of
10cm
Oven Tray and Rack
Crumb Tray
It is advised to always use the oven with the crumb tray fitted in
the bottom. This will make for easier cleaning. Clean regularly.
Bake Tray / Wire Rack Installation Height
The oven is fitted with 3 height fitting options suitable for bake,
grill or toast cooking. Position as required
Rack Position Guide
Top – Grill Broil function
Middle – Toast Pizza Bagel function
Lower – Roast Bake and preheat
Cooking Options
Bake
1. Select the desired element heating operating configuration
Bake + Grill (rotisserie and fan options) on the selector
switch.
2. Turn the timer dial to the desired cooking time.
3. Turn the thermostat dial for the desired temperature.
4. The power on indicator will light.
5. Open door and place oven tray with food item into the oven
at the desired height. Close the oven door.
6. When finished baking, turn the temperature knob fully anti
clockwise and turn the function switch to OFF to turn the
oven off. Remove baking tray using heat proof gloves or
the bake tray handle.
Caution: If the timer has not returned to OFF allow it to
return to the OFF position by itself. The timer is a manual
timer and forcing it off may damage it over time. Allowing it
to return to zero will not affect the oven operation.
Grill
1. Select the desired element heating operating configuration
Grill (rotisserie and fan options) on the selector switch.
2. Turn the timer dial to the desired cooking time. .
3. Turn the thermostat dial for the desired temperature.
4. The power on indicator will light
5. Place the food item in the oven leaving the door half open.
6. When finished cooking, turn the temperature knob fully anti
clockwise and turn the function switch to OFF to turn the
oven off. Remove baking tray using heat proof gloves or
the bake tray handle.
Caution: If the timer has not returned to OFF allow it to
return to the OFF position by itself. The timer is a manual
timer and forcing it off may damage it over time. Allowing it
to return to zero will not affect the oven operation.
Warning! Hot surfaces
When cooking the outer surfaces reach
high temperatures. Handle with care. Use
handles and knobs and heat proof gloves.
Cooking Guide
Food Time (min) Temp Shelf Position
Bread 9-12 190°C Middle
Cakes 25-35 190C Bottom
Pizza 12-15 200C Middle
Chicken 30-40 220-250°C Rotisserie
Fish 15 250°C Top
Helpful Information
250°C = 482°F 1lb = 453g
200°C = 392°F 3lb = 1.360kg
150°C = 302F 5lb = 2.265kg
100C = 212°F 10lb = 4.53kg
Rotisserie
Note. When selected the rotisserie motor will operate regardless
of whether you have the rotisserie accessory fitted.
The rotisserie accessory connects to the internal motor drive
socket located on the middle right of the oven wall. To fit the
rotisserie, connect one end to this drive and then fit the
supporting end to the left support of the oven wall. The rotisserie
will rotate automatically when the selection with that option is
chosen. Note. The holder only fits correctly in one position.

Fan Operation
The fan will operate and circulate the hot air when the fan
selection mode is chosen, creating an even temperature and
heating within the oven
Cleaning
Warning!
Electric shock risk! Do not immerse this
appliance or supply cord in any liquid. Always
disconnect from the mains supply before cleaning.
Scalding or Burns! Allow it to cool completely
before cleaning. Hot surfaces create a hazard.
Damage! Do not use harsh abrasives, solvents or
scouring material as they may damage the metals
or plastics.
Outer
Clean the outer case with a warm damp clean sponge cloth, dry
with a dry towel. If required use a little mild detergent on the
sponge.
Inner
Wipe the inside of the oven with a hot damp sponge cloth. Dry
before re use. A mild cleaning spray or detergent may be used.
Apply to the sponge, not the oven.
Door
Wipe the glass with a hot damp sponge, dry with a dry towel.
Clean the glass surface with a glass cleaner spray if necessary.
Accessories
Wash all accessories and trays in hot water and detergent, dry
with a dry towel.
Warning! Crumb Tray
Empty regularly as any residual build up may
present a fire hazard and effect the operation of
the oven.
Important Safety Instructions
Please read all these safety instructions carefully before use.
Follow these WARNINGS!
Warning! Children
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of knowledge, unless they have been given supervision
or instruction concerning safe use of the appliance by a person
responsible for their safety. Young children must be supervised
to ensure that they do not play with the appliance.
Safely dispose of any plastic bags or other packaging that may
present a hazard to young children of suffocation or choke
hazard.
Warning! Unattended Appliances
Do not leave any appliance unattended when in use.
CAUTION! This appliance must not be operated by means of an
external timer or separate remote control system.
Warning! Safety
For household indoor use only, do not use outdoors.
Not for commercial use.
Do not let the supply cord hang over the edge of any table or
bench as young children may pull on the cord creating a risk of
electric shock, burns, scalding, personal injury or damage.
Warning! Heat
Always place the appliance on a heat resistant surface.
Always allow a gap around the appliance and do not cover the
appliance.
Warning! The temperature of accessible surfaces may be high
when the appliance is operating.
Warning! Hot steam may be ejected when opening the door!
Warning! Moisture
Do not immerse this appliance in any liquid. Do not operate with
wet hands or near any vessel filled with water. Do not splash the
appliance with water
Warning! Power Cord
Do not abuse or damage the supply cord. If for any reason the
cord is damaged, it must be replaced by the manufacturer, its
service agent or a similarly qualified person in order to avoid
hazard. A replaceable cord must be replaced with an authorised
replacement from an authorized service agent.
Warning! Use
This appliance is intended to be used in household and similar
applications such as
- staff kitchen areas in shops, offices and other working
environments
- farm houses
To support rail
To rotisserie socket

- by clients in hotels, motels and other residential type
environments
- bed and breakfast type environments.
Do not place on or near a hot gas or electric burner, or in a
heated oven or in a microwave oven.
Warning! Extreme caution must be used when moving an
appliance containing hot oil or other hot liquids.
Do not cover any part of the appliance with metal foil.
Do not store items in or on the appliance.
Do place cardboard, plastic, paper or similar in the oven.
Do not use the appliance for any other than its intended
purpose.
Warning! Service or damaged
Refer all servicing to authorised personal. Return it to the
retailer if it is damaged in any way.
Warning! If the element cooking surface is cracked, switch off
the appliance to avoid the risk of electric shock.
Distributed by
Asia Pacific Brands Ltd
PO Box 113001 Broadway
Newmarket, 1149
Auckland, New Zealand
