Michelin MEMS EVOLUTION 4 User manual
MFP MICHELIN © 2023 All rights reserved.
Exclusive property of Manufacture Française des Pneumatiques Michelin.
Any reproduction or utilization prohibited without the consent of Michelin.
Manufacture Française des Pneumatiques Michelin
23 Place des Carmes-Déchaux
63000 Clermont-Ferrand
France
DISPOSAL
The MEMS EVOLUTION 4 ACTIVE ANTENNA must not be disposed of in landfill.
At the end of its life, the MEMS EVOLUTION ACTIVE ANTENNA must be removed
from the vehicle and deposited in a container dedicated to the recycling of
electronic equipment. If users do not have access to the appropriate recycling
facility, your local Michelin MEMS representative is able to provide a container
dedicated to the purpose of collecting MEMS equipment.
CONTACT DETAILS
For more information or assistance, please contact the Michelin MEMS
representative for your country.
Brasil, Chile & Perú : +55 (21) 36 21 4646
USA, Canada & México : +1 864 458 5000
Australia : +61 3 86 71 1003
South Africa : +27 115 790 300
Features, specifications are subject to change without notification.
Document version 1.7
PRODUCT NAME
MEMS EVOLUTION ACTIVE ANTENNA –Part Number CAI 960299
PRODUCT DESCRIPTION
The MEMS EVOLUTION ACTIVE ANTENNA receives, via antennas, pressure and
temperature data transmitted by the MEMS SENSORS. This information is to be
forwarded to the MEMS EVOLUTION TRANSCEIVER, together with any messages
that may require corrective action to be taken in order to maximise the service
life of the tire.
PRODUCT INSTALLATION & SECURITY
please refer to the MEMS 4 Hardware Installation & Maintenance Guide
FCC CERTIFICATION
Model : AA-V3.2
FCC ID : FI5-EX1-02
FCC Warning:
Please take attention that changes or modification not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Note: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
product generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this product does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by Michelin may void the user's authority to operate the equipment.
PRODUCT SPECIFICATION
Performance Characteristics
•RX frequency: 433.92MHz ISM band
Electrical Performance
•Supply voltage: 12VDC
•In less than 10mA under 12V
Operating Conditions
•Operating temperature: -40°C to +70°C, -40°F to +158°F
•Sealing: IP66
Storage Conditions
•Storage temperature: -50°C to +80°C, -58°F to +176°F
Physical Characteristics
•Approximate dimensions: Height= 85mm. Length=130mm.
Width=130mm
•Approximate weight: approximately 355g
•Available connections: CAN Bus
Environment
•RoHS compliant
